FlexiDomeXF & DN | User Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 2
SAFETY PRECAUTIONS
Important Safeguards
1. Read these instructions.
2. Keep these instructions.
3. Comply with all warnings.
4. Follow all instructions.
5. Do not use this equipment near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other equipment (including amplifiers) that produce heat.
Danger
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product's enclosure
that may be of sufficient magnitude to constitute a risk to persons.
Warning
The exclamation mark within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
Caution
To reduce the risk of electric shock, do not remove cover (or
back). No user-serviceable parts inside. Refer servicing to
qualified service personnel.

FlexiDomeXF & DN | User Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 3
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. Both
the wide blade and the third prong are provided for your safety. If the
supplied plug does not fit into your outlet, consult an electrician for
advice.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
equipment.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this equipment during lightning storms or when unused for
long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required
when the equipment has been damaged in any way, such as when
power supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the equipment, the equipment does not operate
normally, or has been dropped.
14. An all-pole mains switch with a contact separation of at least 3mm in
each pole shall be incorporated in the electrical installation of the
building.
Caution
The Low Voltage power supply unit must comply with EN/UL
60950. The power supply must be a SELV-LPS unit or a SELV -
Class 2 unit (Safety Extra Low Voltage - Limited Power Source).

FlexiDomeXF & DN | User Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 4
FCC Information
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
Note
Any change or modification of the equipment not expressly approved by
Bosch could void the user's authority to operate the equipment. For
additional information or to speak to a representative, please contact the
Bosch Security Systems location nearest to you or visit our web site at
www.boschsecuritysystems.com

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 5
Introduction
The FlexiDomeXF camera is a small, discreet, high-security surveillance
dome containing a high-performance 1/3-inch CCD color camera with
integral varifocal lens. The integrated unit is mounted to an electrical box
or to a wall or ceiling. The sturdy construction and high impact resistant
polycarbon dome protect the camera module from damage.
The camera incorporates 15-bit digital signal processing for outstanding
picture performance under all lighting conditions. The FlexiDomeXF
camera is easy to install and ready to use, and offers the best solution for
demanding scene conditions.
Features include:
• Impact-resistant dome
• Tamper-resistant housing
• Noise elimination, true color reproduction
• Adaptive dynamic range optimization
• Bilinx™ bi-directional coaxial communications
• Enhanced video motion detection
FlexiDomeDN is the Day/Night camera version with mechanically
switching IR filter.

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 6
Type number overview
FlexiDomeXF
FlexiDomeDN
Unpacking
Unpack carefully and handle the equipment with care. The packaging
contains:
• Integrated FlexiDome camera
• Mounting hardware kit
• Special screwdriver for tamper resistant screw
• Lens adjustment cap
• Installation manual
Note
If equipment appears to have been damaged during shipment, repack it in
the original packaging and notify the shipping agent or supplier.
Type number VDC-
485V03-10
VDC-
885V04-10
VDC-
485V03-20
VDC-
485V04-20
Lens Varifocal
3-9.5 mm
F1.0-360
Varifocal
3.7-12 mm
F1.6-360
Varifocal
3-9.5 mm
F1.0-360
Varifocal
3.7-12 mm
F1.6-360
Standard PAL NTSC
Supply voltage 24 Vac, 50Hz or 12 Vdc 24 Vac, 60Hz or 12 Vdc
CCD type 1/3"
Type number VDN
495V03-10
VDN
495V03-20
Lens Varifocal Wide
3-9.5 mm
F1.0-360
Varifocal Wide
3-9.5 mm
F1.0-360
Standard PAL NTSC
Supply voltage 24 Vac, 50Hz or 12 Vdc 24 Vac, 60Hz or 12 Vdc
CCD format 1/3"

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 7
Disassembly
The camera/housing unit consists of the following parts:
To disasemble the unit proceed as follows:
• Using the special screwdriver, loosen the three tamper resistant screws
in the trim ring (the screws remain in place).
• Remove the trim ring with dome by pulling it off of the base.
• Remove the inner liner by pulling it off of the base.
Caution
Installation should only be performed by qualified service
personnel in accordance with the National Electrical Code or
applicable local codes.
Caution
The camera module is a sensitive device and must be handled
carefully. Do not drop when disassembling the unit.
Camera module and
mounting base
Inner liner
Trim ring
Dome

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 8
Mounting the unit
The unit may be mounted in several different ways depending on the type
of surface, whether an electrical box is used and whether the connection is
via the rear or the side (surface mounted).
If the unit is surface mounted, use the separately available raised mounting
base (VDA 455SMB) and mount the unit onto this base.
Tips
• Refer to the dimensions drawing to find the exact position of the screw
holes and the entry hole for the wires.
• Partially screw in two screws for the keyholes and use them to
temporarily hang the camera while the connections are made.
The following figures show the different ways of mounting the unit.
Figure 1 Rear connection - hollow surface
Caution
Installation should only be performed by qualified service
personnel in accordance with the National Electrical Code or
applicable local codes.
Wires
Strong surface
(four pre-drilled
8mm holes)
Three screws
(supplied)
Mounting
base

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 9
Figure 2 Connection to an electrical box (4S)
Figure 3 Surface mounting - side connection
S4 Electrical box
Two screws
(not supplied)
Mounting
base
Wires
Three screws
(M5, supplied)
Surface
mounting box
(VDA-455SMB)
Conduit
Three screws
(supplied with
camera)
Camera unit
and base
Solid surface
(three pre-drilled
8mm holes)

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 10
Figure 4 Surface mounting - rear connection
Surface mounting
When using the surface mounting box:
• With a side connection, remove the cap covering the side entrance.
With a rear connection, leave the cap in place.
• Attach the conduit to the mounting base.
• Release the two clips at the bottom of the watertight connection
compartment to remove it from the mounting base.
• Open the cover of the watertight compartment in the mounting base by
releasing the 5 clips.
• Run the power and video wires through separate rubber grommets into
the watertight compartment.
• Run the cable from the camera into the watertight compartment
through the supplied grommet.
• Make the connection inside the watertight compartment and screw on
the cover to seal it.
Note
In order to ensure a watertight cable entry, use round cables of between 5
and 6 mm (0.2 - 0.24 inches) for power and video connection. Use some
silicon spray on the cable to help slide the grommets onto it.
Cap
Three screws
(M5, supplied)
Surface
mounting box
(VDA-455SMB)
Conduit
Three screws
(supplied with
camera)
Camera unit
and base
Solid surface
(three pre-drilled
8mm holes)
Wires

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 11
Connection in outdoor applications
Safety precautions:
Coax grounding: If an outside cable system is connected to the unit,
ensure that the system is grounded.
U.S.A. models only - Section 810 of the National Electrical Code, ANSI/
NFPA No.70, provides information regarding proper grounding of the
mount and supporting structure, grounding of the coax to a discharge unit,
size of grounding conductors, location of discharge unit, connection to
ground electrodes, and requirements for the grounding electrode.
Power lines: An outdoor system should not be located in the vicinity of
overhead power lines, electrical lights, or power circuits, or where it may
contact such power lines or circuits. When installing an outdoor system,
extreme care should be taken to keep from touching power lines or circuits,
as this contact may be fatal. U.S.A. models only - refer to the National
Electrical Code Article 820 regarding installation of CATV systems.
24 VAC power source: This unit is intended to operate with a limited power
source, this power source must comply with EN60950. When the unit is
intended to operate at 24 VAC, normal input voltage is between 12 VAC and
28 VAC. Voltage applied to the unit's power input should not exceed 28 VAC.
User supplied wiring, from 24 VAC supply to unit, must be in compliance
with electrical codes (Class 2 power levels). Do not ground the 24 VAC supply
at the terminals or at the unit's power supply terminals.
Connection: The unit has
connection terminals on flying
leads. In wet or outdoor
installations make use of the
VDA-455SMB accessory or use a
field wiring box with Nema3 or
IP55 protection level or better.
Make the connections inside the
water tight compartment. After
connections are made ensure that
the watertight compartment is
tightly closed and cables and
conduits are properly sealed to
prevent ingress of water. VDA-455SMB

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 12
Connection and set-up
Power and video connections
The wiring harness has a BNC connector to accept the video coax cable
(with male BNC connector) and two stripped low voltage power wires for
connection to a power connector. (A UTP adapter is available as an
accessory to allow a UTP video cable to be connected to the BNC
connector.)
The easiest way to connect the low voltage power lines and the video
connection is as follows:
• Bring the building connections through the surface wire hole so that
they hang clear.
• Partially insert two screws into the pre-drilled holes (or adapter plate).
• Using the keyholes, hang the mounting base on one screw temporarily
and tilt the base slightly to gain access to the cable connections.
• Connect the BNC connector of the camera module to the video coax
cable.
• Connect the stripped power wires to the power supply connector.
Note
For a DC supply the polarity is not important. For an AC supply try to
maintain a consistent wiring polarity in multiple camera systems to help
avoid rolling when switching.
• In damp environments ensure that the connections are sealed. (The
surface mounting box has a sealed compartment for this.)
• Push the connections back through the surface wire hole.
• Secure the mounting base to the surface with three screws.
Caution
Before proceeding, be sure to disconnect the power from the
cable to be installed into the unit. Be sure that the unit is of the
proper voltage type for the line power being used.

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 13
Setting up the camera
You can connect a monitor to the miniature 2.5mm jack socket on the
printed circuit board to help set up the camera. This socket provides a
composite video signal (with sync). An optional cable (code number
S1460) is available for making this connection.
Warning: Hot Surface
The Heater will be HOT when in operation - DO NOT TOUCH.
Always switch the heater OFF, when working on the camera.
Refer to the installer menu (see Menu Structure) for instructions.
Thumbwheels
Monitor jack
Navigation
switches
Focus
Focal length
Heater

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 14
Camera positioning
The physical default position of the camera is that the top of the image
corresponds to the indication TOP.
The camera module position can be adjusted along three axes. When
adjusting the camera position ensure that the picture display on the
monitor is level. Set the camera to the desired position by performing the
following steps:
• For horizontal adjustment (pan), rotate the camera module in the base.
Do not rotate more than 360°.
• For vertical adjustment (tilt), loosen thumbscrews, position camera,
then gently tighten thumbscrews to secure camera.
• To obtain a horizontal horizon (for tilted ceilings or sidewall
mounting), rotate the base of the lens as necessary to align the picture
shown on the monitor. Do not rotate more than 340°.
Focal length and focus
Before adjusting, place the adjustment cap on the lens to ensure that the
image sharpnes is the same as when the dome is in place.
• To set the field of view of the varifocal lens, loosen the focal length
screw and turn the mechanism until the required view is displayed on
the monitor. (Image goes out of focus.)
• Focus the image on the monitor by loosening the focus screw and
turning the mechanism until the image is in focus.
• Readjust the focal length if necessary.
• Repeat these two adjustments until the desired view is in focus.
• Tighten both screws.
Remove the adjustment cap from the lens and the monitoring jack.
Caution
The CCD image sensors are highly sensitive and require special
care for proper performance and extended lifetime. Do not expose
them to direct sunlight or bright spotlights in operating and non-
operating conditions. Avoid bright lights in the field of view of the
camera.

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 15
Heater
When using the camera at low temperatures, select the heater setting to
"Auto" in the Installer Menu (see Menu Structure).
Closing the unit
When the camera position is set and all adjustments have been made, close
the unit.
• Place the inner liner in position aligning its fin with the bracket on the
base.
• Place the dome onto the base and rotate until it clips into place. (If
necessary clean its surface with a soft cloth.)
• Place the sealing ring and the trim ring over the dome.
• Align the tamper resistant screws in the trim ring with a thread holes in
the mounting base.
• Use the special screwdriver supplied to tighten the three tamper
resistant screws.

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 16
Day/Night switching
The FlexiDomeDN Day/Night Camera is equipped with a motorized IR
filter. The IR filter can be removed in low-light or IR illuminated
applications.
If Auto switching mode is selected, the camera automatically switches the
filter depending on the observed light level. The switching level is
programmable. In Auto switching mode the camera prioritizes motion (the
camera gives sharp images without motion blur as long as the light level
permits) or color (the camera gives color pictures as long as the light level
permits). The camera recognizes IR illuminated scenes to prevent
unwanted switching to color mode.
There are two different methods of switching:
• via Bilinx™ communication, or
• automatically, based on the observed light levels.

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 17
Advanced Set-up
The FlexiDomeXF&DN normally provides an optimal picture without the
need for further adjustments. However, advanced set-up options are
available for getting the best results from the camera under special
circumstances. There are two upper level menus; a Main menu and an
Installer menu.
The Main menu allows you to select and set-up the picture enhancement
functions. If you are not happy with your changes, you can always recall
the default values for the mode.
The camera also has an Installer menu in which the installation settings
can be set.
The Main and Installer menus have functions that can be selected directly
or submenus for more detailed set-up.
Accessing and navigating menus
Five keys are used for navigating through the various menus. To access the
set-up menus, press the menu/select key (center). The main menu appears
on the OSD. Use the arrow keys for navigation.
When the Bilinx™ communications link is active, the buttons on the
camera are disabled. You can also set up Bilinx™ so that the camera
buttons remain disabled even when Bilinx™ is not actively controlling the
camera. This prevents unauthorized change of the camera settings.

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 18
Menu Structure
* Only for the Day/Night version of the camera, other versions show NightSense.
Main menu
ALC
Enhance
Color
BLC
VMD
Exit
ALC
ALC level
Shut/Gain
Peak / average
ALC speed
Shut/Gain
Shutter
Defshut
Sens up
Gain
Max. gain
Day/Night*
ENHANCE
Autoblack
Sharpness
DNR
XF-dynamic
Day/Night
Day/night
Switch lvl
Priority
IR contrast
Mono burst
COLOR
White balance
WB speed
R-gain
G-gain
B-gain
Saturation
BLC
BLC
BLC level
BLC area
Area
VMD
VMD
Area
Active
Motion
Sensitivity
Area

FlexiDomeXF & DN | Installation Manual
Bosch Security Systems | 2005-10 | V1.0
EN | 19
Installer
Set focus now
Comm
Sync
Camera ID
Heater
Defaults
Exit
Sync
Sync
Detected sync
V phase
Camera ID
Camera ID
ID position
MAC address
Defaults
Restore all?
