Installation and Operation Instructions Document 1344C
WARNING
If the information in this manual is not
followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
Do not store or use gasoline or other
ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
nearby phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call
the re department.
Installation and service must be performed
by a qualied installer, service agency, or gas
supplier.
FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician,
qualied in hot water boiler and heater installation and maintenance. Improper installation and/or operation
could create carbon monoxide gas in ue gases which could cause serious injury, property damage, or
death. Improper installation and/or operation will void the warranty.
AVERTISSEMENT
Assurez-vous de bien suivres les instructions
données dans cette notice pour réduire au
minimum le risque d’incendie ou d’explosion
ou pour éviter tout dommage matériel, toute
blessure ou la mort.
Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inammables dans
le voisinage de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d’allumer d’appareils.
• Ne touchez à aucun interrupteur. Ne pas vous
servir des téléphones dansle bâtiment où vous
vous trouvez.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de
gaz, appelez le sservice des incendies.
L’installation et l’entretien doivent être assurés par
un installateur ou un service d’entretien qualié ou
par le fournisseur de gaz.
Installation and Operation
Instructions for
with Touchscreen Display
Modulating Boilers and
Volume Water Heaters
Indoor models
BNTH Sizes 285 – 850 MBTU/h
BNTV Sizes 150 – 850 MBTU/h
Outdoor models
BNTH & BNTV Sizes 150 – 850 MBTU/h
BruteTM
H2374700C

B RADFORD W HITE
Section 1 -
General Information
1.1 Introduction.......................................................1
1.2 ModelIdentication...........................................1
1.3 ApplianceOverview.......................................2-7
1.4 Dimensions, Indoor Models..............................8
1.5 Dimensions,OutdoorModels .........................10
1.6 Warranty ......................................................... 11
1.7 InstallationKit .................................................12
Section 2 -
Locating the Appliance
2.1 GeneralInformation........................................14
2.2 LocatingApplianceforCorrectVentDistance
 fromOutsideWallorRoofTermination...........14
Section 3 -
Venting and Combustion Air
3.1 GeneralVenting..............................................15
3.2 CombustionAir ...............................................15
3.3 Venting............................................................17
3.4 LocatingVent&CombustionAirTerminals.....20
3.5 CommonVentTest .........................................23
Section 4 -
Gas Supply and Piping
4.1 GasSupplyandPiping ...................................24
Section 5 -
Pump Requirements
5.1 BruteBoilerFlowand
 HeadRequirements........................................25
5.2 BruteWaterHeater
 FlowandHeadRequirements ........................25
Section 6A -
Water Connections - BNTH Boiler
6A.1 BNTHSystemPiping:HotSupply
 Connections....................................................26
6A.2 BNTHColdWaterMake-Up ...........................26
6A.3 CondensateDrain...........................................27
6A.4 FreezeProtection ...........................................27
6A.5 BNTHSuggestedPipingSchematics ........27-33
6A.6 RecognizedChemicals...................................27
Section 6B -
Water Connections - BNTV Water Heater
6B.1 BNTVWaterQuality .......................................34
6B.2 PipingRequirements ......................................34
6B.3 ColdWaterMake-Up ......................................34
6B.4 CondensateDrain...........................................35
6B.5 FreezeProtection ...........................................35
6B.6 BNTVSuggestedPipingSchematics .............35
6B.7 BNTVSuggestedPumps................................35
Section 7 –
Electrical and Wiring Diagrams
7.1 InstallationWarnings.......................................37
7.2 MainPowerConnections...........................37-38
7.3A PumpConnectionsandOperation..................37
7.3B OptionalVariableSpeedPumpControl ..........37
7.4 HydronicHeatingUsingExternalMod............39
7.5 OptionalFieldConnections.............................39
7.6 LeadLagConnections....................................40
7.7 BuildingAutomationSystemsConnections ....41
7.8 SystemWiringDiagram ..................................42
7.9 LadderDiagram ..............................................43
Table of Contents
i

Brute HIGH EFFICIENCY COMMERCIAL BOILERS AND VOLUME WATER HEATERS
ii
Section 9 -
First Start Up and Adjustment
9.1 FillingtheBoilerSystem .................................69
9.2 FirstOperation................................................69
9.3 ShuttingDowntheBruteUnit ..........................70
9.4 RestartingtheBruteUnit .................................70
Section 10 -
Maintenance
10.1 SystemMaintenance ......................................71
10.2 ApplianceMaintenanceandComponent
Description......................................................71
10.3 BatteryBackUpforDateandTime ................74
10.4 GasConversion..............................................74
Section 11 -
Troubleshooting
11.1 AboutLockouts,Holds,andAlerts ...................75
11.1.1RespondingtoaLockout,Hold,orAlert .....75
11.1.2ViewingtheLockoutandAlertHistories ......75
11.2 TroubleshootingTable.................................77-84
11.3 DiagnosticTestsandInput/OutputIndicators ..85
11.4 LeadLagFollowerDiagnostics........................86
11.5 Statistics...........................................................86
11.6 Analysis............................................................86
11.7 ControlSnapshot .............................................86
11.8 OperatingSequence ........................................87
Section 12 -
Replacement Parts
12.1 GeneralInformation.......................................88
12.2 PartsList...................................................88-90
12.3 PartsIllustrations ......................................90-97
Section 8 -
Using the Touch Screen
8.1 TheTouchScreen ........................................45
8.2 UsingtheTouchScreen ................................45
8.3 Login(requiredforsomeparameters) ...........46
8.4 VericationProcessforSafety-Related
  Parameters ....................................................47
8.5 CheckingIndividualParameters....................48
8.6 SettingtheDateandTime..............................49
8.7 The Conguration Menu .............................50
TheCongurationSub-Menus(ALL18) .......51
8.7.1 SystemIdentication&Access...................51
8.7.2ACH-CentralHeatConguration..............51
 2BSettingUp4-20mASetPoint ..................51
8.7.3 OutdoorResetConguration......................52
8.7.4 DHW-DomesticHotWaterConguration .52
8.7.5 WarmWeatherShutdownConguration ....52
8.7.6 DemandPriorityConguration ...................53
8.7.7 ModulationConguration............................53
8.7.8 PumpConnections .....................................53
8.7.9 StatisticsConguration...............................54
8.7.10HighLimits..................................................54
8.7.11StackLimits ................................................54
8.7.12Anti-CondensationConguration................54
8.7.13FrostProtectionConguration....................54
8.7.14SystemConguration .................................54
8.7.15FanConguration .......................................55
8.7.16SensorConguration..................................55
About Lead Lag
..............................................56
8.7.17LeadLagFollowerConguration...............58
8.7.18LeadLagLeaderConguration.................60
8.8 Congurefora
  BuildingAutomationSystem..........................63
8.9 Combustion Setup ...................................64
8.10 AdjustingCO2 ...............................................66

B RADFORD W HITE

Page 1
Brute HIGH EFFICIENCY COMMERCIAL BOILERS AND VOLUME WATER HEATERS
Section 1 -
GENERAL INFORMATION
WARNING
Brute units must be installed in accordance with the
procedures detailed in this manual, or the Bradford
White warranty will be voided. The installation must
conform to the requirements of the local jurisdiction
having authority, and, in the United States, to the latest
edition of the National Fuel Gas Code,ANSI Z223.1/
NFPA54. In Canada, the installation must conform
to the latest edition of CSAB149.1 Natural Gas and
Propane Gas Installation Code, and/or local codes.
Where required by the authority having jurisdiction,
the installation of Brute boilers must conform to
the Standard for Controls and Safety Devices for
Automatically Fired Boilers,ANSI/ASME CSD-1. Any
modications to the boiler, its gas controls, or wiring
may void the warranty. If eld conditions require
modications, consult the factory representative before
initiating such modications.
1.1 Introduction
This manual provides information necessary for the
installation, operation, and maintenance of Bradford White
Brute appliances. Read it carefully before starting the
installation.
All application and installation procedures should be reviewed
completely before proceeding with the installation. Consult
the Bradford White factory, or local factory representative,
with any problems or questions regarding this equipment.
Experience has shown that most operating problems are
caused by improper installation.
Brute is protected against over pressurization. A pressure
relief valve is included with each Brute. Some Brutes may
require that the PRV be installed prior to lling the system.
DANGER
The inlet gas pressure to the appliance must not
exceed 13” W.C. (3.2kPa).
All installations must be made in accordance with
1) American National Standard Z223.1/NFPA54-Latest
Edition “National Fuel Gas Code” or
2) CSA B149.1 “Natural Gas and Propane Installation Code”
or in Canada reference the B149.1 latest edition and with
the requirement of the local utility or other authorities having
jurisdiction. Such applicable requirements take precedence over
the general instructions contained herein. All electrical wiring
is to be done in accordance with the local codes, or in the
absence of local codes, with:
1) The National Electrical CodeANSI/NFPA No. 70-latest
Edition, or 2) CSA STD. C22.1 “Canadian Electrical Code
- Part 1”. This appliance must be electrically grounded in
accordance with these codes.
1.2 ModelIdentication
Consult the rating plate on the unit. The following information
describes the model number structure.
(1-3) ModelSeriesDesignation
B N T = Bradford White, Brute
(4) Usage
H = Hydronic
V = Volume Water
(5-7) Size
1 5 0 = 150,000 BTU/hr input
1 9 9 = 199,000 BTU/hr input, BNTVonly
2 1 0 = 210,000 BTU/hr input, BNTH only
2 8 5 = 285,000 BTU/hr input
3 9 9 = 399,000 BTU/hr input
5 0 0 = 500,000 BTU/hr input
6 0 0 = 600,000 BTU/hr input
7 5 0 = 750,000 BTU/hr input
8 5 0 = 850,000 BTU/hr input
(8) Fuel
N = Natural Gas
P = LP Gas
(9) Options Code
X = Standard Unit
J = CSD-1, FM, GAP, IL Code (size 500-850 only)
C - STANDARD (Canada)
D - CSD-1 (Canada)
E - OUTDOOR
F - OUTDOOR (Canada)
G - CSD-1, OUTDOOR
H - CSD-1, OUTDOOR (Canada)
(10) Pump Options
N = Pump included (150-500 only)
X = No pump (conguration available for all sizes)
W = HLW w/ Pump (option for BNTV only)
L = HLW w/out Pump (option for BNTV only)
(11) Revision
3 = Third version
ModelNomenclature
2 3 4 5 6 7 8 9 10 11
SERIES
BradfordWhite
Brute
USAGE
H - HYDRONIC
V - VOLUME
WATER
SIZE
MBTU/h
1 5 0
1 9 9
2 1 0
2 8 5
3 9 9
5 0 0
6 0 0
7 5 0
8 5 0
FUEL
N - NATURAL
P - PROPANE
OPTIONS CODE
X - STANDARD
J - CSD-1, FM, GAP,
IL (500-850 only)
C - STANDARD (Canada)
D - CSD-1 (Canada)
E - OUTDOOR
F - OUTDOOR (Canada)
G - CSD-1, OUTDOOR
H - CSD-1, OUTDOOR
(Canada)
PUMP OPTIONS
N - PUMP INCL.
(150-500 only)
X - NO PUMP
W -HLW w/PUMP
(opt for BNTV only)
L - HLW w/out
PUMP
(opt for BNTV only)
REVISION
3 - THIRD REG DESIGNATION
B
3
N T
B- INTERNAL USE
1
B

Page 2
B RADFORD W HITE
1.3 ApplianceOverview
The Bradford White Brute is offered in both
Indoor and Outdoor models for all sizes. The physical
appearance of the Indoor and Outdoor Brutes is
drastically different because the Outdoor model offers a
fully weathertight enclosure that hides the touchscreen.
Whereas the indoor model is not fully weathertight and
the touchscreen can be accessed without having to open
the unit. See Figure 1 through Figure 11.
Both variations of the Brute have the On/Off switch
on the outside of the unit.
Both units have the Rating Plate on the outside
panel to the right. See Figure 2 and Figure 3
DOOR
HANDLE
(PULL TO OPEN)
(RELEASE BOTH
LATCHES TO OPEN)
DOOR
LATCHES
ON / OFF
SWITCH THE TOUCH SCREEN
ON OUTDOOR UNIT
IS LOCATED BEHIND
FRONT PANEL
Outdoor
Indoor
Figure 1. AllBrutemodelsopenfromthefront
The only component (interior) difference between the
Indoor and Outdoor models is that all of the piping for the
Outdoor model, with the exception of the exhaust vent, is
at the BACK of the unit. See Figure 3
The gas connection, the air inlet, and the water inlet and
outlet are all at the back of the unit. This is consistent for
all sizes.

Page 3
PRV
Brute HIGH EFFICIENCY COMMERCIAL BOILERS AND VOLUME WATER HEATERS
RATING PLATE
RATING PLATE
Figure 2. ConnectionpipingisonTOPforALLIndoorSizes
Figure 3. ConnectionpipingisontheBACKforALLOutdoorSizes
WATER INLET
WATER OUTLET*
AIR INLET
FILTER BOX
GAS
CONNECTION
*PRV must be added to this pipe
during installation.
GAS
CONNECTION
EXHAUST
VENT
EXHAUST
VENT
WATER INLET
WATER OUTLET
AIR INLET
CONDENSATE
TRAP OUTLET
(Trap is built-in)
CONDENSATE
TRAP OUTLET
(Trap is built-in)
Outdoor 150 MBH
Indoor 150 MBH
For piping dimensions/
locationsforalloutdoorunits,
SeeTable2onpage10
For piping dimensions/
locationsforallIndoorunits,
SeeTable1onpage8

Page 4
B RADFORD W HITE
Figure 5. LocationofComponents,Size285
EXHAUST VENT CONNECTION
AIR INLET CONNECTION
GAS CONNECTION
TOUCHSCREEN
HEAT EXCHANGER
GAS VALVE VENTURI
AIR/ GAS
BLOWER
WATER INLET
WATER OUTLET
PRESSURE RELIEF VALVE
AIR PRESSURE SWITCH
DRAIN VALVE
CONDENSATE TRAP
AIR TRANSITION
ON / OFF SWITCH
Figure 4. LocationofComponents,Sizes150-210
EXHAUST VENT CONNECTION
GAS CONNECTION
AIR PRESSURE SWITCH
TOUCHSCREEN
HEAT EXCHANGER GAS VALVE
VENTURI
AIR/ GAS
BLOWER
PRESSURE RELIEF VALVE
WATER INLET
WATER OUTLET
AIR INLET CONNECTION
DRAIN VALVE
CONDENSATE TRAP
AIR TRANSITION
ON / OFF SWITCH

Page 5
Brute HIGH EFFICIENCY COMMERCIAL BOILERS AND VOLUME WATER HEATERS
EXHAUST VENT CONNECTION
GAS CONNECTION
TOUCHSCREEN
HEAT EXCHANGER
MANUAL SHUTOFF
GAS VALVE
VENTURI
AIR/ GAS
BLOWER
PRESSURE RELIEF VALVE
WATER INLET
WATER OUTLET
AIR INLET CONNECTION
DRAIN VALVE
CONDENSATE TRAP
GAS VALVE
ON / OFF SWITCH
Figure 6. LocationofComponents,IndoorSize399
Figure 7. LocationofComponents,IndoorSize500
EXHAUST VENT CONNECTION
PRESSURE RELIEF VALVE
TOUCHSCREEN
HEAT EXCHANGER
MANUAL SHUTOFF
GAS VALVE
VENTURI
GAS VALVE
WATER INLET
WATER OUTLET
AIR INLET CONNECTION
DRAIN VALVE
CONDENSATE TRAP
GAS CONNECTION
AIR/ GAS BLOWER
GAS PRESSURE
SWITCH
AIR PRESSURE SWITCH
ON / OFF SWITCH

Page 6
B RADFORD W HITE
Figure 8. LocationofComponents,Size600
EXHAUST VENT CONNECTION
GAS CONNECTION
PRESSURE RELIEF VALVE
TOUCHSCREEN
HEAT EXCHANGER
MANUAL SHUTOFF
GAS VALVE
VENTURI
AIR/ GAS BLOWER
AIR PRESSURE SWITCH
WATER INLET
WATER OUTLET
AIR INLET CONNECTION
DRAIN VALVE
CONDENSATE TRAP
GAS VALVE
MANUAL SHUTOFF
GAS VALVE
ON / OFF SWITCH
Figure 9. LocationofComponents,Sizes750and850
WATER INLET
WATER OUTLET
AIR INLET
DRAIN VALVE
CONDENSATE TRAP
AIR/ GAS BLOWER
PRESSURE RELIEF
VALVE
TOUCHSCREEN
HEAT EXCHANGER
EXHAUST VENT
CONNECTION
VENTURI
GAS VALVE
GAS CONNECTION
MANUAL SHUTOFF
GAS VALVE
ON / OFF SWITCH
