Boss Audio Systems Chaos Exxtreme CX104DVC User manual

CX104DVC
10
CX104DVC
10
03

Box Volume : 1.0 Cu Ft
Port Frequency : 41 Hz
Port Diameter : 3 lnches
Port Length : 6 lnches
Box is given as internal air volume including driver displacement
Ported Enclosure
Frequency
CX104DVC Amplitude Response(dB/Hz)
Box Volume : 1.0 Cu Ft
Box is given as internal air volume including driver displacement
Sealed Enclosure
Recommended Enclosures
Frequency
Please note : Our recommended box volumes are given for
internal air requirements.
CX104DVC Amplitude Response(dB/Hz)
Sealed Enclosure
Ported Enclosure
39
43

36
1.0
5.945
1.216
1.424
0.148
1.8
94
600W/1200W
36
1.717
5.824
2.435
1.414
0.148
3.6
94
600W/1200W
36
1.029
6.191
1.235
1.565
0.148
7.2
94
600W/1200W
2 4 8
10” (254mm) Subwoofer
(600 Watts RMS Sealed Enclosure)
Not Use
2 ohms 4 ohms
8 ohms 4 ohms
Wiring
Please take every precaution to wire your DVC woofers
for the correct impedance
Not Used
+-+-
+
-
+
-
+-+-+-+
-
10” (254mm) BLACK POLY INJECTION CONE
BUTYL RUBBER SURROUND
DUAL 2” (51mm) HIGH TEMPERATURE KAPTON
VOICE COIL
1200 WATTS PEAK/600 WATTS RMS
FREQUENCY RESPONSE: 35 Hz-2.2 KHz
SENSITIVITY: 94dB (1 WATT/1 METER)
IMPEDANCE: DUAL 4 OHMS
MOUNTING DEPTH: 5-1/2” (140mm)
MOUNTING DIAMETER: 9-5/16” (236mm)
