8
DE – Anleitung
Schnellstart
Beschreibung
1Aufsteckbürste
2Visuelle Andruckkontrolle
3Ein-/Ausschalter
(Moduswahl)
4Ladekontrollleuchte
5Niedrig-Ladekontrollleuchte
6Handstück
7Ladestation
(modellabhängig)
FR- Guide de
démarrage rapide
Description
1
Brossette
2
Voyant du capteur de
pression
3
Bouton marche/arrêt
(sélection des modes)
4
Voyant indicateur de niveau
de charge
5
Voyant indicateur de
batterie déchargée
6
Corps de brosse
7
Chargeur/base de
chargement (suivant le
modèle)
GB – Quick Start Guide
Description
1
Brush head
2
Pressure sensor light
3
On/off button (mode
selection)
4
Charge indicator light
5
Low charge indicator light
6
Handle
7
Charger / Charger base
(depending on model)
ES – Guía rápida de inicio
Descripción
1
Cabezal del cepillo
2
Luz del sensor de presión
3
Botón de encendido/
apagado (selección
de modo)
4
Luz del indicador de carga
5
Luz indicadora de batería
baja
6
Mango
7
Cargador / Base de carga
(según modelo)
91470059
91470059_D601_WE_QG.indd 891470059_D601_WE_QG.indd 8 21.09.17 10:5521.09.17 10:55
CSS APPROVED Effective Date 11Oct2017 GMT - Printed 22Nov2017 Page 7 of 12

9
PT – Guia de Introdução
Descrição
1
Cabeça de escovagem
2
Luz do sensor de pressão
3
Botão ligar/desligar
(seleção de modo)
4
Luz indicadora de carga
5
Luz indicadora de pouca
carga
6
Cabo
7
Carregador / Base de
carregamento
(dependendo do modelo)
NL – Gids voor snel
opstarten
Omschrijving
1
Opzetborstel
2
Poetsdruk sensor lampje
3
Aan/uit schakelaar
(poetsstandselectie)
4
Oplaad indicatielampje
5
Lage batterij indicatielampje
6
Handgreep
7
Oplader/Oplaadstation
(afhankelijk van het model)
IT – Guida Rapida
Descrizione
1
Testina per spazzolino
2
Spia del sensore di
pressione
3
Pulsante on/off (selezione
modalità)
4
Indicatore del livello di
ricarica
5
Indicatore del livello ricarica
bassa
6
Manico
7
Caricatore / Base di ricarica
(in base al modello)
DK – Hurtigguide
Beskrivelse
1
Børstehoved
2
Tryksensorlys
3
Tænd-/slukknap
(valg af funktion)
4
Indikatorlys for opladning
5
Indikatorlys for lavt batteri
6
Tandbørste
7
Oplader/laderdel
(afhængigt af model)
91470059_D601_WE_QG.indd 991470059_D601_WE_QG.indd 9 21.09.17 10:5521.09.17 10:55
CSS APPROVED Effective Date 11Oct2017 GMT - Printed 22Nov2017 Page 8 of 12

10
SE – Snabbstartsguide
Beskrivning
1
Borsthuvud
2
Trycksensorlampa
3
På-/av-knapp (funktionsval)
4
Lampa, laddningsindikator
5
Indikatorlampa för låg
batterispänning
6
Tandborsthandtag
7
Laddare/laddningsstation
(beroende på modell)
FI – Pikaopas
Kuvaus
1
Harjaspää
2
Paineentunnistimen
merkkivalo
3
Virtapainike (harjaustilan
valitsin)
4
Latauksen merkkivalo
5
Alhaisen latauksen
merkkivalo
6
Runko-osa
7
Laturi / latausalusta
(mallista riippuen)
GR – Οδηγός γρήγορης
έναρξης
Περιγραφή
1
Κεφαλή βουρτσίσματος
2
Φωτεινή ένδειξη αισθητήρα
πίεσης
3
Κουμπί ενεργοποίησης/
απενεργοποίησης (επιλογή
προγράμματος)
4
Φωτεινή ένδειξη φόρτισης
5
Φωτεινή ένδειξη χαμηλής
μπαταρίας
6
Λαβή οδοντόβουρτσας
7
Φορτιστής / Βάση φορτιστή
(αναλόγως το μοντέλο)
NO – Hurtigguide
Beskrivelse
1
Børstehode
2
Trykksensorlys
3
På/av-knapp
(innstillingsvalg)
4
Ladeindikatorlys
5
Indikatorlys for lavt
batterinivå
6
Håndtak
7
Lader/Ladebase
(avhengig av modell)
