20 | English
Symbols and their meaning
– Maximum suction power for applica-
tions with a high level of dust genera-
tion
– Reduced suction power for applica-
tions with a low level of dust genera-
tion, and also to regulate the suction
between the connected power tool
and the surface of the workpiece, for
example (e.g. when sanding)
Permitted connected load of the connec-
ted power tool (country-specific)
AFC Automatic filter cleaning
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The dust extractor is intended for collecting, vacuuming,
conveying and separating wood chips as well as non-flam-
mable dry dusts, non-flammable liquids and water-air mix-
tures. The dust extraction capability of the dust extractor
has been tested and corresponds to dust classM. It is suit-
able for the increased demands in professional use, e.g. in
trade, industry and workshops.
Dust extractors from dust class M in accordance with IEC/
EN60335-2-69 may only be used to vacuum and extract
harmful dust with an exposure limit of ≥0.1mg/m3.
Only use the dust extractor if you can fully evaluate all func-
tions and carry them out without restrictions, or if you have
received corresponding instructions.
Product features
The numbering of the product features refers to the repres-
entation of the vacuum cleaner on the graphic pages.
(1) Container
(2) Sealing plug for extraction connection
(3) Hose adapter
(4) Holder for vacuum hose
(5) Socket for power tool
(6) Volume flow rate controller
(7) Mode selector switch
(8) Suction power regulator
(9) AFC button
(10) Carrying handle
(11) L-Boxx holder
(12) Guide handle
(13) Top part of dust extractor
(14) Cable holder
(15) Catch for top part of dust extractor
(16) Wheel
(17) Castor brake
(18) Castor
(19) Castor frame
(20) Closing flap for filter cover
(21) Holder for crevice nozzle/curved nozzle
(22) Holder for suction tubes
(23) Dump hose
(24) Holder for floor nozzle
(25) Dust extraction adapter
(26) False air intake
(27) Vacuum hose
(28) Curved nozzle
(29) Disposal bag
(30) Flat-pleated filter (PES)
(31) Crevice nozzle
(32) Rubber lip
(33) Brush inserts
(34) Floor nozzle
(35) Suction tube
(36) Adapter for vacuum hose holder
(37) Snap fastener
(38) Control LED
(39) Filter cover
(40) Fill level sensors
Technical data
Wet/dry dust extractor GAS 55 M AFC
Article number 3 601 JC3 3..
Rated power input W 1,200
Frequency Hz 50–60
Container volume (gross) l 55
Net volume (liquid) l 40
Dust bag volume l 27
Max. vacuumA)
1 609 92A 7Z9 | (15.02.2023) Bosch Power Tools

English | 21
Wet/dry dust extractor GAS 55 M AFC
– Dust extractor hPa 230
– Turbine hPa 254
Max. volume flow rateA)
– Dust extractor l/s
m³/s
36
0.036
– Turbine l/s
m³/s
74
0.074
Max. suction power W 1,380
Area of pleated filter m² 0.615
Dust class M
Weight according to EPTA-Pro-
cedure01:2014 kg 16.2
Protection class /I
Protection rating IPX4
A) Measured using a vacuum hose 3 m long and 35 mm in diameter
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Values can vary depending upon the product and are subject to ap-
plication and environmental conditions. For further information
www.bosch-professional.com/wac.
Automatic start/stop
Rated voltage Maximum power Minimum power
230 V 2200 W 100 W
Permitted connected load of the connected power tool.
These values can differ for other country-specific models. Please take
note of the information on the socket of the dust extractor.
Noise/Vibration Information
Noise emission values determined according to
EN60335-2-69.
Typically the A-weighted sound pressure level of the dust ex-
tractor is 70 dB(A). Uncertainty K=3dB. The noise level
when working can exceed 80dB(A).
Wear hearing protection
Total vibration values ah (triax vector sum) and uncertainty K
determined according to EN60335-2-69: ah<2.5m/s2,
K=1.5m/s2.
Assembly
uPull the plug out of the socket before cleaning or per-
forming maintenance on the vacuum cleaner, making
tool adjustments, changing accessories or putting
away the vacuum cleaner. This safety measure prevents
the vacuum cleaner from being started accidentally.
Fitting the holder for the vacuum hose (see
figure A)
– Slide the holder (4) for the vacuum hose firmly into the
corresponding adapters (36) from above until they click
into place.
Fitting the vacuum hose (see figureB)
– Attach the vacuum hose (27) to the hose adapter (3) and
turn it clockwise as far as it will go.
Note: The friction generated by the dust in the vacuum hose
and accessory during extraction causes an electrostatic
charge that the user may experience as static discharge (de-
pending on environmental factors and their physiological
state).
Bosch generally recommends using an anti-static vacuum
hose (accessory) to vacuum up fine dust and dry materials.
Fitting the vacuuming accessories (see figure C)
The vacuum hose (27) is equipped with a clip system which
can be used to connect vacuuming accessories (dust extrac-
tion adapter (25), curved nozzle (28)).
Fitting the nozzles and tubes
– Push the curved nozzle (28) onto the vacuum hose (27)
until you hear both snap fasteners (37) on the vacuum
hose engage.
– Then attach the required extraction accessory (floor
nozzle, crevice nozzle, suction tube, etc.) firmly to the
curved nozzle (28).
– To remove the accessory, press the snap fasteners (37)
inwards and pull apart the components.
Fitting the dust extraction adapter
– Push the dust extraction adapter (25) onto the vacuum
hose (27) until you hear both snap fasteners (37) on the
vacuum hose engage.
– To remove the adapter, press the snap fasteners (37) in-
wards and pull apart the components.
Inserting/removing the disposal bag or dust bag
(dry extraction) (see figureD)
A disposal bag (29) or dust bag must be used for the dry ex-
traction of dust class M materials.
Insofar as materials with or without an exposure limit of
≥1mg/m3 (dust class L materials) are extracted, these can
be sucked straight into the container.
Note: If using a paper filter bag, you must make sure that
automatic filter cleaning (AFC) is switched off; you should
also do the same if using a fleece filter bag (see " Automatic
filter cleaning (see figure I)", page23).
WARNING The dust extractor contains dust
particles that pose a risk to health.
Emptying and maintenance procedures, including the
disposal of dust containers, should only be carried out by
professionals. Suitable protective equipment is re-
quired. Do not operate the vacuum cleaner unless the
complete filter system is correctly inserted. Otherwise,
you are putting your health at risk.
Inserting the disposal bag
– Open the catches (15) and remove the top part of the va-
cuum cleaner (13).
