MIDI Implementation
Model: DD-500
Date: September 28, 2017
Version: 2.00
1. Recognized data
Received messages are transmitted without change according to the "MIDI: MIDI IN->OUT" and "MIDI: USB IN->OUT" settings.
■Channel Voice Message
These messages are received if the "MIDI: Rx CHANNEL" setting matches the MIDI channel number of the incoming message.
●Control Change
○Bank Select
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H 00H
n = MIDI Channel Number: 0H –FH (0 - 15) 0=ch.1 15=ch.16
mm = Bank Number (MSB) : 00H - 02H ( 0 - 2)
* After this unit starts up, it operates with 00H as the bank number until a bank select message is received.
○Control Change Number #1～#31 (MSB), #33 - #63 (LSB), #64～#95
Status 2nd Byte 3rd Byte
BnH ccH vvH
n = MIDI Channel Number: 0H –FH (0 - 15) 0=ch.1 15=ch.16
cc = Control Change Number: 01H - 1FH (MSB), 20H - 3FH (LSB), 40H - 5FH (1 - 31, 32 - 63, 64-95)
vv = Value : 00H - 7FH (0 - 127)
* Recognized if "MIDI CC IN" = ON.
* Recognized if the "Assign: SRC" setting is CC#1--#31 or CC#64--#95.
Target value = (parameter min) + ((((cc value) - (act range low)) * (parameter range)) / ((act range High) - (act range Low)))
* When a CC# matching the CC# that is specified as "MIDI: EFFECT SW," "MIDI: EFFECT A," "MIDI: EFFECT B," "MIDI: TIME CC," "MIDI: FEEDBACK CC," "MIDI: E.LEVEL CC,"
"MIDI: TONE CC," "MIDI: MOD DEPTH CC," "MIDI: CTL1 CC," "MIDI: CTL2 CC," "MIDI: EXP CC," "MIDI: LOOP ON/OFF," "MIDI: LOOP REC/DUB,"
"MIDI: LOOP PLAY," "MIDI: LOOP STOP," "MIDI: LOOP CLEAR" is received, that controller is controlled.
* LSB (#33 - #63) is received when "TIME CC" set to CC #1 - #31
CC #1 - #31
MSB value = 0
Parameter value = parameter min
MSB value = 127
Parameter value = parameter max
Others
Parameter value = (((cc MSB+LSB value) * (parameter range)) / 16383)
cc MSB+LSB value = (MSB value) * 128 + (LSB value)
CC #64 - #95
Parameter value = (((cc value) * (parameter range)) / 127)
* "FEEDBACK CC," "E.LEVEL CC," "TONE CC," "MOD DEPTH CC"
Parameter value = (((cc value) * (parameter range)) / 127)
Parameter range = (parameter max) - (parameter min)
●Program Change
Status 2nd Byte
CnH ppH
n = MIDI Channel Number : 0H - FH (0 - 15) 0 = ch.1, 15 = ch.16
pp = Program Number : 00H - 7FH (0 - 127)
* This message switches to the patch that is specified by "MIDI PC MAP."
■System Realtime Messages
●Timing Clock
Status
F8H
* Recognized if the "MIDI: SYNC" setting is other than INTERNAL.

p. 2
●Active Sensing
Status
FEH
* When an Active Sensing message is received, the interval of all subsequent messages will begin to be monitored.
When the message interval is being monitored, and the interval exceeds 400 ms, the display indicates "MIDI OFFLINE" and the unit returns to a state in which message interval
is not monitored.
■System Exclusive Messages
Status Data Byte Status
F0H, iiH, dev, ddH, ..., eeH, F7H
Byte Explanation
F0H: System Exclusive Message status
iiH: ID number
41H: Roland's manufacturer ID
7EH: Universal Non-realtime message
dev: Device ID (dev: 00H-1FH, 7FH) * 7FH = Broadcast
dd,...,ee = data: 00H-7FH(0-127)
F7H: EOX (End of Exclusive)
●Universal Non-Realtime System Exclusive Messages
○Identity Request Message (Device Inquiry)
Status Data Byte Status
F0H, 7EH, dev, 06H, 01H, F7H
Byte Explanation
F0H: System Exclusive Message status
7EH: Universal Non-realtime Message
dev: Device ID (dev: 00H-1FH, 7FH) * 7FH = Broadcast
06H: Sub ID # 1 (General Information)
01H: Sub ID # 2 (Identity Request)
F7H: EOX (End of Exclusive)
When this message is received, this unit transmits the prescribed identity reply message (see transmitted data).
●One Way Communication
○Request Data 1 RQ1 (11H)
Status Data Byte Status
F0H, 41H, dev, 00H, 00H, 00H, 4DH, 11H, aaH, bbH, ccH, ddH, ssH, ttH, uuH, vvH, sum, F7H
Byte Explanation
F0H: System Exclusive Message status
41H: Manufacturer ID (Roland)
dev: Device ID (00H-1FH, 7FH) * 7FH = Broadcast
00H: Model ID # 1 (DD-500 Ver.2)
00H: Model ID # 2 (DD-500 Ver.2)
00H: Model ID # 3 (DD-500 Ver.2)
4DH: Model ID # 4 (DD-500 Ver.2)
11H: Command ID (RQ1)
aaH: Address MSB
bbH: Address
ccH: Address
ddH: Address LSB
ssH: Size MSB
ttH: Size
uuH: Size
vvH: Size LSB
sum: Checksum
F7H: EOX (End of Exclusive)

p. 3
○Data Set 1 DT1 (12H)
Status Data Byte Status
F0H, 41H, dev, 00H, 00H, 00H, 4DH, 12H, aaH, bbH, ccH, ddH, eeH, ... hhH, sum, F7H
Byte Explanation
F0H: System Exclusive Message status
41H: Manufacturer ID (Roland)
dev: Device ID (00H-1FH, 7FH) * 7FH = Broadcast
00H: Model ID # 1 (DD-500 Ver.2)
00H: Model ID # 2 (DD-500 Ver.2)
00H: Model ID # 3 (DD-500 Ver.2)
4DH: Model ID # 4 (DD-500 Ver.2)
12H: Command ID (DT1)
aaH: Address MSB
bbH: Address
ccH: Address
ddH: Address LSB
eeH: Data
:
ffH: Data
sum: Checksum
F7H: EOX (End of Exclusive)
2. Transmitted data
■Channel Voice Messages
* Set the channel voice message transmit MIDI channel number to "MIDI: Tx CHANNEL."
●Control Change
○Bank Select
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H 00H
n = MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
mm = Bank Number (MSB): 00H - 02H ( 0 - 2)
* If the "MIDI: PC OUT" setting is ON, this message is transmitted when you switch patches. If the "BANK SEL OUT" setting is MSB, only BnH 00H mmH (MSB) is transmitted.
○Control Change Number #1～#31 (MSB), #33-#63 (LSB)、#64～#95
Status 2nd Byte 3rd Byte
BnH ccH vvH
n = MIDI Channel Number: 0H - FH (0 - 15) 0=ch.1 15=ch.16
cc = Control Change Number: 01H - 1FH, 20H - 3FH, 40H - 5FH (1 - 31, 32 - 63, 64 - 95)
vv = Value : 00H - 7FH (0 - 127)
* Transmitted if "MIDI CC OUT" = ON.
* When you operate a controller, the CC# specified by "MIDI: EFFECT CC," "MIDI: EFFECT A," "MIDI: EFFECT B," "MIDI: TIME CC," "MIDI: FEEDBACK CC," "MIDI: E.LEVEL CC,"
"MIDI: TONE CC," "MIDI: MOD DEPTH CC," "MIDI: CTL1 CC," "MIDI: CTL2 CC," "MIDI: EXP CC" is transmitted.
* LSB (#33 - #63) is transmitted when "MIDI: TIME CC" set to CC #1 - #31
CC #1 - #31
Parameter value = min
vv (MSB) = 0
vv (LSB) = 0
Parameter value = max
vv (MSB) = 127
vv (LSB) = 127
Others
vv (MSB) = (((parameter value) * 16383) / (time range)) / 128
vv (LSB) = (((parameter value) * 16383) / (time range)) - (vv (MSB) * 128)
CC #64 - #9
vv = (((parameter value) * 127) / (time range))
* "FEEDBACK CC," "E.LEVEL CC," "TONE CC," "MOD DEPTH CC"
vv = (((parameter value) * 127) / (parameter range))
Parameter range = (parameter max) - (parameter min)

p. 4
●Program Change
Status 2nd Byte
CnH ppH
n = MIDI Channel Number: 0H - FH (0 - 15) 0 = ch.1 15 = ch.16
pp = Program Number: 00H - 7FH (0 - 127)
* If the "MIDI: PC OUT" setting is ON, this message is transmitted when you switch patches.
* Patch numbers correspond to program numbers as follows.
BANK SEL.
PATCH# MSB LSB PROG#
01A 00H 00H 00H
: :
43B 00H 00H 7FH
43C 01H 00H 00H
: :
86A 01H 00H 7FH
86B 02H 00H 00H
: :
99C 02H 00H 28H
■System Realtime Message
●Timing Clock
Status
F8H
* If both "MIDI: SYNC" = INTERNAL and "MIDI: REALTIME SRC" = INT, this message is transmitted at intervals corresponding to the tempo.
* If the "MIDI: REALTIME SRC" setting is other than INT, this message is transmitted when timing clock messages corresponding to the setting are received.
●Active Sensing
Status
FEH
* This message is always transmitted at intervals of approximately 250 ms.
■System Exclusive Message
Status Data Byte Status
F0H 41H, ddH, ..., eeH, F7H
Byte Explanation
F0H: System Exclusive Message status
41H: Roland's manufacturer ID
dd,...,ee = data: 00H-7FH(0-127)
F7H: EOX (End of Exclusive)
●Universal Non-realtime System Exclusive Message
○Identity Reply Message
Status Data Byte Status
F0H, 7EH, dev, 06H, 02H, 41H, 4DH, 03H, 00H, 00H, 00H, 00H, 00H, 01H, F7
Byte Explanation
F0H: System Exclusive Message status
7EH: ID Number (Universal Non-realtime Message)
dev: Device ID (dev: 00H - 1FH)
06H: Sub ID # 1 (General Information)
02H: Sub ID # 2 (Identity Reply)
41H: Roland's manufacturer ID
4DH: 03H Device family code # 1 (DD-500 Ver.2)
00H: 00H Device family code # 2 (DD-500 Ver.2)
00H: Software revision level # 1
00H: Software revision level # 2
00H: Software revision level # 3
01H: Software revision level # 4
F7H: EOX (End of Exclusive)
* This message is transmitted when an identity request message is received.

p. 5
●One Way Communication
○Data Set 1 DT1 (12H)
Status Data Byte Status
F0H, 41H, dev, 00H, 00H, 00H, 4DH, 12H, aaH, bbH, ccH, ddH, eeH, ... hhH, sum, F7H
Byte Explanation
F0H: System Exclusive Message status
41H: Roland's manufacturer ID
dev: Device ID (00H-1FH)
00H: Model ID # 1 (DD-500 Ver.2)
00H: Model ID # 2 (DD-500 Ver.2)
00H: Model ID # 3 (DD-500 Ver.2)
4DH: Model ID # 4 (DD-500 Ver.2)
12H: Command ID (DT1)
aaH: Address MSB
bbH: Address
ccH: Address
ddH: Address LSB
eeH: Data
:
ffH: Data
sum: Checksum
F7H: EOX (End of Exclusive)
3. System Exclusive Address Map
DD-500 Ver.2 (Model ID : 00H 00H 00H 4DH)
-----------------------------------------------------------------------------------------------------------------
|Start |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 00 00 | Setup
| 10 00 00 00 | System
| 20 00 00 00 | MIDI PC MAP
| 30 00 00 00 | BANK (Temporary)
| 30 04 00 00 | BANK (BANK 1)
| : | :
| 33 0C 00 00 | BANK (BANK 99)
-----------------------------------------------------------------------------------------------------------------
* Setup
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 00 | Setup Common
-----------------------------------------------------------------------------------------------------------------
* System
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 00 | System Common
| 00 10 00 | System CTL
-----------------------------------------------------------------------------------------------------------------
* MIDI PC MAP
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 00 | MIDI PC MAP
-----------------------------------------------------------------------------------------------------------------
* BANK
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 00 | BANK BANK
| 00 10 00 | BANK PATCH (patch A)
| 00 20 00 | BANK PATCH (patch B)
| 00 30 00 | BANK PATCH (patch C)
-----------------------------------------------------------------------------------------------------------------

p. 6
* Setup Common Parameters Offset Address
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 | 0000 000a | Current Patch Number (0 - 296)
| | | PATCH 01A - PATCH 99C
| | 0000 bbbb |
| | 0000 cccc |
-----------------------------------------------------------------------------------------------------------------
* System Common Parameters Offset Address
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 | 0000 00dd | Global Output Mode (0 - 2)
| | | STEREO, A:DIR B:EFX, DIRECT MUTE
| 00 01 | 0000 000d | Bank wait mode (0 - 1)
| | | WAIT, IMMEDIATE
|00 02 | 0ddd dddd | Bank Extent Begin (0 - 98)
| | | 01 - 99
| 00 03 | 0ddd dddd | Bank Extent End (0 - 98)
| | | 01 - 99
| 00 04 | 0000 000d | Global Knob Lock Switch (0 - 1)
| | | OFF, ON
|00 05 | 0000 000d | Global Knob Mode (0 - 1)
| | | IMMEDIATE, HOOK
| 00 06 | 0000 00dd | Phrase Loop Mode (0 - 2)
| | | 96k MONO, 48k ST, 48k MONO
| 00 07 | 0000 000d | Global Bypass Mode (0 - 1)
| | | BUFFERED, TRUE
| 00 08 | 0000 000d | Global Pedal Action (0 - 1)
| | | PUSH, RELEASE
|00 09 | 0000 0ddd | Foot Switch Hold Time (0 - 4)
| | | 1sec, 2sec, 3sec, 4sec, 5sec
| 00 0A | 0000 00dd | Foot Switch Mode (0 - 3)
| | | NORMAL, A/B/C, A/B SIMUL, SW DN/UP
| 00 0B | 0000 00dd | Global Display Type (0 - 3)
| | | DISP_TIME, DISP_BPM, DISP_PATCH, DISP_PARAM
| 00 0C | 000d dddd | MIDI Rx Channel (0 - 16)
| | | Ch.1, Ch.2, Ch.3, Ch.4, Ch.5, Ch.6, Ch.7, Ch.8, Ch.9, Ch.10, Ch.11, Ch.12, Ch.13, Ch.14, Ch.15,
| | | Ch.16, OFF
|00 0D | 000d dddd | MIDI Tx Channel (0 - 17)
| | | Ch.1, Ch.2, Ch.3, Ch.4, Ch.5, Ch.6, Ch.7, Ch.8, Ch.9, Ch.10, Ch.11, Ch.12, Ch.13, Ch.14, Ch.15,
| | | Ch.16, Rx, OFF
|00 0E | 0000 000d | MIDI Program Change IN (0 - 1)
| | | OFF, ON
| 00 0F | 0000 000d | MIDI Program Change OUT (0 - 1)
| | | OFF, ON
| 00 10 | 0000 000d | MIDI Bank Select OUT (0 - 1)
| | | MSB, M+L
|00 11 | 0000 000d | MIDI Control Change IN (0 - 1)
| | | OFF, ON
| 00 12 | 0000 000d | MIDI Control Change OUT (0 - 1)
| | | OFF, ON
| 00 13 | 00dd dddd | MIDI Effect A Control Change (0 - 63)
| | | OFF, CC#1, CC#2, CC#3, CC#4, CC#5, CC#6, CC#7, CC#8, CC#9, CC#10, CC#11, CC#12, CC#13, CC#14,
| | | CC#15, CC#16, CC#17, CC#18, CC#19, CC#20, CC#21, CC#22, CC#23, CC#24, CC#25, CC#26, CC#27, CC#28,
| | | CC#29, CC#30, CC#31, CC#64, CC#65, CC#66, CC#67, CC#68, CC#69, CC#70, CC#71, CC#72, CC#73, CC#74,
| | | CC#75, CC#76, CC#77, CC#78, CC#79, CC#80, CC#81, CC#82, CC#83, CC#84, CC#85, CC#86, CC#87, CC#88,
| | | CC#89, CC#90, CC#91, CC#92, CC#93, CC#94, CC#95 ……(*A)
| 00 14 | 00dd dddd | MIDI Effect B Control Change (*A)
| 00 15 | 00dd dddd | MIDI TAP/CTL Switch Control Change (*A)
| 00 16 | 00dd dddd | MIDI Feedback Control Change (*A)
| 00 17 | 00dd dddd | MIDI Effect Level Control Change (*A)
| 00 18 | 00dd dddd | MIDI Tone Control Change (*A)
| 00 19 | 00dd dddd | MIDI Mod Depth Control Change (*A)
| 00 1A | 00dd dddd | MIDI CTL1 Control Change (*A)
| 00 1B | 00dd dddd | MIDI CTL2 Control Change (*A)
| 00 1C | 00dd dddd | MIDI EXP Control Change (*A)
| 00 1D | 00dd dddd | MIDI EFFECT ON/OFF Control Change (*A)
| 00 1E | 00dd dddd | MIDI LOOPER ON/OFF Control Change (*A)
| 00 1F | 00dd dddd | MIDI LOOPER [REC/DUB] Control Change (*A)
| 00 20 | 00dd dddd | MIDI LOOPER [PLAY] Control Change (*A)

p. 7
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 21 | 00dd dddd | MIDI LOOPER [STOP] Control Change (*A)
| 00 22 | 00dd dddd | MIDI LOOPER [CLEAR] Control Change (*A)
| 00 23 | 0000 00dd | MIDI Sync (0 - 3)
| | | INTERNAL, EXT (USB), EXT (MIDI), AUTO
| 00 24 | 0000 00dd | MIDI source of realtime message to output (0 - 2)
| | | INT, USB, MIDI
| 00 25 | 0000 00dd | MIDI In THRU into Out (0 - 3)
| | | OFF, USB, MIDI, U+M
|00 26 | 0000 00dd | USB In THRU into Out (0 - 3)
| | | OFF, USB, MIDI, U+M
|00 27 | 0000 000d | effect sw (0 - 1) (*1)
| | | OFF, ON
| 00 28 | 0000 000d | effect sw2 (0 - 1) (*1)
| | | OFF, ON
| 00 29 | 0ddd dddd | LOOP Level (0 - 100)
| | | 0 - 100
|00 2A | 00dd dddd | MIDI Time Control Change (*A)
| 00 2B | 0000 000d | Feedback loop sw (0 - 1)
| | | OFF, ON
-----------------------------------------------------------------------------------------------------------------
* System CTL Parameters Offset Address
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 | 0000 000d | TAP/CTL preference (0 - 1)
| | | PATCH, SYSTEM
| 00 01 | 0000 dddd | TAP/CTL Function (0 - 9)
| | | OFF, TAP, HOLD, WARP, TWIST, MOMENT, ROLL 1/2, ROLL 1/4, ROLL 1/8, FADE
| 00 02 | 0000 000d | CTL1 preference (0 - 1)
| | | PATCH, SYSTEM
| 00 03 | 0000 dddd | CTL1 Function (0 - 14)
| | | OFF, TAP, HOLD, WARP, TWIST, MOMENTARY, ROLL 1/2, ROLL 1/4, ROLL 1/8, FADE, EFFECT SW, BANK UP,
| | | BANK DOWN, LOOPonOff,
| | | LOOP CLR
|00 04 | 0000 000d | CTL1 Mode (0 - 1)
| | | MOMENT, TOGGLE
| 00 05 | 0000 000d | CTL2 preference (0 - 1)
| | | PATCH, SYSTEM
| 00 06 | 0000 dddd | CTL2 Function (0 - 14)
| | | OFF, TAP, HOLD, WARP, TWIST, MOMENTARY, ROLL 1/2, ROLL 1/4, ROLL 1/8, FADE, EFFECT SW, BANK UP,
| | | BANK DOWN, LOOPonOff,
| | | LOOP CLR
|00 07 | 0000 000d | CTL2 Mode (0 - 1)
| | | MOMENT, TOGGLE
| 00 08 | 0000 000d | EXP preference (0 - 1)
| | | PATCH, SYSTEM
| 00 09 | 0000 0ddd | Exp Pedal Function (0 - 6)
| | | OFF, TIME, FEEDBACK, TONE, E.LEVEL, MOD DEPTH, MOD RATE
| 00 0A | 0000 0aaa | Exp target min (0 - 23000)
| | | 0 - 23000
|| 0000 bbbb |
| | 0000 cccc |
| | 0000 dddd |
| 00 0E | 0000 0aaa | Exp target max (0 - 23000)
| | | 0 - 23000
|| 0000 bbbb |
| | 0000 cccc |
| | 0000 dddd |
| 00 12 | 0000 000d | TAP/CTL Mode (0 - 1)
| | | MOMENT, TOGGLE
| 00 13 | 0ddd dddd | TAP/CTL Rise time (0 - 100)
| | | 0 - 100
|00 14 | 0ddd dddd | TAP/CTL Fall time (0 - 100)
| | | 0 - 100
|00 15 | 0ddd dddd | CTL1 Rise time (0 - 100)
| | | 0 - 100
|00 16 | 0ddd dddd | CTL1 Fall time (0 - 100)
| | | 0 - 100

p. 8
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
|00 17 | 0ddd dddd | CTL2 Rise time (0 - 100)
| | | 0 - 100
|00 18 | 0ddd dddd | CTL2 Fall time (0 - 100)
| | | 0 - 100
|00 19 | 0ddd dddd | TAP/CTL Hold level (0 - 120)
| | | 0 - 120
|00 1A | 0ddd dddd | TAP/CTL Warp level (0 - 120)
| | | 0 - 120
|00 1B | 0ddd dddd | TAP/CTL Twist level (0 - 120)
| | | 0 - 120
|00 1C | 0ddd dddd | CTL1 Hold level (0 - 120)
| | | 0 - 120
|00 1D | 0ddd dddd | CTL1 Warp level (0 - 120)
| | | 0 - 120
|00 1E | 0ddd dddd | CTL1 Twist level (0 - 120)
| | | 0 - 120
|00 1F | 0ddd dddd | CTL2 Hold level (0 - 120)
| | | 0 - 120
|00 20 | 0ddd dddd | CTL2 Warp level (0 - 120)
| | | 0 - 120
|00 21 | 0ddd dddd | CTL2 Twist level (0 - 120)
| | | 0 - 120
-----------------------------------------------------------------------------------------------------------------
* MIDI PC MAP Parameters Offset Address
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 | 0000 000a | BANK: #1 PC: #001 (0 - 296)
| | | PATCH 01A - PACH 99C ……(*B)
| | 0000 bbbb |
| | 0000 cccc |
| 00 03 | 0000 000a | BANK: #1 PC: #002 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| 00 06 | 0000 000a | BANK: #1 PC: #003 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| 00 09 | 0000 000a | BANK: #1 PC: #004 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| 00 0C | 0000 000a | BANK: #1 PC: #005 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| 00 0F | 0000 000a | BANK: #1 PC: #006 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| : | :
| : | :
| 00 7E | 0000 000a | BANK: #1 PC: #043 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| 01 01 | 0000 000a | BANK: #1 PC: #044 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| : | :
| : | :
| 01 7F | 0000 000a | BANK: #1 PC: #086 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| 02 02 | 0000 000a | BANK: #1 PC: #087 (*B)
|| 0000 bbbb |
| | 0000 cccc |
| : | :
| : | :
| 02 7D | 0000 000a | BANK: #1 PC: #128 (*B)
| | 0000 bbbb |
| | 0000 cccc |

p. 9
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 03 00 | 0000 000a | BANK: #2 PC: #001 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| : | :
| : | :
| 05 7D | 0000 000a | BANK: #2 PC: #128 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| 06 00 | 0000 000a | BANK: #3 PC: #001 (*B)
| | 0000 bbbb |
| | 0000 cccc |
| : | :
| : | :
| 08 7D | 0000 000a | BANK: #3 PC: #128 (*B)
| | 0000 bbbb |
| | 0000 cccc |
-----------------------------------------------------------------------------------------------------------------
* BANK BANK Parameters Offset Address
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 | 0000 000d | Structure (0 - 1)
| | | SERIES, PARALLEL
| 00 01 | 0000 000d | Output mode (0 - 1)
| | | MIX, A/B
|00 02 | 0000 000d | Sync (0 - 1)
| | | OFF, ON
| 00 03 | 0000 00dd | Feedback loop select (0 - 2)
| | | OFF, PATCH A, PATCH B
|00 04 | 0000 aaaa | Direct level adjust (0 - 150)
| | | 50% - 200%
| | 0000 bbbb |
-----------------------------------------------------------------------------------------------------------------
* BANK PATCH Parameters Offset Address
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 00 | 0ddd dddd | Patch Name1 (32 - 126)
| | | 32 - 126 [ASCII]
|00 01 | 0ddd dddd | Patch Name2 (32 - 126)
| | | 32 - 126 [ASCII]
|: | :
| : | :
| 00 0F | 0ddd dddd | Patch Name16 (32 - 126)
| | | 32 - 126 [ASCII]
|00 10 | 0000 dddd | Delay MODE (0 - 11)
| | | STANDARD, TERA ECHO, SLOW ATTACK, FILTER, SHIMMER, SFX, REVERSE, PATTERN, DUAL, VINT. DIGITAL,
| | | TAPE, ANALOG
| 00 11 | 0000 00aa | Delay Time (1 - 10000)
| | | 1ms - 10.0s
| | 0000 bbbb |
| | 0000 cccc |
| | 0000 dddd |
| 00 15 | 0000 00aa | BPM (15 - 2400000)
| | | Quarter Note=1.5 -=240000.0
|| 0000 bbbb |
| | 0000 cccc |
| | 0000 dddd |
| | 0000 eeee |
| | 0000 ffff |
| 00 1B | 0000 dddd | Note (0 - 12)
| | | 16th, 8th triplet, dotted 16th, 8th, quarter triplet, dotted 8th, quarter, half triplet,
| | | dotted quarter, half, whole triplet, dotted half, whole
|00 1C | 0ddd dddd | Feedback (0 - 100)
| | | 0 - 100
|00 1D | 0ddd dddd | Tone (0 - 100)
| | | -50 - +50

p. 10
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
|00 1E | 0ddd dddd | Effect Level (0 - 120)
| | | 0 - 120
|00 1F | 0ddd dddd | Direct Level (0 - 100)
| | | 0 - 100
|00 20 | 0ddd dddd | Modulation Depth (0 - 100)
| | | 0 - 100
|00 21 | 0ddd dddd | Modulation Rate (0 - 113)
| | | 0 - 100, whole, dotted half, whole triplet, half, dotted quarter, triplet half, quarter,
| | | dotted 8th, triplet quarter,
| | | 8th, dotted 16th, triplet 8th, 16th
| 00 22 | 0000 000d | Carryover OFF/ON (0 - 1)
| | | OFF, ON
| 00 23 | 0000 00dd | EQ ON/OFF (0 - 3)
| | | OFF, PRE, FEEDBACK LOOP, POST
| 00 24 | 00dd dddd | EQ Total Level (0 - 40)
| | | -20dB - +20dB
|00 25 | 000d dddd | EQ Low Cut Filter Freq (0 - 17)
| | | FLAT, 20.0Hz, 25.0Hz, 31.5Hz, 40.0Hz, 50.0Hz, 63.0Hz, 80.0Hz, 100Hz, 125Hz, 160Hz, 200Hz, 250Hz,
| | | 315Hz, 400Hz, 500Hz, 630Hz, 800Hz
|00 26 | 00dd dddd | EQ Low Gain (0 - 40)
| | | -20dB - +20dB
|00 27 | 00dd dddd | EQ Low Mid Gain (0 - 40)
| | | -20dB - +20dB
|00 28 | 000d dddd | EQ Low Mid Freq (0 - 27)
| | | 20.0Hz, 25.0Hz, 31.5Hz, 40.0Hz, 50.0Hz, 63.0Hz, 80.0Hz, 100Hz, 125Hz, 160Hz, 200Hz, 250Hz, 315Hz,
| | | 400Hz, 500Hz, 630Hz, 800Hz, 1.00kHz, 1.25kHz, 1.60kHz, 2.00kHz, 2.50kHz, 3.15kHz, 4.00kHz,
| | | 5.00kHz, 6.30kHz, 8.00kHz, 10.0kHz
| 00 29 | 0000 0ddd | EQ Low Mid Q (0 - 5)
| | | 0.5, 1, 2, 4, 8, 16
| 00 2A | 00dd dddd | EQ High Mid Gain (0 - 40)
| | | -20dB - +20dB
|00 2B | 000d dddd | EQ High Mid Freq (0 - 27)
| | | 20.0Hz, 25.0Hz, 31.5Hz, 40.0Hz, 50.0Hz, 63.0Hz, 80.0Hz, 100Hz, 125Hz, 160Hz, 200Hz, 250Hz, 315Hz,
| | | 400Hz, 500Hz, 630Hz, 800Hz, 1.00kHz, 1.25kHz, 1.60kHz, 2.00kHz, 2.50kHz, 3.15kHz, 4.00kHz,
| | | 5.00kHz, 6.30kHz, 8.00kHz, 10.0kHz
| 00 2C | 0000 0ddd | EQ High Mid Q (0 - 5)
| | | 0.5, 1, 2, 4, 8, 16
| 00 2D | 00dd dddd | High EQ Gain (0 - 40)
| | | -20dB - +20dB
|00 2E | 0000 dddd | High Cut Filter Freq (0 - 15)
| | | 630Hz, 800Hz, 1.00kHz, 1.25kHz, 1.60kHz, 2.00kHz, 2.50kHz, 3.15kHz, 4.00kHz, 5.00kHz, 6.30kHz,
| | | 8.00kHz, 10.0kHz, 12.5kHz, 16.0kHz, FLAT
| 00 2F | 000d dddd | Low DAMP (0 - 20)
| | | -20dB - +0dB
| 00 30 | 000d dddd | Low DAMP FREQ (0 - 16)
| | | 20.0Hz, 25.0Hz, 31.5Hz, 40.0Hz, 50.0Hz, 63.0Hz, 80.0Hz, 100Hz, 125Hz, 160Hz, 200Hz, 250Hz, 315Hz,
| | | 400Hz, 500Hz, 630Hz, 800Hz
|00 31 | 000d dddd | Hi Damp GAIN (0 - 20)
| | | -20dB - +0dB
| 00 32 | 0000 dddd | Hi Damp FREQ (0 - 14)
| | | 630Hz, 800Hz, 1.00kHz, 1.25kHz, 1.60kHz, 2.00kHz, 2.50kHz, 3.15kHz, 4.00kHz, 5.00kHz, 6.30kHz,
| | | 8.00kHz, 10.0kHz, 12.5kHz, 16.0kHz
| 00 33 | 0ddd dddd | DUCK Sens (0 - 100)
| | | 0 - 100
|00 34 | 0ddd dddd | DUCK Pre Depth (0 - 100)
| | | 0 - 100
|00 35 | 0ddd dddd | DUCK Post Depth (0 - 100)
| | | 0 - 100
|00 36 | 0ddd dddd | Effect Pan (0 - 100)
| | | L50 - CENTER - R50
|00 37 | 0ddd dddd | Direct Pan (0 - 100)
| | | L50 - CENTER - R50
|00 38 | 0000 dddd | TAP/CTL Function (0 - 9)
| | | OFF, TAP, HOLD, WARP, TWIST, MOMENT, ROLL 1/2, ROLL 1/4, ROLL 1/8, FADE
| 00 39 | 0000 dddd | CTL1 Function (0 - 14)
| | | OFF, TAP, HOLD, WARP, TWIST, MOMENTARY, ROLL 1/2, ROLL 1/4, ROLL 1/8, FADE, EFFECT SW, BANK UP,
| | | BANK DOWN, LOOPonOff, LOOP CLR
|00 3A | 0000 000d | CTL1 Mode (0 - 1)
| | | MOMENT, TOGGLE

p. 11
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 3B | 0000 dddd | CTL2 Function (0 - 14)
| | | OFF, TAP, HOLD, WARP, TWIST, MOMENTARY, ROLL 1/2, ROLL 1/4, ROLL 1/8, FADE, EFFECT SW, BANK UP,
| | | BANK DOWN, LOOPonOff, LOOP CLR
|00 3C | 0000 000d | CTL2 Mode (0 - 1)
| | | MOMENT, TOGGLE
| 00 3D | 0000 0ddd | Exp Pedal Function (0 - 6)
| | | OFF, TIME, FEEDBACK, TONE, E.LEVEL, MOD DEPTH, MOD RATE
| 00 3E | 0000 00aa | Exp target min (0 - 10000)
| | | 0 - 10000
|| 0000 bbbb |
| | 0000 cccc |
| | 0000 dddd |
| 00 42 | 0000 00aa | Exp target max (0 - 10000)
| | | 0 - 10000
|| 0000 bbbb |
| | 0000 cccc |
| | 0000 dddd |
| 00 46 | 0000 000d | ASSIGN1 sw (0 - 1)
| | | OFF, ON
| 00 47 | 0ddd dddd | ASSIGN1 source (0 - 69)
| | | TAP/CTL, EXP PDL, CTL1 PDL, CTL2 PDL, INT PDL, WAVE PDL, INPUT, CC#1, CC#2, CC#3, CC#4, CC#5,
| | | CC#6, CC#7, CC#8, CC#9, CC#10, CC#11, CC#12, CC#13, CC#14, CC#15, CC#16, CC#17, CC#18, CC#19,
| | | CC#20, CC#21, CC#22, CC#23, CC#24, CC#25, CC#26, CC#27, CC#28, CC#29, CC#30, CC#31, CC#64, CC#65,
| | | CC#66, CC#67, CC#68, CC#69, CC#70, CC#71, CC#72, CC#73, CC#74, CC#75, CC#76, CC#77, CC#78, CC#79,
| | | CC#80, CC#81, CC#82, CC#83, CC#84, CC#85, CC#86, CC#87, CC#88, CC#89, CC#90, CC#91, CC#92, CC#93,
| | | CC#94, CC#95
|00 48 | 0000 000d | ASSIGN1 source mode (0 - 1)
| | | MOMENT, TOGGLE
| 00 49 | 0000 aaaa | ASSIGN1 target (0 - 205)
| | | EFFECT SW, MODE, TIME, BPM, NOTE, FEEDBACK, TONE, EFFECT LEVEL, FEEDBACK DAMP, MOD DEPTH,
| | | MOD RATE, MOD MODE, CARRYOVER, DIRECT LEVEL, INPUT LEVEL, EQ SW, EQ LEVEL, EQ LO.CUT, EQ LO.GAIN,
| | | EQ LM.GAIN, EQ LM.FREQ, EQ LM.Q, EQ HM.GAIN, EQ HM.FREQ, EQ HM.Q, EQ HI.GAIN, EQ HI.CUT, LO DAMP,
| | | LO DAMP F, HI DAMP, HI DAMP F, DUCK SENS, DUCK PreDepth, DUCK PostDepth, EFFECT PAN, DIRECT PAN,
| | | TERA RESO, TERA EQ SW, SLOW TRG, SLOW SENS, SLOW RISE TIME, SLOW CURVE, FILTER MODE, LFO TYPE,
| | | LFO RATE, LFO DEPTH, FILTER TYPE, CUTOFF, RESONANCE, FILTER POS, TOUCH POLARITY, TOUCH SENS,
| | | TOUCH PEAK, TOUCH FREQ, TOUCH DECAY, SHIMMER TYPE, PITCH MODE, PS CHAR, PITCH SHIFT, PITCH FINE,
| | | PITCH2 SHIFT, PITCH2 FINE, PITCH BAL, DIRECT FB, PITCH FB, PITCH2 FB, PITCH RISE, OVERTONE UPR,
| | | OVERTONE LWR, OVERTONE DIR, SFX TYPE, SFX LOFI BIT, SFX LOFI RATE, SFX LOFI BAL, SFX TREM WAVE,
| | | SFX TREM RATE, SFX TREM DEPTH, SFX TREM POS, SFX PHSR RATE, SFX PHSR DEPTH, SFX PHSR RESO,
| | | SFX PHSR MANU, PATTERN NOTE, PATTERN TYPE, PATTERN, DELAY1 TIME, DELAY1 LEVEL, DELAY1 PAN,
| | | DELAY2 TIME, DELAY2 LEVEL, DELAY2 PAN, DELAY3 TIME, DELAY3 LEVEL, DELAY3 PAN, DELAY4 TIME,
| | | DELAY4 LEVEL, DELAY4 PAN, DELAY5 TIME, DELAY5 LEVEL, DELAY5 PAN, DELAY6 TIME, DELAY6 LEVEL,
| | | DELAY6 PAN, DELAY7 TIME, DELAY7 LEVEL, DELAY7 PAN, DELAY8 TIME, DELAY8 LEVEL, DELAY8 PAN,
| | | DELAY9 TIME, DELAY9 LEVEL, DELAY9 PAN, DELAY10 TIME, DELAY10 LEVEL, DELAY10 PAN, DELAY11 TIME,
| | | DELAY11 LEVEL, DELAY11 PAN, DELAY12 TIME, DELAY12 LEVEL, DELAY12 PAN, DELAY13 TIME, DELAY13 LEVEL,
| | | DELAY13 PAN, DELAY14 TIME, DELAY14 LEVEL, DELAY14 PAN, DELAY15 TIME, DELAY15 LEVEL, DELAY15 PAN,
| | | DELAY16 TIME, DELAY16 LEVEL, DELAY16 PAN, PATTERN STEP, STEP1 LEN, STEP1 LEVEL, STEP2 LEN,
| | | STEP2 LEVEL, STEP3 LEN, STEP3 LEVEL, STEP4 LEN, STEP4 LEVEL, STEP5 LEN, STEP5 LEVEL, STEP6 LEN,
| | | STEP6 LEVEL, STEP7 LEN, STEP7 LEVEL, STEP8 LEN, STEP8 LEVEL, STEP9 LEN, STEP9 LEVEL, STEP10 LEN,
| | | STEP10 LEVEL, STEP11 LEN, STEP11 LEVEL, STEP12 LEN, STEP12 LEVEL, STEP13 LEN, STEP13 LEVEL,
| | | STEP14 LEN, STEP14 LEVEL, STEP15 LEN, STEP15 LEVEL, STEP16 LEN, STEP16 LEVEL, STEP17 LEN,
| | | STEP17 LEVEL, STEP18 LEN, STEP18 LEVEL, STEP19 LEN, STEP19 LEVEL, STEP20 LEN, STEP20 LEVEL,
| | | STEP21 LEN, STEP21 LEVEL, STEP22 LEN, STEP22 LEVEL, STEP23 LEN, STEP23 LEVEL, STEP24 LEN,
| | | STEP24 LEVEL, DUAL MODE, D1 TYPE, D1 E.LEVEL, DUAL LINK, D2 TYPE, D2 TIME, D2 FEEDBACK,
| | | D2 TIME LINK, D2 FB LINK, D2 E.LEVEL, V. DIGI TYPE, FILTER, TIMEx2, DELAY PHASE, FEEDBACK PHASE,
| | | TAPE TYPE, TAPE WOW&FLUTR, TAPE HEAD, EchoR HEAD, EchoR SELECTOR, TAPE MOD RATE, STAGE,
| | | FEEDBACK LP, TAP/CTL LED
|| 0000 bbbb |
| 00 4B | 0000 00aa | ASSIGN1 target min (0 - 2400000)
| | | 0 - 2400000
|| 0000 bbbb |
| | 0000 cccc |
| | 0000 dddd |
| | 0000 eeee |
| | 0000 ffff |

p. 12
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 00 51 | 0000 00aa | ASSIGN1 target max (0 - 2400000)
| | | 0 - 2400000
|| 0000 bbbb |
| | 0000 cccc |
| | 0000 dddd |
| | 0000 eeee |
| | 0000 ffff |
| 00 57 | 0ddd dddd | ASSIGN1 Active Range LO (0 - 126)
| | | 0 - 126
|00 58 | 0ddd dddd | ASSIGN1 Active Range HI (1 - 127)
| | | 1 - 127
|00 59 | 0ddd dddd | ASSIGN1 Wave Rate (0 - 113)
| | | 0 - 100, whole, dotted half, whole triplet, half, dotted quarter, triplet half, quarter,
| | | dotted 8th, triplet quarter, 8th, dotted 16th, triplet 8th, 16th
| 00 5A | 0000 00dd | ASSIGN1 Wave Form (0 - 2)
| | | SAW, TRI, SIN
|00 5B | 0ddd dddd | ASSIGN1 Internal Pedal Trigger (0 - 68)
| | | PAT CNG, EXP LO, EXP MID, EXP HI, CTL1 PDL, CTL2 PDL, CC#1, CC#2, CC#3, CC#4, CC#5, CC#6, CC#7,
| | | CC#8, CC#9, CC#10, CC#11, CC#12, CC#13, CC#14, CC#15, CC#16, CC#17, CC#18, CC#19, CC#20, CC#21,
| | | CC#22, CC#23, CC#24, CC#25, CC#26, CC#27, CC#28, CC#29, CC#30, CC#31, CC#64, CC#65, CC#66, CC#67,
| | | CC#68, CC#69, CC#70, CC#71, CC#72, CC#73, CC#74, CC#75, CC#76, CC#77, CC#78, CC#79, CC#80, CC#81,
| | | CC#82, CC#83, CC#84, CC#85, CC#86, CC#87, CC#88, CC#89, CC#90, CC#91, CC#92, CC#93, CC#94, CC#95
|00 5C | 0ddd dddd | ASSIGN1 Internal Pedal Time (0 - 100)
| | | 0 - 100
|00 5D | 0000 00dd | ASSIGN1 Internal Pedal Curve (0 - 2)
| | | LINEAR, SLOW, FAST
| 00 5E | 0000 000d | ASSIGN2 sw (0 - 1)
| | | OFF, ON
| : | : |
| : | : |
| 00 76 | 0000 000d | ASSIGN3 sw (0 - 1)
| | | OFF, ON
| : | : |
| : | : |
| 01 0E | 0000 000d | ASSIGN4 sw (0 - 1)
| | | OFF, ON
| : | : |
| : | : |
| 01 26 | 0000 000d | ASSIGN5 sw (0 - 1)
| | | OFF, ON
| : | : |
| : | : |
| 01 3E | 0000 000d | ASSIGN6 sw (0 - 1)
| | | OFF, ON
| : | : |
| : | : |
| 01 56 | 0000 000d | ASSIGN7 sw (0 - 1)
| | | OFF, ON
| : | : |
| : | : |
| 01 6E | 0000 000d | ASSIGN8 sw (0 - 1)
| | | OFF, ON
| : | : |
| : | : |
| 02 06 | 0ddd dddd | Assign Input Sens (0 - 100)
| | | 0 - 100
|02 07 | 0000 000d | LED status (0 - 1) (*2)
| | | OFF, ON
| 02 08 | 0ddd dddd | Input level (0 - 100)
| | | 0 - 100
|02 09 | 0ddd dddd | Tera Echo Resonance (0 - 100)
| | | 0 - 100
|02 0A | 0ddd dddd | Slow Attack Sens (0 - 100)
| | | 0 - 100
|02 0B | 0ddd dddd | Slow Attack Rise Time (0 - 100)
| | | 0 - 100
|02 0C | 0000 00dd | Filter LFO Type (0 - 2)
| | | TRI, SIN, SQR
|02 0D | 0ddd dddd | Filter LFO Rate (0 - 113)
| | | 0 - 100, whole, dotted half, whole triplet, half, dotted quarter, triplet half, quarter,
| | | dotted 8th, triplet quarter, 8th, dotted 16th, triplet 8th, 16th

p. 13
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 02 0E | 0ddd dddd | Filter LFO Depth (0 - 100)
| | | 0 - 100
|02 0F | 0000 00dd | Filter Type (0 - 2)
| | | LPF, BPF, HPF
|02 10 | 000d dddd | Filter Cutoff Frequency (0 - 19)
| | | 100Hz, 125Hz, 160Hz, 200Hz, 250Hz, 315Hz, 400Hz, 500Hz, 630Hz, 800Hz, 1.00kHz, 1.25kHz, 1.60kHz,
| | | 2.00kHz, 2.50kHz, 3.15kHz, 4.00kHz, 5.00kHz, 6.30kHz, 8.00kHz, 10.0kHz
| 02 11 | 0ddd dddd | Filter Resonance (0 - 100)
| | | 0 - 100
|02 12 | 0000 000d | Filter Position (0 - 1)
| | | PRE, POST
| 02 13 | 00dd dddd | Pitch Pitch (0 - 48)
| | | -24 - +24
|02 14 | 0ddd dddd | Pitch Pitch Fine (0 - 100)
| | | -50 - +50
|02 15 | 0ddd dddd | Pitch/Direct Balance (0 - 100)
| | | 0 - 100
|02 16 | 0ddd dddd | Direct Feedback (0 - 100)
| | | 0% - 100%
| 02 17 | 0000 dddd | SFX LoFi Bit Depth (0 - 15)
| | | OFF, 15, 14, 13, 12, 11, 10, 9, 8, 7, 6, 5, 4, 3, 2, 1
|02 18 | 000d dddd | SFX LoFi Sample Rate (0 - 31)
| | | OFF, 1/2, 1/3, 1/4, 1/5, 1/6, 1/7, 1/8, 1/9, 1/10, 1/11, 1/12, 1/13, 1/14, 1/15, 1/16, 1/17, 1/18,
| | | 1/19, 1/20, 1/21, 1/22, 1/23, 1/24, 1/25, 1/26, 1/27, 1/28, 1/29, 1/30, 1/31, 1/32
| 02 19 | 0ddd dddd | SFX LoFi Balance (0 - 100)
| | | 0 - 100
|02 1A | 0ddd dddd | SFX Tremolo Wave (0 - 100)
| | | 0 - 100
|02 1B | 0ddd dddd | SFX Tremolo Rate (0 - 113)
| | | 0 - 100, whole, dotted half, whole triplet, half, dotted quarter, triplet half, quarter,
| | | dotted 8th, triplet quarter, 8th, dotted 16th, triplet 8th, 16th
| 02 1C | 0ddd dddd | SFX Tremolo Depth (0 - 100)
| | | 0 - 100
|02 1D | 0000 000d | SFX Tremolo Position (0 - 1)
| | | PRE, POST
| 02 1E | 0000 dddd | Pattern (0 - 10)
| | | PAT1, PAT2, PAT3, PAT4, PAT5, PAT6, PAT7, PAT8, PAT9, PAT10, USER
| 02 1F | 0000 aaaa | Delay1 Delay Time (0 - 188)
| | | 0% - 100%, 0/16 - 16/16, 0/12 - 12/12, 0/32 - 32/32, 0/24 - 24/24
| | 0000 bbbb |
| 02 21 | 0ddd dddd | Delay1 Level (0 - 100)
| | | 0 - 100
|02 22 | 0ddd dddd | Delay1 Pan (0 - 100)
| | | L50 - CENTER - R50
|02 23 | 0000 aaaa | Delay2 Delay Time (0 - 188)
| | | 0% - 100%, 0/16 - 16/16, 0/12 - 12/12, 0/32 - 32/32, 0/24 - 24/24
| | 0000 bbbb |
| : | : |
| : | : |
| 02 5D | 0ddd dddd | Delay16 Level (0 - 100)
| | | 0 - 100
|02 5E | 0ddd dddd | Delay16 Pan (0 - 100)
| | | L50 - CENTER - R50
|02 5F | 0000 dddd | PATTERN NOTE (0 - 12)
| | | 16th, 8th triplet, dotted 16th, 8th, quarter triplet, dotted 8th, quarter, half triplet,
| | | dotted quarter, half, whole triplet, dotted half, whole
|02 60 | 0000 0ddd | Dual Mode (0 - 4)
| | | SERIES, PARALLEL, A/B, A/B SERIS, A/B PARA
| 02 61 | 0000 00dd | Dual D1 Type (0 - 2)
| | | STANDARD, ANALOG, TAPE
| 02 62 | 0ddd dddd | Dual D1 Effect Level (0 - 100)
| | | 0 - 100
|02 63 | 0000 000d | Dual Link (0 - 1)
| | | OFF, ON
| 02 64 | 0000 000a | Dual D2 Time (1 - 5000)
| | | 1 - 5000
| | 0000 bbbb |
| | 0000 cccc |
| | 0000 dddd |
| 02 68 | 0ddd dddd | Dual D2 Time (LINK=ON) (1 - 100)
| | | 1% - 100%

p. 14
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
| 02 69 | 0ddd dddd | Dual D2 Feedback (0 - 100)
| | | 0 - 100
|02 6A | 0ddd dddd | Dual D2 Feedback (LINK=ON) (0 - 100)
| | | 0% - 100%
| 02 6B | 0ddd dddd | Dual D2 Effect Level (0 - 100)
| | | 0 - 100
|02 6C | 0000 00dd | Vintage Type (0 - 2)
| | | SDE-2000, SDE-3000, DD-2
|02 6D | 0000 000d | Vintage Filter Switch (0 - 1)
| | | OFF, ON
| 02 6E | 0000 000d | Vintage TIME x 2 Switch (0 - 1)
| | | OFF, ON
| 02 6F | 0000 00dd | Tape Type (0 - 2)
| | | RE-201, EchoP, EchoR
|02 70 | 0000 00dd | Analog Stage (0 - 2)
| | | 4096, 4096x2, 4096x4
| 02 71 | 0000 000d | Vintage Delay Phase (0 - 1)
| | | NOR, INV
|02 72 | 0000 000d | Vintage Feedback Phase (0 - 1)
| | | NOR, INV
|02 73 | 0000 0ddd | Tape Number of Head (0 - 6)
| | | 1, 2, 3, 1+2, 1+3, 2+3, 1+2+3
|02 74 | 0000 dddd | Feedback damp (0 - 10)
| | | 0 - 10
| 02 75 | 0000 000d | Slow attack target (0 - 1)
| | | EFFECT, ALL
|02 76 | 0ddd dddd | Slow attack curve (0 - 100)
| | | -50 - +50
|02 77 | 0000 000d | Filter Mode (0 - 1)
| | | AUTO, TOUCH
|02 78 | 0000 000d | Filter touch polarity (0 - 1)
| | | DOWN, UP
| 02 79 | 0000 aaaa | Filter touch sens (0 - 200)
| | | -100 - 100
|| 0000 bbbb |
| 02 7B | 0ddd dddd | Filter touch peak (0 - 100)
| | | 0 - 100
|02 7C | 0ddd dddd | Filter touch fequency (0 - 100)
| | | 0 - 100
|02 7D | 0ddd dddd | Filter touch decay (0 - 100)
| | | 0 - 100
|02 7E | 0000 dddd | Shimmer rise time (0 - 10)
| | | 0 - 10
| 02 7F | 0000 000d | Shimmer type (0 - 1)
| | | PITCH, OVERTONE
| 03 00 | 0ddd dddd | Shimmer overtone upper (0 - 100)
| | | 0 - 100
|03 01 | 0ddd dddd | Shimmer overtone lower (0 - 100)
| | | 0 - 100
|03 02 | 0ddd dddd | Shimmer overtone direct (0 - 100)
| | | 0 - 100
|03 03 | 0000 000d | Shimmer pitch shifter mode (0 - 1)
| | | MONO, STEREO
| 03 04 | 0ddd dddd | Shimmer pitch shifter feedback (0 - 100)
| | | 0 - 100
|03 05 | 0ddd dddd | Shimmer pitch shifter2 feedback (0 - 100)
| | | 0 - 100
|03 06 | 00dd dddd | Shimmer Pitch2 Pitch (0 - 48)
| | | -24 - +24
|03 07 | 0ddd dddd | Shimmer Pitch2 Pitch Fine (0 - 100)
| | | -50 - +50
|03 08 | 0000 000d | Shimmer Pitch shifter character (0 - 1)
| | | 1 - 2
|03 09 | 0000 000d | SFX type (0 - 1)
| | | TREMOLO, PHASER
| 03 0A | 0ddd dddd | SFX phaser rate (0 - 113)
| | | 0 - 100, whole, dotted half, whole triplet, half, dotted quarter, triplet half, quarter,
| | | dotted 8th, triplet quarter, 8th, dotted 16th, triplet 8th, 16th
|03 0B | 0ddd dddd | SFX phaser depth (0 - 100)
| | | 0 - 100

p. 15
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
|03 0C | 0ddd dddd | SFX phaser resonance (0 - 100)
| | | 0 - 100
|03 0D | 0ddd dddd | SFX phaser manual (0 - 100)
| | | 0 - 100
|03 0E | 0000 000d | Pattern type (0 - 1)
| | | DELAY, GATE
| 03 0F | 0000 00dd | Pattern Step number (0 - 3)
| | | 8, 12, 16, 24
| 03 10 | 0ddd dddd | Pattern STEP1 length (0 - 100)
| | | 0 - 100
|03 11 | 0ddd dddd | Pattern STEP1 Level (0 - 100)
| | | 0 - 100
| : | : |
| : | : |
|03 3E | 0ddd dddd | Pattern STEP24 length (0 - 100)
| | | 0 - 100
|03 3F | 0ddd dddd | Pattern STEP24 Level (0 - 100)
| | | 0 - 100
|03 40 | 0000 00dd | Dual D2 Type (0 - 2)
| | | STANDARD, ANALOG, TAPE
| 03 41 | 0ddd dddd | Tape wow and flutter (0 - 100)
| | | 0 - 100
|03 42 | 0ddd dddd | Tape Modulation rate (0 - 100)
| | | 0 - 100
|03 43 | 0000 dddd | TAPE EchoR head (0 - 11)
| | | 1, 2, 3, 4, 1+2, 2+3, 3+4, 1+3, 2+4, 1+2+3, 2+3+4, 1+2+3+4
|03 44 | 0000 00dd | TAPE EchoR selector (0 - 2)
| | | ECHO, REPEAT, SWELL
|03 45 | 0000 000d | Modulation mode (0 - 1)
| | | SINGLE, BI-PHASE
|03 46 | 0000 000d | Input mode (0 - 1)
| | | A/B, MIX
|03 47 | 0000 000d | Tempo hold (0 - 1)
| | | OFF, ON
| 03 48 | 0000 dddd | Output gain (0 - 12)
| | | -6dB - +6dB
| 03 49 | 0000 000d | Feedback loop sw (0 - 1)
| | | OFF, ON
| 03 4A | 0000 00dd | Tera Echo EQ sw (0 - 2)
|| | OFF, PRE, POST
| 03 4B | 0000 000d | TAP/CTL Mode (0 - 1)
| | | MOMENT, TOGGLE
| 03 4C | 0ddd dddd | TAP/CTL Rise time (0 - 100)
| | | 0 - 100
|03 4D | 0ddd dddd | TAP/CTL Fall time (0 - 100)
| | | 0 - 100
|03 4E | 0ddd dddd | CTL1 Rise time (0 - 100)
| | | 0 - 100
|03 4F | 0ddd dddd | CTL1 Fall time (0 - 100)
| | | 0 - 100
|03 50 | 0ddd dddd | CTL2 Rise time (0 - 100)
| | | 0 - 100
|03 51 | 0ddd dddd | CTL2 Fall time (0 - 100)
| | | 0 - 100
|03 52 | 0ddd dddd | TAP/CTL Hold level (0 - 120)
| | | 0 - 120
|03 53 | 0ddd dddd | TAP/CTL Warp level (0 - 120)
| | | 0 - 120
|03 54 | 0ddd dddd | TAP/CTL Twist level (0 - 120)
| | | 0 - 120
|03 55 | 0ddd dddd | CTL1 Hold level (0 - 120)
| | | 0 - 120
|03 56 | 0ddd dddd | CTL1 Warp level (0 - 120)
| | | 0 - 120
|03 57 | 0ddd dddd | CTL1 Twist level (0 - 120)
| | | 0 - 120
|03 58 | 0ddd dddd | CTL2 Hold level (0 - 120)
| | | 0 - 120
|03 59 | 0ddd dddd | CTL2 Warp level (0 - 120)
| | | 0 - 120

p. 16
-----------------------------------------------------------------------------------------------------------------
|Offset |
| Address | Description
-----------------------------------------------------------------------------------------------------------------
|03 5A | 0ddd dddd | CTL2 Twist level (0 - 120)
| | | 0 - 120
|03 5B | 0000 000d | FADE IN/OUT (0 - 1)
| | | FADE OUT - FADE IN
-----------------------------------------------------------------------------------------------------------------
(*1) EFFECT ON/OFF status when FOOT SW MODE set to A/B SIMUL
(*2) LED ON/Off status when ASSIGN target set to LED

p. 17
[DIGITAL DELAY] Date: September 28, 2017
Model DD-500 MIDI Implementation Chart Version: 2.00
------------------------------------------------------------------------------------------------------------------------------------------
| | Transmitted | Recognized | Remarks |
| Function... | | | |
------------------------------------------------------------------------------------------------------------------------------------------
| Basic Default | 1-16, OFF | 1-16, OFF | Memorized |
| Channel Changed | 1-16, OFF | 1-16, OFF | |
------------------------------------------------------------------------------------------------------------------------------------------
| Default | Mode 3 | Mode 3 | |
| Mode Messages | x | x | |
| Altered | *********** | x | |
------------------------------------------------------------------------------------------------------------------------------------------
| Note | x | x | |
| Number: True Voice | *********** | *********** | |
------------------------------------------------------------------------------------------------------------------------------------------
| Velocity Note On | x | x | |
| Note Off | x | x | |
------------------------------------------------------------------------------------------------------------------------------------------
| After Key's | x | x | |
| touch Ch's | x | x | |
------------------------------------------------------------------------------------------------------------------------------------------
| Pitch Bend | x | x | |
------------------------------------------------------------------------------------------------------------------------------------------
| 0 | o (0 - 2) | o (0 - 2) | Bank select (MSB) |
| 32 | o (always 0) *3 | o | Bank select (LSB) |
| 1 - 31 | o *1 | o *2 | |
| 64 - 95 | o *1 | o *2 | |
| Control | | | |
| Change | | | |
| | | | |
------------------------------------------------------------------------------------------------------------------------------------------
| Prog | o 0-127 | o 0-127 | |
| Change :True Number | ************* | 0-127 |Program Number 1-128 |
------------------------------------------------------------------------------------------------------------------------------------------
| System Exclusive | o | o | |
------------------------------------------------------------------------------------------------------------------------------------------
| System : Song Pos | x | x | |
| Common : Song Sel | x | x | |
| : Tune | x | x | |
------------------------------------------------------------------------------------------------------------------------------------------
| : Clock | o | o | |
| System : Start | x | x | |
| Realtime : Continue | x | x | |
| : Stop | x | x | |
------------------------------------------------------------------------------------------------------------------------------------------
| : All sound off | x | x | |
|Aux : Reset All controllers | x | x | |
|Message : Local On/Off | x | x | |
| : All notes Off | x | x | |
| : Active Sense | o | o | |
| : Reset | x | x | |
------------------------------------------------------------------------------------------------------------------------------------------
| Notes | *1 Transmitted with the CC# set by MIDI CC# parameter |
| | *2 Recognized with the CC# set by MIDI CC# parameter# or ASSIGN SRC |
| | *3 Transmitted when “MIDI: BANK SEL OUT” = M+L |
| | |
| | |
------------------------------------------------------------------------------------------------------------------------------------------
Mode 1 : OMNI ON, POLY Mode 2 : OMNI ON, MONO o : Yes
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF, MONO x : No
