Bosch Onvif NTC-255-PI User manual

Video | Day/Night Infrared IP Bullet Camera
Day/Night Infrared IP Bullet Camera
www.boschsecurity.com
The Bosch NTC-255-PI infrared IP bullet camera is
a ready-to-use, robust network camera. This cam-
era brings Bosch’s high-performance technology
into the realm of small office and retail businesses
by offering a cost-effective solution for a broad
range of applications.
The robust aluminum camera body is designed for
outdoor surveillance or indoor areas where water
ingress might occur. The built-in active infrared il-
luminator ensures effective vision under extreme
low-light conditions.
The H.264 compression technology gives clear im-
ages while reducing bandwidth and storage by up
to 30%.
Features
uHigh performance active infrared illumination
uSharp images of moving objects
uDual H.264 and M-JPEG streams simultaneously
uOutdoor IP66-rated robust design
uEasy connection

Technical specifications
Power
Input voltage +12 VDC or
Power-over-Ethernet
Power consumption 6.0 W (max)
Video
Sensor type ¼-inch CMOS
Sensor pixels 640 x 480
Sensitivity 1.0 lx (IR off)
0 lx (IR on)
Video resolution VGA, QVGA
Video compression H.264 MP (Main Profile); H.264 BP+ (Baseline Pro-
file Plus); M-JPEG
Max. frame rate 30 fps
Night vision
Distance 25 m (82 ft)
LED 32 LED high efficiency array, 850 nm
Lens
Lens type Varifocal 3.7 to 10 mm, DC Iris F1.4 to close, D/N
switch
Lens mount Board mounted
Connection
Analog video out 2.5 mm jack for installation only
Alarm input Short or DC 5V activation
Relay out Input rating Maximum 1 A 24 VAC/VDC
Audio
Audio input Line in jack connector
Audio output Line out jack connector
Audio communication Two-way, full duplex
Audio compression G.711, L16 (live and recording)
Software Control
Unit configuration Via web browser or PC surveillance software
Network
Protocols HTTP, HTTPs, SSL, TCP, UDP, ICMP, RTSP, RTP, Tel-
net, IGMPv2/v3, SMTP, SNTP, FTP, DHCP client,
ARP, DNS, DDNS, NTP, SNMP, UPnP, 802.1x, iSCSI
Ethernet 10/100 Base-T, auto-sensing, half/full duplex, RJ45
PoE IEEE 802.3af compliant
Mechanical
Dimensions (H x W x D) 100 x 100 x 291 mm
(3.94 x 3.94 x 11.46 in)
Weight 1.55 kg (3.42 lb) approx.
Environmental
Operating temperature
Camera -20 ºC to +55 ºC (-4 ºF to +131 ºF)
Storage temperature -20 ºC to +70 ºC (-4 ºF to +158 ºF)
Humidity 10% to 80% relative humidity (non condensing)
Certifications and approvals
Region Certification
Europe CE
Standards
EN 60950-1
UL 60950-1
UL 60950-22
CAN/CSA-C22.2 NO. 60950-1
CAN/CSA-C22.2 N0. 60950-22
EN 50130-4:1995 + A1:1998 + A2:2003
FCC Part15 Subpart B, Class B
EMC directive 2004/108/EC
EN 55022 class B
EN 61000-3-2 :2006
EN 61000-3-3 : 1995+A1 :2001+A2 :2005
EN 55024
VCCI J55022 V2 / V3
AS/NZS CISPR 22 (equal to CISPR 22)
ICES-003 Class B
EN 50121-4:2006
IEC 60825-1
Product certifications CE, FCC, UL, cUL, C-tick, CB, VCCI
Ingress protection IP66
Ordering information
NTC-255-PI Infrared IP Bullet Camera NTC-255-PI
