Bove Technology Walrus-ID-470 User manual

www.bovetech.com
Walrus LoRaWAN-ID
Gateway
Read this Guide before installing the application

Copyright© 2020 Bove Intelligent Technology Co., Ltd
Thank you for choosing our products
⚫The contents of this manual are subject to change without prior notice
as a result of continuing improvements to the meter’s performance
and functions.
⚫Every effort has been made in the preparation of this manual to ensure
the accuracy of its contents. However, should you have any questions
or find any errors, please contact BOVE TECHNOLOGY.
⚫Copying or reproducing all or any part of the contents of this manual
without the permission of BOVE TECHNOLOGY is strictly prohibited.
Bove Intelligent Technology Co., Ltd
Add: Level 9, Jiaxing Pioneer Building, No. 1539,
ChengNan Road, Jiaxing, Zhejiang, P.R.
China, 314000
Tel: [phone]
Fax: [phone]
Email: [e-mail]
www.bovetech.com

Copyright© 2020 Bove Intelligent Technology Co., Ltd
CONTENT
1.PRODUCT OVERVIEW ........................................................................................................................................... 1
1.1 DESCRIPTION ............................................................................................................................................................ 1
1.2 FEATURES ................................................................................................................................................................. 1
2. GLOBAL ELECTRICAL SPECIFICATIONS AND RELIABILITY ............................................................................. 1
2.1 POWER SUPPLY ........................................................................................................................................................ 1
2.2 SPECIFICATIONS ........................................................................................................................................................ 2
3. MECHANICAL SIZE AND PACKAGE INFORMATION.......................................................................................... 3
3.1 MECHANICAL SIZE ..................................................................................................................................................... 3
3.2 PACKAGE INFORMATION ............................................................................................................................................ 3

Copyright© 2020 Bove Intelligent Technology Co., Ltd
1 / 3
1. Product overview
1.1 Description
Walrus is an IOT gateway based on LoRaWAN and target to LPWAN network. The GW could
support LoRaWAN Class A/C protocol and Wi-Fi IEEE 802.11b/g/n standard. The 2.4G
wireless transmission rate up to 150Mbps. Users could connect the GW to Cloud server via
Wi-Fi.
This gateway integrates a 1T1R 802.11n WI-FI module, adopts MT7688AN highly integrated
SOC master, contains a 580MHZ MIPS24KEc CPU, a 100M Ethernet port, 1 * USB2.0, LTE
module (some models). An SX1308 LoRa baseband processing chip is integrated at the same
time, which can support 8 multi-SF channels (SF12 to SF7), 1 single-SF channel and 1
high-speed GFSK channel. The output power can be up to 25dBm, and the sensitivity is
-142dBm @ 300bps. Under certain transmission cycle and data length conditions, a single
gateway can access tens of thousands of nodes.
Walrus is a smart, easy installation and high reliability device. Customers could setup a quick
LoRaWAN network for their LPWAN application with Walrus.
1.2 Features
⚫Upstream supports 8 parallel Multi-SF LoRa channels, 1 Single-SF LoRa channel, and 1
high-speed GFSK channel
⚫Half duplex mode for LoRaWAN communication
⚫The transmitting power is up to 25dBm, and the receiver sensitivity is -142dBm @ 300bps
⚫Support LoRaWAN ClassA / C protocol
⚫Support 802.11 b/g/n wireless protocol
⚫Support 10 / 100M Ethernet port and WIFI connection for Internet access
⚫Support Ethernet cable within 100m
⚫Support LTE 4G (optional models)
⚫M2M, IOT Internet of Things, Low Power Wide Area Network LPWAN
⚫Wireless Sensor Network
⚫Industry 4.0, industrial equipment monitoring
⚫Wireless remote monitoring
⚫Smart Home, Smart Building, Smart Community, Smart City
⚫Wireless alarm and security system
⚫Environmental data monitoring
2. Global electrical specifications and reliability
2.1 Power Supply
Walrus is equipped with 12V / 1.5 A 5 energy efficiency power adapter, input voltage range of

Copyright© 2020 Bove Intelligent Technology Co., Ltd
2 / 3
90 ~ 264VAC; 50 ~ 60HZ, output voltage range 11.4 ~ 12.6 V.
2.2 Specifications
Conducted Receiver sensitivity and Transmitter output power would be used to evaluate the
performance here.
Sensitivity
Test condition：32byte payload, PER=10%, +25°C.
Conducted Receiver sensitivity
Part Number
Bandwidth/kHz
Spreading Factor
Sensitivity/dBm
Walrus-ID-470
125
12
-140
7
-125
250
12
-136
7
-122
500
12
-133
7
-119
Walrus-ID-868
125
12
-139
7
-125
250
12
-136
7
-122
500
12
-133
7
-119
Walrus-ID-915
125
12
-139
7
-125
250
12
-136
7
-122
500
12
-133
7
-119

Copyright© 2020 Bove Intelligent Technology Co., Ltd
3 / 3
3. Mechanical size and package information
3.1 Mechanical size
Walrus Mechanical size
3.2 Package information
3.2.1 Package list
Package List
Material
PN
Qty
Walrus
Walrus-ID-xxx
1
Adapter
12/1.5A
1
Antenna of WIFI
6dBi High-efficiency
omnidirectional antenna
1
Antenna of LoRa
High-efficiency omnidirectional
antenna
1
Antenna of 4G (Optional)
High-efficiency omnidirectional
antenna
1

Copyright© 2020 Bove Intelligent Technology Co., Ltd
