Boschmann presents a demo-car that shows you what we are
about! After a lot of consideration the “car-audio-rookie” came
with a great audio system for a very reasonable price. Of course
this car has been pimped out in an extreme way but without a
doubt it’s the sound that counts the most.
The front doors have been build with 2 component sets and 2
midbass speakersets.
The MB 6.2 CTI produces a pure mid and high tone, while the
V 6 ALX midbass speakers produce a both thight and very clear
bass sound.
Behind the backseat (where it is still able to sit) we placed 4
extreme 12” subwoofers. After the moult was formed with
polyester, the total was finished with skai. All AZX-W12 tpo
subwoofers are lead up to 2 class “D” amplifiers which are
processed in the trunk.
In the trunk you can find 2 pieces of 4-channel amplifiers
(PCH 868 ATX) which lead up to the front speakers, 2 PSX-D2
amplifiers (dual mono block) which lead up to the 4 subwoofers
and 2 power capacitors (CT .0 F) for some extra power. The
trunk is also completely finished with skai.
Besides the audio part, the car got a lot more attractive gadgets
such as: Touchscreen navigation, 5 LCD monitors (of which 2 are
17” that can see from the outside) DVD player, Playstation2, Mp3
player and a NECOM million colour under car kit LED set. Of
course all the connection requirements and cables are NECOM
as well.
For more info check our website:
Boschmann Benelux: www.boschmann.eu
Boschmann International: www.boschmann.com
car-audio dealers check: www.neeskensbv.eu

productfolder 29-4-2008
The design and specifications subject to change without notice.

productfolder 29-4-2008
The design and specifications subject to change without notice.
BOSCHMANN R2430V G NMETAL LINE
Dimensions: 4inch Ø
System: 3 way
Max/RMS power: 250W Max/ 95W RMS
Impedance: 4Ω
Freq. response.: 45Hz- 23.000Hz
Recommended amp: 5-80RMS
Incl.: grill and connection requirements
BOSCHMANN R2530V G NMETAL LINE
Measurement: 5.25inch / 13cm Ø
System: 3 way
Max/RMS power: 300W Max/ 110W RMS
Impedance: 4Ω
Freq. response.: 40Hz- 23.000Hz
Recommended amp: 5-90RMS
Incl.: grill and connection requirements
BOSCHMANN R2630V G NMETAL LINE
Dimensions: 6.5inch / 16.5cm Ø
System: 3 way
Max/RMS power: 350W Max/ 150W RMS
Impedance: 4Ω
Freq. response.: 35Hz- 23.000Hz
Recommended amp: 5-110RMS
Incl.: grill and connection requirements
BOSCHMANN PR5700V G NMETAL LINE
Dimensions: 5x7inch / 13x18cm Ø
System: 3 way
Max/RMS power: 180W Max/ 90W RMS
Impedance: 4Ω
Freq. response.: 35Hz- 23.000Hz
Recommended amp: 5-80RMS
Incl.: connection requirements
BOSCHMANN R2630CX G NMETAL LINE
Dimensions: 6.5inch / 16.5cmØ
System: 3 way
Max/RMS power: 400W Max/ 150W RMS
Impedance: 4Ω
Freq. response: 30Hz- 23.000Hz
Recommended amp: 5-125RMS
Incl.: grill and connection requirements
BOSCHMANN ALX 442 GIGA SERIE
Dimensions: 4inch / 10cm Ø
System: 2 way
Max/RMS power: 250W Max/ 125WRMS
Impedance: 4Ω
Freq. response: 70 Hz- 21.000Hz
Recommended amp: 5-35W RMS a channel
Sensitivity: 93 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable

productfolder 29-4-2008
The design and specifications subject to change without notice.
BOSCHMANN ALX 552 GIGA SERIE
Dimensions: 5.25inch / 13cm Ø
System: 2 way
Max/RMS power: 300W Max/ 150W RMS
Impedance: 4Ω
Freq. response: 65 Hz- 21.000Hz
Recommended amp: 5-50W RMS a channel
Sensitivity: 93 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN ALX 662 GIGA SERIE
Dimensions: 6.5inch / 16.5cm Ø
System: 2 way
Max/RMS power: 350W Max/ 175W RMS
Impedance: 4Ω
Freq. response: 60 Hz- 21.000Hz
Recommended amp: 5-75W RMS a channel
Sensitivity: 93 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMA
NN ALX993
GIGA SERIE
Dimensions: 6x9inch / 15x23cm Ø
System: 3 way
Max/RMS power: 1000W Max/ 350W RMS
Impedance: 4Ω
Freq. response: 40 Hz- 23.000Hz
Recommended amp: 5-125W RMS a channel
Sensitivity: 93 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN LCX 4300J
Dimensions: 4inch / 10cm Ø
System: 3 way
Max/RMS power 100 watts
Impedance: 4Ω
Freq. response: 80Hz-22.000Hz
Sensitivity: 90dB/w*m(SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN LCX 5300J
Dimensions: 5.25inch / 13cm Ø
System: 3 way
Max/RMS power 150 watts
Impedance: 4Ω
Freq. response: 70Hz-22.000Hz
Sensitivity: 90dB/w*m(SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN LCX 6300J
Dimensions: 6.5inch / 16.5cm Ø
System: 3 way
Max/RMS power 200 watts
Impedance: 4Ω
Freq. response: 60Hz-22.000Hz
Sensitivity: 91dB/w*m(SPL)
Incl.: connection requirements, grill and speakercable

productfolder 29-4-2008
The design and specifications subject to change without notice.
BOSCHMANN LCX 9400J
Dimensions: 6x9inch / 15x23cm Ø
System: 4 way
Max/RMS power 300 watts
Impedance: 4Ω
Freq. response: 45Hz-25.000Hz
Sensitivity: 92dB/w*m(SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN RSX 450E
Dimensions: 4inch / 10cm Ø
System: 2 way
Max/RMS power 150 watts
Impedance: 4Ω
Freq. response: 75Hz-22.500Hz
Sensitivity: 90dB/w*m(SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN RSX 550E
Dimensions: 5.25inch / 13cm Ø
System: 2 way
Max/RMS power 180 watts
Impedance: 4Ω
Freq. response: 65Hz-22.500Hz
Sensitivity: 90dB/w*m(SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN RSX 650E
Dimensions: 6.5inch / 16.5cm Ø
System: 2 way
Max/RMS power 230 watts
Impedance: 4Ω
Freq. response: 60Hz-23.000Hz
Sensitivity: 91dB/w*m(SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN RSX 699E
Dimensions: 6x9inch / 15x23cm Ø
System: 3 way
Max/RMS power 300 watts
Impedance: 4Ω
Freq. response: 55Hz-23.000Hz
Sensitivity: 91dB/w*m(SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN G3032s G NMETAL LINE
Dimensions: 3,5inch / 8.7cm Ø
System: 2 way
Max/RMS power: 130W Max/ 55W RMS
Impedance: 4Ω
Freq. response: 75Hz- 27.300Hz
Recommended amp: 5-48W RMS a channel
Sensitivity: 90 dB/W*m (SPL)
Incl.: connection requirements and speakercable

productfolder 29-4-2008
The design and specifications subject to change without notice.
BOSCHMANN G4532s G NMETAL LINE
Dimensions: 4inch / 10cm Ø
System: 2 way
Max/RMS power: 200W Max/ 85W RMS
Impedance: 4Ω
Freq. response: 45Hz- 23.000Hz
Recommended amp: 5-75W RMS a channel
Sensitivity: 89 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN G5532s G NMETAL LINE
Dimensions: 5.25inch / 13cm Ø
System: 2 way
Max/RMS power: 260W Max/ 100W RMS
Impedance: 4Ω
Freq. response: 40Hz- 23.000Hz
Recommended amp: 5-90W RMS a channel
Sensitivity: 90 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN G6532s G NMETAL LINE
Dimensions: 6.5inch / 16,5cm Ø
System: 2 way
Max/RMS power: 300W Max/ 135W RMS
Impedance: 4Ω
Freq. response: 35Hz- 23.000Hz
Recommended amp: 5-100W RMS a channel
Sensitivity: 90 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN G4632s G NMETAL LINE
Dimensions: 4x6inch / 10x15cm Ø
System: 2 way
Max/RMS power: 260W Max/ 100W RMS
Impedance: 4Ω
Freq. response: 35Hz- 23.000Hz
Recommended amp: 5-90W RMS a channel
Sensitivity: 90 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN G9633s G NMETAL LINE
Dimensions: 6x9inch / 15x23cm Ø
System: 4 way
Max/RMS power: 400W Max/180W RMS
Impedance: 4Ω
Freq. response: 30Hz- 23.000Hz
Recommended amp: 5-170W RMS a channel
Sensitivity: 91 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN PR6390 T RBO SERIES
Dimensions: 6x9inch / 15x23cm Ø
System: 3 way
Max/RMS power: 700W Max/ 350W RMS
Impedance: 4Ω
Freq. response: 45Hz- 23.000Hz
Recommended amp: 5-110W RMS a channel
Sensitivity: 93 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable

productfolder 29-4-2008
The design and specifications subject to change without notice.
BOSCHMANN PR6013 T RBO SERIES
Dimensions: 6.5inch / 16.5cm Ø
System: 3 way
Max/RMS power: 550W Max/ 250W RMS
Impedance: 4Ω
Freq. response: 55Hz- 23.000Hz
Recommended amp: 5-100W RMS a channel
Sensitivity: 93 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN XLR9948e XLR LINE
Dimensions: 6x9inch / 15x230cm Ø
System: 4 way
Max/RMS power: 400W Max/ 200W RMS
Impedance: 4Ω
Freq. response: 40Hz- 23.000Hz
Recommended amp: 5-100W RMS a channel
Sensitivity: 92 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN XLR6638e XLR LINE
Dimensions: 6.5inch / 16.5cm Ø
System: 3 way
Max/RMS power: 270W Max/ 135W RMS
Impedance: 4Ω
Freq. response: 55Hz- 23.000Hz
Recommended amp: 5-65W RMS a channel
Sensitivity: 91 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN XLR9949e XLR LINE
Dimensions: 6x9inch / 15x230cm Ø
System: 4 way
Max/RMS power: 400W Max/ 200W RMS
Impedance: 4Ω
Freq. response: 40Hz- 23.000Hz
Recommended amp: 5-100W RMS a channel
Sensitivity: 92 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN XLR6639s XLR LINE
Dimensions: 6.5 inch / 16.5cm Ø
System: 3 way
Max/RMS power: 280W Max/ 140W RMS
Impedance: 4Ω
Freq. response: 55Hz- 23.000Hz
Recommended amp: 5-70W RMS a channel
Sensitivity: 90 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable
BOSCHMANN PR9448ny G NMETAL LINE
Dimensions: 6x9inch / 15x23cm Ø
System: 4 way
Max/RMS power: 500W Max/ 250W RMS
Impedance: 4Ω
Freq. response: 38Hz- 23.000Hz
Recommended amp: 5-125W RMS a channel
Sensitivity: 93 dB/W*m (SPL)
Incl.: connection requirements, grill and speakercable

productfolder 29-4-2008
The design and specifications subject to change without notice.
BOSCHMANN PR-222 JX- SERIES
Dimensions: 9x9x7cm
System: 2 way cabinet speaker
Max/RMS power: 80W Max/ 45W RMS
Impedance: 4Ω
Freq. response: 75Hz- 18.000Hz
Recommended amp: 5-25W RMS a channel
Sensitivity: 90 dB/W*m (SPL)
Incl.: bracket, speakercable, connection requirements
BOSCHMANN MM 2xg G NMETAL LINE
Dimensions: 1inch / 2.5cm Ø
System: Titanium Tweeter
Max/RMS power: 130W Max/ 85W RMS
Freq. response: 5.000 Hz- 24.000Hz
Sensitivity: 93 dB/W*m (SPL)
Incl.: inline cross-overs, en speakercable
BOSCHMANN MM 6 G NMETAL LINE
Dimensions: 1inch 2.5cm Ø
System: Titanium NdFeB Tweeter
Max/RMS power: 200W Max / 60W rms
Freq. response: 3.000 Hz- 30.000Hz
Sensitivity: 93 dB/W*m (SPL)
Incl.: inline cross-overs, en speakercable
BOSCHMANN ALT 7s GIGA SERIE
Dimensions: 1inch Ø
System: Titanium Neodymium dome
Max/RMS power: 200W Max/ 60W RMS
Impedance: 4Ω
Freq. response: 3.000 Hz- 30.000Hz
Recommended amp: 5-135W RMS a channel
Sensitivity: 93 dB/W*m (SPL)
Incl.: connection requirements and speakercable
BOSCHMANN AV4200xt 2-way COMPO
Dimensions: Woofer 10cm Ø
Max power: 120W Max
BOSCHMANN AV5200xt 2-way COMPO
Dimensions: Woofer 13cm Ø
Max power: 150W Max
BOSCHMANN AV6200xt 2-way COMPO
Dimensions: Woofer 16.5cm Ø
Max power: 200W Max
Tweeter: 2.6cm/ 120W max
BOSCHMANN RV6200xt CLARITY SERIES
Dimensions: Woofer 6.5inch Ø
Tweeter 2inch / 4.8cm Ø
System: 2-way component kit
Max power: W-160W Max/ T-150W Max
Impedance: 4Ω
Freq. response: 50Hz- 25.000Hz
Sensitivity: 93 dB/W*m (SPL)
Mounting depth: 64.5mm depth
Incl.: 2-way cross-over, grill en speakercable

productfolder 29-4-2008
The design and specifications subject to change without notice.
BOSCHMANN MB6.2CTI CLARITY SERIES
Dimensions: Woofer 6.75inch / 17cm Ø
Tweeter 2inch / 4.8cm Ø
System: 2-way component kit
Max power: W-350W Max/ T-150W Max
Impedance: 4Ω
Freq. response: 60Hz- 25.000Hz
Sensitivity: 93 dB/W*m (SPL)
Magnet depth: 78mm depth
Incl.: 2-way cross-over, grill en speakercable
BOSCHMANN MB83CTI CLARITY SERIES
Dimensions: Woofer 8inch / 20cm Ø
midtone 4inch / 10cm Ø
Tweeter 1inch Ø
System: 3-way component kit
Max power: W-400W Max/ T-100W Max
Impedance: 4Ω
Freq. response: 40Hz- 22.000Hz
Sensitivity: 93 dB/W*m (SPL)
Incl.: 2-way cross-over, speakercable
BOSCHMANN 400-5star MID-TONE SPEAKERS
Dimensions: 4inch / 10cm Ø
Max/RMS power: 150W Max/ 50W RMS
BOSCHMANN 500-5star
Dimensions: 5.25inch / 13cm Ø
Max/RMS power: 180W Max/ 60W RMS
BOSCHMANN 600-5star
Dimensions: 6.5inch / 16.5cm Ø
Max/RMS power: 200W Max/ 65W RMS
BOSCHMANN EVO-45 MIDTONE SPEAKERS
Dimensions: 4inch / 10cm Ø
Max/RMS power: 100W Max/ 50W RMS
BOSCHMANN EVO-55
Dimensions: 5.25inch / 13cm Ø
Max/RMS power: 150W Max/ 60W RMS
BOSCHMANN EVO-65
Dimensions: 6.5inch / 16.5cm Ø
Max/RMS power: 200W Max/ 65W RMS
BOSCHMANN V-6ALX T RBO SERIES
Dimensions: 6.75inch / 17cm Ø
System: high power subwoofer set
Max/RMS power: 300W Max/ 150W RMS
Sensitivity: 93 dB
Freq. response: 50 Hz – 5000Hz
BOSCHMANN SYLB8 EXTREME SERIES
Dimensions: 8 inch / 20cm Ø
Max/RMS power: 350W Max
BOSCHMANN SYLB10 EXTREME SERIES
Dimensions: 10inch / 25cm Ø
Max/RMS power: 400W Max
BOSCHMANN SYLB12 EXTREME SERIES
Dimensions: 12inch / 30cm Ø
Max/RMS power: 450W Max
