AutoDome Easy II IP Table of Contents | en 3
Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03
Table of Contents
1Safety 7
1.1 Important Safety Instructions 7
1.2 Safety Precautions 10
1.3 Important Notices 10
1.4 Customer Support and Service 17
2 Unpacking 18
2.1 Parts List 18
2.2 Safety Rules 19
3 Description 20
4 Installing a Surface Mount 22
4.1 Description 22
4.1.1 Additional Tools Required 23
4.1.2 Preparing the Surface Mount for an Indoor Installation 23
4.1.3 Preparing the Surface Mount for an Outdoor Installation 25
4.1.4 Installing the Camera to the Mounting Plate 29
5 Installing a Wall Mount 33
5.1 Description 33
5.1.1 Additional Tools Required 34
5.1.2 Preparing the Wall Mount for an Indoor Installation 34
5.1.3 Preparing the Wall Mount for an Outdoor Installation 36
5.1.4 Installing the Camera to the Mounting Plate 40
6 Installing a Recessed Mount 44
6.1 Description 44
6.1.1 Additional Requirements 44
6.1.2 Preparing the Ceiling for Installation 45
6.1.3 Installing the Camera to the Mounting Plate 48

4en | Table of Contents AutoDome Easy II IP
F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
7 Installing a Pipe Mount 52
7.1 Description 52
7.1.1 Tools/Supplies Required 53
7.1.2 Preparing the Ceiling for Installation 53
7.1.3 Installing the Camera to the Mounting Plate 60
8 Preparing the Wiring 63
8.1 Power 63
8.2 Connecting the Power 64
8.2.1 Power Connections to Indoor Cameras 65
8.2.2 Power Connections to Outdoor Cameras 66
8.2.3 Power Connections to Heater (all outdoor models) 67
8.3 Ethernet Connection (IP models) 67
9 Alarms and Relay Connections 69
9.1 Alarm Input 69
9.2 Connecting Alarms (inputs 1 through 2) 70
9.2.1 Connecting a Normally Open Alarm 70
9.2.2 Connecting a Normally Closed Alarm 71
9.3 Alarm Outputs 72
9.3.1 Connecting an Open Collector Output 72
10 Getting Started 73
10.1 Powering On 73
11 Using the AutoDome Easy II IP 74
11.1 Overview of Features 75
11.2 System Requirements 76
11.3 Connecting the AutoDome Easy II IP to the PC 77
11.4 Configuring the AutoDome Easy II IP Camera 78
11.5 The LIVEPAGE 79
11.5.1 Entering a Keyboard Control Command 82
11.6 Saving Snapshots 85
11.7 Recording Video Sequences 85

AutoDome Easy II IP Table of Contents | en 5
Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03
12 Configuring the AutoDome Easy II IP 86
12.1 Basic Mode: Device Access 87
12.2 Basic Mode: Date/Time 88
12.3 Basic Mode: Network 89
12.4 Basic Mode: Encoder Profile 90
12.5 Basic Mode: Recording 91
12.6 Basic Mode: System Overview 91
13 On-Screen Display Menu Navigation 92
13.1 Setup Menu 92
13.2 Camera Setup Menu 94
13.3 Lens Setup 97
13.4 PTZ Setup Menu 99
13.5 Display Setup Menu 102
13.5.1 Specifying a Shot or a Sector Title 105
13.6 Communication Setup Menu 106
13.7 Alarm I/O Setup 108
13.8 Alarm I/O Rule Setup Menu 111
13.9 Language Menu 114
13.10 Diagnostics Menu 115
14 Common User Commands (unlocked) 118
14.1 Setting AutoPan Mode 118
14.2 Setting Preset Shots 119
14.3 Configuring Preposition Tours 119
14.4 Programming the Inactivity Operation 120
14.5 Recorded Tours 120

6en | Table of Contents AutoDome Easy II IP
F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
15 Keyboard Commands by Number 122
16 Preventive Maintenance 127
17 Troubleshooting 128
17.1 AutoDome Easy II IP Operation and Control 129
18 BVIP Firmware Updates 132
18.1 Upgrading the AutoDome Easy II IP 132
18.2 Beginning the Firmware Update Process 132
Index 134

AutoDome Easy II IP Safety | en 7
Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03
1Safety
1.1 Important Safety Instructions
Read, follow, and retain for future reference all of the following
safety instructions. Heed all warnings on the unit and in the
operating instructions before operating the unit.
1. Cleaning - Unplug the unit from the outlet before cleaning.
Follow any instructions provided with the unit. It is
generally sufficient to use a dry cloth for cleaning, but a
moist lint-free cloth or leather shammy may also be used.
Do not use liquid cleaners or aerosol cleaners.
2. Heat sources - Do not install the unit near any heat
sources such as radiators, heaters, stoves, or other devices
(including amplifiers) that produce heat.
3. Ventilation - Any openings in the unit housing are provided
for ventilation to prevent overheating and ensure reliable
operation. Do not block or cover these openings. Do not
place the unit in an enclosure unless proper ventilation is
provided, or the manufacturer's instructions have been
adhered to.
4. Water - Do not use this unit near water, for example near a
bathtub, washbowl, sink, laundry basket, in a damp or wet
basement, near a swimming pool, or in any area classified
as a wet location. To reduce the risk of fire or electrical
shock, do not expose this unit to rain or moisture.
5. Object and liquid entry - Never push objects of any kind
into this unit through openings, as they may touch
dangerous voltage points or short out parts, which could
result in a fire or electrical shock. Never spill liquid of any
kind on the unit. Do not place objects filled with liquids,
such as vases or cups, on the unit.
6. Lightning - For added protection during a lightning storm,
or when leaving this unit unattended and unused for long
periods, unplug the unit from the wall outlet and
disconnect the cable system. This will prevent damage to
the unit from lightning and power line surges.

8en | Safety AutoDome Easy II IP
F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
7. Control adjustment - Adjust only those controls specified
in the operating instructions. Improper adjustment of
other controls may cause damage to the unit. Use of
controls or adjustments, or performance of procedures
other than those specified, may result in hazardous
radiation exposure.
8. Overloading - Do not overload outlets and extension cords.
This can cause fire or electrical shock.
9. Power disconnect - Units with or without ON/OFF
switches have power supplied whenever the power cord is
inserted into the power source; however, the unit is
operational only when the ON/OFF switch is in the ON
position. The power cord is the main power disconnect
device for switching off the voltage for all units.
10. Power sources - Operate the unit only via the type of
power source indicated on the label. Before proceeding,
be sure to disconnect the power from the cable being
connected to the unit.
– For battery powered units, refer to the operating
instructions.
– For units supplied by an external power source, use
only the recommended or approved power supplies.
– For limited power source units, this power source
must comply with EN60950. Substitutions may
damage the unit or cause fire or shock.
– For 24 VAC units, voltage applied to the unit's power
input should not exceed +/- 10% or 21.6-26.4 VAC.
User-supplied wiring must comply with local electrical
codes (Class 2 power levels). Do not ground the
supply at the terminals or at the unit's power supply
terminals.
– If unsure of the type of power supply to use, contact
your dealer or local power company.
11. Servicing - Do not attempt to service this unit yourself.
Opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.

AutoDome Easy II IP Safety | en 9
Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03
12. Damage requiring service - Unplug the unit from the main
AC power source and refer servicing to qualified service
personnel when any damage to the equipment has
occurred, for example if:
– the power supply cord or plug is damaged
– exposure to moisture, water, and/or inclement
weather (rain, snow etc.)
– liquid has been spilled in or on the equipment
– an object has fallen into the unit
– the unit has been dropped or the unit cabinet is
damaged
– the unit exhibits a distinct change in performance
– the unit does not operate normally when the user
correctly follows the operating instructions.
13. Replacement parts - Be sure the service technician uses
replacement parts specified by the manufacturer, or that
they have the same characteristics as the original parts.
Unauthorized substitutions may cause fire, electrical
shock, or other hazards.
14. Safety check - Safety checks should be performed on
completion of service or repairs to the unit, to ensure that
the unit is in proper operating condition.
15. Installation - Install in accordance with the manufacturer's
instructions and in accordance with applicable local codes.
16. Attachments, changes, or modifications - Only use
attachments/accessories specified by the manufacturer.
Any change to or modification of the equipment not
expressly approved by Bosch could void the warranty or, in
the case of an authorization agreement, authority to
operate the equipment.

10 en | Safety AutoDome Easy II IP
F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
1.2 Safety Precautions
1.3 Important Notices
Accessories - Do not place this unit on an unstable stand,
tripod, bracket, or mount. The unit may fall, causing serious
injury to persons and/or severe damage to the unit. Use only
with the cart, stand, tripod, bracket, or table specified by the
manufacturer. When a cart is used, exercise caution and care
when moving the cart/apparatus combination to avoid tipping it
over, which could result in injury. Quick stops, excessive force,
or uneven surfaces may cause the cart/unit combination to
overturn. Mount the unit in line with the manufacturer's
instructions.
All-pole power switch - Incorporate an all-pole power switch,
with a contact separation of at least 3 mm in each pole, into the
electrical installation of the building. If it is needed to open the
housing for servicing and/or other activities, use this all-pole
DANGER!
This symbol indicates an imminently hazardous situation such
as “Dangerous Voltage” inside the product. If not avoided, this
will result in an electrical shock, serious bodily injury, or death.
WARNING!
Indicates a potentially hazardous situation. If not avoided, this
may result in minor or moderate injury. Alerts the user to
important instructions accompanying the unit.
CAUTION!
Indicates a potentially hazardous situation. If not avoided, this
may result in damage to property or risk of damage to the unit.
NOTICE!
This symbol indicates information or a company policy that
relates directly or indirectly to the safety of personnel or
protection of property.

AutoDome Easy II IP Safety | en 11
Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03
switch as the main disconnect device for switching off the
voltage to the unit.
Camera grounding - When mounting the camera in potentially
damp environments, ensure the system is grounded through
the metal housing of the unit (see section: Connecting the
Power).
Camera signal - Protect the cable with a primary protector if
the camera signal is over 140 feet, in accordance with NEC800
(CEC Section 60).
Coax grounding:
– Ground the cable system if connecting an outside cable
system to the unit.
– Connect outdoor equipment to the unit's inputs only after
this unit has had its grounding plug connected to a
grounded outlet or its ground terminal is properly
connected to a ground source.
– Disconnect the unit's input connectors from outdoor
equipment before disconnecting the grounding plug or
grounding terminal.
– Follow proper safety precautions, such as grounding, for
any outdoor device connected to this unit.
U.S.A. models only - Section 810 of the National Electrical Code,
ANSI/NFPA No. 70, provides information regarding proper
grounding of the mount and supporting structure, grounding of
the coax to a discharge unit, size of grounding conductors,
location of discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.
Your Bosch product was developed and manufactured with
high-quality material and components that can be recycled and
reused. This symbol means that electronic and electrical
appliances that have reached the end of their service life must
be collected and disposed of separately from household waste
material. Separate collecting systems are usually in place for
disused electronic and electrical products. Please dispose of
these units at an environmentally compatible recycling facility,
in line with European Directive 2002/96/EC.

12 en | Safety AutoDome Easy II IP
F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
Environmental statement - Bosch has a strong commitment to
the environment. This unit has been designed to respect the
environment as much as possible.
Electrostatic-sensitive device - Take proper CMOS/MOS-FET
handling precautions to avoid electrostatic discharge.
NOTE: You must wear grounded wrist straps and observe
proper ESD safety precautions when handling the electrostatic-
sensitive printed circuit boards.
Fuse rating - For security protection of the device, the branch
circuit protection must be secured with a maximum fuse rating
of 16 A. This must be in accordance with NEC800 (CEC Section
60).
Grounding and polarization - This unit may be fitted with a
polarized alternating current line plug (a plug with one blade
wider than the other blade). This safety feature allows the plug
to fit into the power outlet in only one way. If unable to insert
the plug fully into the outlet, contact a locally certified
electrician to replace the obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
Alternatively, this unit may be fitted with a 3-pole grounding
plug (a plug with a third pin for earth grounding). This safety
feature allows the plug to fit into a grounded power outlet only.
If unable to insert the plug into the outlet, contact a locally
certified electrician to replace the obsolete outlet. Do not
defeat the safety purpose of the grounding plug.
Outdoor signals - The installation for outdoor signals, especially
regarding clearance from power and lightning conductors and
transient protection, must be in accordance with NEC725 and
NEC800 (CEC Rule 16-224 and CEC Section 60).
Moving - Disconnect the power before moving the unit. Move
the unit with care.
PoE (Indoor models only) - Never supply power via the
Ethernet connection (PoE) when power is already supplied via
the power connector nor to an outdoor model.

AutoDome Easy II IP Safety | en 13
Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03
Permanently connected equipment - Incorporate a readily
accessible disconnect device in the building installation wiring.
Pluggable equipment - Install the socket outlet near the
equipment so it is easily accessible.
Power disconnect - Units have power supplied whenever the
power cord is inserted into the power source. The power cord
is the main power disconnect for all units.
Power lines - Do not locate the camera near overhead power
lines, power circuits, electrical lights, or anywhere where it
might come into contact with power lines, circuits, or lights.
SELV
All the input/output ports are Safety Extra Low Voltage (SELV)
circuits. SELV circuits should only be connected to other SELV
circuits.
Because the ISDN circuits are treated like telephone-network
voltage, avoid connecting the SELV circuit to the Telephone
Network Voltage (TNV) circuits.
Video loss - Video loss is inherent to digital video recording;
therefore, Bosch Security Systems cannot be held liable for any
damage that results from missing video information. To
minimize the risk of lost digital information, Bosch Security
Systems recommends multiple, redundant recording systems,
and a procedure to back up all analog and digital information.
NOTICE! This is a class A product. In a domestic environment
this product may cause radio interference, in which case the
user may be required to take adequate measures.

14 en | Safety AutoDome Easy II IP
F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
FCC & ICES INFORMATION
(U.S.A. and Canadian Models Only)
This device complies with part 15 of the FCC Rules. Operation is
subject to the following conditions:
– this device may not cause harmful interference, and
– this device must accept any interference received,
including interference that may cause undesired operation.
Note
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules and ICES-003 of Industry Canada. These limits are
designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and radiates
radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct
the interference at his expense.
Intentional or unintentional modifications not expressly
approved by the party responsible for compliance shall not be
made. Any such modifications could void the user's authority to
operate the equipment. If necessary, the user should consult
the dealer or an experienced radio/television technician for
corrective action.
The user may find the following booklet, prepared by the
Federal Communications Commission, helpful: How to Identify
and Resolve Radio-TV Interference Problems. This booklet is
available from the U.S. Government Printing Office,
Washington, DC 20402, Stock No. 004-000-00345-4.

AutoDome Easy II IP Safety | en 15
Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03
INFORMATIONS FCC ET ICES
(modèles utilisés aux États-Unis et au Canada uniquement)
Ce produit est conforme aux normes FCC partie 15. La mise en
service est soumises aux deux conditions suivantes:
– cet appareil ne peut pas provoquer d'interférence nuisible
et
– cet appareil doit pouvoir tolérer toutes les interférences
auxquelles il est soumit, y compris les interférences qui
pourraient influer sur son bon fonctionnement.
AVERTISSEMENT: Suite à différents tests, cet appareil s’est
révélé conforme aux exigences imposées aux appareils
numériques de Classe A en vertu de la section 15 du règlement
de la Commission fédérale des communications des États-Unis
(FCC). Ces contraintes sont destinées à fournir une protection
raisonnable contre les interférences nuisibles quand l'appareil
est utilisé dans une installation commerciale. Cette appareil
génère, utilise et émet de l'energie de fréquence radio, et peut,
en cas d'installation ou d'utilisation non conforme aux
instructions, générer des interférences nuisibles aux
communications radio. L’utilisation de ce produit dans une
zone résidentielle peut provoquer des interférences nuisibles.
Le cas échéant, l’utilisateur devra remédier à ces interférences
à ses propres frais.
Au besoin, l’utilisateur consultera son revendeur ou un
technicien qualifié en radio/télévision, qui procédera à une
opération corrective. La brochure suivante, publiée par la
Commission fédérale des communications (FCC), peut s’avérer
utile : « How to Identify and Resolve Radio-TV Interference
Problems » (Comment identifier et résoudre les problèmes
d’interférences de radio et de télévision). Cette brochure est
disponible auprès du U.S. Government Printing Office,
Washington, DC 20402, États-Unis, sous la référence n° 004-
000-00345-4.
AVERTISSEMENT: Ce produit est un appareil de Classe A. Son
utilisation dans une zone résidentielle risque de provoquer des
interférences. Le cas échéant, l’utilisateur devra prendre les
mesures nécessaires pour y remédier.

16 en | Safety AutoDome Easy II IP
F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
Disclaimer
Underwriter Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of
this product. UL has only tested fire, shock and/or casualty
hazards as outlined in UL's Standard(s) for Safety for Information
Technology Equipment, UL/IEC 60950-1. UL Certification does
not cover the performance or reliability of the security or
signaling aspects of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR
CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR
SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT.
Copyright
This user guide is the intellectual property of Bosch Security
Systems, Inc. and is protected by copyright.
All rights reserved.
Trademarks
All hardware and software product names used in this
document are likely to be registered trademarks and must be
treated accordingly.
NOTICE!
This user guide has been compiled with great care and the
information it contains has been thoroughly verified. The text
was complete and correct at the time of printing. The ongoing
development of the products may mean that the content of the
user guide can change without notice. Bosch Security Systems
accepts no liability for damage resulting directly or indirectly
from faults, incompleteness or discrepancies between the user
guide and the product described.

AutoDome Easy II IP Safety | en 17
Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03
1.4 Customer Support and Service
If this unit needs service, contact the nearest Bosch Security
Systems Service Center for authorization to return and shipping
instructions.
Service Centers
USA
Repair Center
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Customer Service
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Technical Support
Telephone: [phone]
Fax: [phone] or 717-735-6560
E-mail: [email protected]
Canada
Telephone: [phone]
Fax: [phone]
Europe, Middle East, Africa Region
Repair Center
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Asia Region
Repair Center
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Warranty and additional information
For additional information and warranty queries, please contact
your Bosch Security Systems representative or visit our website
at www.boschsecurity.com.

18 en | Unpacking AutoDome Easy II IP
F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
2 Unpacking
This equipment should be unpacked and handled with care. If
an item appears to have been damaged in shipment, notify the
shipper immediately. Verify that all the parts listed in
Section 2.1 Parts List are included. If any items are missing,
notify your Bosch Security Systems Sales or Customer Service
Representative.
The original packing carton is the safest container in which to
transport the unit and must be used if returning the unit for
service. Save it for possible future use.
2.1 Parts List
The AutoDome Easy II IP includes the following components:
– One (1) PTZ Dome (Dome camera)
– One (1) accessory kit including
– One (1) 2-wire camera power cable, red and black
wires
– One (1) 2-wire heater power cable, white/red and
white/black wires (outdoor models only)
– One (1) 4-wire alarm in/out cable
– One (1) mounting bracket
– One (1) outdoor installation kit (outdoor models only)
– One (1) user manual

AutoDome Easy II IP Unpacking | en 19
Bosch Security Systems, Inc. Installation Manual F.01U.164.576 | 2.0 | 2010.03
2.2 Safety Rules
To ensure safety, the following warnings are specified:
– The device must be installed and maintained by skilled
technical personnel.
– Connect the device to a power source corresponding to
the indications given on the marking label.
– Use only the attachments/accessories specified by the
manufacturer.
– Unplug the device during lightning storms or when unused
for long periods of time.
– Do not use the device near water (indoor models only).
– Do not use the device in the presence of flammable
substances.
– Do not allow children or unauthorized personnel to use the
device.
– Do not block any ventilation openings.
– Keep this manual for future reference.

20 en | Description AutoDome Easy II IP
F.01U.164.576 | 2.0 | 2010.03 Installation Manual Bosch Security Systems, Inc.
3 Description
The AutoDome Easy II is part of a larger building block for any
surveillance/security system. By using multiple keyboard
controllers and multiple dome cameras, no place is too large for
monitoring. Extensible and flexible architecture facilities
remote control functions for a variety of external switching
devices such as multiplexers and DVRs.
Figure 3.1 System Configuration
1 Alarm Input (sensor) 12 AutoDome Easy II IP
2 Multiplexer 13 Network
3 RS-485 Cable 14 Computer
4 Junction Box 15 Encoder/Decoder
5 AutoDome Easy II
6 AutoDome Easy II
7 AutoDome Easy II
8 RS-485 Cable
9Monitor
10 Keyboard
11 DVR
2
34
1
56 7
8
1010
1111
9
1 2 3
4 5 6
7 8 9
0
Shot
MonProd
Clr
9
1212
1313
1414
1515
