Catler GR 8030 User manual

THE SMART
GRILL ™
GR 8030
Instructions
for use

THE
SMART
GRILL ™

CONTENTS
5 Catler recommends safety rst
8 Know your Catler product
11 Assembling your Catler product
13 Operating your Catler product
22 Grilling tips
25 Care & cleaning
28 Troubleshooting
30 Recipes
CONTENTS 3

CONGRATULATIONS
4
Congratulations
on the purchase of your new Catler product.

5
CATLER RECOMMENDS SAFETY FIRST
CATLER RECOMMENDS SAFETY FIRST
We at Catler are very safety conscious. We design and manufacture
consumer products with the safety of you, our valued customer,
foremost in mind. In addition, we ask that you exercise adegree of
care when using any electrical appliance and adhere to the following
precaution:
IMPORTANT SAFEGUARDS FOR YOUR CONTACT GRILL GR 8030
WARNING:
AFTER PUTTING INTO OPERATION, THE TOP PLATE
GETS VERY HOT. DO NOT TOUCH THE HOT SURFACE.
TO LIFT UP THE TOP PLATE, USE ONLY THE LEVELLING
HANDLE! WHEN TURNED OFF THE DEVICE, THE TOP
PLATE WILL STAY WARM FOR SOME TIME. BEFORE ANY
FUTHER OPERATION, LET THE DEVICE COOL DOWN. IF
YOUR SKIN GETS IN TOUCH WITH AHOT SURFACE, YOU
RISK ABURN!
• Carefully read all instructions
before operating and save for
future reference.
• Remove any promotional
stickers or labels before using
the Contact Grill for the rst
time.
• Do not place the Contact Grill
near the edge of abench or
table during operation. Ensure
the surface is level, clean and
free of water, etc.
• Do not place the Contact Grill
on or near ahot gas or electric
burner, or where it could touch
aheated oven. Use the Contact
Grill well away from walls.
• Provide adequate space
above and on all sides for air
circulation around the Contact
Grill.
• Do not place the Contact
Grill on any surface that may
be aected by heat. The
use of aheat resistant mat
is recommended on these
surfaces.
• Contact Grill is not intended
to be operated by means of
en external timer or separate

6CATLER RECOMMENDS SAFETY FIRST
remote control system.
• Always ensure the Contact Grill
is properly assembled before
use.
• Do not touch hot surfaces. Use
the handle to lift and open the
top plate. Take care when using
the Adjustable Grilling Height
Control.
• Do not leave the Contact Grill
unattended when in use.
• Do not place anything on top
of the Contact Grill when the
lid is closed, when in use and
when stored.
• Always switch the Contact
Grill o, then switch o at the
power outlet, then unplug
and allow to cool, if appliance
is not in use, before cleaning,
before attempting to move
the appliance, disassembling,
assembling and when storing
the appliance.
• Keep the exterior housing and
the non-stick cooking plates
clean. Follow the cleaning
instructions provided in this
book.
IMPORTANT SAFEGUARDS FOR ALL ELECTRICAL APPLIANCES
• Fully unwind the cord before
use.
• To protect against electric
shock, do not immerse cord,
plug or appliance in water or
any other liquid.
• Do not let the cord hang over
the edge of atable or counter,
touch hot surfaces, or become
knotted.
• It is recommended to inspect
the appliance regularly. Do
not use the appliance if power
supply cord, plug or appliance
becomes damaged in any way.
Return the entire appliance to
the nearest authorised Catler
service center for examination
and/or repair.
• Any maintenance other than
cleaning should be performed
at an authorised service center.
• This appliance is for household
use only. Do not use this
appliance for anything other
than its intended use. Do not
use in moving vehicles or
boats. Do not use outdoors.
• The installation of aresidual
current device (safety switch)

7
CATLER RECOMMENDS SAFETY FIRST
is recommended to provide
additional safety protection
when using electrical
appliances. It is advisable that
asafety switch with arated
residual operating current
not exceeding 30mA be
installed in the electrical circuit
supplying the appliance. See
your electrician for professional
advice.
CAUTION: HOT SURFACE
THE TEMPERATURE OF ACCESSIBLE SURFACES
MAY BE HIGH WHEN THE APPLIANCE IS OPERATING.
• This appliance is not intended
for use by young children
or inrm persons without
supervision.
• Young children should be
supervised to ensure that they
do not play with the appliance.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in asafe way
and understand the hazards
involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
unless they are older than 8
and supervised.
• Keep the appliance and its cord
out of reach of children less
than 8 years.
SAFE THESE INSTRUCTIONS

8ASSEMBLING YOUR FOOD PROCESSOR FP 8010
Know
your Catler product

A. Stainless Steel Housing with Die-Cast
Arms
B. Cast Aluminium, Non-Stick Plates
Coated with titanium infused
Quantanium™ for scratch resistance and
oil free cooking.
C. Removable, Dishwasher Safe Plates
Flat plate for eggs and pancakes, ribbed
plate to sear meats.
D. Bottom PLATE RELEASE
Removes the bottom cooking plate.
Independently remove the top and
bottom cooking plates for easy cleaning
or to interchange plate positions.
E. Integrated, Removable Drip Tray
Catches excess fat for healthier cooking.
In BBQ mode, the unique design drains
fat from both plates into the same drip
tray.
F. 30 Minute Timer Dial with Sound Alert
Pressing the centre button of the dial
activates the count-down timer.
G. Temperature Conversion Button
Converts the default Celsius reading to
Fahrenheit.
H. Temperature Responsive LCD
Backlight illuminates blue (stand by) and
orange (heating/ready).
9
KNOW YOUR CATLER PRODUCT
KNOW YOUR CATLER PRODUCT
Open Flat BBQ Mode
Enough space for
grilling on both desks
simultaneously.

10 KNOW YOUR CATLER PRODUCT
I. Temperature Dial (160°C–230°C)
With LOW, PANINI (sandwich) and SEAR
modes.
J. Cord Storage
Located on the underside of the grill.
K. Adjustable Plate Tilt
Adjusts the angle of the bottom cooking
plate to drain fats, or can be made at for
eggs and pancakes.
L. Multipurpose Control Feature
Controls the grilling height to reduce the
weight of the top plate on delicate foods;
locks the plates for upright storage;
release of BBQ Mode.
M. BBQ MODE Marking
N. Adjustable Height Setting Marking
O. Levelling Support
Integrated into the top plate release, use
to adjust the position of the oating top
plate.
P. Top PLATE RELEASE
Removes the top cooking plate.
1-Hour auto shut-o automatically stops
heating the cooking plates after 1 hour of no
activity.
ELEMENT IQ™
Sensors detect when the cooking plates drop
in temperature and compensate by injecting
heat for rapid recovery back to the selected
cooking temperature. 2400 watt embedded
heating elements ensure consistently
high heat for faster cooking and reduced
preheating time.

11
Assembling
your Catler product

12 ASSEMBLING YOUR CATLER PRODUCT
PREPARING THE GRILL FOR USE
1. Remove and safely discard any packing
material and promotional labels from the
grill
2. Wipe the cooking plates and drip tray
with asoft damp sponge. Dry thoroughly.
3. Ensure the drip tray is correctly inserted
into the grill.
4. Ensure the cooking plates are correctly
inserted and securely locked into
position.
NOTE
The grill features 2 × PLATE RELEASE.
These allow you to independently
remove the top and bottom cooking
plates for easy cleaning, or to
interchange plate positions.
To use the PLATE RELEASE: Always
ensure the grill is completely cool.
Use the handle to open the top plate
to a90 degree position. Use the ‘Plate
Release’ on the front, right side of the
top plate to remove the top cooking
plate, and the‘Plate Release’ on the left
side of the control panel to remove the
bottom cooking plate. Once released,
gently slide the plates o the grill.
NOTE
If the cooking plates are incorrectly
inserted, the LCD screen will display
INSERT PLATE. Use the 2 × PLATE
RELEASE to remove the plates then
re-insert so they securely lock into
position. Always ensure the grill is
completely cool before releasing and
removing the cooking plates.
5. Place the grill on aat, dry surface.
Ensure there is aminimum distance
of 10cm of space on both sides of the
appliance.
6. Unwind the power cord completely and
insert the power plug into agrounded
wall outlet.
7. The grill alert will sound and the LCD
screen will display OFF and the default‘0’
zero time.
8. The grill is now ready for the preheating
cycle.
NOTE
When the grill is turned on and
heating for the rst time, it may emit
ane smoke haze. This is due to the
protective substances on the heating
elements. It is safe and not detrimental
to the performance of the grill.
ASSEMBLING YOUR CATLER PRODUCT

Operating
your Catler product

14 OPERATING YOUR CATLER PRODUCT
USE IN OPEN FLAT BBQ MODE
The grill opens at to provide an extra large
grilling surface. The ribbed cooking plate
is perfect for searing meats while the at
cooking plate is ideal for eggs, pancakes and
vegetables.
1. Ensure the drip tray is correctly inserted
into the grill.
2. Ensure the cooking plates are correctly
inserted and securely locked into
position.
NOTE
If the cooking plates are incorrectly
inserted, the LCD screen will display
INSERT PLATE. Use the 2 × PLATE
RELEASE to remove the plates then
re-insert so they securely lock into
position. Always ensure the grill is
completely cool before releasing and
removing the cooking plates. Refer to
page 12 for more information on using
the PLATE RELEASE.
3. Place the grill on aat, dry surface.
Ensure there is aminimum distance
of 10cm of space on both sides of the
appliance.
4. Unwind the power cord completely and
insert the power plug into agrounded
wall outlet.
5. The grill alert will sound and the LCD
screen will display OFF and the default‘0’
zero time.
6. To preheat the grill:
a) Ensure the top plate of the grill is in the
closed, OPEN position. This will ensure
faster, more ecient preheating.
b) Turn the Temperature dial to adjust the
temperature in 5°C/10°F increments.
Rotate the dial to SEAR (210°C–230°C)
for fast preheating, PANINI (Sandwich)
(180°C–205°C), LOW (160°C–175°C) or
select an alternative temperature. The
grill will start to heat and the LCD screen
will illuminate orange and display the
selected temperature, HEATING and the
default ‘0’ zero time.
c) Allow the grill to preheat.
OPERATING YOUR CATLER PRODUCT

15
OPERATING YOUR CATLER PRODUCT
NOTE
The grill features atemperature
conversion button on the left side
of the LCD screen. The temperature
reading on the grill is preset to
Celsius. Pressing the temperature
conversion button converts the Celsius
temperature reading into Fahrenheit.
The corresponding °C or °F symbol will
be displayed on the LCD screen.
NOTE
If you have changed the default Celsius
temperature reading to Fahrenheit,
the setting will remain in the memory
of the grill until the Temperature
Conversion Button is pressed asecond
time or the grill is unplugged from
the wall outlet. When the grill is
plugged back into the wall outlet, the
temperature reading will automatically
return to the preset Celsius setting.
7. While the grill is preheating, adjust the
angle of the cooking plates to the desired
position by turning the PLATE TILT dial.
The PLATE TILT dial is located on the
lower back, right side of the grill.
NOTE
We recommend using:
- The angle position to drain fats for
healthier cooking.
- The at position for cooking eggs,
pancakes, Turkish bread, foccacias
and leaner meats. The unique indent
between the two cooking plates
channels juices from both plates into
the same drip tray while cooking.
8. Once the grill has preheated to the
selected temperature, the grill alert
will sound and HEATING will no longer
illuminate. The LCD screen will display
the selected temperature and the default
‘0’ zero time.
NOTE
Always allow the grill to completely
preheat to the selected temperature
before cooking.
NOTE
The LCD screen may display HEATING
during the cooking process.
This is normal, indicating that
the correct temperature is being
maintained.
9. To open the grill into BBQ mode:
a) Ensure the grill has completely preheated
and the LCD screen no longer displays
HEATING.
b) Ensure the top cooking plate is in the
closed, OPEN position. It must be in the
BBQ mode position to release the lock
and open the grill into BBQ mode.

16 OPERATING YOUR CATLER PRODUCT
c) With your left hand, grip the handle.
With your right hand, pull the adjustable
height control clip on the right side
of the grill towards you, into the BBQ
mode position. Continue to pull the
clip forward and simultaneously lift the
handle to open, then gently lower the
top plate into the horizontal BBQ mode
position.
10. Place food on either or both of the
cooking plates. Refer to grilling tips
(page 22) and recipes (page 30).
NOTE
Do not use spray-on, non-stick coatings
as these will aect the performance of
the non-stick cooking plates.
NOTE
The LCD screen may display HEATING
during the cooking process.
This is normal, indicating that
the correct temperature is being
maintained.
11. The grill features an optional countdown
timer which monitors the time elapsed
during cooking. To activate the count-
down timer:
a) Ensure the grill has completely
preheated, the LCD screen no longer
displays HEATING and food has been
placed on the cooking plates.
b) Turn the timer dial to adjust the time in
one minute increments up to 30 minutes.
Rotate the dial clockwise to increase the
time, or counter-clockwise to reduce
the time. The LCD screen will display the
selected time.
c) Press the centre button of the timer
dial once to activate the setting. The
LCD screen will display acount-down
indicator and the time will begin to count
down.

17
OPERATING YOUR CATLER PRODUCT
NOTE
The count-down timer can be stopped
or paused at any time by pressing the
centre button of the timer dial asecond
time. The LCD screen will no longer
display the count-down indicator.
However, the grill will not turn o, it
will remain heating. To reset or clear
the timer either:
- Rotate the timer dial clockwise
to increase the time, or
counterclockwise to reduce the time.
Or,
- Press the centre button of the
timer dial and hold for 3 seconds
until the time on the LCD screen
displays‘0’zero. Rotate the timer dial
clockwise to increase the time, or
counterclockwise to reduce the time.
12. Once the selected time has elapsed, the
grill alert will sound and the default ‘0’
zero time will be displayed. However,
the grill will not turn o. It will remain
heating, maintaining the selected
temperature, ready for the next cooking
cycle.
NOTE
The cooking and heating cycle can be
stopped at any time by turning the
Temperature Dial to the OFF position.
The LCD screen will display OFF and
the default ‘0’ zero time.
Allow the grill to cool completely and
disconnect from the wall outlet.
NOTE
The grill features a1-Hour auto shut-
o feature. This ensures the grill is not
accidentally left on for an extended
period of time. If the temperature or
timer dials are not adjusted within
1 hour, the auto shut-o feature will
automatically stop heating the cooking
plates. The LCD screen will display OFF
for 5 minutes then cease to illuminate.
However, the default display OFF
and ‘0’ zero time will still be visible.
To re-activate the grill, adjust the
temperature or timer dials.
13. When the food is cooked, remove from
the cooking plates using heat proof
plastic or wooden utensils.
NOTE
Never use metal or sharp utensils as
these can cause damage to the non-
stick coating of the cooking plates.
WARNING:
Fully unwind the power cord from the
cord storage before use.

18 OPERATING YOUR CATLER PRODUCT
USE AS ACONTACT GRILL
OR SANDWICH PRESS
1. Ensure the drip tray is correctly inserted
into the grill.
2. Ensure the cooking plates are correctly
inserted and securely locked into
position.
NOTE
If the cooking plates are incorrectly
inserted, the LCD screen will display
INSERT PLATE. Use the 2 × PLATE
RELEASE to remove the plates then
re-insert so they securely lock into
position. Always ensure the grill is
completely cool before releasing and
removing the cooking plates. Refer to
page 10 for more information on using
the PLATE RELEASE.
3. Place the grill on aat, dry surface.
Ensure there is aminimum distance
of 10cm of space on both sides of the
appliance.
4. Unwind the power cord completely and
insert the power plug into agrounded
wall outlet.
5. The grill alert will sound and the LCD
screen will display OFF and the default‘0’
zero time.
6. To preheat the grill:
a) Ensure the top plate of the grill is in the
closed, ‘OPEN’position. This will ensure
faster, more ecient preheating
b) Turn the Temperature dial to adjust the
temperature in 5°C/10°F increments.
Rotate the dial to‘SEAR’ (210°C-230°C)
for fast preheating,‘PANINI’(Sandwich)
(180°C-205°C), ‘LOW’ (160°C-175°C) or
select an alternative temperature. The
grill will start to heat and the LCd screen
will illuminate orange and display the
selected temperature,‘HEATING’ and the
default ‘0’ zero time.
c) Allow the grill to preheat.

19
OPERATING YOUR CATLER PRODUCT
NOTE
The grill features atemperature
conversion button on the left side
of the LCD screen. The temperature
reading on the grill is preset to
Celsius. Pressing the Temperature
Conversion Button converts the Celsius
temperature reading into Fahrenheit.
The corresponding °F or °C symbol
will be displayed on the LCD screen. If
you have changed the default Celsius
temperature reading to Fahrenheit,
the setting will remain in the memory
of the grill until the temperature
conversion button is pressed asecond
time or the grill is unplugged from
the wall outlet. When the grill is
plugged back into the wall outlet, the
temperature reading will automatically
return to the preset Celsius setting.
7. While the grill is preheating, adjust the
angle of the bottom cooking plate to the
desired position by turning the PLATE
TILT dial. The PLATE TILT dial is located on
the lower back, right side of the grill.
NOTE
We recommend using:
- The angle position to drain fats for
healthier cooking.
- The at position for cooking eggs,
pancakes, Turkish bread, foccacias
and leaner meats.
8. Once the grill has preheated to the
selected temperature, the grill alert
will sound and HEATING will no longer
illuminate. The LCD screen will display
the selected temperature and the default
‘0’ zero time.
NOTE
Always allow the grill to completely
preheat to the selected temperature
before cooking.
NOTE
The LCD screen may display HEATING
during the cooking process. This is
normal, indicating that the correct
temperature is being maintained.
9. To open the grill:
a) Ensure the grill has completely preheated
and the LCD screen no longer displays
‘HEAT!
b) Ensure the top cooking plate is closed.
The Adjustable Height Control clip,
located on the right side of the top plate,
should be in the ‘OPEN’.
c) Use the handle to open the top plate to
a90 degree position.
10. Place food on the bottom cooking plate.
NOTE
Do not use spray-on, non-stick coatings
as these will aect the performance of
the non-stick cooking plates.

20 OPERATING YOUR CATLER PRODUCT
NOTE
For best cooking results when toasting
sandwiches on the PANINI setting.
- Always place sandwiches in the
centre bottom plate.
- Toasting should take approximately
5–8 minutes. Exact toasting time will
be amatter of preference and the
type of bread and llings used. For
more tips and tricks, refer to grilling
tips (page 22) and recipes (page 30).
NOTE
The LCD screen may display HEATING
during the cooking process. This is
normal, indicating that the correct
temperature is being maintained.
11. Use the handle to close the top cooking
plate. The top cooking plate has two
features designed to produce optimum
cooking results:
a) Floating top plate. The top cooking plate
is hinged, allowing the top plate to be
positioned horizontally on the food
surface. This ensures the front of the
food is as evenly cooked as the back. It
also allows the top plate to oat above
the food surface, radiating heat to create
open sandwich style melts.
NOTE
The surfaces of the grill are hot during
and after operation. Always use the
integrated leveling support/PLATE
RELEASE on the front, right side of the
top cooking plate when adjusting the
position of the top plate.
Alternatively, use protective hot pads
or insulated oven mitts.
NOTE
Never use the leveling handle to open
the top cooking plate. Always use
the handle to open and close the top
cooking plate.
WARNING:
The levelling support may get hot
during and after operation. Always
use the levelling support as pictured.
WARNING:
Never grip the levelling support or
use it to open the top cooking plate.
Always use the grill handle to open
and close the top cooking plate.
b) Adjustable height control. This
feature reduces the weight of the top
plate on delicate foods like sh and
accommodates varying thicknesses of
food like artisan breads. Located on the
right side of the top plate, the clip xes
the top plate to arange of positions
above the bottom plate. To set the
adjustable height control, use the handle
to lift the top plate and simultaneously
move the adjustable height control
clip to the desired height. Then slowly
lower the top plate until it rests on the
adjustable height control clip.
