Braavos 7198-63 User manual

Double press the multifunction button to redial the
last number you dialed.
front side
Braavos Wireless Charging
True Wireless Earbuds
| 01
| 05
| 03
| 07
| 02
| 06
| 04
| 08
Instruction Manual
7198-63
Hello! This is your instruction manual, to
help create the best possible experience
with this cool product. Earbuds Power Case Charging
Cable
**Charge the devices completely before
initial use.**
Long press the Multi-function for about 3
seconds, the LED indicator will ash blue/red
and a warning tone will sound.
Press and hold the button for 5 seconds,
the LED will light red and a sound will alert
accordingly. Once one earbud is turned off
the other will automatically turn off if they
were connected.
Turn OFF your devices Bluetooth, press the
multi-function button on both earbuds for
3 seconds until you hear “Power On”. The
earbuds will pair together automatically. The
right earbud will be ashing Red and Blue.
Now Turn on your mobile devices bluetooth.
If done succesfuly only one “Braavos” pairing
name will appear.
If having trouble pairing, Press and hold the
Multi-function button on both earbuds at the
same time for 5 seconds.
You will see blue and red light blinks, choose
right earbuds and press the Multi-function
button twice, you will hear a prompt sound,
the earbuds will pair automatically now.
Right earbuds will be ashing RED and Blue
Magnetic contact recharging, once placed
into the charging case earbuds will begin
to charge automatically.
The LED light of the case will turn blue, the
earbud LED will turn red when charging.
The LED light of case and earbuds will
turn off when charging is complete.
**Wireless charger is NOT included**
Place the wireless charging symbol (found
on the back of the power case) so its
facing up on the wireless charging pad.
When charging the Power Case LED will
ash Green.
Once fully charged, the Power Case LED
will turn solid Green.
Use the Micro-USB cable to connect to
an adapter or computer to charge the
power case.
When charging the Power Case LED will
ash Green.
Once fully charged, the Power Case LED
will turn solid Green.
Multi-function
button/Earbud LED
Microphone
Ear tips
Charging LED
Micro-USB input
Wireless Charging
Reciever
1.
2.
3.
4.
5.
6.
•
•
•
•
•
•
•
•
•
Safety Precautions:
Included Contents: Charging:
Stereo Earbud Usage:
3. Power ON: After rst time pairing
4. Power OFF: One earbud
1. Pairing: First time
Resetting:
1. Charging the earbuds
2. Charging the power case
3. Wireless Charging the power case
Please follow the rules described in
this manual closely to ensure your
safety.
Before using the earbuds, we would
strongly encourage you read this
manual.
Do not modify, repair or dismantle the
earbuds or power bank.
Do not use any liquids to clean the
products.
Do not use the earbuds near water, or
intense temperatures.
1.
2.
3.
4.
5.
Select “Braavos” from your bluetooth
function.When you hear “Device
Connection”,You’ve successfully connected
to your bluetooth. The earbuds are now
ready to be used.
2. Search and Pairing
Previously paired earbuds will connect
automatically after power ON.
Answer/End Call:
Right Ear Earbud
Left Ear Earbud
Reject a call:
Redial:
Press the Multi-function button once to answer
an incoming call, and again to end the call.
Play/Pause: Press the multifunction button once
to pause, and press again to play.
Next Track: Press the multifunction button once to
play the next track.
Press and hold the multifunction button to reject
an incoming call.
5. Calling (Right Earbud)
6. Playing Audio

back side
| 09
| 13
| 11
| 15
| 10
| 14
| 12
| 16
Charging time
Charging time
Bluetooth Range
Play time
Mic Sensitivity
1.5 hrs (from 0-100)
2.5 hrs (from 0-100)
10m
2 hrs
WARNING–When using this product, basic
precautions should always be followed, including
the following:
Fully read the instructions before using the
product.
The unit will only achieve full performance after
2 or 3 completed charge and discharge cycles.
Do not overcharge your case. The unit may
become hot under excessive use. Remove your
case once it is fully charged. Never charge your
case for more than 7 hours at a time.
To reduce the risk of injury, close supervision is
required when the product is used near children.
Do not expose the device to moisture.
Do not use the device in excess of its output
rating. Overload outputs above the rating may
result in a risk of re or injury.
Do not use the device if damaged or modied.
Damaged or modied batteries may exhibit
Changes or modications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates
uses and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
unpredictable behaviour resulting in re,
explosion or risk of injury.
Do not disassemble the device. Take the device
to a qualied technician if service or repair is
required. Incorrect reassembly may result in a
risk of re or injury.
Do not expose the device to re or excessive
temperatures. Exposure to re or temperatures
above 212ºF/100°C may cause explosion.
Have servicing performed by a qualied repair
person using only identical replacement parts.
This will ensure that the safety of the product
is maintained.
Mobile devices cannot connect with the earbuds if
the earbuds are not in pairing mode.
If the earbuds are unable to connect to a mobile
device via Bluetooth for 5+ minutes, the earbuds
will power off automatically.
Earbud Tech Specications
Power Case Tech Specications
Items
Items
Specications
Specications
Start-up failure
No sound when
paired
No indication
during charging
Shut down
automatically
Noise during
calls
Low volume
Signal
interrupted
low battery
wrong pairing
Earbuds aren’t
securely inserted
low battery
mobile device is
too far away
earbuds are
turned down low
environment
disturbance,
distance to far
from mobile
device
charge earbuds
and power case
re-pairing
check earbuds,
and try again
charge earbuds
and power case
bring mobile
device closer
adjust earbuds to
comfort & sound
bring the mobile
device closer to
the earbuds
Troubleshooting
Safety Precautions
FCC Statement
Issue Reason Solution
1.
2.
3.
4.
5.
6.
7.
8.
•
•
-
-
-
-
•
9.
10.
11.
12.
MADE IN CHINA
-42+3db
Power ON: Long press the multifunction
button for about 3 seconds, the indicator
lights will ash blue/red & a warning tone
will sound.
Long press the multi-functional button for
5 seconds, the indicator lights will ash red
and blue. Connect through Bluetooth, search
“Braavos” & click connecting, It will pair
automatically.
Single Earbud Usage:
2. Power ON/OFF
3. Once the earbud is successfully connected
with your device, you can listen to audio.
Power OFF: Long press the multifunction
button for about 5 seconds, the red LED
will light once, then Off, and a warning tone
will sound.
4. Answer/End calls: Press the multi-button
once to answer an incoming call, and again
to end.
5. Reject a call: Press and hold the
multifunction button to reject an incoming call.
6. Redial: Double press the multifunction
button to redial the last number you dialed.
7. Music: short press the button to pause the
music or play the music.
1. Pairing for the rst time
Now turn on your mobile devices blueooth. If
done successfully only one “Braavos” pairing
name will appear.
