Botron B2000 User manual

PROPERTIES SPECIFICATIONS
BotronB2000Technical Data Sheet
Cutting Length:
Tape Width:
Core & Roll Size
Internal Diameter :
Outside Diameter:
Max Outside Diameter:
Optional:
Power Repurement
V:
Hz:
W:
Dimensions:
Weight:
11mm - 58mm
3mm - 22mm
1”, 1.25“ & 3”
Up to 6“
6.7”
Extension Stand
AC 100V, 120V, 220-240V
50/60Hz
160W
11.8” x 6.5” x 6.7”
6.4lbs
Product Notes and Features
• Easy Length Adjustment
• Steel Blades
• Top Touch Start Button
• Photocell Control
PART NUMBERS
B2000 Automatic Carousel Tape Dispenser
Features:
Botron’s B2000 Auto Feed Carousel Tape Dispenser
automatically cuts the tape and places it on a rotating
carousel for easy use. When you need multiple pieces of
tape at your fingertips this unit will do just that. Hold’s up
to 10 pre-cut pieces on the carousel.
1 of 2

BEFORE YOU START OPERATION
1. Turn power switch to “ON” position.
2. Load preferred tape onto spool.
3. Close safety guard.
4. Adjust width and length.
5. Press button on top of carousel to start.
6. Remove all tape before pushing button again.
7. If desired width and length are off, readjust and press
button again.
Disclaimer. All statements of technical information are believed to be true and are based upon tests we
believe to be reliable. The proper use and application for this product must be the responsibility of the user.
The statements herein shall have no force or effect.
Botron Company Inc. | 21601 N 21st Ave Phoenix AZ 85027 | Ph# 623-582-6700 | Fax# [phone]
2 of 2
1. When loading the tape, make sure the ON/OFF switch is
in the OFF position.
2. While operating the B2000 make sure the safety guard
is down. The blades are very sharp, do not attempt to work
on the machine without the guard in place.
3. When there are finger marks, oils and/or dirt on the
carousel, the tape will not stick properly. Use a dry cloth to
clean.
Note: For more thorough cleaning, wipe the carousel with
alcohol. (Never clean with thinner.)
4. To avoid shortening the life of the motor, run the B2000
without tape as little as possible.
5. This is an industrial tape dispenser. It is not for home
use. Do not use around children.
6. The B2000 can be used efficiently by one or two
operators. Allow the motor to rest from time to time.
