ThermoWorks Reference Thermapen User manual

Reference
Thermapen®
Operating Instructions
Range
Resolution
Accuracy
Sensor Type
Probe
Auto-Off
Environmental Range
Battery
Display
Dimensions
Weight
Calibration
–94.00 to 392.00°F (–69.99 to 199.99°C)
0.01° or 0.1° - user selectable
±0.10°F (±0.05°C) from 32 to 212°F (0 to 100°C),
otherwise ±0.36°F (±0.2°C)
1/3 DIN Thin Film PT100 to BS EN 60751 (4 wire)
4.25 L x 0.125 inches dia. (108 L x 3.3mm dia.)
10 minutes - user selectable
32 to 122°F (0 to 50°C)
2 x 3 volt CR2032 lithium coin cell, 1000 hours
0.83 H x 1.89 W inches (21 H x 48 W mm) LCD
6.1 H x 1.85 W x 0.75 D inches (153 H x 47 W x 19 D mm)
0.22lb. (100g)
UKAS Accredited Certificate included
SPECIFICATIONS
P-12-001-02-e Ref: 547-145 12.02.20
Made in the UK
Utah, U.S.A.
Phone: [phone]
Fax: [phone]
www.thermoworks.com
For warranty, service, and technical assistance, please contact
ThermoWorks’ Technical Support at [phone] or email at
[e-mail].
ACCESSORIES/RELATED ITEMS
Stainless Steel
Wall Bracket
(THS-830-002)
Wall Bracket
(10203)
Protective
Silicone Boot
(THS-830-260)

INSTRUMENT OPERATION
The instrument is switched on by unfolding the
probe until the display shows the temperature.
The unit is turned off by folding the probe
back into the side of the instrument. The probe
should not be rotated more than 180 degrees as
damage will occur. It is recommended to store
the probe, in the closed position, when not in
use.
Apply the probe to the substance to be measured. For optimum accuracy
immerse at least 2.75″(70mm) of the probe in the substance. DO NOT
immerse the probe all the way to the plastic rotating hub. The probe should
be allowed adequate time to stabilize to the temperature of the item to be
measured.
INSTRUMENT
CONFIGURATION
This instrument has four user
selectable slide switches
(switch bank), adjustable
with a paperclip, and a single
push button ‘Trim Adjust’
which is located under the
battery cover.
Switch 1 - Display Units - Changes display units between °F (factory default)
and °C. To change to °C push the switch toward the batteries.
Switch 2 - Resolution - To change the resolution from 0.01°F (factory default)
to 0.1°F push the switch away from the batteries.
Switch 3 - Auto-off - To disable the auto-off (factory default – 10minutes)
push the switch away from the batteries.
Switch 4 - Reading Trim - For normal use, we do not recommend using the
‘Trim Adjust’. For further details visit www.thermoworks.com.
INSTRUMENT CLEANING
Clean the instrument regularly with an anti-bacterial probe wipe to avoid
potential bacterial growth.
BATTERY REPLACEMENT
A battery symbol indicates that the batteries will need
replacing. The instrument continues to measure accurately
but we recommend that the batteries be changed as soon
as possible. To replace the batteries, remove the battery
cover using a coin (U.S. quarter works best). Remove the
batteries by pulling the battery retaining clip back while
holding the unit upside down. Replace both batteries,
positive side up, replace cover.
ERROR MESSAGES
‘Err’ will be displayed if the probe develops a fault. If the error message
remains, contact ThermoWorks Tech Support for further assistance.
EMC/RFI
Instrument performance may be affected if operated within a high frequency
radio field, such as near a mobile phone, or if subjected to an electrostatic
shock.
WARNING
IPA and other solvents may cause damage to the case and screen of this
instrument.
GUARANTEE
This instrument carries a two-year warranty against defects in either
components or workmanship. During this period, products that prove to be
defective will, at the discretion of ThermoWorks, be either repaired or replaced
without charge. This warranty does not apply to probes, where a six-month
period is offered. Full details of liability are available within ThermoWorks’
Terms & Conditions of Sale at www.thermoworks.com/product-warranty.
