OPERATION MANUAL
Data logger LogBox AA
0141 0315-82 07.06.2016 B+B Thermo-Technik GmbH | Heinrich-Hertz-Str. 4 | D-78166 Donaueschingen
Technical changes resserved Fon [phone] | Fax [phone] | [e-mail] | bb-sensors.com 1 / 2
Quick guide LogBox AA
LogBox is an electronic data logger with two analog input channels.
Values measured by these channels (data) are stored in the logger
electronic memory (acquisitions) for later download to a PC for visualization
and analysis in the form of tables or graphs.
The logger is supplied with LogChart-II software, which enables to set up
the logger operation mode. It is also used for data visualization. Other
parameters such as signal input type, Logging interval, etc., are easily
selected through the LogChart-II software.
The complete installation and operation manual for the electronic data
logger is in the CD-ROM packed with the product.
Technical data
Features
Values
Inputs
Thermocouples J; K; N; R; S; T
Pt100
4…20 mA; 0…50 mV; 0…10 V
Inputimpedance
0…50 mV, Pt100 and thermocouples: >10 MΩ
0…10 V: > 1 MΩ
4…20 mA: 100 Ω
Meauring ranges
J -50…760 °C (-58…1400 ºF)
K -50…760 °C (-58…1400 ºF)
N -100…400 °C (-148…752 ºF)
T -90...1300 °C (-130…2372 ºF)
R 0…1760 °C (32…3200 ºF)
S 0…1760 °C (32…3200 ºF)
Pt100 -200…530 °C (-328…986 ºF)
0…20 mA
Linear program range of -32768 to 32767
0…50 mV
Linear program range of -32768 to 32767
0…10 V
Linear program range -32768 to 32767
Accuracy
Thermocouples J, K and T: .
25% of the measuring range ±1 °C;
Thermocouples N, R, and S:
0,25% of the measuring range ±3,7 °C
Pt100:
0,2% of the measuring range;
4…20 mA, 0…50 mV and 0…10 V:
0,2% of the measuring range
Memory capacity
32000 (32k)
Measuring interval
Minimum: 10 seconds, maximum: 18 hours
Power supply
3.6 V Lithium battery (1/ 2 AA)
Estimated autonomy
1 year with one daily download and 5 minutes
measuring interval
Operating temperature
-40…70 °C
Housing
Polycarbonate
Ingress protection
IP 67, IP65 , depending on model
Dimensions
60 x 70 x 35 mm
CE-conformance
2014/300/EU
According to
EN 61326-1
Logger-PC data transfer
According to the number of logs.
40 seconds for 16000 logs.
PC Interface
Ir/USB or Ir/Serial
LogChart-ll Software
Umgebung
Set up Software for Windows 95, 98, NT, 2000 and
XP. Menus in Portuguese, English or Spanish.
Sets up, reads and displays data on the screen.
0568 0034
Data logger LogBox AA IP67. Memory capacity up
to 32 000 values, operating temperature: -40…80
°C, Inputs: thermocouples of all sorts, Pt100, 0…50
mV, 4…20 mA, 0…10 V
0568 0033
Data logger LogBox AA IP65. Memory capacity up
to 32 000 values. Operating temperature: -40 …80
°C, Inputs: thermocouples of all sorts, Pt100, 0…50
mV, 4…20 mA, 0…10 V
0568 0036
IrLink 3 Infrared communication interface with USB-
connection and LogChart II Software. Suitable to
the loggers TagTemp and LogBox RHT
Package contents

OPERATION MANUAL
Data logger LogBox AA
0141 0315-82 07.06.2016 B+B Thermo-Technik GmbH | Heinrich-Hertz-Str. 4 | D-78166 Donaueschingen
Technical changes resserved Fon [phone] | Fax [phone] | [e-mail] | bb-sensors.com 2 / 2
Besides this manual, the user must check if the items below accompany the
product:
The electronic logger LogBox-AA or LogBox-DA;
A CD-ROM with the software, manuals and a USB driver
A communication interface upon request
Identification
The identification label is on the logger body. Check if the features
described are in accordance with your order.
Installating LogChartII
LogChart-II is the software provided with the logger to allow for
configuration and data offload. To install, run the LC_II_Setup.exe file
provided with the CD-ROM. For additional software usage instructions
chek the HELP menu.
Note: Be sure your Windows date separator is configured as a slash:
dd/mm/yy or dd/mm/yyyy.
Communication with the logger
Make sure the communication interface is connected to the PC port
selected. The interface must be constantly directed towards the front
part of the logger (communication window) at a maximum distance of 1
m. (See Fig. 1).
Attention
Please avoid extreme mechanical and inappropriate exposure.
The device/product is not suitable for potential explosive areas and
medical-technical applications.
