Bose CVT-5 User manual

1
BOSE®
PANARAY®
SOUND SYSTEM
CVT-5CONSTANT
VOLTAGE
TRANSFORMER
OWNER’SGUIDE

2
Contents
CVT-5ConstantVoltageTransformer
ForThePanaray
®
502
®
AControlledArray ............................... 3
BeforeYouBegin… ............................................................ 3
AttachingtheCVT-5Transformer
ToThe502AArray .............................................................. 4
ElectricalConnections ........................................................ 9
NoteOnPainting ............................................................... 11
NoteOnReplacementParts ................................................ 11
ForInformation .................................................................. 12

3
CVT-5 Constant Voltage Transformer
For The Panaray
®
502
®
A Controlled
Array
ThankyouforpurchasingtheBose
®
CVT-5ConstantVoltageTransformer
forthePanaray502AControlledArray.TheCVT-5isanintegral,factory-
designed70/100Vtransformerengineeredforquickinstallationonthe
502Aarray.Thetransformerhandlesupto150Wofpower(infour
differenttaps)toaccommodateavarietyofdistributedvoice-only
applicationrequirements.Thecompact,custommoldedenclosureofthe
CVT-5attachesflushtotherearofthe502Aarray.Thisprovidesan
aestheticadvantageandagoodfitwhenyouusetheCVT-5transformer
inconjunctionwithBosePanaraymountingaccessories.
BeforeYouBegin…
Thetransformer’ssymmetricalhousingallowsyoutoattachtheCVT-5
withitsspeakerterminalspointingawayfromortowardthe502A
array’sfourrearattachment
points(Figure1).
Beforemakingthe
attachment,considerwhich
orientationrequiresthe
leastspeakercable.Thatmay
helpyoudecidetheorientation
youprefer.
Blue
(75W)
Green
(38W) White
(19W)
Black
(–)
Figure1

4
AttachingTheCVT-5TransformerTo
The
502
®
AArray
1. Use a Phillips head screwdriver to remove the
four screws that secure the connector plate to
the rear of the 502A array (Figure 2).
2. Use a small slot screwdriver to carefully pry the
connector away from the rear baffle. Pull it out a
short distance (Figure 3).
3. Use wire cutters to cut the two wires near the
solder terminals on the inside of the connector
panel (Figure 3). Put the panel aside.
4.
Strip
1
¦
2
"(12mm)ofinsulationfromtheendofthetwowires
insidethe502Aarray.

5
Figure2
Figure3

6
5. A. Identifythepositiveoutputleadfromthetrans-former
accordingtothesystem’spowerrequire-ments(see
tablebelow).Thatlead’spowerratingindicateswhere
youwill“tap”thetransformer.
Red ................................................ 150W
Blue ........................................ 75W
Green ..................................... 38W
White ...................................... 19W
B. Pullthecutaway tipoftheinsulation offthatlead.
C. Clipthethreeunusedleadsoffatthetransformer
windings(Figure4a).
D. Connectthepositivelead,whichishangingloose,to
theredwireinsidethearray(Figure4b).
E. ConnecttheblackwireontheCVT-5transformertothe
blackwireinsidethearray.
Note: Solderingandinsulatingwithelectricaltapeisthemethod
Bose
®
recommendsforconnectingwires.Usingasmallcrimp-type
buttsplicerisalsoacceptable.
Wedonotrecommendwirenuts,terminalblocks,orsimilar
solderlessdevices,whichcouldrattleinsidethe502
®
Aarrayor
touchtherearofoneofthe driverconesduringuseofthesystem.

7
Figure 4b
Figure 4a
+
–

8
6. Press the CVT-5 transformer housing down into
the flange in the orientation you prefer.
7. Use the four screws removed from the connector
plate to secure the CVT-5 to the array (Figure 5).
Figure 5

9
ElectricalConnections
Notice the arrangement of terminals on the back of the
CVT-5 transformer housing (Figure 6).
1. For 70V systems, connect the positive or hot
speaker lead coming from the amplifier to the
terminal labeled +70V. For100V systems,
connect the positive lead to the terminal labeled
+100V.
Figure6

10
2. Connect the ground or negative lead to the
terminal labeled GND. Do not use the terminal
marked N/C, which has no function.
3. For parallel connections in a chain, connect the
next array’s cable to the same terminals used
above.
Note:Bose
®
recommendsusingsolder-typespadelugsontheends
ofthespeakercables.Tomakeparallelconnectionsefficiently,you
canattachtheendsoftheincomingandoutgoingcablestoa
singlepairofspadelugs,whichthenattachtotheselected
terminals.
Ifyoudonotusespadelugs,makesurethattheincomingand
outgoingcablesareofthesamediameter.Thatwillensureanequal
force on them from the terminal strip flanges.

11
NoteOnPainting
If you plan to paint the 502
®
A arrays, Bose
®
recommends
installing each CVT-5 transformer first, so you can paint
the502A/CVT-5assemblies all at once.
Before painting, mask off the label on the rear of the
transformerhousingto preserve identification of the input
terminals.
Forfullinstructionson painting the Panaray
®
components
and accessories, please consult the Bose Panaray
InstallationGuide.
NoteOnReplacementParts
IfyouhavetroubleinstallingoroperatingtheCVT-5Constant
VoltageTransformer,contactBoseTechnicalService.Call(800)
367-4008or(508)366-9896.Orrefertothe“ForInformation”listing
onpage12.

12
ForInformation
USA
1-800-444-BOSE(2673)8:30
a.m.to9p.m.ET
Canada
1-800-444-BOSE(2673)
9a.m.to 5p.m.ET
EuropeanHeadquarters
BoseB.V.,Nijverheidstraat8,
1135GEEdam,Netherands
TEL02993-71055
FAX02993-68163
Australia
BoseAustralia,Inc.,
11MurielAvenue,
Rydalmere,N.S.W.2116
TEL02684-1022
FAX02684-1665
Belgique/België
BoseN.V.,Essenestraat
15,1740Ternat
TEL02-5826200
FAX02-5823717
Danmark
BoseA/S,Industrivej7,2605
Brøndby
TEL4343-7777
FAX4343-7818
Deutschland
BoseGmbH,Max-Planck-Straße
36,Postfach1125,
61381Friedrichsdorf,
TEL06172-71040
FAX06172-710419
Epaña
BoseProductsB.V.,Avda.
Aragón334,28022Madrid
TEL01-3290210
FAX01-7472080
France
BoseS/A,6,rueSaintVincent,
78100Saint-Germain-en-Laye
TEL01-30610461
FAX01-30614105
Ireland

13
BoseLtd.,CastleblayneyRoad,
Carrickmacross,
CoMonaghan
TEL042-61988
FAX042-61998
Italia
BoseS.p.A.,ViaLuigiCapucci
12,00147Rome TEL
06-5127641/2
FAX06-5115438
Nederland
BoseB.V.,Nijverheidstraat
8,1135GEEdam
TEL02993-66661
FAX02993-68166
Norge
BoseA/S,Sundkroken9H,
2008Fjerdingby
TEL63-838703
FAX63-838704
Schweiz
BoseA.G.,Rünenbergerstrasse
13A,
4460Gelterkinden
TEL061-995544
FAX061-995502
Sverige
BoseA/S,Blandsädsgatan2D,
43146Mölndal
TEL031-878850
FAX031-274891
UnitedKingdom
BoseU.K.Ltd.,TrinityTrading
Estate,Sittingbourne,
KentME102PD
TEL0795-475341/5 FAX
0795-427227
OtherLocations
Bose Service,OtisStreetPark,
Building3,POBox5045,
Westborough,MA01581-5045
USA
TEL(508)366-9896 FAX
(508)366-8443

14
©1996 Bose Corporation, The Mountain,
Framingham, MA 01701-9168 U.S.A.
JN93712 PN172164 Rev. 01 AM172164 Rev. 01
