Brannan 11/015/2 Operational manual
Measurement for life. Measurement for life.
brannan.co.uk
+44 (0)1946 816600
brannan.co.uk
DIGITAL VETERINARY THERMOETER
View me on
the website
Description Barcode Product No
Digital veterinary thermometer 5 011405 110152 11/015/2
Easy to use battery operated electronic thermometer with chart giving Hobday’s
specication (the normal body temperature for a variety of animals).
Product features:
• Compact, accurate and durable
• Large scale integration device
• Non hazardous
• Complete with battery, instructions and Hobday chart
Product specications:
Temperature range: 32°C to 42°C
Ingress protection: IP22
Accuracy: +/-0.1°C between 35.5°C and 42°C, otherwise +/-0.2°C
Resolution: 0.1°C
Approx response time*: Approx 60 seconds
Expected lifespan: Approx 5 years
Battery: 1 x LR41 or equivalent (included)
Approx battery life: 100 hours continuous use (2+ years when idle)
Storage temperature: -25°C to +55°C / <95% RH
Operating temperature: +5°C to +35°C / <80% RH
CE & RoHS/WEEE: Compliant
Hazard information (SDS): See brannan.co.uk for information
LCD dimensions: 7mm x 20mm
Product dimensions: Net: 133mm x 24mm x 14mm
Gross: 142mm x 41mm x 20mm
Product weight: Net: 13.5g (including batteries and instruction sheet)
Gross weight: Box: 17g
Gross: 30.5g (including 12g protective tube)
www.brannan.co.uk
Measurement for life. Measurement for life.
+44 (0)1946 816600
brannan.co.uk
Hobday’s
Specication
Instructions for use:
1. Press the on/o button. The display will read 188.8°C
2. Release the power switch and the display will show L°C with °C ashing.
3. Position the probe.
4. Once the degree sign on the display has stopped ashing (usually within 30 to 60 seconds), the LCD will show the correct temperature.
The temperature reading will not change after the °C stops ashing. An alarm signal will sound for approximately 10 seconds when the °C stops ashing.
5. Remove the thermometer, being careful to avoid pressing the on/o button. The temperature may be read before removal because the display will retain
the stabilized temperature reading.
6. The unit will automatically turn o in 8-10 minutes. However, to prolong battery life, press the power switch once the temperature had been noted to turn
o thermometer.
Battery replacement:
When the battery is almost exhausted, the “ “ symbol will appear in the display window.
1. Remove battery cover as shown in illustration.
2. Use toothpick or insulated probe to remove battery. Avoid using any sharp metal object for this operation.
3. Insert new battery with positive side facing upwards.
4. Replace and close the cover securely.
Warning: Do not attempt to recharge the battery. Do not dispose of battery in or near re as it may explode.
Swallowing a button battery may be fatal.
Precaution
1. Do not drop - unit is not shock proof
2. Do not soak the display in water - only the probe is waterproof
3.Do not boil - clean the unit by wiping with a dry cloth and sterilize the probe with ethyl rubbing) alcohol
4.Do not allow the unit to come into contact with thinners or chemical solvents.
5.Do not store in direct sunlight or at high temperature
6.Do not bend the unit
7.Do not attempt to disassemble the unit except to replace the battery.
Man Cat Horse Dog Cow Pig Sheep Fowl
37°C 38°C 38°C 38.8°C 38.9°C 39.5°C 40°C 41.7°C
www.brannan.co.uk
