CCTV | UML-202-90 20-inch Color LCD Display Monitor
The UML-202-90 is a high-resolution (Ultra Extended
Graphics Array - UXGA), high-performance liquid crystal
display (LCD) video display monitor. Available in an
ergonomic and aesthetically pleasing design, this state-of-
the- art monitor includes a 51 cm (20.1 in.) color thin film
transistor (TFT) active matrix LCD panel with 1600 by 1200
pixels. Designed for the professional CCTV security
marketplace, the UML-202-90 monitor includes two looping
composite video inputs, two looping audio inputs and one
looping Y/C input.
Functions
This monitor includes an analog RGB mode, a Digital DVI,
and an HDMI (high definition multimedia) input to
accommodate the increasing use of PCs and digital video
devices in security applications. The HDMI input supports
full HD up to 1080P. To enhance the multi-input capability,
the monitor includes a “picture-in-picture” function. This
also enables any of the composite video or Y/C input to be
inserted into the RGB/DVI/HDMI input display.
A security officer can make standard adjustments to
monitor display parameters with user-friendly choices
displayed using on-screen menus (available in several
languages) and front panel controls.
For additional security, the UML-202-90 includes a front
panel lockout feature that disables the front panel control
buttons. Long-life fluorescent backlights maintain the
monitor’s brightness level over time, because the LCD
monitor design avoids the brightness degradation
experienced with aging CRT-type monitors. This energy-
saving technology also provides a sharp display, free of the
annoying flicker prevalent in traditional CRT monitors,
allowing longer use of your LCD monitor with little or no
eyestrain. The versatile design allows this monitor to accept
NTSC and PAL signal formats automatically as well as power
supply voltages from 90 to 240 VAC. Compact styling makes
the UML-202-90 the color monitor of choice for large-
screen, space-constrained applications. With its wide range
viewing angle, 178° by 178°, this monitor may be easily
viewed whether it is placed on a desktop, mounted to a
VESA standard wall mount, or rack mounted in a standard
51 cm (20.1 in.) EIA rack.
Certifications and Approvals
Electromagnetic Com-
patibility (EMC)
Complies with FCC Part 15, ICES-003, and CE
regulations
Product Safety Complies with CE regulations, UL, EN, and IEC
Standards
UML-202-90 20-inch Color LCD Display
Monitor
▶High-resolution (500 TVL or UXGA, 1600 x 1200) image
▶Picture-in-Picture or split screen function for viewing
video on the PC screen
▶Easy to use controls with remote and on-screen menu
display
▶Analog RGB, digital DVI, and digital HDMI inputs
▶Two (2) composite BNC inputs and loop-through
outputs
▶Component video
▶Y/C (S-video) and loop-through video and audio inputs
▶Long-life fluorescent backlight maintains optimal
screen brightness throughout monitor life
▶High-brightness (300 cd/m2) display
▶High-contrast ratio (800:1)
www.boschsecurity.com

2 | UML-202-90 20-inch Color LCD Display Monitor
Technical Specifications
Electrical
Rated Voltage 110/230 VAC, 50/60 Hz
Voltage Range 90 to 264
Power at Rated Voltage 70 W
Sync Format PAL/NTSC
LCD Panel TFT LCD
Screen Size (H x V) 408 x 306 mm
(16 x 12 in.)
Viewable Picture
Area
20.1 in. (53 cm) measured diagonally
Pixel Pitch (H x V) 0.255 x 0.255 mm
(0.01 x 0.01 in.)
Resolution 1600 x 1200 pixels, 500 TV lines typical
Aspect Ratio 4:3
Display Colors 8-bit interface; 16.7 million colors
Response Time 16 ms (typical)
Backlight Six (6) cold cathode fluorescent tubes, rated life
50,000 hours, at 50% brightness
LCD Panel Optical Characteristics
Luminance 300 cd/m2, hard-coating (3H), non-glare treat-
ment
Contrast Ratio (CR) 800:1
Viewing Angle 178° horizontal, 178° vertical
@ CR ≥ 10
Video Input
Composite Video (CVBS) 1.0 Vp-p (0.5–1.5 Vp-p), automatic switching
from 75 Ohm unbalanced termination to Hi-Z
with passive loop-through operation
Y/C (S-video) 0.7 Vp-p (Y-signal), 0.3 Vp-p (C-signal) 75 Ohm
termination
Picture-in-Picture Video 1, Video 2, S-video
HDMI/DVI/RGB Inputs
Analog RGB 0.7 Vp-p (0.5–1 Vrms)
Picture-in-Picture Video 1, Video 2, S-video
DVI/RGB/HDMI Timing
Modes
640 x 480, 60/72/75 Hz
800 x 600, 60/72/75 Hz
1024 x 768, 60/70/75 Hz
1280 x 1024, 60/75 Hz
1600 x 1200, 60 Hz
Component Timing Resolution V-freq (Hz)
640 x 480 (480i) 60
720 x 576 (576i) 50
640 x 480 (480P) 60
720 x 576 (576P) 50
1280 x 720 (720P) 50, 60
1920 x 1080 (1080i) 50, 60
1920 x 1080 (1080P) 50, 60
HDMI/DVI/RGB Inputs
HDMI Timing Resolution V-freq (Hz)
640 x 480 (480P) 60
720 x 576 (576P) 50
1280 x 720 (720P) 50, 60
1920 x 1080 (1080i) 50, 60
1920 x 1080 (1080P) 50, 60
Audio Input 1.0 V line level, mono
Audio Output Loop-through line level
Speaker: two (2), 2 W
Controls
Front Panel Push-buttons
Input Selects Video 1, Video 2, S-video, RGB, DVI, or
HDMI input
Menu Selects on-screen display (OSD)
Up arrow, Menu select
Down arrow, Menu select
Left arrow, decrease
Right arrow, increase
Power On/Off
Front Panel Lockout Multiple push-button combination
On-Screen Display
Video Custom (Brightness, Contrast, Color, tint,
Sharpness),
Picture/Sound (Picture Mode, Color Tone, Mute,
Volume, Size, Auto Adjust, H-position, V-posi-
tion, Frequency),
PIP (PIP, Input Source, Size, Position, Swap,
Sound Select),
Setup (Reset, Language, OSD Tone, Blue
Screen, Key Lock, Version)
DVI/RGB Custom (Brightness, Contrast, Sharpness),
Picture/Sound (Picture Mode, Color Tone, Mute,
Volume, PC, Auto Adjust, H-position, V-position,
Frequency),
PIP (PIP, Input Source, Size, Position, Swap,
Sound Select),
Setup (Reset, Language, OSD Tone, Blue
Screen, Key Lock, Version)
Indicators
LED Power On (green)
Power Off (red)
Standby\Sleep Mode (flashes red)
On-Screen "No Signal” (Moving OSD)
Connectors
Video 1 Composite video: two (2) BNC (1 in, 1 out)
Video 2 Composite video: two (2) BNC (1 in, 1 out)
Y/C (S-Video) Two (2) mini-DIN, 4-pin (1 in, 1 out)
Component Y, Pb, Pr
Audio PC: one (1) 1/8 in. mini phono plug
Video: four (4) RCA (2 in, 2 out)

UML-202-90 20-inch Color LCD Display Monitor | 3
Connectors
DVI-D
HDMI
RGB
One (1) DVI to DVI cable included
One (1) cable not included
One (1) RGB to RGB cable included
Power Cord Two (2) 3-wire with a grounded plug, 1.8 m (6 ft)
long, one (1) with a European/Continental plug
type and one (1) with a U.S. plug type
Mechanical
Cabinet Material Front: ABS plastic
Chassis: electrolytic galvanized iron
Finish Charcoal black
Mount Wall mounting compatible with standard brack-
et, 100 mm centers, M4 thread
Dimensions
Monitor Only
(W x H x D)
460.4 x 395.1 x 81 mm
(18.1 x 15.5 x 3.19 in.)
Packaging Dim
(W x H x D)
540 x 485 x 180 mm
(21.2 x 19.1 x 7.0 in.)
Weight Monitor only: 8.5 kg (18.7 lb)
Package: 10.5 kg (23.1 lb)
Environmental
Operating Temp. 0°C to 40°C (32°F to 104°F)
Storage Temp. –20°C to 60°C (–4°F to 140°F)
Humidity 10%-95%, non-condensing
Ordering Information
UML-202-90 20-inch Color LCD Display
Monitor
UML-202-90
Accessories
UMM-LW-20B Fixed Wall Mount
Fixed wall mount for flat panel LCD monitors,
black
UMM-LW-20B
UMM-LW-30B Swivel/Tilt Wall Mount
Swivel/Tilt wall mount for flat panel LCD mon-
itors, black
UMM-LW-30B
