Cordless handstick vacuum
cleaner
BBS61 BCS61 BKS61 BLS61 BSS61
[en] User manual Cordless handstick vacuum cleaner 7
[ar]      24
[ko]       41

A B C
D E F
I
J
H
L
G
K
1

1
2
3
4
5
6
7
8
9
2

< 1,2m
3 4
5


6
7


8
9



10

11 12
13 14
15

16


17



18



19


20
21 22


23

 

24
25 26

en
7
Table of contents
1 Safety ............................................8
1.1 General information....................8
1.2 Intended use...............................8
1.3 Restriction on user group...........9
1.4 Safety instructions ......................9
2 Preventing material damage .....12
3 Environmental protection and
saving energy.............................12
3.1 Disposing of packaging ...........12
4 Unpacking and checking ...........12
4.1 Unpacking the appliance
and parts ..................................12
4.2 Included with the appliance .....12
5 Familiarising yourself with
your appliance............................13
5.1 Appliance .................................13
5.2 Controls ....................................13
5.3 Status display...........................13
6 Accessories................................13
7 Before using for the first time ...14
7.1 Installing the base station1.......14
7.2 Inserting and charging the
battery.......................................15
8 Basic operation ..........................15
8.1 Charging...................................15
8.2 Installing the appliance ............17
8.3 Dismantling the appliance........17
8.4 Switching on the appliance ......17
8.5 Switching off the appliance ......17
8.6 Using turbo mode ....................17
8.7 Vacuuming with accessories....17
9 Cleaning and servicing ..............17
9.1 Cleaning products ....................17
9.2 Cleaning the appliance ............18
9.3 Emptying the dust container ....18
9.4 Cleaning the filter unit ..............18
9.5 Cleaning the nozzles ................19
10 Troubleshooting.......................20
11 Transportation, storage and
disposal ....................................22
11.1 Disposing of old appliance ....22
11.2 Disposing of batteries ............22
11.3 Sending batteries ...................22
12 Customer Service.....................22
12.1 Product number (E-Nr.) and
production number (FD).........23
12.2 Warranty conditions................23
1Depending on the appliance specifications

en Safety
8
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡Do not connect the appliance if it has been damaged in transit.
1.2 Intended use
Only use this appliance:
¡With genuine parts and accessories. Damage caused by using
third-party products is not covered under the warranty.
¡For cleaning surfaces.
¡In private households and in enclosed spaces in a domestic en-
vironment at room temperature.
¡Up to an altitude of max. 2000m above sea level.
Do not use the appliance:
¡For vacuum-cleaning persons or animals.
¡For vacuuming up harmful, sharp-edged, hot or burning sub-
stances.
¡For vacuuming up damp substances or liquids.
¡For vacuuming up highly flammable or explosive materials and
gases.
¡For vacuuming up ash or soot from stoves and central heating
systems.
¡For vacuuming up toner dust from printers and photocopiers.
¡For vacuuming up building rubble.
Disconnect the appliance from the power supply when:
¡cleaning the appliance.

Safety en
9
1.3 Restriction on user group
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Children must not play with the appliance.
Cleaning and user maintenance must not be performed by chil-
dren unless they are being supervised.
1.4 Safety instructions
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶Repairs to the appliance should only be carried out by trained
specialist staff.
▶Only use genuine spare parts when repairing the appliance.
If the appliance or the power cord of the quick charger1 is dam-
aged, this is dangerous.
▶Never operate a damaged appliance.
▶Never operate an appliance with a cracked or fractured surface.
▶Call customer services. →Page22
An ingress of moisture can cause an electric shock.
▶Only use the appliance in enclosed spaces.
▶Never expose the appliance to intense heat or humidity.
▶Do not use steam- or high-pressure cleaners to clean the appli-
ance.
If the insulation of the power cord on the quick charger1 is dam-
aged, this is dangerous.
▶Never let the power cord come into contact with hot appliance
parts or heat sources.
▶Never let the power cord come into contact with sharp points or
edges.
▶Never kink, crush or modify the power cord.
1Depending on the appliance specifications

en Safety
10
Improper installation is dangerous.
▶Connect and operate the charging cable1 and the quick
charger1 only in accordance with the specifications on the rating
plate.
▶Connect the charging cable1 and the quick charger1 to a power
supply with alternating current only via a properly installed
socket with earthing.
WARNING‒Risk of burns!
The filter systems may become warm during operation and may
catch fire when used in conjunction with flammable substances or
substances that contain alcohol.
▶When cleaning the appliance, do not use flammable substances
or substances that contain alcohol.
WARNING‒Risk of injury!
Moving parts and openings on the appliance may cause injury.
▶Keep clothing, hair, fingers and other body parts away from the
openings on the appliance and the moving parts.
▶Never point the pipe or the nozzles towards eyes, hair, ears or
mouths.
An appliance that falls may endanger people.
▶Ensure that children do not play with the appliance, even when
it is in the base station1.
WARNING‒Danger: Magnetism!
Permanent magnets that are contained in the appliance may af-
fect electronic implants, e.g. heart pacemakers or insulin pumps.
▶Persons with electronic implants must stand at least 10cm
away from the appliance.
WARNING‒Risk of suffocation!
Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶Keep packaging material away from children.
▶Do not let children play with packaging material.
1Depending on the appliance specifications

Safety en
11
WARNING‒Risk of explosion!
A short-circuit may cause the battery to explode.
▶Protect the battery against fire, heat and constant sunlight.
▶Protect the battery against water and penetrating moisture.
▶Never open the battery.
▶When not in use, keep the battery away from metal objects, e.g.
paper clips, coins, keys, nails or screws.
WARNING‒Risk of harm to health!
Fumes that escape from a damaged battery are dangerous.
▶Supply fresh air.
▶If there are any problems, seek medical advice from a doctor.
Liquids that escape from a damaged battery are dangerous.
▶If these come into contact with the skin, wash immediately with
cold water.
▶If these come into contact with the eyes, seek medical help.

en Preventing material damage
12
Preventing material damage
2 Preventing material
damage
Preventing material damage
To prevent material damage to your
appliance, accessories or any other
objects, follow these instructions.
ATTENTION!
Liquid that escapes from a damaged
battery may lead to material damage.
▶Check and clean any wet objects.
▶Replace damaged objects.
Worn or sharp-edged outsides of
nozzles may damage sensitive hard
floors, such as parquet or linoleum.
▶Regularly check the outsides of
the nozzles for wear.
▶Replace the worn nozzle.
Vacuuming without the brush roller in
place may damage the rotating drive
axle.
▶Never use the nozzle without the
brush roller in place.
Dirt in the motor may damage the
motor.
▶Never operate the appliance
without the filter unit.
Environmental protection and saving energy
3 Environmental protec-
tion and saving energy
Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
▶Sort the individual components by
type and dispose of them separ-
ately.
Unpacking and checking
4 Unpacking and check-
ing
Unpacking and checking
Find out here what you need to note
when unpacking the appliance.
4.1 Unpacking the appliance
and parts
1. Take the appliance out of the
packaging.
2. Take all other parts and the ac-
companying documents out of the
packaging and place them to
hand.
3. Remove any packaging material.
4. Remove any stickers or film.
4.2 Included with the appli-
ance
After unpacking all parts, check for
any damage in transit and complete-
ness of the delivery.
Note:The appliance comes with ad-
ditional accessories depending on its
features.
→Fig. 1
A
Base station1
B
Mini electro-nozzle1
C
2-in-1 furniture brush with up-
holstery nozzle1
D
Replacement nozzle for
power brush1
E
Replacement brush for mini
electro-nozzle1
F
Adapter for XXL upholstery
nozzle1
G
Mattress nozzle1
1Depending on the appliance spe-
cifications

Familiarising yourself with your appliance en
13
H
XXL upholstery nozzle1
I
Crevice nozzle1
J
Battery1
K
Quick charger1
L
Charging cable1
1Depending on the appliance spe-
cifications
Familiarising yourself with your appliance
5 Familiarising yourself
with your appliance
Familiarising yourself with your appliance
5.1 Appliance
You can find an overview of the parts
of your appliance here.
→Fig. 2
1
Dust container
2
Fluff filter
3
Cartridge filter
4
Turbo switch
5
On/off switch
6
Status display
7
Dust container release button
8
Suction pipe
9
Floor nozzle with power brush
5.2 Controls
You can find an overview of the con-
trols for your appliance here.
¡Switch on the appliance.
→Page17
¡Switch off the appliance.
→Page17
Use turbo mode. →Page17
5.3 Status display
The status display indicates the differ-
ent operating statuses.
Operating
status
Status display
Normal mode Display lights up
white.
Turbo mode LED slowly flashes
white.
Battery
charge below
20%
Display rapidly
flashes red.
Battery empty Display goes out.
Charging pro-
cess
LED slowly flashes
white.
Battery is
fully charged
Display lights up
white and goes out
after approx. two
minutes.
Over-/under-
temperature
protection
Display lights up red
and goes out after
approx. 10 seconds.
Accessories
6 Accessories
Accessories
Only use original accessories. These have been made especially for your appli-
ance. Here you can find an overview of your appliance's accessories and how
to use them.

en Before using for the first time
14
Accessories Accessory number Use
XXL upholstery nozzle BBZ130SA Clean upholstered fur-
niture.
XXL crevice nozzle BBZ131SA Clean crevices, corners
and narrow and hard-to-
reach places.
Mattress nozzle BBZ133SA Clean mattresses.
Rechargeable battery1BHZUB1830 Supply the appliance
with power.
Rechargeable battery1BHZUB183CN Supply the appliance
with power.
Quick charger1BHZUC18N Charge the 18 V Power
for ALL rechargeable
battery.
Quick charger1BHZUC18NCN Charge the 18 V Power
for ALL rechargeable
battery.
Quick charger1BHZUC18NGB Charge the 18 V Power
for ALL rechargeable
battery.
Accessory set BHZUKIT
1Depending on the country version
Before using for the first time
7 Before using for the
first time
Before using for the first time
Prepare the appliance for use.
7.1 Installing the base
station1
WARNING
Risk of electric shock!
Incorrect installation is dangerous.
▶Check whether any household wir-
ing could be damaged in the in-
stallation area.
▶Do not install the base station hori-
zontally or vertically above, below
or next to a socket.
1. Remove the front panel towards
the front.
→Fig. 3
2. Wall-mount the base station 1.
Install the base station 1 close to a
socket.
3. Insert the appliance plug for the
charging cable1 into the recess in
the base station 1.
→Fig. 4
4. Guide the charging cable1 along
the side of the base station1 and
secure it in the recess.
5. Insert the front panel.
The front panel secures the appli-
ance plug into the base station 1.
1Depending on the appliance specifications

Basic operation en
15
6. Plug the charging cable's mains
plug1 into the socket.
7.2 Inserting and charging
the battery
1. Use the guide rail to insert the bat-
tery into the vacuum cleaner.
→Fig. 5
2. Fully charge the battery.
→"Charging", Page15
Basic operation
8 Basic operation
Basic operation
8.1 Charging
Depending on the appliance features,
you can charge the battery in three
different ways.
WARNING
Risk of fire!
Improper use of the battery and the
rapid charger 1 is dangerous.
▶Only charge the battery in char-
gers that are recommended by the
manufacturer.
▶Only use the battery in connection
with the Bosch appliance.
▶Charge the battery using the ori-
ginal charging cable 1 or the ori-
ginal quick charger 1.
▶Only use batteries from the Power
for ALL 18V series.
Charging using the charging
cable1
Note:The power supply unit on the
charging cable 1 and the appliance
heat up while charging. This is nor-
mal and harmless.
Requirement:The battery has been
inserted.
→"Inserting and charging the bat-
tery", Page15
1. Place the vacuum cleaner close to
the socket.
2. Plug the appliance plug into the
vacuum cleaner.
→Fig. 6
3. Insert the mains plug into the
socket.
aThe status display slowly flashes
white while the battery is charging.
Once the battery is fully charged,
the status display lights up white
for a few minutes.
Tip:To check that the battery has
charged fully, briefly disconnect the
vacuum cleaner from the mains. The
status display then lights up white.
You can charge the vacuum cleaner
whenever it is not in use.
Charging in the base station1
WARNING
Risk of injury!
An appliance that falls may endanger
people.
▶Ensure that children do not play
with the appliance, even when it is
in the base station1.
Note:The power supply unit on the
charging cable 1 and the appliance
heat up while charging. This is nor-
mal and harmless.
Requirement:The battery has been
inserted.
1Depending on the appliance specifications

en Basic operation
16
▶Insert the vacuum cleaner into the
base station 1 from the front.
→Fig. 7
aThe status display flashes white
while the battery is charging. Once
the battery is fully charged, the
status display lights up white for a
few minutes.
Tip:To check that the battery has
charged fully, briefly disconnect the
vacuum cleaner from the mains.
Once the status display lights up
white, the appliance is fully charged.
Charging using the quick charger1
1. Press the release button and re-
move the battery to the rear.
→Fig. 8
2. Observe the enclosed instructions.
Battery charging times
You can find an overview of the bat-
tery charging times here.
Notes
¡The specified charging times may
vary depending on the battery
charging status, the battery tem-
perature and the age of the bat-
tery.
¡You can find out which battery
charging times are achieved with
the quick charger1 in the instruc-
tions of for the quick charger1.
Tip:If the quick charger1 displays a
battery charging status of approx.
80%, you can remove and use the
battery.
Battery charging status
of
18V2,5Ah 18V3,0Ah
80% in hrs 3,5 4
97%–100% in hrs 4 5
Battery runtimes
You can find an overview of the battery runtimes, depending on the battery that
is used, here.
Note
The following modes affect the battery runtime:
¡Mode 1: Normal mode with non-electrical accessory
¡Mode 2: Normal mode with electrical floor nozzle
¡Mode 3: Turbo mode with electrical floor nozzle
Runtime 18V2,5Ah 18V3,0Ah
Mode 1 up to min. 30 35
Mode 2 up to min. 25 30
Mode 3 up to min. 8 10
1Depending on the appliance specifications

Cleaning and servicing en
17
Notes
¡Like every Li-ion battery, the batter-
ies from the Power for ALL 18V
series wear out over time, meaning
that the battery capacity and the
runtime decrease. This is a natural
aging process and not the result of
a material error, manufacturing er-
ror or material defect.
¡You can delay the natural wear by
using the following measures:
Only charge the battery in the
temperature range between
0°C and 45°C.
Only store the battery in the tem-
perature range between -20°C
and 50°C.
Do not store the battery for an
extended period of time if it is
fully charged or fully discharged.
8.2 Installing the appliance
1. Place the suction pipe onto the ap-
pliance's connection port and lock
it in place.
→Fig. 9
2. Insert the end of the suction pipe
into the floor nozzle and lock it in
place.
8.3 Dismantling the appliance
1. Press the release button and pull
the suction pipe out of the floor
nozzle.
→Fig. 10
2. Press the release button and pull
the suction pipe out of the appli-
ance's connection port.
8.4 Switching on the appli-
ance
▶Press ⁠.
→Fig. 11
aThe status display lights up white.
8.5 Switching off the appli-
ance
▶Press .
aThe status display goes out.
8.6 Using turbo mode
Requirement:The appliance has
been switched on.
→"Switching on the appliance",
Page17
▶Press .
→Fig. 12
aThe status display flashes white.
8.7 Vacuuming with ac-
cessories
1. Place the required accessory onto
the suction pipe or the appliance's
connection port.
→Fig. 13
2. After use, insert the accessory into
the base station 1.
→Fig. 14
Cleaning and servicing
9 Cleaning and servicing
Cleaning and servicing
To keep your appliance working effi-
ciently for a long time, it is important
to clean and maintain it carefully.
9.1 Cleaning products
Only use suitable cleaning products.
1Depending on the appliance specifications

en Cleaning and servicing
18
ATTENTION!
Using unsuitable cleaning products
or incorrect cleaning may damage
the appliance.
▶Do not use harsh or abrasive de-
tergents.
▶Do not use cleaning products with
a high alcohol content.
▶Do not use hard scouring pads or
cleaning sponges.
▶Wash sponge cloths thoroughly
before use.
9.2 Cleaning the appliance
Requirement:The appliance is
switched off.
→"Switching off the appliance",
Page17
1. Disconnect the appliance from the
charging cable1.
2. Clean the appliance and the ac-
cessory with a soft cloth and a
commercially available plastic
cleaner.
9.3 Emptying the dust con-
tainer
Empty the dust container at the latest
when the fill level has reached the
mark. In order to achieve the
best possible vacuuming results,
empty the dust container after every
use of the vacuum cleaner.
Requirement:The appliance is
switched off.
→"Switching off the appliance",
Page17
1. Check the fill level of the dust con-
tainer.
→Fig. 15
2. Check how dirty the filter unit is
and clean it if necessary.
→"Cleaning the filter unit",
Page18
3. To remove the dust container,
press the release button.
→Fig. 16
4. Remove the filter unit from the dust
container.
→Fig. 17
5. Empty the dust container.
6. Insert the filter unit into the dust
container and check that it is
seated correctly.
→Fig. 18
7. Insert the dust container.
aThe dust container audibly clicks
into position.
9.4 Cleaning the filter unit
When you empty the dust container,
also clean the filter. This gives you a
good vacuuming result.
ATTENTION!
Penetrating moisture may damage
the filters.
▶Never allow the filters to come into
contact with liquids.
Requirement:The appliance is
switched off.
→"Switching off the appliance",
Page17
1. Remove the dust container.
→Fig. 16
2. Remove the filter unit from the dust
container.
→Fig. 19
3. To unlock the cartridge filter, turn
the filter unit in the direction.
→Fig. 20
4. Remove the cartridge filter.
1Depending on the appliance specifications

Cleaning and servicing en
19
5. Tap out the cartridge filter over a
bin.
→Fig. 21
6. Lightly shake the fluff filter over a
bin and lightly tap on it.
→Fig. 22
7. Clean the fluff filter with a dry cloth.
8. Insert the cartridge filter into the
fluff filter.
→Fig. 23
9. Lock the cartridge filter in the dir-
ection.
10.Insert the filter unit into the dust
container.
→Fig. 18
11.Insert the dust container.
aThe dust container audibly clicks
into position.
9.5 Cleaning the nozzles
Requirement:The appliance is
switched off. →Page17
1. Disconnect the nozzle from the ap-
pliance.
2. Release the brush roller.
→Fig. 24
3. Remove the brush roller sideways
from the nozzle.
4. Use scissors to cut through
threads and hairs along the
bristles1 or cut through the cutting
groove 1.
→Fig. 25
5. Insert the brush roller sideways
along the guide bar and into the
nozzle.
→Fig. 26
6. Lock the brush roller.
Note:The brush roller features a
cleaning function. When operating
the brush roller on carpet, your appli-
ance automatically vacuums the cut
threads and hairs after more than 30
seconds.
1Depending on the appliance specifications

en Troubleshooting
20
Troubleshooting
10 Troubleshooting
Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshoot-
ing information before contacting after-sales service. This will avoid unneces-
sary costs.
WARNING
Risk of electric shock!
Incorrect repairs are dangerous.
▶Repairs to the appliance should only be carried out by trained specialist
staff.
▶Only use genuine spare parts when repairing the appliance.
Fault Cause and troubleshooting
The appliance is not
working.
The battery status dis-
play does not show
any status.
The red battery status
display lights up for
10 seconds.
The battery has not been inserted correctly.
▶Insert the battery correctly.
→"Inserting and charging the battery", Page15
The battery has not been charged.
▶Charge the battery.
→"Charging", Page15
The battery has overheated or overcooled.
1. Switch off the appliance and disconnect the appli-
ance from the power supply.
2. Wait until battery has reached room temperature.
The appliance has overheated or overcooled.
1. Switch off the appliance and disconnect the appli-
ance from the power supply.
2. Wait until the appliance has reached room temper-
ature.
The dust container
cannot be inserted.
The filter unit is not complete.
▶Check whether the filter unit is complete.
The filter unit or dust container is not positioned cor-
rectly.
▶Check whether the filter unit and dust container are
inserted correctly.
Suction is reduced. The filter is blocked.
1. Switch off the appliance and disconnect the appli-
ance from the power supply.
2. Clean the filter unit.
→"Cleaning the filter unit", Page18
The nozzle is blocked.
1. Switch off the appliance and disconnect the appli-
ance from the power supply.
