Powder Coated & Stainless Steel
Restroom Partitions
Floor-to-Ceiling – Series 700
Table of Contents
Pre-Installation Information ....................2
Layout Dimensions for Brackets ................3
Mounting Brackets to Wall ................... 4-5
Leveling Bolts to Pilaster ......................5
Mounting Brackets to Pilasters ............... 6-7
Pilaster Mounting Hardware ................. 7-8
Pilasters and Panels ......................9–11
Telescoping and Wall Hung Pilasters ........ 12-15
Pilaster Shoes .............................16
Hinges ................................17–20
Door Hardware..........................21–24
Urinal Screens ..........................25–27
*HDWT-INSTR-012*
For Standard Height
Doors and Panels Only
WARNING
Before beginning installation, make sure that the wall and floor backing are adequate to support the secure
mounting of the toilet compartment units.
NOTICE
To prevent warping, always lay the material flat. Do not lean the material against the wall or stack unevenly.
To prevent "dimpling," extra caution should be taken when instructed to drill through one side of face only.
IMPORTANT
Read this installation manual completely to ensure proper installation, then file it with the owner or
maintenance department. This installation manual provides instruction for the assembly of normal partition
configurations and standard components. Non-standard configurations or components including but not
limited to curved or angled walls, partial walls, oversized panels, or modified hardware are not covered in
this manual. Compliance and conformity to local codes and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
Product warranties and parts information may be found on Bradley's web site at bradleycorp.com.

2
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
Supplies Required:
Hardware Provided
#14-16 Plastic
Anchor
FAST-T373
#14 x 2"
Button-Head
Sheet Metal Screw
Torx-T27 Drive
FAST-P002
(Stainless)
#10 x 5/8"
Button-Head
Sheet Metal Screw
Torx-T27 Drive
FAST-Z0019
Example of Submittal Drawing
• Chalk line and pencil
• Tape measure and 4' level
• Jigsaw (or hacksaw) and circular saw
• Two spring clamps
• 1/8",9/64", 3/16" and 1/4" drill bits
• Power drill or screw gun with drill bit extension
• 1/4" and 5/16" ceramic tile and masonry drill bit
• Hammer drill
• Spacer, 12" (305mm) high and strong enough to
support weight of panel
#14 x 5/8"
Button-Head
Sheet Metal Screw
Torx-T27 Drive
FAST-Z0016
#5-40 x 11/16"
Flat-Head
Sheet Metal Screw
Torx-T10 Drive
FAST-T300
1/4"- 14 x 5/8"
Sheet Metal Screw
Torx-T27 Drive
FAST-S355A
#10 x 3/4"
Flat-Head
Sheet Metal Screw
Torx-T25 Drive
FAST-Z0006
#14 x 2"
Button-Head
Sheet Metal Screw
Torx-T27 Drive
FAST-Z002
(Chrome Plated)
#10-24 x 3/4"
Button-Head
Barrel Nut
Torx-T27 Drive
FAST-Z003
(Chrome Plated)
#10-24 x 3/4"
Button-Head
Barrel Nut
Torx-T27 Drive
FAST-P003
(Stainless)
#10-24 x 3/4"
Button-Head
Shoulder Screw
Torx-T27 Drive
FAST-Z004
(Chrome Plated)
#10-24 x 3/4"
Button-Head
Shoulder Screw
Torx-T27 Drive
FAST-P004
(Stainless)
#10-24 x 1"
Button-Head
Shoulder Screw
Torx-T27 Drive
FAST-Z004A
(Chrome Plated)
#10-24 x 1"
Button-Head
Shoulder Screw
Torx-T27 Drive
FAST-P004A
(Stainless)
#10-24 x 2"
Flat-Head
Machine Screw
Torx-T25 Drive
FAST-Z0027
5/16" - 18 x 3"
Leveling Bolt
FAST-S0039
61-1/4"
(1556mm)
to face
60-1/2"
(1537mm)
wall to
centerline
36"
(914mm)
center to
center
36"
(914mm)
24"
(610mm)
26"
(660mm)
8"
(203mm)
3" (76mm)
1" (25mm) gap
1"
(25mm)
gap
1/2"
(13mm)
gap
3"
3-1/2"
1-1/2"
20-1/2"
6-1/2"
58-1/2"
(1486mm)
58-1/2"
(1486mm)
#10 x 2"
Flat-Head
Sheet Metal Screw
Torx-T25 Drive
FAST-S0023
#10 x 5/8"
Button-Head
Sheet Metal Screw
Torx-T27 Drive
FAST-S351A

3
Installation Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700
Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006 1/23/2023
*
*
*
*
*
*
C
L
C
L
C
L
C
L
C
L
C
L
Pilaster plumb line
When installing the partition components, consult
the applicabale Bradley Partition submittal
drawing for compartment layout dimensions.
1Layout Dimensions - Stirrup Brackets (Standard)
Pilaster Centerline: Measure from the
back wall forward to the face of the
compartment, subtract 5/8" (16mm) and
mark this location on the floor ("A"). Mark
the same measurement on the opposite end
of your layout ("A1") and draw a straight line
connecting both marks.
For Freestanding (FS) Partitions: Refer
to submittal drawings and determine the
approximate location of the outside panels.
Establish dimensions "A" and "A1" as
explained above.
A
Panel Centerline: Measure the stall width across the
back wall and place a mark at the base of the rear wall
("B"). Repeat this step for each panel, starting each
measurement from the last panel centerline ("B1").
B
Draw a plumb line on all walls from each pilaster
and panel centerline. From the highest point
in the room, measure 18" (457mm) and 64"
(1626mm) from the floor and place a mark on the
pilaster/panel plumb line. These marks represent
the hole center line of the stirrup brackets. Use a
level to transfer that mark to all other plumb lines
("C").
C
Panel
plumb line
C
L
C
L
C
L
C
L
*
*
*
Pilaster plumb line
When installing the partition components, consult
the applicable Bradley Partition submittal drawing
for compartment layout dimensions.
1a Layout Dimensions - Continuous Brackets (Optional)
Pilaster Centerline: Measure from
the back wall forward to the face of the
compartment, subtract 5/8" (16mm)
and mark this location on the floor ("A").
Mark the same measurement on the
opposite end of your layout ("A1") and
draw a straight line connecting both
marks.
For Freestanding (FS) Partitions:
Refer to submittal drawings and
determine the approximate location
of the outside panels. Establish
dimensions "A" and "A1" as explained
above.
A
Panel Centerline: Measure the stall width across the
back wall and place a mark at the base of the rear wall
("B"). Repeat this step for each panel, starting each
measurement from the last panel centerline ("B1").
B
Draw a plumb line on all walls from each pilaster and panel
centerline. From the highest point in the room, measure from
the floor and place a mark on the pilaster/panel plumb line at
dimension "C" for the respective bracket type (see table on right).
Use a level to transfer that mark to all other plumb lines ("D").
C
Panel
plumb line
64"
(1626mm)
18"
(457mm)
"C"
"D"
"C"
"D"
"C"
"C"
"C"
"C"
"B"
"B"
"B1"
"B1"
"A1"
"A1"
"A"
"A"
"C"
"D"
Dim "C"
Stainless
Steel
12-1/2"
(318mm)
Aluminum 12-1/4"
(311mm)

4
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
2Stirrup Brackets to Wall (Standard)
established level line
pilaster/panel plumb line
floor
C
L
Place the center of each stirrup bracket
at the established level line. Center the
bracket opening on the pilaster/panel
plumb line.
A
Insert the plastic anchors in all holes and
secure the brackets to the wall with the
#14 x 2" screws provided.
C
On end panel and pilaster applications, position the bracket
with the ear facing toward the inside of the stall.
Using the bracket as a template, mark the
hole locations on the wall. Remove the
bracket and drill a Ø5/16" hole (min. 2"
[51mm] deep) at each hole location.
B
One-Eared
Bracket
Two-Eared
Bracket
Pilaster bracket is shown here. 1-1/4" opening brackets are
for pilasters and 1" opening brackets are for panels.
2a Continuous Stainless Steel Brackets to Wall (Optional)
established level line
pilaster plumb
line
floor
C
L
Place the bottom of each continuous
bracket at the established level line.
Center the bracket opening on the
pilaster/panel plumb line.
A
Insert the plastic anchors in all holes and
secure the brackets to the wall with the
#14 x 2" stainless screws provided.
C
On pilaster applications, position the bracket with the ear
facing toward the inside of the stall.
Using the bracket as a template, mark the
hole locations on the wall. Remove the
bracket and drill a Ø5/16" hole (min. 2"
[51mm] deep) at each hole location.
B
Brackets are used as templates, but since the hole patterns
may be different, the brackets may not be interchangeable.
Pilaster bracket is shown here; "EAR" brackets are for pilasters and
"U" brackets are for panels.
"Ear"
Bracket
"U" Bracket

5
Installation Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700
Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006 1/23/2023
2b Continuous Aluminum Brackets to Wall (Optional)
established level line
pilaster/panel
plumb line
floor
C
L
Place the bottom of each continuous
bracket at the established level line.
Center the bracket opening on the
pilaster/panel plumb line.
A
Insert the plastic anchors in all holes and
secure the brackets to the wall with the
#14 x 2" stainless screws provided.
C
On end panel and pilaster applications, position the bracket
with the ear facing toward the inside of the stall.
Using the bracket as a template, mark
the hole locations on the wall. Remove
bracket and drill a Ø5/16" hole (min. 2"
[51mm] deep) at each hole location.
B
Brackets are used as templates, but since the hole patterns
may be different, the brackets may not be interchangeable.
Pilaster bracket is shown here; 1-1/4" opening brackets are for
pilasters, and 1" opening brackets are for panels.
One-Eared
Bracket Two-Eared
Bracket
3Leveling Bolts to Pilaster
Use leveling bolt(s) to adjust height of pilaster
as indicated based on pilaster width.
A
3" Pilaster 4" - 14" Pilaster 18" - 24" Pilaster
4" - 8" pilasters have a single, 1-piece bracket that uses a
leveling bolt in the center to adjust the pilaster height.

6
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
4Stirrup Brackets to Pilaster (Standard)
Refer to the submittal drawing to locate the split
dimension and layout location of each marked pilaster.
8' Ceiling: Measure 30-5/8" (778mm) and 76-5/8" (1946mm)
down from the top of each pilaster and place a mark on the
pilaster split centerline.
For ceiling heights other than 8': add or subtract the
appropriate amount to the dimensions shown. For example, a
9' ceiling would add 12" (305mm) to each dimension.
A
Split Split
30-5/8"
(778mm)
76-5/8"
(1946mm)
Place stirrup brackets at each established level line. Center
the bracket opening on the pilaster split centerline. Using the
bracket as a template, mark the hole locations on the pilaster.
Remove the bracket and drill a Ø3/16" pilot hole (through
inside face of pilaster only) at each location.
B
Secure the stirrup brackets to the pilasters using the
#14 x 5/8" screws providied.
C
4a Continuous Brackets to Pilaster (Optional)
Refer to the submittal drawing to locate the split
dimension and layout location of each marked pilaster.
8' Ceiling: Measure down from the top of
the pilaster and place a mark on the pilaster
centerline at dimensions "A" and "B" for the
respective bracket (see table on left).
For ceiling heights other than 8': add
or subtract the appropriate amount to the
dimensions shown. For example, a 9' ceiling
would add 12" (305mm) to each dimension.
A
Secure the continuous bracket to the pilasters
using the #14 x 5/8" stainless screws
provided.
C
Split Split
"A"
"B"
Dim. "A" Dim. "B"
Stainless
Steel
Bracket
25-1/8"
(638mm)
82-1/8"
(2086mm)
Aluminum
Bracket
24-7/8"
(632mm)
82-3/8"
(2092mm)
Place the continuous bracket between each
established level line. Center the bracket
opening on the pilaster split centerline. Using
the bracket as a template, mark the hole
locations on the pilaster. Remove the bracket
and drill a Ø3/16" pilot hole (through inside
face of pilaster only) at each location.
B
Brackets are used as templates but since the hole patterns
may be different, the brackets may not be interchanged.
Continuous stainless steel bracket shown.
Pilaster shown is for reference only. Actual pilaster varies
depending on application.
Pilaster shown is for reference only. Actual
pilaster varies depending on application.
C
L
C
L
C
L

7
Installation Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700
Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006 1/23/2023
5Pilaster Floor Mounting Hardware
This view is an example only. Refer to your submittal drawings to determine placement of the anchors on the pilaster
centerline for your application. Typical anchor centers are measured 1" (25mm) in from each edge of the pilaster (except 3"
pilasters where only one anchor is used).
A
Insert plastic anchors into the holes and
fasten the "L" brackets to the anchors
using the #14 x 2" screws provided.
C
Drill Ø5/16" holes (min 2" [51mm] deep)
into the floor and make sure the holes are
free of dirt and debris.
B
38"
(965mm)
Pilaster Centerline
22"
(559mm)
3"
(76mm) 6"
(152mm)
28"
(711mm)
4b Alcove Brackets to Pilaster
Layouts that use continuous aluminum brackets for pilaster and panel connections will use stirrup brackets for alcove connections.
Continuous stainless steel brackets use continuous alcove brackets.
Refer to the submittal drawing for the layout location of each alcove pilaster
8' Ceiling: Measure down from
the top of the pilaster and place a
mark at dimensions shown for the
respective bracket situation.
For ceiling heights other than 8':
add or subtract the appropriate
amount to the dimensions shown.
For example, a 9' ceiling would add
12" (305mm) to each dimension.
A
Stirrup: Position the center of each
bracket at the marks made in Step A.
Continuous: Center the bracket
between each mark made in Step A.
B
Using the bracket as a template,
mark the hole locations on the
pilaster. Remove the bracket and drill
Ø3/16" holes through the pilaster at
each location.
C
Secure the bracket(s) to the
pilaster using the #14 x 5/8" screws
(stainless on continuous) provided.
D
76-5/8"
(1946mm)
30-5/8"
(778mm)
Stirrup Continuous
82-1/8"
(2086mm)
25-1/8"
(638mm)

8
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
5a Pilaster Ceiling Mounting Hardware
Using the bracket as a template, mark the hole
location on the ceiling. Remove the bracket
and drill a Ø5/16" hole (min 2" [51mm] deep).
C
Remove pilaster and position "L" bracket(s)
accordingly.
3" - 5" Pilasters: Center (1) "L" bracket
between the projected outer edge lines and
flush with the projected inside face line.
6" - 24" Pilasters: Place (2) "L" brackets 1/2"
(13mm) in from each outer edge line and flush
with the projected inside face line.
B
Position the pilaster so that the mounting
bracket(s) sits on the inside of the floor "L"
bracket(s). Verify that the pilaster is plumb in
both directions. Project the outer edges and
inside face of the pilaster onto the ceiling.
A
Each pilaster comes with a matching shoe kit containing the required fasteners and "L" brackets for mounting.
Single "L"
Bracket
Double "L"
Bracket
Insert the plastic anchor and secure the
bracket to the ceiling with the #14 x 2"
stainless screw provided.
D
Outside
Face
1/2"
(13mm)

9
Installation Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700
Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006 1/23/2023
6Pilasters and Panels with Stirrup Brackets (Standard)
Pilasters located at walls should be mounted first. Start at one end and install a panel, then a pilaster. Continue alternating until
installation is complete. When installing in an alcove or in-corner, use an alcove bracket to secure the pilaster to the panel.
Pilasters at Wall Pilasters with Panels
Check to make sure the pilasters are plumb and level to each other. The pilaster height can be adjusted with the leveling bolt that
was placed at the bottom of the pilaster (see page 5 for attaching leveling bolt).
When installing pilaster at walls, the gaps range
from 1/2" to 1-1/4" (13mm to 32mm). Refer to your
submittal drawing for your gap sizes.
Refer to your submittal drawing and leave the appropriate
gaps. Standard gap is 1" (25mm) between the panel and
wall and 1/2" (13mm) between the panel and pilaster.
Spacer 12" (305mm)
Slide a shoe onto the bottom of the pilaster and
use a piece of tape to keep the shoe positioned
above the floor mounting hardware. Slide the other
shoe onto the top of the pilaster and use a piece of
tape to keep the shoe positioned about 5" (127mm)
from the end. Make sure both shoe mounting holes
face the inside of the stall and that the bottom shoe
hole is towards the top, while the top shoe hole is
towards the bottom.
A
Postion the pilaster so the mounting bracket(s) sits
on the inside of the floor "L" bracket(s) while at
the same time placing the pilaster within the wall
brackets. Secure the pilaster mounting bracket(s) to
the floor "L" bracket(s) using the #14 x 5/8" screw(s)
provided.
B
Using the bracket as a template, drill Ø3/16" holes
through the pilaster at each pilaster bracket hole.
Secure the pilaster to the bracket using the
#14 x 5/8" screws provided.
CUsing the bracket as a template, drill Ø3/16" holes
through the panel at each panel bracket hole.
Secure the panel to the bracket using the #14 x 5/8"
screws provided.
D
Place the panel on the spacer and insert the panel into
the wall brackets.
A
Slide a shoe onto the bottom of the pilaster and use a
piece of tape to keep the shoe positioned above the floor
mounting hardware. Slide the other shoe onto the top
of the pilaster and use a piece of tape to keep the shoe
positioned about 5" (127mm) from the end. Make sure
both shoe mounting holes face the inside of the stall and
that the bottom shoe hole is towards the top, while the top
shoe hole is towards the bottom.
B
Position the pilaster so the mounting bracket(s) sits on the
inside of the floor "L" bracket(s) while at the same time
placing the brackets around the panel. Secure the pilaster
mounting bracket(s) to the floor "L" bracket(s) using the
#14 x 5/8" screw(s) provided.
C

10
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
6a Pilasters and Panels with Stainless Steel Continuous Brackets (Optional)
Pilasters located at walls should be mounted first. Start at one end and install a panel, then a pilaster. Continue alternating until
installation is complete. When installing in an alcove or in-corner, use an alcove bracket to secure the pilaster to the panel.
Pilasters at Wall Pilasters with Panels
Check to make sure the pilasters are plumb and level to each other. The pilaster height can be adjusted with the leveling bolt that
was placed at the bottom of the pilaster (see page 5 for attaching leveling bolt).
When installing pilaster at walls, the gaps range
from 1/2" to 1-1/4" (13mm to 32mm). Refer to your
submittal drawing for your gap sizes.
Refer to your submittal drawing and leave the appropriate
gaps. Standard gap is 1" (25mm) between the panel and
wall and 1/2" (13mm) between the panel and pilaster.
Spacer 12" (305mm)
Slide a shoe onto the bottom of the pilaster and
use a piece of tape to keep the shoe positioned
above the floor mounting hardware. Slide the other
shoe onto the top of the pilaster and use a piece of
tape to keep the shoe positioned about 5" (127mm)
from the end. Make sure both shoe mounting holes
face the inside of the stall and that the bottom shoe
hole is towards the top, while the top shoe hole is
towards the bottom.
A
Position the pilaster so the mounting bracket(s) sits
on the inside of the floor "L" bracket(s) while at
the same time placing the pilaster within the wall
bracket. Secure the pilaster mounting bracket(s) to
the floor "L" bracket(s) using the #14 x 5/8" screw(s)
provided.
B
Using the bracket as a template, drill Ø3/16" holes
through the pilaster at each pilaster bracket hole.
Secure the pilaster to the bracket using the
#14 x 5/8" stainless screws provided.
CUsing the bracket as a template, drill Ø3/16" holes
through the panel at each panel bracket hole.
Secure the panel to the bracket using the #14 x 5/8"
stainless screws provided.
D
Place the panel on the spacer and insert the panel into
the wall bracket.
A
Slide a shoe onto the bottom of the pilaster and use a
piece of tape to keep the shoe positioned above the floor
mounting hardware. Slide the other shoe onto the top
of the pilaster and use a piece of tape to keep the shoe
positioned about 5" (127mm) from the end. Make sure
both shoe mounting holes face the inside of the stall and
that the bottom shoe hole is towards the top, while the top
shoe hole is towards the bottom.
B
Position the pilaster so the mounting bracket(s) sits on the
inside of the floor "L" bracket(s) while at the same time
placing the bracket around the panel. Secure the pilaster
mounting bracket(s) to the floor "L" bracket(s) using the
#14 x 5/8" screw(s) provided.
C

11
Installation Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700
Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006 1/23/2023
6b Pilasters and Panels with Aluminum Continuous Brackets (Optional)
Pilasters located at walls should be mounted first. Start at one end and install a panel, then a pilaster. Continue alternating until
installation is complete. When installing in an alcove or in-corner, use an alcove bracket to secure the pilaster to the panel.
Pilasters at Wall Pilasters with Panels
Check to make sure the pilasters are plumb and level to each other. The pilaster height can be adjusted with the leveling bolt that
was placed at the bottom of the pilaster (see page 5 for attaching leveling bolt).
When installing pilaster at walls, the gaps range
from 1/2" to 1-1/4" (13mm to 32mm). Refer to your
submittal drawing for your gap sizes.
Refer to your submittal drawing and leave the appropriate
gaps. Standard gap is 1" (25mm) between the panel and
wall and 1/2" (13mm) between the panel and pilaster.
Spacer 12" (305mm)
Slide a shoe onto the bottom of the pilaster and
use a piece of tape to keep the shoe positioned
above the floor mounting hardware. Slide the other
shoe onto the top of the pilaster and use a piece of
tape to keep the shoe positioned about 5" (127mm)
from the end. Make sure both shoe mounting holes
face the inside of the stall and that the bottom shoe
hole is towards the top, while the top shoe hole is
towards the bottom.
A
Position the pilaster so the mounting bracket(s) sits
on the inside of the floor "L" bracket(s) while at
the same time placing the pilaster within the wall
bracket. Secure the pilaster mounting bracket(s) to
the floor "L" bracket(s) using the #14 x 5/8" screw(s)
provided.
B
Using the bracket as a template, drill Ø1/4" holes
through the pilaster at each pilaster bracket hole.
Secure the pilaster to the bracket using the
#10-24 x 3/4" stainless barrel nuts and #10-24 x 1"
stainless shoulder screws provided.
C
Using the bracket as a template, drill Ø1/4" holes
through the panel at each panel bracket hole. Secure
the panel to the bracket using the #10-24 x 3/4" stainless
barrel nuts and #10-24 x 3/4" stainless shoulder screws
provided.
D
Place the panel on the spacer and insert the panel into
the wall bracket.
A
Slide a shoe onto the bottom of the pilaster and use a
piece of tape to keep the shoe positioned above the floor
mounting hardware. Slide the other shoe onto the top
of the pilaster and use a piece of tape to keep the shoe
positioned about 5" (127mm) from the end. Make sure
both shoe mounting holes face the inside of the stall and
that the bottom shoe hole is towards the top, while the top
shoe hole is towards the bottom.
B
Position the pilaster so the mounting bracket(s) sits on the
inside of the floor "L" bracket(s) while at the same time
placing the bracket around the panel. Secure the pilaster
mounting bracket(s) to the floor "L" bracket(s) using the
#14 x 5/8" screw(s) provided.
C

12
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
6c Telescoping Pilasters (Optional)
Mounting channels are used as templates but may not be interchanged because the hole patterns may be different.
To establish level line, from the highest point in the room, measure 12-1/8" (308mm) from the floor. Use a level to
transfer this mark to the pilaster plumb line.
Floor
Pilaster Plumb Line
Mounting Channel
12-1/8" (308mm)
to Bottom of
Channel (Highest
Point in Floor)
Telescoping Pilaster at Wall
Wall, Pilaster or Panel
Mounting Channel
Telescoping
Channel
Specified
Dimension
Telescoping Pilaster at Pilaster
12-1/8"
(308mm)
Pilaster
Centerline
Mounting Channel
Place the bottom of the mounting channel at the established
level line. Center the channel opening on the pilaster
plumb line.
A
Wall: Using the mounting channel as a template, mark the
hole locations and remove mounting channel. Drill a Ø5/16"
hole (min 2" [51mm] deep) at each hole location.
Pilaster: Using the mounting channel as a template, mark
the hole locations and remove the mounting channel. Drill a
Ø1/4" hole through the pilaster.
B
Wall: Insert the plastic anchors in all holes and secure
the mounting channel to the wall with the #14 x 2" screws
provided.
Pilaster: Secure the mounting channel to the pilaster with
the #10-24 x 3/4" barrel nuts and the #10-24 x 1" shoulder
screws provided.
C
Slide the telescoping channel over the mounting channel.
Refer to the submittal drawings and adjust the width to
meet the specified dimension.
D
Using the holes in the telescoping channel as a template,
drill Ø3/16" holes through the mounting channel. Secure the
telescoping channel to the mounting channel with the
#14 x 5/8" screws provided.
E

13
Installation Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700
Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006 1/23/2023
6d Wall-Hung Pilasters (58") - Stirrup Brackets (Optional)
To establish level line, from the highest point in the room, measure 12" (305mm) from the floor. Use a level to transfer
this mark to the pilaster plumb line.
See Step 2 for instructions on mounting the stirrup brackets to a wall.
Wall
Specified Dimension
(Standard Gap 1")
12"
(305mm)
Pilaster
Plumb Line
Pilasters at Wall Pilasters at Pilasters
Specified
Dimension
See Step 4 for instructions on mounting the stirrup brackets to a pilaster.
Floor
Slide the wall-hung pilaster into the stirrup brackets
and align with the established level line. Refer to
the submittal drawing and adjust to meet the
specified dimension.
A
Using the stirrup brackets as a template, drill
Ø3/16" holes through the pilaster at each bracket
hole. Secure the pilaster to the bracket using the
#14 x 5/8" screws provided.
B
Slide the wall-hung pilaster into the stirrup brackets
and align with the established level line. Refer to
the submittal drawing and adjust to meet the
specified dimension.
A
Using the stirrup brackets as a template, drill
Ø3/16" holes through the pilaster at each bracket
hole. Secure the pilaster to the bracket using the
#14 x 5/8" screws provided.
B
C
L

14
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
6e Wall-Hung Pilasters (58") - Continuous Stainless Steel Brackets (Optional)
To establish level line, from the highest point in the room, measure 12" (305mm) from the floor. Use a level to transfer
this mark to the pilaster plumb line.
See Step 2a for instructions on mounting the continuous stainless
steel brackets to a wall.
Wall
Specified Dimension
(Standard Gap 1")
12"
(305mm)
Pilaster
Plumb Line
Pilasters at Wall Pilasters at Pilasters
Specified
Dimension
See Step 4a for instructions on mounting the continuous stainless
steel brackets to a pilaster.
Floor
Slide the wall-hung pilaster into the continuous
bracket and align with the established level line.
Refer to the submittal drawing and adjust to meet
the specified dimension.
A
Using the continuous bracket as a template, drill
Ø3/16" holes through the pilaster at each bracket
hole. Secure the pilaster to the bracket using the
#14 x 5/8" stainless screws provided.
B
Slide the wall-hung pilaster into the continuous
bracket and align with the established level line.
Refer to the submittal drawing and adjust to meet
the specified dimension.
A
Using the continuous bracket as a template, drill
Ø3/16" holes through the pilaster at each bracket
hole. Secure the pilaster to the bracket using the
#14 x 5/8" stainless screws provided.
B
C
L

15
Installation Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700
Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006 1/23/2023
6f Wall-Hung Pilasters (58") - Continuous Aluminum Brackets (Optional)
To establish level line, from the highest point in the room, measure 12" (305mm) from the floor. Use a level to transfer
this mark to the pilaster plumb line.
See Step 2b for instructions on mounting the continuous aluminum
brackets to a wall.
Wall
Specified Dimension
(Standard Gap 1")
12"
(305mm)
Pilaster
Plumb Line
Pilasters at Wall Pilasters at Pilasters
Specified
Dimension
See Step 4a for instructions on mounting the continuous
aluminum brackets to a pilaster.
Floor
Slide the wall-hung pilaster into the continuous
bracket and align with the established level line.
Refer to the submittal drawing and adjust to meet
the specified dimension.
A
Using the continuous bracket as a template, drill
Ø1/4" holes through the pilaster at each bracket
hole. Secure the pilaster to the bracket using the
#10-24 x 3/4" stainless barrel nuts and #10-24 x 1"
stainless shoulder screws provided.
B
Slide the wall-hung pilaster into the continuous
bracket and align with the established level line.
Refer to the submittal drawing and adjust to meet
the specified dimension.
A
Using the continuous bracket as a template, drill
Ø1/4" holes through the pilaster at each bracket
hole. Secure the pilaster to the bracket using the
#10-24 x 3/4" stainless barrel nuts and #10-24 x 1"
stainless shoulder screws provided.
B
C
L

16
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
7Pilaster Shoes
Using the "L" bracket(s) as a template, drill a Ø9/64"
pilot hole (through inside face of pilaster only). Secure
"L" bracket(s) to pilaster using the #10 x 5/8" fastener(s)
provided.
A
Wraparound Gravity Hinge: Continue to Step D (top shoe
will be secured later).
Continuous Hinge: Position the top shoe so that it rests
flush with the ceiling.
B
Using the hole(s) in the shoe as a template, drill a Ø9/64"
pilot hole (through inside face of pilaster only). Secure
the shoe to the pilaster using the #10 x 5/8" fastener(s)
provided.
C
Position bottom shoe so that it rests flush with the floor.
D
Repeat Step C to secure shoe to pilaster.
E

17
Installation Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700
Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006 1/23/2023
8Wraparound Gravity Hinges (Standard)
Before installing the hinges, make sure the door openings are the appropriate size, all pilasters are plumb and
secured to the floor and ceiling mounting hardware.
Right-hand
inswing
(RHI)
Left-hand
inswing
(LHI)
Right-hand
outswing
(RHO)
Left-hand
outswing
(LHO)
Dim. "A" Dim. "B"
Floor to
Ceiling
(8'-0" Ceiling
Height)
26-1/16"
(662mm)
80-3/16"
(2037mm)
Wall Hung
58"
(1473mm)
2-1/16"
(52mm)
56-3/16"
(1427mm)
For 58" wall hung pilaster, establishing dimensions "A" and "B" as shown in the table will
result in the top of the door being flush with the top of the pilaster when the desired cam
setting on the door is set to 0°.
Refer to your submittal drawings to determine each specific door swing for your application. The door swing is
determined by facing the compartment from the outside. The image below can help determine the door swing type.
8' Ceiling: Measure down from the top of the
pilaster and place a mark at dimensions "A" and
"B" for the respective pilaster type (see table
below). This mark represents the upper hole
location of the top and bottom hinge.
For ceiling heights other than 8': add or
subtract the appropriate amount to the dimensions
shown. For example, a 9' ceiling would add
12" (305mm) to each dimension.
A
Using the hinge as a template, drill Ø1/4" holes
through the pilaster.
B
"A"
"B" "B"
"A"
Floor-to-Ceiling
(8' Ceiling Height Shown)
Position the top shoe so that it rests flush with the
ceiling. Follow step 7C to secure the shoe to the
pilaster.
C
Wall Hung
58" (1473mm)

18
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
Secure the top and bottom pilaster hinge to the pilaster
with the #10-24 x 3/4" barrel nuts and #10-24 x 1"
shoulder screws provided.
D
Assemble the bottom hinge cam and pin as shown.
Insert into the bottom hinge and thread the locknut
loosely onto the bottom hinge pin.
E
Rotate the door to the desired "at rest" position. Push
down on the door while holding it in the "at rest"
position. This sets the male and female cams in the
bottom hinge. Tighten the hex nut to secure the door in
the "at rest" position.
G
8Wraparound Gravity Hinges (Continued)
The door hinge assembly consists of separate door
and pilaster hardware.
Door cam surfaces can become worn under normal use.
The application of lithium grease can help prolong door
cam life and reduce friction between surfaces.
The top hinge pin should snap securely
into place.
Bottom
Hinge
Pin
Cam
Lock Nut
Top Hinge
Pin
Finished View
of Top Hinge
Finished View
of Bottom Hinge
Place the bottom door hinge opening onto the bottom
pilaster hinge. Position the top door hinge opening into
the top pilaster hinge and insert the top hinge pin.
F
For doors requiring a full close, rotate the
door 15° past the closed position.

19
Installation Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700
Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006 1/23/2023
8a Continuous Spring-Loaded Piano Hinge (Optional)
Place a door on a 12" (305mm) spacer and set the door gaps.
Standard hinge side gap is 9/32" (7mm).
A
Position the hinge so it is plumb and centered within the
9/32" (7mm) gap and centered top to bottom (approximately
1/4" (6mm) down from the top of the door).
B
Right-hand
inswing
(RHI)
Left-hand
inswing
(LHI)
Right-hand
outswing
(RHO)
Left-hand
outswing
(LHO)
Closed Door
View
Continuous Piano Hinge Part # Prefix HDWT-S0209 Part # Prefix HDWT-S0208
The part numbers listed are prefixes only and
are used to identify the appropriate door kit
based on your door swing as determined above.
Inswinging doors should have hinges mounted
on the inside of the stall while outswinging doors
should have hinges mounted on the outside of
the stall.
(left hand in, right hand out,
knuckles facing front)
(right hand in, left hand out,
knuckles facing front)
Door
side Pilaster
side
Door
side
Pilaster
side
Using the hinge as a template, drill Ø1/4" holes through the
door at the top and bottom holes. Secure the hinge to the door
using the #10-24 x 3/4" stainless barrel nuts and #10-24 x 3/4"
stainless shoulder screws provided.
C
Check to make sure the hinge side gap is still at 9/32" (7mm).
Using the hinge as a template drill Ø1/4" holes through the
pilaster at the top and bottom holes. Secure the hinge to the
pilaster using the #10-24 x 3/4" stainless barrel nuts and
#10-24 x 1" stainless shoulder screws provided.
D
Before installing the hinges, make sure the door openings are the appropriate size, all pilasters are plumb and
secured to the floor and ceiling mounting hardware.
Refer to your submittal drawings to determine each specific door swing for your application. The door swing is
determined by facing the compartment from the outside. The image below can help determine the door swing type.
Drill Ø1/4" holes through the remaining hinge holes on the door
and pilaster. Secure with the fasteners provided.
E
Spacer 12" (305mm)

20
Powder Coated & Stainless Steel Restroom Partitions, Floor-to-Ceiling — Series 700 Installation
1/23/2023 Bradley • HDWT-INSTR-012 Rev. G: ECO 22-14-006
8b Stainless Steel Flat Hinge (Optional)
From the highest point in the room, measure 12"
(305mm) and 68-3/8" (1737mm) from the floor. Use
a level to transfer these marks to the pilaster plumb
line.
A
Position the bottom of the bottom flat hinge on the
12" (305mm) mark and center on the pilaster plumb
line. Using the flat hinge as a template, mark the
hole locations on the wall. Remove the flat hinge and
drill a Ø1/4" hole (minimum 2" [51mm] deep) at each
hole location.
B
Position the top of the top flat hinge on the
68-3/8" (1737mm) mark and center on the pilaster
plumb line. Using the flat hinge as a template, mark
the hole locations on the wall. Remove the flat hinge
and drill a Ø1/4" hole (minimum 2" [51mm] deep) at
each hole location.
C
Insert plastic anchors in all holes and secure the flat
hinges to the wall with #10 x 2" stainless flat head
screws provided.
D
Floor
Pilaster Plumb Line
68-3/8"
(1737mm)
See Step 1 for instructions on
laying out pilaster plumb line.
12"
(305mm)
See Step 8, E thru G for instructions on attaching the
door to the hinge.
E
