Specifications
Bass Unit
Tweeter
Frequency Response (±3dB)
Recommended Amplifier Power
Sensitivity
Dimensions* (HxWxD)
*Dimensions vary by rock formation.
Your Sound Solution™
Boston Acoustics, Inc. 300 Jubilee Drive Peabody MA 01960 USA phone 978.538.5000 fax 978.538.5100 bostonacoustics.com
RK5
51
/
4" (135mm)
3
/
4" Soft Dome
70Hz–20kHz
5-100 watts
89dB
124⁄5x 10 x 111⁄5"
(352 x 3254 x 285mm)
RK6T2
61
/
2" (165mm)
2 - 1" Soft Dome
60Hz–20kHz
10-150 watts
89dB
16 x 123⁄5x 111⁄5"
(407 x 320 x 285mm)
RK8T2
8" (200mm)
2 - 1" Soft Dome
50Hz–20kHz
20-200 watts
89dB
181⁄2x 144⁄5x 132⁄5"
(470 x 376 x 341mm)
Covered by patents issued and/or pending. Specifications subject to change without notice.
© 2007. All rights reserved.Your Sound Solution is a trademark and Boston, Boston Acoustics, the Boston logo, Kortec, and Voyager are registered trademarks of Boston Acoustics, Inc.
The Voyager RK5 is in a mono configuration and the
Voyager Models RK6T2 and RK8T2 are dual tweeter
stereo models that employ a dual voice coil woofer
and separate tweeters capable of providing stereo
sound from a single speaker. All feature a unique
grille design that blends into the surface of the
enclosure and are voiced to match with other models
in Boston Acoustics Voyager line of outdoor audio
solutions. Each model also features a recessed
weatherproof cavity on the on the bottom that can
house an optional 70/100 Volt Transformer for use in
light commercial installations such as restaurants and
bars or in full commercial applications like malls,
theme parks and large retail spaces using constant
voltage to drive multiple speakers. The tough and
durable outdoor speakers feature waterproof and
rustproof hardware, grilles and connectors and are
designed to withstand the harshest outdoor weather
and temperature extremes.
The new weatherproof Boston Acoustics Rock
Speakers are available in three speaker configurations,
including the Voyager RK5 (51⁄4-inch bass unit),
Voyager RK6T2 (61⁄2-inch bass unit) and Voyager RK8T2
(8-inch bass unit). All speakers are designed to blend
gracefully with virtually any outdoor environment and
all are specially voiced for open-air environments. The
Voyager rock speakers are available in three different
rock formations: New England Granite, Sandstone
and River Rock. For the best audio reproduction
capabilities, the Rock Speakers feature powerful
mica-filled woofers with a butyl rubber surround. A
custom-stepped basket on all models further
enhances woofer performance by moving the woofer
flush with the surface of the enclosure, minimizing the
sonic “tunnel effect.” High-performance tweeters in
the series include 3⁄4-inch soft domes for the RK5 and
dual 1-inch soft domes in the RK6T2 and RK8T2
models.
