Video | FLEXIDOME AN micro 1000
FLEXIDOME AN micro 1000
www.boschsecurity.com
This microdome camera is a ready-to-use, analog
video surveillance camera for indoor use. The high
performance 960H 1/4‑inch CCD sensor provides a
resolution of 720TVL. The camera is an ideal solu-
tion for demanding scene conditions. The flexible,
compact design allows the camera to be used in a
variety of applications. The camera is easy to in-
stall and has a handy menu system where func-
tions such as privacy and motion detection zones
can be set.
Features
uUltra high resolution 960H sensor
uDiscreet microdome housing
uEasy installation
uDigital noise reduction
uEight programmable privacy zones
960H

Technical specifications
Technical specifications
Image Sensor 960H, 1/4" CCD, sensor resolution 720TVL
System PAL or NTSC
Total pixels (H x V) 1020 x 596 (PAL)
1020 x 508 (NTSC)
Effective pixels (H x V) 976 x 582 (PAL)
976 x 494 (NTSC)
Video Output Composite: 1 Vpp, 75 Ohm
Sync. System Internal sync.
S/N Ratio (sharpness,
AGC off)
55 dB min.
Sensitivity (6500K,
F2.8, 30IRE)
0.43 lx
Manual shutter 1/50 – 1/10,000 (PAL)
1/60 – 1/10,000 (NTSC)
Digital Noise Reduction 2DNR
White Balance ATW (1800 – 10500K), Push, User1, User2, Anti
CR, Manual, Push lock
Light compensation OFF/BLC/HLC
Dynamic Range On, Off
AGC On, Off
Electronic Day/Night Auto, Color, B/W
Motion detection On, Off (4 programmable zones)
Privacy On, Off (8 programmable zones, 4 with motion area
on)
Mirror On (horizontal), Off
OSD language English, Japanese, German, French, Russian, Portu-
guese, Spanish, Simplified Chinese
Lens type Fixed board lens 2.5 mm, F2.8
Lens view angle 85° (H), 64° (V)
Lens adjustment (2-ax-
es)
60° tilt, 360° pan
Weight 125 g (0.28 lb)
Dimensions (ØxH) 105 mm x 56 mm
Supply Voltage 12 VDC
Power consumption 1.2 W max. / 0.1 A
Operating Temperature -20 °C to +45 °C
(-4 ºF to +113 ºF)
Operating Humidity 20% to 90% RH
Storage Temperature -20 °C to +70 °C
(-4 ºF to +158 ºF)
Storage Humidity 20% to 90% RH
Certifications and approvals
Standards
FCC Part 15 subpart B, Class B
UL 60950-1, 2nd Edition
CAN/CSA-C22.2 No. 60950-1-07, 2nd Edition
EN 55022, Class B
EN 50130-4
LVD 2006/95/EC
EN 60950-1
IEC 60950-1
Ordering information
FLEXIDOME AN micro 1000 VUC-1055-F211
FLEXIDOME AN micro 1000 VUC-1055-F221
