Bosch Benchmark Series User manual

SERVICE MANUAL
for
Benchmark Series
Induction Slide-in Ranges
HIIP054C, HIIP054U
This manual contains information that is necessary for
servicing the following Bosch induction slide-in ranges:
HIIP054C, HIIP054U
This manual is designed to be used by qualified service
personnel only. Due to the complexity and the risk of
high-voltage electrical shock, Bosch does not recommend
that customers service their own units.
This material is intended for the sole use of BSH
authorized persons and may contain confidential and
proprietary information. Any unauthorized review, use,
copying, disclosure, or distribution in any format is
prohibited.

58300000187895 ARA EN A MAY 2015 Service Manual for Bosch Benchmark Series Induction Slide-in Ranges
Page 2 of 36
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
TABLE OF CONTENTS
1Symbols Used In This Manual..................................................3
2Important Safety Information....................................................4
2.1 Safety before Servicing the Appliance..................................4
3General.......................................................................................6
3.1 Models .................................................................................6
3.2 Data Plate ............................................................................6
3.3 Technical Details..................................................................7
3.4 Warranty...............................................................................7
4Oven Operation .........................................................................8
4.1 Allowable Operating Range by Cooking Mode......................8
4.2 Heating Elements.................................................................8
4.2.1 Elements Used by Cooking Mode .................................8
4.2.2 Element Duty Cycles.....................................................9
4.2.3 Setting Temperature Offsets..........................................9
4.3 Cooling Fan........................................................................10
5Cooktop Operation..................................................................11
5.1 Element Ratings.................................................................11
5.2 Additional Information.........................................................11
6Warming Drawer Operation ....................................................12
7Service and Repair: Oven.......................................................13
7.1 Doors .................................................................................13
7.1.1 Addition of Flat Springs to Door Assembly...................13
7.1.2 Removing and Reinstalling the Door ...........................13
7.1.3 Replacing Hinges........................................................14
7.1.4 Replacing the 2-Pane Glass Pack...............................15
7.2 Door Latch/Motor Assembly ...............................................16
7.2.1 Replacing the Latch/Motor Assembly ..........................17
7.3 Oven High Temperature Cutout (HTC)...............................17
7.3.1 Resetting and Replacing the HTC...............................18
7.4 Control Panel......................................................................18
7.4.1 Replacing the Control Panel Assembly........................19
7.4.2 Replacing the Display Module.....................................19
7.5 Cavity Lights.......................................................................20
7.5.1 Replacing a Lamp .......................................................20
7.6 Convection Fan, Ring Element and Motor..........................20
7.6.1 Replacing the Convection Fan Blade ..........................21
7.6.2 Replacing the Ring Element........................................21
7.6.3 Replacing the Convection Fan Motor ..........................21
7.7 Broil Element......................................................................22
7.7.1 Replacing the Broil Element........................................22
7.8 Bake Element.....................................................................22
7.8.1 Replacing the Bake Element.......................................22
7.9 Temperature Sensor ..........................................................23
7.10 Control Module (Relay Board)............................................23
7.10.1 Replacing the Control Module .....................................23
7.11 Cooling Fan........................................................................24
7.11.1 Replacing the Cooling Fan..........................................24
7.12 Hinge Receivers.................................................................25
7.12.1 Replacing the Hinge Receivers ...................................25
8Service and Repair: Cooktop..................................................26
8.1 Replacing the Maintop........................................................26
8.2 Additional Information.........................................................26
9Service and Repair: warming drawer.....................................27
9.1 Removing the Drawer Assembly from Housing ..................27
9.2 Replacing the Drawer Assembly in Housing.......................27
9.3 Replacing the Element.......................................................27
9.4 Repairing a Drawer that Binds............................................28
10 Troubleshooting......................................................................29
10.1 Error Codes........................................................................29
10.2 Service Mode.....................................................................34
10.2.1 Accessing Service Mode.............................................34
10.2.2 Setting the Option Code..............................................34
10.2.3 Displaying Error Memory.............................................35
10.2.4 Testing Relays ............................................................35
10.2.5 Testing Front Panel.....................................................35
10.3 Wiring Diagrams and Schematics.......................................35
11 Additional References.............................................................36
11.1 QuickFinder........................................................................36
11.2 Technical Support ..............................................................36

58300000187895 ARA EN A MAY 2015 Service Manual for Bosch Benchmark Series Induction Slide-in Ranges
Page 3 of 36
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
1 SYMBOLS USED IN THIS MANUAL
WARNING – this symbol alerts you to dangers that may
result in bodily injury or death
CAUTION – this symbol alerts you to actions that may
result in damage to the product or property

NOTICE – this symbol alerts you to important information
and/or service tips.
VIDEO – related service video available for viewing on
QuickFinder
!
!

58300000187895 ARA EN A MAY 2015 Service Manual for Bosch Benchmark Series Induction Slide-in Ranges
Page 4 of 36
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
2 IMPORTANT SAFETY INFORMATION
Before starting to service an appliance, familiarize yourself with all
safety information and precautions included in this manual.
When repairing the cooktop on the range, also review all safety
information included in the Repair Instructions for the induction
cooktop.
2.1 Safety before Servicing the Appliance
WARNING
Electrical hazards…
Before servicing the appliance, remove electrical power by
either disconnecting the power cord from the wall receptacle
or by putting the circuit breaker in the OFF position.
If tests must be conducted while the appliance is live, always
use a residual-current-operated circuit breaker. The
protective conductor connection must not exceed the
recommended values.
When repairs are complete, perform a function test in
accordance with the appropriate regulations.
Do not, under any circumstances, cut or remove the separate
ground wire or the third (ground) prong from the power cord
plug.
Improper grounding or reverse polarization will cause
malfunction, which can damage the appliance and create an
electrical shock hazard. Make sure the circuit is properly
grounded and polarized in accordance with applicable local
codes and ordinances. Receptacle replacement shall be in
accordance with the National Electric Code.
!
WARNING
Before disassembly, removal, or installation of any
component…
Turn off all burners and electrical power by removing the
power cord from the electrical outlet or putting the circuit
breaker in the OFF position.
Be sure the entire appliance has cooled to a safe
temperature.
Wear protective gear: gloves, long sleeves, safety glasses.
!
WARNING
Use of replacement parts…
Use only authorized replacement parts for this appliance. Use of
unauthorized substitutions may cause non-compliance with safety
standards set for home appliances, will void the warranty, and may
create safety hazards resulting in damage, bodily injury or death.
!
WARNING
Hot surfaces…
To avoid burns and injury, do not handle components and surfaces
that are hot, such as the cooktop burner assemblies, maintop, gas
burners, electric elements, hot surface igniters, heat deflector, interior
oven surfaces or the exterior area immediately surrounding the door.
!

58300000187895 ARA EN A MAY 2015 Service Manual for Bosch Benchmark Series Induction Slide-in Ranges
Page 5 of 36
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
WARNING
Sharp components…
This appliance has sheet metal parts and components which may
have sharp edges. Avoid injury by handling parts with care and using
adequate protective measures, such as wearing gloves.
!
WARNING
Clean-up hazards…
Do not allow any cleaning or polishing solutions/compounds,
disinfectants, or bleaches to remain in contact with the stainless steel
surfaces for long periods, or after clean-up. These may contain
chemicals or materials which could release harmful inhalants and
may cause damage to the appliance. After cleaning or polishing,
always rinse the cleaning/polishing materials with clear water and
wipe dry with a clean, soft, non-abrasive cloth.
!
WARNING
What to do if you smell gas…
Do not try to light any appliance.
Do not touch any electrical switch.
Do not use any phone or cell phone in the building.
Immediately call the gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
If you cannot reach your gas supplier, call the fire
department.
!
WARNING
Fire / Explosion hazards…
Do not store or use flammable vapors, liquids or combustible
materials in the vicinity of the appliance.
Do not use water on grease fires. Turn appliance off and
smother the fire with baking soda or use a dry chemical or
foam-type extinguisher.
!
WARNING
Prior to returning appliance to service, confirm that…
All electrical connections are correct and secure
All safety grounds (internal and external) are correctly and
securely connected
All panels and components are properly and securely
reassembled
!

58300000187895 ARA EN A MAY 2015 Service Manual for Bosch Benchmark Series Induction Slide-in Ranges
Page 6 of 36
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Figure 2Location of data plate
Figure 1Model number nomenclature
H IIP05 4U
FUEL
HD = dual-fuel
HG = gas
HE = electric
HI = induction
T
YPE
I = slide-in
S
ERIES
8 = 800
P =Benchmark
W
IDTH
0=30”
C
OLOR
5 = SS
V
ARIANT
4 = 2014 launch
COUNTRY
U = US
C = Canada
UC = US & Canada
3 GENERAL
The US (HIIP054U) and Canadian (HIIP054C) stainless induction
ranges are full-depth models, designed to replace either a free-
standing or slide-in range in a flush installation. The Benchmark series
models have a glass ceramic cooking surface and 4 induction
elements. The ovens feature European convection and there is a
400W warming drawer with push-to-open (PTO) slides as well.
The ranges feature VFD red and white displays with touch controls for
operation of the electric oven and touch controls on the surface of the
cooktop to control the induction elements. The doors are
QuietClose™ for smooth and quiet operation.
The door skin and warming drawer front are made of grade 430
brushed stainless steel, which is magnetic.
3.1 Models
The model number structure for the 2014 slide-in ranges appears
below.
3.2 Data Plate
The data plate reflecting model number and FD number is located on
the inside of the warming drawer front, as shown in Figure 2; open the
drawer to view.
The first 4 positions of the FD number reflect the year/month the
product was built. FD numbers that begin with 94 were built in 2014;
95 = 2015; 96 = 2016, etc. An FD of 9404 indicates the range was
built in April 2014.
NOTICE
Be prepared to provide the complete Model Number (including the
number after the “/”) and FD number printed on the data tag of the
unit when contacting Bosch Customer Support or Technical Support
for assistance.

58300000187895 ARA EN A MAY 2015 Service Manual for Bosch Benchmark Series Induction Slide-in Ranges
Page 7 of 36
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
3.3 Technical Details
Wattage 240V
13,800W
Wattage 208V
11,400W
Volts
120/208VAC or 120/240VAC; 60Hz
Circuit
40A or 50A (check local code)
*Power Cord
4-prong, 50A, 55”/142cm long
*
Power cord factory installed on Canadian ranges only. For US models, use
power cord set marked “For Use with Ranges” with 120/240V 40 amp minimum
rating.
3.4 Warranty
The product is warranted to be free from defects in materials and
workmanship for a period of 365 days from date of purchase.
Bosch will have no responsibility or liability for repairs or work
performed by a non-authorized servicer.
Find the complete Statement of Limited Product Warranty in the
product’s Use and Care Manual.
Table 1Electrical specifications

58300000187895 ARA EN A MAY 2015 Service Manual for Bosch Benchmark Series Induction Slide-in Ranges
Page 8 of 36
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
4 OVEN OPERATION
This section includes basic information about how the Benchmark
Series slide-in range ovens operate.
4.1 Allowable Operating Range by Cooking Mode
Table 2 reflects the minimum and maximum temperatures by cooking
mode.
Cooking Mode
Min
Max
Default
Bake 100°F 550°F 350°F
Broil Low
450°F
High
550°F
High
Roast 100°F 550°F 325°F
Warm
140°F
225°F
170°F
Sabbath 100°F 425°F N/A
Self-Cleaning 2
hours
4 hours 3 hours
Proof 85°F 125°F 100°F
Convection Bake
100°F
550°F
325°F
Convection Broil Low
450°F
High
550°F High
Convection Roast
100°F
550°F
325°F
Pizza 100°F 550°F 400°F
Convection
Multi-Rack
100°F 550°F 325°F
4.2 Heating Elements
All ovens include an 8-pass 3800W broil element, 4-pass 2400W bake
element and 2000W ring element. The warming drawer has a 400W
element.
When the oven door is opened, all heating elements and the
convection fan will pause. When the door is closed, cycling will
continue.
4.2.1 Elements Used by Cooking Mode
The table below reflects the elements which are used for each
cooking mode.
Cooking Mode Elements Used Description
Bake
Broil, Bake
Upper and lower elements cycle to
maintain oven temperature
Broil
Broil
Intense heat is radiated from the upper
element
Roast
Broil, Bake
Upper and lower elements cycle to
maintain oven temperature; more intense
heat from the upper element is used than
the lower.
Warm
Broil, Bake
Upper and lower elements cycle to
maintain a low oven temperature
Proof
Bake
Lower element is used to maintain a low
temperature
Self-clean
Broil, Bake
Upper and lower elements cycle to
maintain oven temperature; more intense
heat from the upper element is used than
the lower.
Convection Bake
Broil, Bake,
Conv Fan
Upper and lower elements cycle to
maintain oven temperature, and the heat
is circulated by the convection fan
Convection Broil
Broil, Conv Fan
Intense heat is radiated from the upper
element and the convection fan circulates
the air
Table 2Allowable temperature range by cooking mode

58300000187895 ARA EN A MAY 2015 Service Manual for Bosch Benchmark Series Induction Slide-in Ranges
Page 9 of 36
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
Table 5Element duty cycles during Fast Preheat
Cooking Mode Elements Used Description
Convection Roast
Broil, Bake,
Conv Fan
Upper and lower elements cycle to
maintain oven temperature and air is
circulated by the convection fan; more
intense heat from the upper element is
used than the lower.
Convection
Multi-rack
Conv Element,
Conv Fan
Heat is generated by the convection ring
element and circulated by the convection
fan.
Pizza
Broil, Bake,
Conv Fan
Upper and lower elements cycle to
maintain oven temperature, and the heat
is circulated by the convection fan
4.2.2 Element Duty Cycles
The Preheat, Fast Preheat and Regulate tables that follow reflect the
element cycling times for the oven cavities in induction ranges. A two-
point control is used for all cooking modes.
4.2.3 Setting Temperature Offsets
In some cases, it may be necessary to adjust the oven temperature if
the customer reports that food is consistently under- or over-cooked,
even though the oven is operating normally. Temperature Offsets can
Table 3Active elements by cooking mode
Table 4Element duty cycles during Preheat
Table 6Element duty cycles during Regulate

58300000187895 ARA EN A MAY 2015 Service Manual for Bosch Benchmark Series Induction Slide-in Ranges
Page 10 of 36
Copyright by BSH Home Appliances Corporation 1901 Main St ▪Suite 600 ▪Irvine, CA 92614 800 944-2904
This material is intended for the sole use of BSH authorized persons and may contain confidential and proprietary information. Any unauthorized review, use, copying, disclosure, or distribution in any format is prohibited.
be entered by the customer from the Customer Settings menu to raise
or lower the cavity temperature during operation in modes other than
Broil, Convection Broil, Warm, Pizza or Self-clean.
The allowable Offset range is from 0°F to 35°F, positive or negative.
1. Press Settings to access the Customer Settings menu (from
stand-by mode only)
2. Press 9for Temperature Offset.
3. Press Enter to edit the current setting.
4. Press (-) or (+) then enter the offset value using the numeric
keys - always enter the value as 2 digits (i.e, 05).
The new value is saved when the display changes from edit
mode back to display mode.
5. Press Clear On/Off to exit the Settings menu.
Example: A +25° offset will result in a cavity temperature of 350°
when the cooking temperature is set to 325° for any of the cooking
modes affected by the Offset. Similarly, a -25° offset will result in a
cavity temperature of 300° when the cooking temperature is set to
325°.
The adjusted temperature cannot be less than the minimum allowable
temperature for the cooking mode, nor higher than the maximum for
the cooking mode. See Allowable Operating Range by Cooking Mode
section.
4.3 Cooling Fan
The cooling fan is used to maintain allowable temperatures on internal
components and customer-accessible surfaces.
The cooling fan turns on low speed immediately at the start of a
cooking mode. The fan will continue to run for 15 minutes after the
mode has been cancelled.
During Self-clean, the fan turns on high speed immediately at the start
of the cycle and will continue running for 15 minutes after the door
unlocks (@255°C/491°F).
