Bronco Electric Start Charcoal
BMBROCH
OWNER’S MANUAL
rt
Made from 75% Bagasse
(enviromentally-friendly sugar cane
pulp by-product
rt
rt
rt
rt
rt
rt
rt
rt
rt
rt
WARNING
For Outdoor Use Only
(Outside any enclosure)
FOR YOUR SAFETY:
• Improper Installation,
adjustment, alteration,
service or maintenance can
cause injury or property
damage.
• Read the installation,
operation, and maintenance
instructions thoroughly
before installing or
servicing this equipment.
• Failure to follow these
instruction could result
in re or explosion, which
could cause property
damage, personal injury, or
death.
• This instruction manual
contains important
information necessry for
the proper assembly and
safe use of the appliance.
• Read and follow all
warnings and instructions
before assembling and
using the appliance.
• Follow all warnings and
instructions when using the
appliance.
• Keep this manual for future
reference.
FOR YOUR SAFETY:
WARNING
WARNING
• Do NOT store or use
gasoline or other ammable
liquids or vapors in the
vicinity of this or any other
appliance.
• When cooking with oil/
grease, do NOT allow the
oil/grease to exceed 350ºF
(176.5ºC). Do NOT store or
use extra cooking oil in the
vicinity of this or any
other appliance.
Keep this manual for future reference.
This instruction manual contains important information necessary for the
proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using
the appliace.
Follow all warnings and instruction when using the appliance
rt
rt
Never operate this appliance unattended.
DANGER
rt
rt
(a) The burning of Charcoal cooking fuel generates some by products which are on the list of substances
known by the State of California to cause cancer, reproductive harm, or other birth defects. To reduce
exposure to these substances, always operate this unit according to the use and care manual, ensuring you
provide good ventilation when cooking with Charcoal.
(b) Handling the brass material on this product exposes you to lead, a chemical known to the State of Cali-
fornia to cause cancer and birth defects or other reproductive harm. Wash hands after handling.
(c) This product contains chemicals, including lead and compounds, known by the State of California to
cause cancer, reproductive harm, or other birth defects.
(d) Wash your hands after using this product.
For more information go to: www.P65Warnings.ca.gov
WARNING
CALIFORNIA PROPOSITION 65 WARNING:
一：

GRILLS
  

Bronco Electric Start Charcoal
BMBROCH
Important Safeguards
DANGER: Failure to follow the dangers, warnings and cautions in this manual may result in serious bodily injury or death, or in a re or an explosion
causing damage to property
WARNINGS:
This grill is for outdoor use only, and should NOT be used in a build-
ing, garage or any other enclosed area.
Do NOT operate, light or use this appliance within ten feet (3.05 m) of
walls, structures or buildings.
For residential use only. This grill is NOT for commercial use.
Never use charcoal that has been pre-treated with lighter uid.
Use only a high grade plain charcoal, charcoal/wood mixture, lump
charcoal or cooking wood. The conversion to or attempted use of any
other fuel source in this charcoal grill is dangerous and will void your
warranty.
This grill is NOT intended for and should never be used as a heater.
TOXIC fumes can accumulate and cause asphyxiation.
Do NOT use grill for indoor cooking. TOXIC carbon monoxide fumes
can accumulate and cause asphyxiation.
This grill is safety certied for use in the United States and/or Canada
only. Do NOT modify for use in any other location. Modication will
result in a safety hazard and will void your warranty.
Apartment dwellers: Check with management to learn the require-
ments and re codes for using a charcoal grill in your apartment
complex. If allowed, use outside on the ground oor with a ten
foot (3.05 m) clearance from any structure. Do NOT use on or under
balconies.
Minimum clearance from sides and back of unit to combustible
construction is 36 inches (91.4 cm). Do NOT use this appliance under
any type of overhang or roof.
Do NOT use gasoline, kerosene or alcohol for lighting.
Do NOT use in an explosive atmosphere. Keep grill area clear and
free from combustible materials, gasoline and other ammable
vapors and liquids.
Do NOT store or use gasoline or other ammable liquids or vapors
within 25 feet (7.62 m) of this appliance.
Do NOT block holes in sides or back of grill.
Inspect grill before each use.
Do NOT alter grill in any manner. Any alteration will void your war-
ranty.
Do NOT build this model of grill in any built-in or slide-in construc-
tion. Ignoring this warning could cause a re or an explosion that can
damage property and cause serious bodily injury or death.
Do NOT use the grill unless it is COMPLETELY assembled and all parts
are securely fastened and tightened.
This grill should be thoroughly cleaned and inspected on a regular
basis.
Use only Blue Rhino Global Sourcing, Inc. factory-authorized parts.
The use of any part that is not factory-authorized can be dangerous
and will
void your warranty.
Do NOT operate this appliance without reading “Operating Instruc-
tions”
in this manual.
To avoid burns, do NOT touch metal parts of grill until they have
completely cooled, unless you are wearing protective gear (pot hold-
ers, gloves, BBQ mittens, etc.).
Never touch grids (charcoal, cooking or warming), ashes or coals to
see if they are hot.
Do NOT use on wooden decks, wooden furniture or other combusti-
ble surfaces.
This grill is NOT to be used in or on boats or recreational vehicles.
Position grill so wind cannot carry ashes to combustible surfaces.
Do NOT use in high winds.
Never lean over the grill when lighting.
Do NOT leave a lit grill unattended. Keep children and pets away
from grill at all times.
Do NOT attempt to move grill when in use. Allow the grill to cool
before moving or storing.
Do NOT leave grill unattended while preheating or burning o food
residue.
When cooking, re extinguishing materials should be readily accessible.
In the event of an oil/grease re, do NOT attempt to extinguish with
water. Use type BC dry chemical re extinguisher or smother with dirt,
sand or baking soda.
Always open grill lid carefully and slowly as heat and steam trapped
within grill can severely burn you.
If grill has not been cleaned, a grease re can occur that may damage
the product.
Do NOT place empty cooking vessels on the appliance while in
operation.
Use caution when placing anything on the grill while the appliance is in
operation.
Never add lighting uid to hot or warm coals as a ashback may occur
causing serious injury or damage to property.
Always place your grill on a hard, non-combustible level surface. An
asphalt or blacktop surface may not be acceptable for this purpose.
Do NOT remove the ashes until they are completely and fully
extinguished.
Live hot briquettes and coals can create a re hazard.
Always empty the bottom bowl and grill after each use.
Do NOT place fuel (charcoal briquettes, wood or lump charcoal) directly
into bottom of grill. Place fuel only on the charcoal pan/grid.
Do NOT allow charcoal to rest on the walls of grill. Doing so will greatly
reduce the life of the metal and nish of your grill.
Check to make sure the air vents are free of debris and ash before using
the grill.
Extinguished coals and ashes should be placed a safe distance from all
structures and combustible materials.
With a garden hose, completely wet the surface beneath and around
grill to extinguish any ashes, coals or embers that may have fallen
during the cooking or cleaning process.
The use of alcohol, prescription or non-prescription drugs may impair
the consumer’s ability to properly assemble and/or safely operate this
grill.
Always wear protective gloves when adding fuel (charcoal briquettes,
wood or lump charcoal) to retain desired heat level.
Keep all electrical cords away from a hot grill.
Always use a meat thermometer to ensure food is cooked to a safe
temperature.
Never cover entire cooking area with aluminum foil. Laying the foil
on the grates can restrict the intended air ow inside the grill, create
barriers to the proper ow of grease to the catch pan, which sets the
stage for lots of it to build up on the bottom tray, which in turn, builds
the potential for grease res and are ups.
Never turning the grill to high, and letting it run for a while.
Use protective gloves when assembling this product.
Do NOT force parts together as this can result in personal injury or
damage to the product.
Do NOT touch ash receiver or ash receiver handle until grill has
completely cooled, unless you are wearing protective gear.
Do NOT touch air vent or air vent handle until grill has completely
cooled, unless you are wearing protective gear.
Death, serious injury or damage to property may occur if the above is
not followed exactly.

Expanded View
PART LIST
PART LIST
No Name Qty No Name Qty
1 Lid 1 14 Charcoal Pan Holder 1
2 Thermometer 1 15 Le Leg Weld 2
3 Air Vent Assembly 2 16 Right Leg Weld 2
4 Lid Handle Support 2 17 Ash Tray 1
5 Lid Handle 1 18 Ash Tray Handle 1
6Top Hinge 2 19 Cart Boom 1
7Lid Handle Heat Insulaon Board 1 20 Cart Rail 2
8Warming Rack Assembly 1 21 Cart Side Rail 2
9Liing Lever Handle 1 22 Leg Seat 2
10 Grill 2 23 Axle 1
11 Boom Hinge 2 24 Wheel 2
12 Side Shelf 2 25 Power Line holder 1
13 Firebox 1
＠

Bronco Electric Start Charcoal
BMBROCH
HARDWARE LIST
DO NOT RETURN TO PLACE OF PURCHASE.
For assistance, call 1-855-200-8445 toll-free. Please have your owner’s manual and
model number available for reference.
Note: The model number is printed on a label which can be found on the side of the
fi ebox
For Easiest Assembly:
1. Select an area where you will assemble this product.
To protect components, choose a smooth surface that’s
free of cracks or openings.
2. Spread out all parts.
3. Tighten all hardware connections by hand rst. Then,
before completing each step, go back and fully tighten
all hardware.
Be careful not to overtighten. That could damage surfaces
or strip threads.
4. For best results, complete each step in the order presented.
To complete assembly you will need:
• One bag of charcoal (not included)
Typical assembly is approximately 30 minutes.
A:M6*75Q235
NickelPlatedPhiliipsTrussHead............4Pcs
B:M6*75Q235
NickelPlatedPhiliipsTrussHead...........36Pcs
C:M6*40Q235
NickelPlatedPhiliipsTrussHead............8Pcs
D: 6.2 Q235
HeatResistanceWasher.......................2Pcs
E: 6.2 65Mn
LargeLockWasher............................2Pcs
F:M6*15 Q235 ............................4Pcs
G:M8Q235
HexNuts...................................4Pcs
I:M8Q235
Wrench.......................2Pcs
J:Screwdriver..................2Pcs
K:HingeAxis........................2Pcs
L:WavePin..........................2Pcs
M:M4*10Q235
NickelPlatedPhiliipsTrussHead.....2Pcs
N:M5*12Q235
NickelPlatedPhiliipsTrussHead.....2Pcs
P:M5Q235
HexNuts........................4Pcs
H:ST4.2*10Q235
TappingScrew.............................4Pcs
ASSEMBLY INSTRUCTIONS

ASSEMBLY INSTRUCTIONS
3 4
a) Insert the Axle (23) through the Right
Left Weld as shown.
b) Attach the Wheel (23) onto the side of
the Right Left Weld (16) through the
axle and secure each of the Wheel (23)
with a lock nut (G).
c) Ensure the lock nuts are tightened
a) Attach the Cart Rail (20) onto the front
and back of the prepared cart with four
screws (B) each.
b) Repeat same for Cart Side Rail (21).
d) Secure all screws properly with a
screwdriver.
1 2
a) Fit on the Leg Seat (22) to the both Left
Leg Weld (15) with two screw (H) each.
a) Attach both Left Leg Weld (15) and
both Right Leg Weld (16) onto the Cart
Bottom (19) with two screws (B) each
as shown below.
b) Ensure all screws are tightened.
ST4.2*10 4PCS
15
22
H
M6*158PCS
B
16
16
19
M8LOCKNUT 2PCS
G
24
24
23
M6*15 16PCS
B
20
20
21
21

Bronco Electric Start Charcoal
BMBROCH
ASSEMBLY INSTRUCTIONS
7 8
a) Insert the Charcoal Pan Holder (14)
into the firebox as shown.
b) Ensure the charcoal pan holder
support go into the slot on the side of
the firebox as shown.
a) Install the Ash Tray handle (18) onto
the Ash Tray (17) with two screws (B).
b) Inside the prepared ash tray
underneath the firebox from behind.
5 6
a) Put on the Firebox (13) onto the
prepared cart as shown below.
b) Secure the firebox to cart with lock
screw (F) on each of the leg.
a) Install the Lifting Lever Handle on with
one screw (M) as shown below.
M6*15 4PCS
F
14
M4*10 1PCS
M
M6*15 2PCS
B
13
9
17
18

ASSEMBLY INSTRUCTIONS
11 12
a) Install the Power line Holder (25) at the
side of the firebox and under the side
shelf with two screws (B) as shown.
a) Install the Top Hinge (6) onto the
Lid (1) with two screws (C) each.
9 10
a) Install both Bottom Hinge (11) to the
back of the firebox with two screws (C)
each.
a) Start on the right side, install the Side
Shelf (12) onto the side of the firebox
with four screws (B)
b) Repeat the same on the left side for
the other Side Shelf (12).
M6*40 4PCS
C
M6*15 8PCS
B
M6*15 2PCS
B
M6*40 4PCS
C
6
6
1
11
11
12
12
25

Bronco Electric Start Charcoal
BMBROCH
ASSEMBLY INSTRUCTIONS
15 16
a) Install the Air Vent Assembly (3) onto
the side of the Lid with one screw (N)
and one nut (P) each side.
a) Attach the Warming Rack (8) into the
firebox in the order as shown below.
13 14
a) Install the Lid Handle (5) onto the Lid
(1) with two Lid Handle Support (4),
one Lid Handle Heat Insulaon
Board, two spring washers (E), two
at washers (D) and two screws (A)
in order as shown below.
a) Align the hinges and put on the
prepared Lid onto the firebox.
b) Secure the Lid on the firebox with one
hinge axis and wave pin on each side
as shown below.
M6X75 2Pcs
A
5
4
4
7
L:WAVEPIN 2 PCS
K:
HINGE-AXIS 2PCS
First
First
Second
Second
M5*12 2PCS
N
M5 2PCS
P
3
3
AA
BB
CC
DD

a) Place both the Grills (10) into the firebox, sitting on the Support around the
firebox.
ASSEMBLY INSTRUCTIONS
17

Bronco Electric Start Charcoal
BMBROCH
Operating Instructions
CAUTION: Never use charcoal that has been pre-treated with lighter uid.
Use only a high grade plain charcoal, charcoal/wood mixture,
lump charcoal or cooking wood.
First Use
1. Make sure all labels, packaging and protective films h ve been removed from the grill.
2. Remove manufacturing oils before cooking on this grill for the first tim , by operating
the grill for at least 15 minutes with the lid closed. This will “heat clean” the internal parts
and dissipate odors.
Lighting Instructions
CAUTION: Keep outdoor cooking appliance area clear and free from
combustible materials, gasoline and other ammable vapors and
liquids.
CAUTION: Check to make sure the air vents are free of debris and ash
before using the grill.
CAUTION: Attempting to light the grill with the lid closed may cause an
explosion.
CAUTION: When using a liquid starter, always check bottom bowl and
ash receiver before lighting. Fluid can collect in the bottom bowl and/
or ash receiver and could ignite, resulting in a re.
CAUTION: Never add lighting uid to hot or warm coals as ashback
may occur, causing serious injury or damage to property.
1. Open lid and vents.
2. Make sure ash receiver is empty and secure.
3. Remove cooking grid.
4. Arrange charcoal briquettes or other fuel on the charcoal grid.
5. Light per instructions on fuel package.
6. Allow fuel to become glowing coals before cooking.
Direct Cooking
Cooking directly over hot coals is ideal for searing in juices and grilling food requiring less
than 25 minutes of grilling time such as steaks, hamburgers, hot dogs, chicken parts,
vegetables and fruit.
1. Open lid and remove cooking grid.
2. Load and light charcoal per “Lighting” section. Leave lid open.
3. While wearing protective gloves, carefully spread hot coals evenly across charcoal grid
with a long-handled tool.
4. While wearing protective gloves, replace cooking grid, close lid and allow grill to
preheat.
5. While wearing protective gloves, open lid and place food onto cooking grids above the
hot coals with long handle tongs.
6. With lid open or closed, cook until desired internal food temperatures are achieved.
Note: If additional briquettes are needed, remove food from cooking grid and, while
wearing protective gloves, remove the cooking grid and place additional briquettes
without disturbing the hot coals. Carefully replace cooking grid and food.
7. Allow charcoal to burn out by closing lid and all vents. Except in the case of an
emergency, do NOT pour water on hot coals

Operating Instructions
Indirect Cooking
Not cooking directly over hot coals is ideal for slow cooking and grilling foods requiring
more than 25 minutes, such as most roasts, loins, chops, whole chickens, turkey, fish and baked good .
1. Open lid and remove cooking grid.
2. Load and light charcoal per “Lighting” section. Leave lid open.
3. While wearing protective gloves, carefully spread hot coals to the outsides of charcoal
grid with a long-handle tool.
4. While wearing protective gloves, replace cooking grid, close lid and allow grill to
preheat.
5. Wear protective gloves, to open lid. Use long-handled tools to place food onto cooking
grids above the areas without hot coals.
6. With lid closed, cook until desired internal food temperatures are achieved.
Note: If additional briquettes are needed, remove food from cooking grid and, while
wearing protective gloves, remove the cooking grid and place additional briquettes
without disturbing the hot coals. Carefully replace cooking grid and food.
7. Allow charcoal to burn out by closing lid and all vents. Except
in the case of an emergency, do NOT pour water on hot coals.
For more tips on indirect cooking, please see “Tips for Better Cookouts and Longer Grill
Life.”
Turning O
1. Allow charcoal to completely extinguish itself.
WARNING: Do NOT use water to extinguish. This can be dangerous and cause damage.
2. Dispose of the ashes in a proper location.
Controlling Flare-ups:
CAUTION: Do NOT use water on a grease re. This can cause the
grease to splatter and could result in serious burns, bodily harm or
other damage.
CAUTION: Do NOT leave grill unattended while preheating or burning
o food residue. If grill has not been cleaned, a grease re can occur
that may damage the product.
WARNING: When cooking, re extinguishing materials should be
readily accessible. In the event of an oil/grease re, use a type BC dry
chemical re extinguisher or smother with dirt, sand or baking soda.
DO NOT attempt to extinguish with water.
Flare-ups are a part of cooking meats on a grill and add to the unique fl vor of grilling.
Excessive are-ups can over-cook your food and be dangerous.
Important: Excessive fla e-ups result from the build-up of grease in the bottom of your grill.
If a grease fi e occurs, close the lid until the grease burns out. Use caution when opening the lid
as sudden fla e-ups may occur.
If excessive fla e-ups occur, do NOT pour water onto the flame .

Bronco Electric Start Charcoal
BMBROCH
Operating Instructions
Minimize Flare-ups:
1. Trim excess fat from meats prior to cooking.
2. Cook high fat content meats indirectly.
3. Ensure that your grill is on a hard, level, non-combustible surface.
CAUTION:
1. All cleaning and maintenance should be done when grill is cool
and with the ashes properly disposed of.
2. Do NOT clean any grill part in a
Notices
1. This grill should be thoroughly cleaned and inspected on a regular basis.
2. Abrasive cleaners will damage this product.
3. Never use oven cleaner to clean any part of grill.
Before Each Use
1. Keep the grill area free and clear from any combustible materials, gasoline, and other
flammable apors and liquids.
2. See below for proper cleaning instructions.
Cleaning Surfaces
1. Wait for grill to fully cool.
2. Wipe surfaces clean with a mild dishwashing detergent or baking soda mixed with water.
3. For stubborn stains, use a citrus-based degreaser and a nylon scrubbing brush.
4. Rinse clean with water.
5. Allow to air dry.
Before Storing
1. Wait for grill to fully cool.
2. Clean all surfaces.
3. If storing the grill indoors, cover the grill and store in a cool dry place.
4. If storing the grill outdoors, cover the grill with a grill cover for protection from the weather.
Cleaning and Care

BMBROCH
Bronco Electric Start Charcoal
PRODUCT REGISTRATION
For faster warranty service, please register your product immediaterly.
REPLACEMENT PARTS
For replacement parts, please contrct Captivate Brands USA, Inc. via 1-855-200-8445
WARRANTY
Captivate Brands USA, Inc warrants to the original retail purchaser of this product, and to no other person, that if this
product is assembled, maintained, and operated in accordance with the printed instructions accompanying it, then
for a period of one (1) year from the date of purchase, the product’s components shall be free from defects in material
and workmanship, except for the cooking surface which is not covered by the Limited Warranty. Captivate Brands
USA, Inc may require reasonable proof of your date of purchase. Therefore, you should retain your sales slip or invoice.
This Limited Warranty shall be limited to the repair or replacement of parts, which prove defective under normal use
and service and which Captivate Brands USA, Inc shall determine in its reasonable discretion upon ex-amination to be
defective. Before returning any parts, you should contact Captivate Brands USA, Inc’s Customer Care Department
using the contact information listed below. If Captivate Brands USA, Inc confirms, after examination, a defect covered
by this Limited Warranty in any returned part, and if Captivate Brands USA, Inc approves the claim, Captivate Brands
USA, Inc will replace such defective part without charge. If you return defective parts, transporta-tion charges must be
prepaid by you. Captivate Brands USA, Inc will return replacement parts to the original retail purchaser, freight or
postage prepaid.
This Limited Warranty does not cover any failures or operating difficulties due to accident, abuse, misuse, alteration,
misapplication, improper installation or improper maintenance or service by you or any third party, or failure to
perform normal and routine maintenance on the product as set out in this owner’s manual. In addition, the Limited
Warranty does not cover damage to the nish, such as scratches, dents, discoloration, rust or other weather damage,
after purchase.
This Limited Warranty is in lieu of all other express warranties. CAPTIVATE BRANDS USA, INC disclaims all warranties
for products that are purchased from sellers other than authorized retailers or distributors, including the warranty of
merchantability or the warranty of fitness for a particular purpose. CAPTIVATE BRANDS USA, INC ALSO DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANT-
ABILITY AND FITNESS FOR A PARTICULAR PURPOSE. CAPTIVATE BRANDS USA, INC SHALL HAVE NO LIABILITY TO
PURCHASER OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAM-
AGES.
Captivate Brands USA, Inc further disclaims any implied or express warranty of, and assumes no responsibility for,
defects in workmanship caused by third parties.
This Limited Warranty gives the purchaser specific legal ights; a purchaser may have other rights depending upon
where he or she lives. Some jurisdictions do not allow the exclusion or limitation of special, incidental or consequen-
tial damages, or limitations on how long a warranty lasts, so the above exclusion and limitations may not apply to
everyone.
Captivate Brands USA, Inc does not authorize any person or company to assume for it any other obligation or li-
ability in connection with the sale, installation, use, removal, return, or replacement of its equipment, and no such
representations are binding on Captivate Brands USA, Inc.
Captivate Brands USA, Inc
25541 Arctic Ocean Drive
Lake Forest, CA. 92630
Tel: [phone]
Email: ser[email protected]om
