Bosch 11239VS - NA SDS-plus 1" Rotary Hammer User manual

ROTARY HAMMER
Model 0611239739
INDUSTRIAL
April 2001 11239VS
S-BPowerToolCompany ChicagoIL60646-5999
73 27
821
81 38 80
40
38
8181
21
83
47
830
85
66 823
23
24
34
44
45
25
37 14
48
15
13
35
819
803
x
826
58
96
55405367
57 56
46
22 78 50
x
73
69
821
95 65
76
60 859
59
61
68
70
87 54
90
2
894
801
cd
d
b
a
105
810
92
816
180
108
91
86
7
103
104
818
4
43 41 20 110
6
c
72
b
101 102
805
86
9
820 86
852
17
86
20
808
89
79
33
832
88
75
849
752
123
122
124
121 720
120
= Pos. 897
898
74

Pos. PartNumber Description{Qty.} F/C Pos. PartNumber Description{Qty.} F/C
85 1 610 913 015 Needle Bearing 56
86 1 603 435 050 Screw {13} 89
87 1 610 209 006 Retainer 89
88 2 910 021 122 Screw {4} 89
89 2 910 141 142 Screw {2} 89
90 2 910 131 154 Screw {4} 89
91 2 912 401 008 Screw 89
92 2 910 611 405 Screw {4} 89
95 1 610 210 075 O-Ring 78
96 1 610 224 006 Retainer 89
101 1 614 449 012 Cable 10
102 1 614 431 028 Cable 10
103 1 614 437 017 Cable 10
104 3 604 460 038 Cable 10
105 1 614 449 013 Cable {2} 10
108 1 611 091 003 Terminal Block 10
110 1 611 110 A41 Label 9
120 1 612 025 050 AuxiliaryHandle 74
121 1 618 040 073 Support 9
122 1 613 450 017 Screw 89
123 1 611 316 018 Clamp 80
124 2 915 051 180 Nut 89
720 2 602 025 112 Auxiliary Handle Assy. 74
w/pos. 121, 122, 123, 124
752 1 613 001 010 Depth Rod 9
801 1 615 108 103 Housing 70
803 1 614 010 706 Armature w/Fan 120V AW
w/pos. 13, 14, 15, 35, 47, 48
805 3 604 460 555 Cord 11
808 1 611 104 999 Nameplate 9
810 1 617 014 139 Brush Set 26
816 1 617 000 397 Brush Holder Assembly 25
w/pos. 810
818 2 603 410 001 Screw {2} 89
819 1 617 000 382 Gear Housing Assembly 72
w/pos. 37, 50, 69
820 1 615 104 018 Cover 70
821 1 618 598 221 Tool Holder Assembly 91
w/pos.21,38,40,46,53-58,
65,67,76,80,81,87,95,96,849
823 1 617 016 009 Gear Assembly 33
w/pos. 23, 24, 66
826 1 618 700 073 Piston Assembly 47
w/pos. 73
830 1 612 210 118 Eccentric Assembly 34
w/pos. 34
832 1 612 026 090 Selector Knob 63
w/pos. 75, 79
849 1 618 598 220 Tool Holder 83
852 1 615 500 310 Brush Cover 64
859 1 610 314 004 Sleeve Assembly 77
w/pos. 59, 61, 68, 70
894 2 603 435 015 Screw {2} 89
897 1 617 000 383 Service Pack 78
w/pos. 59, 61, 65, 68, 69,
70, 72, 73, 75, 76, 95
898 1 615 437 503 Oil w/pos. 74 1
11239VS ROTARY HAMMER
2 1 614 220 148 Field 120V 22
4 2 607 200 513 Switch VS w/pos. 818 17
6 2 600 703 018 Strain Relief 11
7 1 611 035 005 Cord Clamp 89
9 1 611 110 A40 Label 9
13 2 600 905 072 Ball Bearing 60
14 1 610 905 026 Ball Bearing 61
15 1 616 610 088 Fan 23
17 1 615 132 075 Grip 74
20 1 615 104 016 Housing 71
21 1 615 806 047 Tube 43
22 1 616 333 038 Gear 32
23 1 616 333 039 Gear 33
24 1 616 312 001 Gear 31
25 1 616 317 061 Gear 34
27 1 610 311 016 Striker 44
33 1 615 808 082 Gear Housing Cover 70
34 2 916 080 910 Circlip 89
35 1 600 502 023 Rubber Bearing Sleeve 82
37 1 613 123 004 Shaft 54
38 1 610 202 018 Washer {2} 65
40 1 903 230 013 Ball 7mm {7} 66
41 3 604 618 008 Spring 27
43 1 610 390 043 Bushing 82
44 1 611 329 019 Fork 62
45 1 614 611 016 Spring {2} 27
46 1 610 290 071 Seal Ring 85
47 1 610 250 010 Bushing 82
48 1 611 329 020 Plate 62
50 1 610 290 059 Washer 65
53 1 610 422 012 Thrust Ring 65
54 1 610 508 039 Cap 92
55 1 610 190 040 Plate 62
56 1 610 499 042 Sleeve 82
57 1 610 516 015 Bushing 82
58 1 614 615 004 Spring 27
59 1 610 314 003 Sleeve 82
60 1 615 190 087 Bearing 82
61 1 610 210 156 O-Ring 78
65 1 610 210 164 O-Ring 78
66 1 610 100 612 Washer 65
67 1 614 601 032 Retainer 89
68 1 610 205 008 Felt Washer 77
69 1 610 283 031 Seal 77
70 1 610 283 032 Seal 77
72 1 610 210 157 O-Ring 78
73 1 610 210 121 O-Ring {2} 42
74 1 611 014 002 Gasket 79
75 1 610 210 155 O-Ring 78
76 1 610 415 000 Seal 77
* 78 1 610 102 051 Shim 0.3mm 65
* 78.1 1 610 102 052 Shim 0.4mm 65
* 78.2 1 610 102 053 Shim 0.5mm 65
79 1 928 491 082 Screw 89
80 1 614 615 003 Spring 27
81 1 614 601 033 Retainer {3} 89
83 1 614 601 036 Retainer 89
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
