Bosch Multi-X MX25E Assembly instructions

IMPORTANT: IMPORTANT : IMPORTANTE:
Read Before Using Lire avant usage Leer antes de usar
For English Version Version française Versión en español
See page 2 Voir page 18 Ver la página 34
Operating/Safety Instructions
Consignes de fonctionnement/sécurité
Instrucciones de funcionamiento y seguridad
1-877-BOSCH99 (1-877-267-2499) www.boschtools.com
Call Toll Free for
Consumer Information
& Service Locations
Pour obtenir des informations
et les adresses de nos centres
de service après-vente,
appelez ce numéro gratuit
Llame gratis para
obtener información
para el consumidor y
ubicaciones de servicio
MX25E
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 1

-2-
Work area safety
Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust
or fumes.
Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
Electrical safety
Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges
and refrigerators. There is an increased risk
of electric shock if your body is earthed or
grounded.
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
If operating the power tool in damp locations
is unavoidable, use a Ground Fault Circuit
Interrupter (GFCI) protected supply. Use of
an GFCI reduce the risk of electric shock.
Personal safety
Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention
while operating power tools may result in
serious personal injury.
Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the
switch is in the off-position before
connecting to power source and / or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energizing power tools that have the
switch on invites accidents.
Remove any adjusting key or wrench before
turning the power tool on. A wrench or a
key left attached to a rotating part of the power
tool may result in personal injury.
Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewelry or long hair can be caught in
moving parts.
If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
Power tool use and care
Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
SA E ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
!
WARNING
General Power Tool Safety Warnings
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 2

-3-
Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment
or binding of moving parts, breakage of
parts and any other condition that may
affect the power tool’s operation. If damaged,
have the power tool repaired before use.
Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
Use the power tool, accessories and tool
bits etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
Service
Have your power tool serviced by a qualified
repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
Safety Rules for Oscillating Tools
Hold power tool by insulated gripping
surfaces when performing an operation
where the cutting tool may contact hidden
wiring or its own cord. Contact with a "live"
wire will make exposed metal parts of the tool
"live" and shock the operator.
Use clamps or another practical way to
secure and support the workpiece to a
stable platform. Holding the work by hand or
against your body leaves it unstable and may
lead to loss of control.
Use a metal detector to determine if there
are gas or water pipes hidden in the work
area or call the local utility company for
assistance before beginning the operation.
Striking or cutting into a gas line will result in
explosion. Water entering an electrical device
may cause electrocution.
Always hold the tool firmly with both hands
for maximum control. Keep proper footing
and balance at all times. This enables better
control of the power tool in unexpected
situations.
Keep hands away from cutting area. Do
not reach under the material being cut. The
proximity of the blade to your hand is hidden
from your sight.
Do not use dull or damaged blades. Bent
blade can break easily or cause kickback.
Exercise extreme caution when handling
the accessories. The accessories are very
sharp.
Wear protective gloves when changing
cutting accessories. Accessories become
hot after prolonged usage.
Use thick cushioned gloves and limit the
exposure time by taking frequent rest
periods. Vibration caused by the tool may be
harmful to the hands and arms.
Before scraping, check workpiece for nails.
If there are nails, either remove them or set
them well below intended finished surface.
Striking a nail with accessory edge could
cause the tool to jump.
Do not wet sand with this tool. Liquids
entering the motor housing is an electrical
shock hazard.
Never work in area which is soaked with a
liquid, such as a solvent or water, or
dampened such as newly applied
wallpaper. There is an electrical shock
hazard when working in such conditions with a
power tool and heating of the liquid caused by
scraping action may cause harmful vapors to
be emitted from workpiece.
Always wear eye protection and a dust
mask for dusty applications and when
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 3

-4-
GFCI and personal protection devices like
electrician’s rubber gloves and footwear will
further enhance your personal safety.
Do not use AC only rated tools with a DC
power supply. While the tool may appear to
work, the electrical components of the AC
rated tool are likely to fail and create a hazard
to the operator.
Keep handles dry, clean and free from oil
and grease. Slippery hands cannot safely
control the power tool.
Develop a periodic maintenance schedule
for your tool. When cleaning a tool be
careful not to disassemble any portion of
the tool since internal wires may be
misplaced or pinched or safety guard return
springs may be improperly mounted.
Certain cleaning agents such as gasoline,
carbon tetrachloride, ammonia, etc. may
damage plastic parts.
Risk of injury to user. The power cord must only
be serviced by a Bosch Factory Service Center
or Autho rized Bosch Service Station.
Some dust created by power
sanding, sawing, grinding,
drilling, and other construction activities
contains chemicals known to cause cancer,
birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and
other masonry products, and
• Arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type of
work. To reduce your exposure to these
chemicals: work in a well ventilated area, and
work with approved safety equipment, such as
those dust masks that are specially designed
to filter out microscopic particles.
Additional Safety Warnings
!
WARNING
sanding overhead. Sanding particles can be
absorbed by your eyes and inhaled easily
and may cause health complications.
Use special precautions when sanding
chemically pressure treated lumber, paint
that may be lead based, or any other
materials that may contain carcinogens. A
suitable breathing respirator and protective
clothing must be worn by all persons entering
the work area. Work area should be sealed by
plastic sheeting and persons not protected
should be kept out until work area is thoroughly
cleaned.
Do not use sandpaper intended for larger
sanding pads. Larger sandpaper will extend
beyond the sanding pad causing snagging,
tearing of the paper or kick-back. Extra paper
extending beyond the sanding pad can also
cause serious lacerations.
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 4

-5-
IMPORTANT: Some of the following symbols may be used on your tool. Please study them
and learn their meaning. Proper interpretation of these symbols will allow you to operate the
tool better and safer.
Symbol Name Designation/Explanation
V Volts Voltage (potential)
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
kg ilograms Weight
min Minutes Time
s Seconds Time
Diameter Size of drill bits, grinding wheels, etc.
n0No load speed Rotational speed, at no load
n Rated speed Manufacturers rated speed
.../min Revolutions or reciprocation Revolutions, strokes, surface speed,
per minute orbits etc. per minute
0 Off position Zero speed, zero torque...
1, 2, 3, ... Selector settings Speed, torque or position settings.
I, II, III, Higher number means greater speed
Infinitely variable selector with off Speed is increasing from 0 setting
Arrow Action in the direction of arrow
Alternating current Type or a characteristic of current
Direct current Type or a characteristic of current
Alternating or direct current Type or a characteristic of current
Class II construction Designates Double Insulated
Construction tools.
Earthing terminal Grounding terminal
Warning symbol Alerts user to warning messages
Li-ion RBRC seal Designates Li-ion battery recycling
program
Ni-Cad RBRC seal Designates Ni-Cad battery recycling
program
Read manual symbol Alerts user to read manual
Wear eye protection symbol Alerts user to wear eye protection
Symbols
0
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 5

-6-
This symbol designates that this tool is listed by Underwriters Laboratories.
This symbol designates that this tool is listed by the Canadian Standards
Association.
This symbol designates that this tool is listed by the Canadian Standards
Association, to United States and Canadian Standards.
This symbol designates that this tool complies to NOM Mexican Standards.
This symbol designates that this tool is listed by Underwriters Laboratories,
to United States and Canadian Standards.
This symbol designates that this tool is listed by the Intertek Testing
Services, to United States and Canadian Standards.
Symbols (continued)
IMPORTANT: Some of the following symbols may be used on your tool. Please study them
and learn their meaning. Proper interpretation of these symbols will allow you to operate the
tool better and safer.
This symbol designates that this tool is recognized by Underwriters Laboratories.
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 6

-7-
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
NOTE: For tool specifications refer to the nameplate on your tool.
Multi-X Oscillating Power Tool
Model number MX25E
No load speed n08,000-20,000/min
Voltage rating 120 V 60 Hz
FIG. 1
OIS
ACCESSORY
HOLDER
SLIDE
"ON/OFF"
SWITCH
VENTILATION
OPENINGS
VARIABLE SPEED
CONTROL DIAL
POWER
CORD
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 7

-8-
Disconnect the plug from
the power source before
making any assembly, adjustments or
changing accessories. Such preventive
safety measures reduce the risk of starting the
tool accidentally.
For all work or when
changing accessories
always wear protective gloves. Such
preventive safety measures reduce the risk of
injury from sharp edges of the accessories.
Application tools can become very hot while
working. Danger of burns!
INSTALLING AND REMO ING
ACCESSORIES
1. Loosen the hex bolt and blade washer using
the hex wrench provided (Fig. 2).
2. Clean OIS accessory holder, accessory and
the hex bolt with a clean cloth.
3. Place the accessory onto the accessory
holder making sure the accessory engages
all pins in the holder and the accessory is
flush aganist the OIS accessory holder.
The OSCAD1 adapter is provided to allow you
to attach the accessory in intermediate
positions. Use of adapter will also allow you to
use many competitor accessories.
4. Securely tighten the hex bolt and blade
washer with the hex wrench (Fig. 2).
5. To remove accessory, loosen and remove
hex bolt and blade washer, then remove
accessory from holder (Fig. 1).
NOTE: Some accessories, such as scrapers or
blades, may be mounted either straight on the
tool, or at an angle to enhance usability (Fig. 2).
INSTALLING AND REMO ING
SANDING SHEETS
Your backing pad uses hook-and-loop backed
accessories, which firmly grip the backing pad
when applied with moderate pressure.
1. Align the sanding sheet and press it onto the
sanding plate by hand.
2. Firmly press the power tool with the sanding
sheet against a flat surface and briefly
switch the power tool on. This will promote
good adhesion and helps to prevent
premature wear.
3. To change, merely peel off the old sanding
sheet, remove dust from the backing pad if
necessary, and press the new sanding
sheet in place.
After considerable service the backing pad
surface will become worn, and the backing pad
must be replaced when it no longer offers a firm
grip. If you are experiencing premature wear
out of the backing pad facing, decrease the
amount of pressure you are applying during
operation of the tool.
For maximum use of abrasive, rotate pad 120
degrees when tip of abrasive becomes worn.
Assembly
!
WARNING
!
WARNING
RUBBER
BACKING PAD
SANDING
SHEET
OIS
ACCESSORY
HOLDER
OSCAD1 ADAPTER
(only if necessary)
PLUNGE CUT
BLADE
HEX
BOLT
5 MM
HEX
WRENCH
FIG. 2
BLADE
WASHER
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 8

-9-
CONNECTING THE DUST EXTRACTION
ATTACHMENT
The optional dust extraction attachment (sold
separately) is only for use when sanding. It is
not designed for use when cutting or grinding.
Assemble and attach the parts of the dust
extraction as shown in figure 3.
1. Before mounting the dust extraction
attachment pieces, remove any accessory
that is attached to the tool.
2. Make sure that the dust extraction hood's
felt ring is undamaged and faces tightly
against the sanding plate. Replace a
damage felt ring immediately.
3. Attach the two parts of the dust extraction
tube to each other and to the dust extraction
hood.
4. Position the assembled dust extraction
attachment onto the tool over the accessory
attachment area.
5. Secure the assembled dust extraction tube
onto the tool using the retaining clip as
shown in figure 3.
6. Attach the rubber backing pad and sanding
sheet.
7. Place a vacuum hose or vacuum cleaner
hose adapter onto the dust extraction tube.
8. Connect the vacuum hose to a vacuum
cleaner.
The vacuum cleaner must be suitable for the
material being worked. When vacuuming dry
dust that is especially detrimental to health or
carcinogenic, use a vacuum cleaner that is
specifically intended for that purpose.
FELT RING
RETAINING
CLIP VAC024
1-1/4”
OR
1-1/2” HOSE
FIG. 3
BOSCH
VACUUM
HOSE
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 9

-10-
Operating Instructions
LEARNING TO USE THE TOOL
Getting the most out of your oscillating tool is a
matter of learning how to let the speed and the
feel of the tool in your hands work for you.
The first step in learning to use the tool is to
get the “feel” of it. Hold it in your hand and feel
its weight and balance (Fig. 4). Depending on
the application, you will need to adjust your
hand position to achieve optimum comfort and
control. The unique comfort grip on the body of
the tool allows for added comfort and control
during use.
When holding tool, do not cover the air vents
with your hand. Blocking the air vents could
cause the motor to overheat.
IMPORTANT! Practice on scrap material first
to see how the tool’s high-speed action
performs. eep in mind that your tool will
perform best by allowing the speed, along with
the correct accessory, do the work for you. Be
careful not to apply too much pressure.
Instead, lower the oscillating accessory lightly
to the work surface and allow it to touch the
point at which you want to begin. Concentrate
on guiding the tool over the work using very
little pressure from your hand. Allow the
accessory to do the work.
Usually it is better to make a series of passes
with the tool rather than to do the entire job
with one pass. To make a cut, for example,
pass the tool back and forth over the work. Cut
a little material on each pass until you reach
the desired depth.
SLIDE "ON/OFF" SWITCH
The tool is switched "ON" by the slide switch
located on the topside of the motor housing
(Fig. 1).
TO TURN THE TOOL "ON" slide the switch
button forward to the “I” .
TO TURN THE TOOL "OFF" slide the switch
button backward the “0” .
ELECTRONIC FEEDBACK
Your tool is equipped with an internal
electronic feedback system that provides a
“soft start”, which will reduce the stresses that
occur from a high torque start. The system
also helps to keep the preselected speed
virtually constant between no-load and load
conditions.
ARIABLE SPEED DIAL
This tool is equipped with a variable speed
dial. The speed may be controlled during
operation by presetting the dial in any one of
six positions (Fig. 1).
OPERATING SPEEDS
The Bosch Multi-X has a high oscillating
motion of 8,000 - 20,000 /min (OPM). The
high speed motion allows the Bosch Multi-X
to achieve with excellent results. The
oscillating motion allows the dust to fall to the
surface rather than slinging particles into the
air.
To achieve the best results when working
with different materials, set the variable
speed control to suit the job (See Speed
Chart on Page 12 for guidance) . To select
the right speed for the accessory in use,
practice with scrap material first.
FIG. 4
INTENDED USE
This Bosch Multi-X Oscillating Tool is
intended for dry sanding of surfaces, corners,
edges, for scraping, for sawing soft metals,
wood and plastic components, and for grout
removal using the applicable tools and
accessories recommended by Bosch.
Introduction
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 10

-11-
NOTE: Speed is affected by voltages
changes. A reduced incoming voltage will
slow the OPM of the tool, especially at the
lowest setting. If your tool appears to be
running slowly, increase the speed setting
accordingly. The tool may not start at the
lowest switch setting in areas where outlet
voltage is less than 120 volts. Simply move
the speed setting to a higher position to
begin operation.
The variable speed control settings are
marked on the speed control dial. The
settings for approximate /min (OPM) are:
Switch Setting Speed Range
/min (OPM)
1 8,000
2 10,400
3 12,800
4 15,200
5 17,600
6 20,000
You can refer to the charts on next page to
determine the proper speed, based on the
material and accessory being used. These
charts enable you to select both the correct
accessory and the optimum speed at a glance.
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 11

-12-
Multi-X Accessory Speed Settings
 ""'& ,#%## ""'& ,#%"' ##  , ("('  ##  , ("('  ##'   , ("('  *  %#('!#)   , %#('!#)   , %$%   + %$% 


      
  


      
  




     
 

      
  

 
 

    
  

 
 

    
"

       


 
!
       
 


         
 
     
 
 

 
 
 


 


"
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:55 AM Page 12

-13-
APPLICATIONS
Your Bosch Multi-X oscillating tool is intended
for sanding and cutting wooden materials,
plastic, plaster and non-ferrous metals. It is
especially suitable for working close to edges,
in tight spaces, and for flush cutting.
Below are some typical uses for your Bosch
Multi-X oscillating tool.
For all accessories, work
with the accessory away
from the body. Never position hand near or
directly in front of working area. Always hold
the tool with both hands and wear protective
gloves.
Flush Cutting
Remove excess wood from door jamb, window
sill and/or toekick. Removing excess copper or
PVC pipe.
Removal work
e.g. carpets & backing, old tile adhesives,
caulking on masonry, wood and other
surfaces.
Removal of excess materials
e.g. plaster, mortar splatters, concrete on tiles,
sills.
Preparation of surfaces
e.g. for new floors and tiles.
Detail sanding
e.g. for sanding in extremely tight areas
otherwise difficult to reach and require hand
sanding
CUTTING
Saw blades are ideal for making precise cuts
in tight areas, close to edges or flush to a
surface.
Select a medium to high speed for making
initial plunge, start off at medium speed for
increased control. After making your initial cut,
you can increase speed for faster cutting
ability.
Flush cutting blades are
intended to make precise cuts to
allow for installation of flooring or
wall material. When flush cutting
it is important not to force the tool during the
plunge cut. If you experience a strong vibration
in your hand during the plunge cut, this
indicates that you are applying too much
pressure. Back the tool out and let the speed
of the tool do the work. While keeping the teeth
of the blade in the work surface, move the
back of the tool in a slow sideways motion.
This motion will help expedite the cut.
When making a flush cut it is always a good
idea to have a piece of scrap material (tile or
wood) supporting the blade. If you need to rest
the flush cutting blade on a delicate surface,
you should protect the surface with cardboard
or masking tape.
The flat saw blade is ideal for
making precise cuts in wood,
plaster, drywall material.
Applications include cutting openings in
flooring for venting, repairing damaged
flooring, cutting openings for electrical boxes.
The blade works best on softer woods such as
pine. For harder woods, the blade life will be
limited.
Select a medium to high speed.
The flat saw blade can also be used for
window restoration making glazing easy to
remove. The saw blade can be placed directly
against the edge of the window frame, guiding
the blade through the glazing.
GROUT REMO AL
Grout removal blades are ideal
for removing damaged or
cracked grout. Grout blades
come in different widths (1/16" and 1/8") to
tackle different grout line widths. Before
selecting a grout blade measure the grout line
width to pick the appropriate blade.
Select a medium to high speed.
To remove the grout, use a back and forth
motion, making several passes along the grout
line. The hardness of the grout will dictate how
many passes are needed. Try and keep the
grout blade aligned with the grout line and be
careful not to apply too much side pressure on
the grout blade during the process. To control
plunge depth use the carbide grit line on the
blade as an indicator. Be careful not to plunge
beyond the carbide grit line to avoid damage to
the backer board material.
The grout blades can handle both sanded and
unsanded grout. If you notice the blade
clogging during the grout removal process, you
can use a brass brush to clean the grit, thus
exposing the grit again.
The grout blade geometry is designed so that
the blade can remove all grout up to the
surface of a wall or corner. This can be
Operating Applications
!
WARNING
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:56 AM Page 13

-14-
accomplished by ensuring that the segmented
portion of the blade is facing the wall or corner.
SCRAPING
Scrapers are suitable for removing old coats of
varnish or adhesives, removing bonded
carpeting, e.g. on stairs/steps and other
small/medium size surfaces.
Select low to medium speed.
Rigid scrapers are for large area
removal, and harder materials
such as vinyl flooring, carpeting
and tile adhesives. When
removing strong, tacky adhesives, grease the
scraper blade surface with (petroleum jelly
or silicone grease) to reduce gumming up.
The carpet/vinyl flooring removes easier if
it is scored prior to removal so the scraper
blade can move underneath the flooring
material.
Flexible scrapers are used for
hard to reach areas and softer
material such as caulk.
Mount the scraper blade with the logo side
facing up. With the flexible scraper, make sure
that the screw head does not make contact
with surface during the scraping process (a 30
- 45 degree pitch is recommend). This can be
accomplished by making sure that the tool is at
an angle to the blade. You should be able to
see the blade flex during the scraping process.
If you are removing caulk from a delicate
surface such as a bath tub or tile back splash,
we recommend taping or protecting the
surface that the blade will rest on. Use rubbing
alcohol to clean the surface after the caulk
and/or adhesive is removed.
Turn the tool on and place desired accessory
on the area where material is to be removed.
Begin with light pressure. The oscillating
motion of accessory only occurs when
pressure is applied to the material to be
removed.
Excessive pressure can gouge or damage the
background surfaces (e.g,. wood, plaster).
SANDING
Sanding accessories are suitable
for dry sanding of wood, metal,
surfaces, corners and edges and
hard to reach areas.
Work with the complete surface of the sanding
pad, not only with the tip.
Corners may be finished using the tip or edge
of the selected accessory, which should
occasionally be rotated during use to distribute
the wear on the accessory and backing pad
surface.
Sand with a continuous motion and light
pressure. DO NOT apply excessive pressure -
let the tool do the work. Excessive pressure
will result in poor handling, vibration, and
unwanted sanding marks and premature wear
on the sanding sheet.
Always be certain that smaller workpieces are
securely fastened to a bench or other support.
Larger panels may be held in place by hand on
a bench or sawhorses.
Open-coat aluminum oxide sanding sheets are
recommended for most wood or metal sanding
applications, as this synthetic material cuts
quickly and wears well. Some applications,
such as metal finishing or cleaning, require
special abrasive pads which are available from
your dealer. For best results, use Bosch
sanding accessories which are of superior
quality and are carefully selected to produce
professional quality results with your oscillating
tool.
The following suggestions may be used as a
general guide for abrasive selection, but the
best results will be obtained by sanding a test
sample of the workpiece first.
Grit Application
Coarse For rough wood or metal
sanding, and rust or old
finish removal.
Medium For general wood or metal
sanding
Fine For final finishing of wood,
metal, plaster and other
surfaces.
With the workpiece firmly secured, turn tool on
as described above. Contact the work with the
tool after the tool has reached its full speed,
and remove it from the work before switching
the tool off. Operating your oscillating tool in
this manner will prolong switch and motor life,
and greatly increase the quality of your work.
Move the oscillating tool in long steady strokes
parallel to the grain using some lateral motion
to overlap the strokes by as much as 75%.
DO NOT apply excessive pressure - let the
tool do the work. Excessive pressure will result
in poor handling, vibration, and unwanted
sanding marks.
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:56 AM Page 14

-15-
Material Application Grit Size
All wooden materials (e.g.,
hardwood, softwood, chipboard,
building board) Metal materials–
Metal materials, fiberglass
and plastics
Paint, varnish, filling compound
and filler
Selecting Sanding/Grinding Sheets
For coarse-sanding, e.g. of
rough, unplanned beams and
boards
For face sanding and planing
small irregularities
For finish and fine sanding of
wood
For sanding off paint
For sanding primer (e.g., for
removing brush dashes, drops
of paint and paint run)
For final sanding of primers
before coating
Coarse
Medium
Fine
Coarse
Medium
Fine
40/60
80/120
180/240
40/60
80/120
180/240
Sand Paper (Red)
Sand Paper (White)
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:56 AM Page 15

-16-
FIG. 6FIG. 5
CORRECT: Sand with a smooth
back and forth motion, allowing the
weight of the tool to do the work.
INCORRECT: Avoid sanding with
only the tip of the pad. eep as
much sand paper in touch with the
work surface as possible.
CORRECT: Always sand with the
pad and sandpaer flat against the
work surface. Work smoothly in a
back and forth motion.
INCORRECT: Avoid tipping the
pad. Always sand flat.
CORRECT: Always cut with a
smooth back and forth motion.
Never force the blade. Apply light
pressure to guide the tool.
INCORRECT: Do not twist the tool
while cutting.This can cause the
blade to bind.
CORRECT: Make sure flexible
scraper blade flexes enough
INCORRECT: Avoid screw head
touching surface with flexible
scraper blade.
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:56 AM Page 16

-17-
If an extension cord is
necessary, a cord with
adequate size conductors that is capable
of carrying the current necessary for your
tool must be used. This will prevent
excessive voltage drop, loss of power or
overheating. Grounded tools must use 3-wire
extension cords that have 3-prong plugs and
receptacles.
NOTE: The smaller the gauge number, the
heav i er the cord.
RECOMMENDED SIZES OF EXTENSION CORDS
120 OLT ALTERNATING CURRENT TOOLS
!
WARNING
Extension Cords
Tool’s
Ampere
Rating
Cord Size in A.W.G. Wire Sizes in mm2
3-6
6-8
8-10
10-12
12-16
18 16 16 14 0.75 0.75 1.5 2.5
18 16 14 12 0.75 1.0 2.5 4.0
18 16 14 12 0.75 1.0 2.5 4.0
16 16 14 12 1.0 2.5 4.0 —
14 12 —— ————
25 50 100 150 15 30 60 120
Cord Length in Feet Cord Length in Meters
Service
Preventive maintenance
performed by unauthorized
per so n nel may result in misplacing of
internal wires and components which
could cause serious hazard. We
recommend that all tool service be performed
by a Bosch Factory Service Center or Autho -
rized Bosch Service Station.
TOOL LUBRICATION
Your Bosch tool has been properly lubricated
and is ready to use. It is recommended that
tools with gears be regreased with a special
gear lubricant at every brush change.
CARBON BRUSHES
The brushes and commutator in your tool
have been engineered for many hours of
dependable service. To maintain peak
efficiency of the motor, we recommend every
two to six months the brush es be examined.
Only genuine Bosch replace ment brushes
specially designed for your tool should be
used.
BEARINGS
Bearings which become noisy (due to heavy
load or very abrasive material cut ting) should
be replaced at once to avoid overheating or
motor failure.
Cleaning
To avoid accidents always
dis connect the tool from
the power supply before cleaning or
performing any main tenance. The tool may
be cleaned most effectively with compressed
dry air. Always wear safety gog gles when
cleaning tools with compressed air.
Ventilation openings and switch levers must
be kept clean and free of foreign matter. Do
not at tempt to clean by inserting pointed
objects through openings.
Certain cleaning agents
and sol vents damage
plastic parts. Some of these are: gasoline,
carbon tetrachlo ride, chlo rinated cleaning
solvents, ammonia and house hold detergents
that contain ammonia.
!
WARNING
!
WARNING
Maintenance
!
CAUTION
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:56 AM Page 17

-18-
Veuillez lire tous les avertissements et toutes les consignes de sécurité. Si l'on
n'observe p s ces vertissements et ces consignes de sécurité, il existe un risque de
choc électrique, d'incendie et/ou de blessures corporelles gr ves.
CONSERVE TOUS LES AVERTISSEMENTS ET TOUTES LES CONSIGNES
DE SÉCURITÉ POUR RÉFÉRENCE FUTURE.
D ns les vertissements, le terme « outil électroport tif » se r pporte à votre outil br nché sur le secteur ( vec fil) ou
à votre outil limenté p r piles (s ns fil).
Avertissements généraux concernant la sécurité des outils électroportatifs
AVERTISSEMENT
!
Sécurité du lieu de travail
Maintenez le lieu de travail propre et bien éclairé.
Les risques d’ ccident sont plus élevés qu nd on
tr v ille d ns un endroit encombré ou sombre.
N’utilisez pas d’outils électroportatifs dans des
atmosphères explosives, comme par exemple en
présence de gaz, de poussières ou de liquides
inflammables. Les outils électroport tifs produisent
des étincelles qui risquent d’enfl mmer les poussières
ou les v peurs.
Éloignez les enfants et les visiteurs quand vous vous
servez d’un outil électroportatif. Vous risquez une
perte de contrôle si on vous distr it.
Sécurité électrique
Les fiches des outils électroportatifs doivent
correspondre à la prise. Il ne faut absolument jamais
modifier la fiche. N’utilisez pas d’adaptateur de prise
avec des outils électroportatifs munis d’une fiche de
terre. Le risque de choc électrique est moindre si on
utilise une fiche non modifiée sur une prise qui lui
correspond.
Évitez tout contact du corps avec des surfaces reliées
à la terre tels que tuyaux, radiateurs, gazinières ou
réfrigérateurs. Le risque de choc électrique ugmente
si votre corps est relié à l terre.
N’exposez pas les outils électroportatifs à la pluie ou
à l’humidité. Si de l’e u pénètre d ns un outil
électroport tif, le risque de choc électrique ugmente.
Ne maltraitez pas le cordon. Ne vous en servez
jamais pour transporter l’outil électroportatif, pour le
tirer ou pour le débrancher. Éloignez le cordon de la
chaleur, des huiles, des arêtes coupantes ou des
pièces mobiles. Les cordons bîmés ou emmêlés
ugmentent les risques de choc électrique.
Si vous utilisez un outil électroportatif à l’extérieur,
employez une rallonge conçue pour l’extérieur. Ces
r llonges sont f ites pour l’extérieur et réduisent le
risque de choc électrique.
S'il est absolument nécessaire d'utiliser l'outil
électroportatif dans un endroit humide, utilisez une
alimentation protégée par un disjoncteur de fuite de
terre (GFCI). L'utilis tion d'un disjoncteur GFCI réduit
les risques de choc électrique.
Sécurité personnelle
Restez concentré, faites attention à ce que vous
faites, et servez-vous de votre bon sens lorsque vous
utilisez un outil électroportatif. N'employez pas
d’outils électroportatifs quand vous êtes fatigué ou
sous l’emprise de drogues, d’alcool ou de
médicaments. Qu nd on utilise des outils
électroport tifs, il suffit d’un moment d’in ttention pour
c user des blessures corporelles gr ves.
Utilisez des équipements de sécurité personnelle.
Portez toujours une protection oculaire. Le port
d'équipements de sécurité tels que des m sques
ntipoussières, des ch ussures de sécurité
ntidér p ntes, des c sques de ch ntier et des
protecteurs d'oreilles d ns des conditions ppropriées
réduir le risque de blessure corporelle.
Évitez les démarrages intempestifs. Assurez-vous que
l'interrupteur est dans la position arrêt (Off) avant de
brancher l'outil dans une prise de courant et/ou un
bloc-piles, de le ramasser ou de le transporter. Le
tr nsport d'un outil électroport tif vec le doigt sur l
gâchette ou le br nchement de cet outil qu nd
l'interrupteur est en position de m rche (ON) est une
invite ux ccidents.
Enlevez toutes les clés de réglage avant de mettre
l’outil électroportatif en marche. Si on l isse une clé
sur une pièce tourn nte de l’outil électroport tif, il y
risque de blessure corporelle.
Ne vous penchez pas. Conservez toujours une bonne
assise et un bon équilibre. Ceci vous permettr de
mieux m îtriser l’outil électroport tif d ns des situ tions
in ttendues.
Habillez-vous de manière appropriée. Ne portez pas
de vêtements amples ou de bijoux. Attachez les
cheveux longs. N’approchez pas les cheveux, les
vêtements ou les gants des pièces en mouvement.
Les vêtements mples, les bijoux ou les cheveux longs
risquent d’être h ppés p r les pièces en mouvement.
Si l’outil est muni de dispositifs permettant le
raccordement d’un système d’aspiration et de
collecte des poussières, assurez-vous que ces
dispositifs sont raccordés et utilisés correctement.
L'utilis tion d'un dépoussiéreur peut réduire les
d ngers ssociés à l' ccumul tion de poussière.
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:56 AM Page 18

-19-
Utilisation et entretien des outils
électroportatifs
Ne forcez pas sur l’outil électroportatif. Utilisez l’outil
électroportatif qui convient à la tâche à effectuer.
L’outil qui convient à l tâche f it un meilleur tr v il et
est plus sûr à l vitesse pour lequel il été conçu.
Ne vous servez pas de l’outil électroportatif si son
interrupteur ne parvient pas à le mettre en marche ou
à l’arrêter. Tout outil électroport tif qui ne peut p s
être comm ndé p r son interrupteur est d ngereux et
doit être rép ré.
Débranchez la fiche de la prise ou enlevez le bloc-pile
de l’outil électroportatif avant tout réglage,
changement d’accessoires ou avant de ranger l’outil
électroportatif. De telles mesures de sécurité
préventive réduisent le risque de dém rr ge intempestif
de l’outil électroport tif.
Rangez les outils électroportatifs dont vous ne vous
servez pas hors de portée des enfants et ne permettez
pas à des personnes qui ne connaissent pas l’outil
électroportatif ou qui ignorent ces consignes de s’en
servir. Les outils électroport tifs sont d ngereux d ns
les m ins d’utilis teurs inexpérimentés.
Entretenez les outils électroportatifs. Vérifiez que les
pièces mobiles sont alignées correctement et ne
coincent pas. Vérifiez qu’il n’y a pas de pièces
cassées ou d’autre circonstance qui risquent
d’affecter le fonctionnement de l’outil électroportatif.
Si l’outil est abîmé, faites-le réparer avant de
l’utiliser. De nombreux ccidents sont c usés p r des
outils électroport tifs m l entretenus.
Maintenez les outils coupants affûtés et propres. Les
outils coup nts entretenus correctement et dotés de
bords tr nch nts ffûtés sont moins susceptibles de
coincer et sont plus f ciles à m îtriser.
Utilisez l'outil électroportatif, les accessoires et les
embouts d'outil, etc. conformément à ces instructions,
en tenant compte des conditions de travail et des
travaux à réaliser. L'emploi d’outils électroport tifs
pour des tâches différentes de celles pour lesquelles ils
ont été prévus peut résulter en une situ tion d ngereuse.
Entretien
Faites réparer votre outil électroportatif par un agent
de service qualifié n’utilisant que des pièces de
rechange identiques. Ceci ssure que l sécurité de
l’outil électroport tif est préservée.
Tenez les outils électroportatifs par les surfaces
isolées de préhension en exécutant une opération
au cours de laquelle les outils de coupe peuvent
venir en contact avec les fils cachés. Le cont ct
vec un fil sous tension rendr les pièces mét lliques
exposées de l'outil sous tension et c user des chocs
à l'opér teur.
Utilisez des brides ou d’autres moyens pratiques de
brider ou de supporter la pièce sur une plate-forme
stable. Tenir l pièce à l m in ou contre le corps est
inst ble et risque de résulter en une perte de contrôle.
Utilisez un détecteur de métaux afin d’établir s’il y a
des tuyaux d’eau ou à gaz dissimulés dans l’aire de
travail ou appelez la compagnie de service public
locale pour assistance avant de commencer
l’opération. Le f it de fr pper une conduite de g z ou
de couper d ns celle-ci provoquer une explosion.
L’e u pénétr nt d ns un pp reil électrique peut
entr îner une électrocution.
Tenez toujours l’outil fermement à deux mains pour
mieux le maîtriser. Conservez toujours une bonne
assise et un bon équilibre. Ceci vous permettr de
mieux m îtriser l’outil électroport tif d ns des situ tions
in ttendues.
Tenez les mains à l'écart de l'aire de coupe. Ne
tendez pas la main sous la lame de scie ou à
proximité de celle-ci. L proximité de l l me p r
r pport à votre m in peut vous être dissimulée.
N'utilisez pas de lames émoussées ou
endommagées. Les l mes pliées peuvent isément se
fr cturer ou c user un rebond.
Faites extrêmement attention lorsque vous
manipulez des accessoires. Les ccessoires sont
très tr nch nts.
Portez des gants de protection lorsque vous
changez des accessoires de coupe. Les ccessoires
deviennent très ch uds près une utilis tion
prolongée.
Utilisez des gants épais et rembourrés, et limitez la
durée d'exposition en faisant des pauses fréquentes.
Les vibr tions c usées p r l'outil pourr ient être
nuisibles ux m ins et ux br s.
Avant de racler, vérifiez l'ouvrage pour y relever des
clous. Si vous relevez des clous, enlevez-les ou
enfoncez-les bien en dessous de la surface finie
recherchée. Le cont ct du bord de l' ccessoire vec
un clou pourr it f ire s uter l'outil.
Ne poncez pas par voie humide à l'aide de cette
outil. L pénétr tion de liquides d ns le c rter du
moteur constitue un risque de secousses électriques.
Ne travaillez jamais dans un endroit qui est imbibé
de liquide, tel que solvant ou eau, ou humecté tel
qu'un papier peint nouvellement appliqué. Il existe
un d nger de secousses électriques en tr v ill nt
d ns ces conditions vec un outil électrique, et le
Consignes de sécurité pour les outils oscillants
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:56 AM Page 19

-20-
ch uff ge du liquide c usé p r le r cl ge peut f ire
dég ger des v peurs nocives du m téri u.
Portez toujours des lunettes de protection et un
masque anti-poussières pour les applications
poussiéreuses et lors du ponçage au-dessus de la
tête. Des p rticules de ponç ge peuvent être
bsorbées p r vos yeux et inh lées f cilement et
peuvent c user des problèmes de s nté.
Utilisez des précautions spéciales en ponçant le
bois d'oeuvre traité chimiquement par pression, la
peinture pouvant contenir du plomb, ou tout autre
matériau qui peut contenir des agents
cancérigènes. Toutes les personnes pénétr nt d ns l
zone de tr v il doivent porter un respir teur et des
vêtements protecteurs déqu ts. L' ire de tr v il doit
être scellée p r des feuilles en pl stique, et les
personnes non protégées doivent être m intenues à
l'extérieur jusqu'à ce que l' ire de tr v il soit dûment
nettoyée.
N'utilisez pas du papier de verre destiné à des blocs
de ponçage plus gros. Le p pier de verre de
dimensions plus gr ndes fer s illie u-delà du bloc
de ponç ge entr în nt insi des ccrocs, un
déchirement du p pier ou un rebond. Le p pier
supplément ire f is nt s illie u-delà du bloc de
ponç ge peut ég lement c user des l cér tions
gr ves.
Avertissements supplémentaires concernant la sécurité
L’emploi d’un GFCI et de dispositifs de protection
personnelle tels que g nts et ch ussures d’électricien en
c outchouc méliorent votre sécurité personnelle.
N’utilisez pas un outil conçu uniquement pour le C.A.
sur une alimentation en C.C. Même si l’outil semble
fonctionner, les compos nts électriques d’un outil prévu
pour le C.A. tomberont prob blement en p nne et
risquent de créer un d nger pour l’utilis teur.
Maintenez les poignées sèches et exemptes d’huile et
de graisse. On ne p s m îtriser un outil électroport tif
en toute sécurité qu nd on les m ins gliss ntes.
Créez un agenda d’entretien périodique pour votre
outil. Quand vous nettoyez un outil, faites attention de
n’en démonter aucune pièce car il est toujours
possible de mal remonter ou de pincer les fils
internes ou de remonter incorrectement les ressorts
de rappel des capots de protection. Cert ins gents de
nettoy ge tels que l’essence, le tétr chlorure de
c rbone, l’ mmoni que, etc. risquent d’ bîmer les
pl stiques.
Risque de blessure pour l'utilis teur. Le cordon
d' liment tion électrique ne doit être rép ré que p r un
Centre de service usine de Bosch ou p r une St tion
service gréée de Bosch.
Les travaux à la machine
tel que ponçage, sciage,
meulage, perçage et autres travaux du bâtiment
peuvent créer des poussières contenant des produits
chimiques qui sont des causes reconnues de cancer,
de malformation congénitale ou d’autres problèmes
reproductifs. Ces produits chimiques sont, par
exemple :
• Le plomb proven nt des peintures à b se de plomb,
• Les crist ux de silices proven nt des briques et du
ciment et d’ utres produits de m çonnerie, et
• L’ rsenic et le chrome proven nt des bois tr ités
chimiquement.
Le nive u de risque dû à cette exposition v rie vec l
fréquence de ces types de tr v ux. Pour réduire
l’exposition à ces produits chimiques, il f ut tr v iller
d ns un lieu bien ventilé et porter un équipement de
sécurité pproprié tel que cert ins m sques à poussière
conçus spéci lement pour filtrer les p rticules
microscopiques.
AVERTISSEMENT
!
DM 2610958399 10-10:DM 2610958399 10-10 10/5/10 10:56 AM Page 20
