Bradford White SW-2-65-L User manual

Residential PowerStor®Series Single-Wall
Energy Saver Indirect Water Heater
The PowerStor®Series Single-Wall Models feature:
■Heat Exchanger—Single-Wall 11⁄2"O.D. glass coated (Vitraglas®)carbon
steel coil. The coil has a heat transfer area of 14.2 sq. ft. and a stored water
volume of 2.7 Gal. Maximum supply temperature from the boiler must not
exceed 250° F.
■Factory Installed Hydrojet®Total Performance System—Cold water inlet
sediment reducing device helps prevent sediment build up in tank.
Increases first hour delivery of hot water while minimizing temperature build
up in tank.
■Vitraglas®Lining—Bradford White water heater tanks are protected from
the corrosive effects of hot water by an exclusive ceramic porcelain-like
coating. The Bradford White high silica Vitraglas®lining provides a tough
interior surface for our hot water tanks.
■Immersed Adjustable Honeywell Aquastat—Fast acting immersion
aquastat for automatic temperature control (adjustable from 80°F to 160°F).
■Supply and Return Connections—1" NPT female connections are located
on the front for both the boiler collector supply and return.
■2" Non-CFC Foam Insulation—Covers the side and top of tank, reducing
the amount of heat loss. This results in less energy consumption, improved
operation efficiencies and jacket rigidity.
■Potable Water Connections—3⁄4" NPT factoryinstalled true dielectric
fittings extend water heater life and eases installation.
■Three Protective Aluminum Anode Rods—Provide added protection
against corrosion for long trouble-free service.
■Steel Tank—Heavy gauge steel automatically formed, rolled and welded to
assure a continuous seam for glass lining.
■T&P Relief Valve—Included.
■Brass Drain Valve.
■I=B=R Certified—These water heaters arerated by the Institute of Boiler
and Radiation Manufacturers (I=B=R) to provide accurate performance data
within the standards of the certification. The I=B=R rating is issued by the
Hydronics Institute Division of GAMA and provide a recognized standardfor
proper comparison of hydronic appliances.
Limited Lifetime Tank and Heat Exchanger Warranties / 6-Year Limited Warranty on Component Parts.
For more information on warranty, please visit www.bradfordwhite.com
For products installed in USA, Canada and Puerto Rico. Some states do not allow limitations on warranties. See complete copy of the
warranty included with the heater.
Photo is of
SW-2-65-L
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 7,063,133 B2; 5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385; 5,574,822; 5,372,185; 5,485,879;
5,277,171; (B1)5,341,770; 5,660,165; 5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448; 4,829,983; 4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968; 4,672,919;
Re. 34,534. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS: 1,272,914; 1,280,043; 1,289,832; 2,045,862; 2,112,515; 2,108,186; 2,107,012; 2,092,105.
Vitraglas®and Hydrojet®are registered trademarks of BradfordWhite®Corporation.
554-B-0508-A

Single Wall Energy Saver Models Meet or exceed ASHRAE 90.1b (current standard)
Model
Number
Approx.
Shipping
Weight
lbs.
A
Floor to
Heater
Top
in.
C
Floor to
T&P
Conn.
in.
B
Jacket
Dia.
in.
Capacity
SW-2-30-L
SW-2-40R-L
SW-2-50R-L
SW-2-65-L
SW-2-80-L
SW-2-120-L
U.S.
Gal.
30
38
48
60
75
116
Imp.
Gal.
25
32
40
50
62
97
335/8
411/8
461/4
591/4
59
621/2
281/4
343/8
401/8
531/8
527/8
553/4
140
172
180
196
224
355
22
22
22
22
24
281/4
E
Floor to
Exchanger
Outlet
in.
53/8
53/8
53/8
53/8
53/8
63/8
271/2
271/2
271/2
271/2
271/2
281/2
343/8
417/8
47
60
593/4
631/4
D
Floor to
Water
Conn.
in.
Model
Number
Approx.
Shipping
Weight
kg.
A
Floor to
Heater
Top
mm.
C
Floor to
T&P
Conn.
mm.
B
Jacket
Dia.
mm.
Capacity
SW-2-30-L
SW-2-40R-L
SW-2-50R-L
SW-2-65-L
SW-2-80-L
SW-2-120-L
Liters
114
143
182
227
284
439
854
914
1175
1505
1499
1588
718
873
1019
1349
1343
1416
64
77
82
89
102
161
559
559
559
559
610
718
E
Floor to
Exchanger
Outlet
mm.
137
137
137
137
137
162
F
Floor to
Exchanger
Inlet
in.
F
Floor to
Exchanger
Inlet
mm.
699
699
699
699
699
720
111/2
111/2
111/2
111/2
111/2
111/2
G
Floor to
Aquastat
in.
G
Floor to
Aquastat
mm.
292
292
292
292
292
292
873
1064
1194
1524
1518
1607
D
Floor to
Water
Conn.
mm.
Residential PowerStor®Indirect Water Heater
General
All units arecertified at 300 PSI (2068 kPa) test pressure
and 150 PSI (1034 kPa) working pressure. All potable water connections are 3/4" (19mm) NPT on 8" (203mm) centers.
Dimensions and specifications subject to change without notice in accordance with our policy of continuous product improvement.
Suitable for Water (Potable) Heating and Space Heating.
Toxic chemicals, such as those used for boiler treatment, shall NEVER be introduced into the potable side of this system. The potable side may NEVER be
connected to any existing heating system or component(s) previously used with a non-potable water heating appliance.
Based on 200°F boiler water temperature and 50°F
potable water inlet.
Printed in U.S.A.
554-B-0508-A
©2008, Bradford White Corporation. All rights reserved.
Ambler,PA
For U.S. and Canada field service, contact your professional installer or local BradfordWhite sales representative.
Sales 800-523-2931 ●Fax [phone] / Technical Support800-334-3393 ●Fax [phone] ●Warranty 800-531-2111 ●Fax [phone]
International: Telephone [phone] ●Telefax 215-641-9750 / www.bradfordwhite.com
Sales / Technical Support866-690-0961 /905-238-0100 ●Fax [phone] /www.bradfordwhite.com
Model
Number
140°F 115°F
DOE Water Heater Performance
SW-2-30-L
SW-2-40R-L
SW-2-50R-L
SW-2-65-L
SW-2-80-L
SW-2-120-L
1
Maximum First
Hour Rating
(Gal.) @
279
288
297
306
321
357
429
438
447
456
470
507
140°F 115°F
4.2
4.2
4.2
4.2
4.2
4.2
6.7
6.7
6.7
6.7
6.7
6.7
Continuous
Draw Rating
(Gal./Min.) @
AApproximate
Boiler Output
Needed for
Ratings (BTU/Hr.)
220,000
220,000
220,000
220,000
220,000
220,000
5
Model
Number
I=B=R Water Heater Ratings
SW-2-30-L
SW-2-40R-L
SW-2-50R-L
SW-2-65-L
SW-2-80-L
SW-2-120-L
1
First Hour
Delivery
@ 135°F
(Gal.)
255
260
265
275
295
315
Continuous
Draw Rating
@ 135°F
(Gal./Hr.)
A
235
235
235
235
235
235
Standby
Heat Loss
Rating
(°F/Hr.)
1.2
1.1
0.9
0.8
0.6
0.4
Minimum
Heat Source
Flow Rate
(Gal./Min.)
13.7
13.7
13.7
13.7
13.7
13.7
Minimum
Output Rate
of Heat Source
(BTU/Hr.)
157,000
157,000
157,000
157,000
157,000
157,000
5
DAF
EG
C
B
DA
F
EG
C
B
POTABLE
CONNECTIONS
ANODE RODS
(TYPICAL)
(TYPICAL)
These certified ratings wereobtained with a heat source output
rate and flow rate as specified and a 180°Fboiler water supply
temperature. Other results will be obtained under different
conditions.
