INSTALLATION INSTRUCTIONS
PLUMBING CONNECTIONS: Connectinlethoseusing
either5/8"or3/4"IDhose(asleeveisincludedtoadapt
pump inlet from 5/8" to 3/4"). Make sure all inlet
connections are airtight and free of sharp bends or
restrictions.
NOTICE:Thetoiletinletmustnotbeconnectedtoa
pressurized watersystem.
Connect 1" or 1-1/2" hose to discharge port (Adaptor
98023-0080 is included to convert discharge port to
1-1/2"IDhose),andmakesuitableconnectiontoholding
tank or other discharge system. Avoid sharp bends or
restrictions.
Ifthetoiletis,orcanbe,belowwaterlineatanynormal
(includingstatic)attitudeofvesselheeland/ortrim,a3/4"
VentedLoopFittingmustbeinstalledinthelengthofhose
connecting the flushing pump to the inlet seacock.The
Vented Loop Fitting must be positioned so it remains
slightly* above the waterline at all angles of heel and
trim.
*Recommended minimum height above waterline is 8".
Forabovewaterlineinstallations,acheckvalvemayhave
tobeinstalledintheflushwaterintakelinetoensurerapid
pumppriming.Toretainwaterinbowl,makealoopinthe
dischargelineabout8inchesabovebaseofbowl.
Do not connect the toilet to the vessels
portablewaterforitssourceofsupply.Todosocanresult
incontaminationofportablewatersupply.Iffreshwateris
preferredforflushing,provideaseparatefreshwatertank
tosupplywatertothetoiletonly.
DO NOT CONNECT INLET HOSE TO A PRESSURIZED
PORTION OF THE WATER SYSTEM.
ELECTRICAL CONNECTIONS: Selectalocationforthe
switchandinstructionplate,makingsurewireleadsfrom
both the toilet and power source can be routed to the
switch. Ensure the panel where installing switch is no
morethan1"thick.Drilla5/8"mountingholeandinstall
switchandinstructionplate.Usestrandedcopperwireof
the correct size (determined from the electrical
specificationschart)toconnectonesideoftheswitchto
thepositivepowersource.
NOTICE:Correctwiresizeandsecurewireconnections
are very important. Undersized wire and unsecured or
corrodedwireconnectionswillcauseareductioninpump
performanceandpossiblepumpfailure.An appropriate
size fuse or equivalent circuit breaker (determined
from electrical specifications chart) must be installed
in the positive power lead within seven inches of the
power source or in the electrical power distribution
breaker/fuse panel.Connecttheothersideoftheswitch
to the orange (positive) motor lead. Connect the black
(negative)motorleadtothenegativesideofthebattery
orgroundedbussbar.
NOTICE: Correctmotorpolarity(orangetopositive,black
tonegative) is important. Reverse polarity can damage
motor and void warranty. Full voltage at the motor is
required to properly operate Jabsco Electric Toilet. The
toiletmust be wiredina circuit independent of allother
accessories.
OPERATING INSTRUCTIONS
Make sure inlet and outlet seacocks are all open; push
switchbuttontooperate.Operateuntilbowliscompletely
flushedanddischargepumphasscavengedwaterfrom
bottomofbowl.
The Jabsco electric marine toilet will provide years of
troublefreeserviceifproperlyused.Itwillhandlewaste
andtoilettissue.Itwillnothandlerags,sanitarynapkins
orhardsolidobjects.
Clean toilet with mild non-abrasive cleaners without
strongaromatics.Cleanershavinghighconcentrationsof
aromatics, such as pine cleaners and strongly scented
de-greaserconcentrates,cancausethepump'simpeller
toswellandpossiblybindup.
Ifbowldoesnotpumpoutandbeginstofill,partiallyclose
inletvalveuntilbowlisclearedandcompletelypumped
out. Then operate for a few seconds with both valves
open to clear entire toilet and discharge system. For
maximum safety, when toilet is not in use or vessel is
unattended, close both the inlet and discharge
seacocks.
Todrainforwinterlayup,closeinletvalveandoperatefor
afewsecondsuntilallwaterispumpedout.
DISASSEMBLY
WARNING Floodhazard.Closeinletandoutletseacockspriorto
disassembling toilet. Failure to do so can result in
floodingwhichcancauselossofpropertyandlife.
Disconnect pump inlet and discharge hoses. Remove
fourscrews,KeyNo.23,pulloutcompletemotor,pump
andmaceratorassembly.Removemaceratorhousingfrom
base.
Remove discharge port, Key No. 9, and inspect joker
valve.Unscrewchopperplatelocknut,KeyNo.12,by
turning counterclockwise, facing plate and remove
chopper. Prevent shaft from turning by inserting a
screwdriver in slot of shaft protruding from rear of
motor.Loosencentrifugalimpellersetscrewandslide
impelleroffmotorshaft.
Remove four flathead screws, Keys No. 17 & 18,
wearplate,KeyNo.21,shaftsealingsleeve,KeyNo.20,
ELECTRICAL SPECIFICATIONS
AMP FUSE WIRE SIZE PER FEET OF RUN*
VOLTAGE DRAW SIZE 0'-10' (0 M-3 M) 10'-15' (3 M-4,6 M) 15'-25' (4,6 M-7,6 M) 25'-40' (7,6 M-12,2 M) 40'-60' (12,2 M-18,3 M)
12Vdc 16 25 #12(4mm2) #10(6mm2) #10(6mm2) #8(10mm2) #6(16mm2)
24Vdc 8 15 #16(1.5mm2) #14(2.5mm2) #12(4mm2) #10(6mm2) #10(6mm2)
*Lengthofrunistotaldistancefrompowersourcetoproductandbacktoground.
