Breville Easy Glide User manual

Easy Glide 1800w steam iron
www.breville.co.uk

2
features
Water tank inlet cover
Steam control
Shot of steam button
Spray button
Temperature selector
Indicator light
Flexible cord protector
1.
2.
3.
4.
5.
6.
7.
Due to our policy of continuous improvement, the actual product may differ slightly from the one illustrated in these instructions.
Heel rest
Cord wrap
Stainless steel soleplate
Pointer
Water level maximum indicator
Water tank
Spray nozzle
8.
9.
10.
11.
12.
13.
14.
q w e r
o
asd
t y
u
i
f
g

3
before rst use
Remove all packaging including any soleplate protection before heating the
iron.
Wipe over the soleplate with a cloth moistened with methylated spirit. Remove the
methylated spirit with a damp cloth then dry the soleplate thoroughly.
Fill the water tank and then empty it. This will rinse out any foreign particles remaining in
the water tank from the manufacturing process. Never ll your iron directly under a tap.
Always use the measuring cup supplied.
Before connecting your iron to the mains supply, make sure your supply voltage is the
same as the one indicated on your iron.
When you rst use your iron, there may be a slight odour and it may smoke slightly for the
rst few minutes of operation. This is quite normal and will disappear.

4
lling your iron
Never use fabric conditioner, starches or any other chemicals or additives.
Ensure the iron is switched off and unplugged from the mains supply socket.
Set the steam control to the no steam position (0).
Place the iron horizontally on a at, stable, dry, heat resistant and level surface and
open the water tank inlet cover.
Using the supplied measuring cup, ll the water tank with ordinary tap water. To avoid
air locks, tilt the iron slightly while lling it.
Don’t ll the iron above the water level indicator MAX marking. Check the water level
by standing the iron on its heel.
When the iron is lled close the water tank inlet cover.
TIP: We recommend that you:
Start with the fabrics to be ironed on a low temperature such as synthetic material.
Finish ironing with those fabrics which respond best to higher temperatures such as
linen.
If you iron a fabric made of a blend of bres; set the temperature control dial for the
most delicate bre.
Never use the burst of steam button on silks or synthetics.
When using starch, it should be sprayed onto the reverse side of the fabric and the
soleplate cleaned more frequently.
Do not iron over sharp or hard objects such as buttons, studs and zippers, as these
will scratch the surface of the soleplate.
1.
2.
3.
4.
5.
6.
•
•
•
•
•

5
using your iron
Ironing without steam
You may see this ‘Do not steam’ symbol on certain delicate fabrics. If you
intend to dry iron fabrics, there is no need to ll the water tank. However, if water is
already in the water tank, you do not need to empty it.
Set the steam control to the no steam position (0).
Plug your iron into the mains supply and switch on.
Set the temperature selector to the required temperature.
The indicator light will illuminate while the iron is heating up.
When the light goes out, your iron is ready to use. The indicator light will continue to
turn on and off during ironing as the iron maintains the soleplate temperature.
Steam ironing
During steam ironing, if you do not allow the iron to reach the selected
temperature water may drip from the soleplate.
It is recommended that for harder to iron fabrics such as cotton and linen, steam should
be used when ironing.
When ironing cotton and linen always select the highest temperature. Steam should
never be used on delicate fabrics like nylons, acrylics and synthetics.
Following the steps on page 4 ll the iron with water.
Plug your iron into the mains supply and switch on.
Turn the temperature selector until the pointer is within the steam setting range.
The indicator light will illuminate. When the indicator light goes out the iron is ready
to use. The indicator light will continue to turn on and off during ironing as the iron
maintains the soleplate temperature.
Adjust the steam control for the desired steam output.
Adjust the steam control lever to the right to increase the amount of steam , or to
the left to decrease the amount of steam .
The iron will automatically begin to steam as soon as the iron is used.
The steam can be shut off at any time by setting the steam control to the no steam
position (0).
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
6.
7.
Pointer
Temperature selector

6
using your iron
Burst of Steam
Note: The temperature selector must be set within the steam setting range (see page
5) when using the shot of steam function. Wait for several seconds between each
press of the steam button.
Press the shot of steam button whenever you have a stubborn crease that needs
extra steam. Steam will burst from the holes in the soleplate into the fabric.
Vertical Steam Ironing
Never iron garments when they are being worn.
Your iron can be used for vertical steam ironing. This process can be applied to
curtains, dresses on hangers etc.
Following the steps on page 4 ll the iron with water.
Plug your iron into the mains supply and switch on.
Turn the temperature selector until the pointer is within the steam setting range. The
hotter the iron, the more steam is generated.
The temperature indicator light will illuminate to show that the iron is heating.
When the indicator light goes out, the iron is ready to use. The indicator light will
cycle on and off during ironing as the iron maintains the soleplate temperature.
Hold the iron 15cm (6 inches) from the fabric.
Press the shot of steam button. The steam will penetrate the fabric removing the
creases. To apply more steam press the shot of steam button again.
Spraying
Note: The spray function will only operate when there is water in the water tank.
The water spray can be used to help iron heavy fabrics or difcult areas (collars,
pockets, sleeves, creases, etc). It can also be used when ironing delicate fabrics
which cannot be steam ironed.
Simply press the spray button as required to emit a spray of water. If the spray is
being used for the rst time, or if the iron has been standing for some time, you
may need to press the spray button a few times to prime the spray before it works
correctly.
1.
1.
2.
3.
4.
5.
6.
7.
8.
1.
2.

7
using your iron
Note: When the temperature selector is changed from a high setting to a lower
setting during ironing, the indicator light will go out immediately. This indicates that
the iron is cooling to the selected temperature. To ensure that the iron has reached
the selected temperature and is not too hot, wait until the indicator light comes on
again, and then goes out before ironing.
Anti-Drip Function
The supply of water is cut off automatically to avoid any drips from the soleplate
when the temperature of the iron is insufcient to produce steam.
•

8
Do not use harsh abrasives, chemical cleaners or solvents to clean the exterior
of your iron because they will damage the surface.
Cleaning the Soleplate on your Iron
After each use, allow iron to cool fully before wiping the soleplate with a damp soft cloth.
If polyester has burnt to the soleplate, iron a damp cotton cloth while hot. If necessary,
allow unit to cool fully and wipe over the soleplate with a soft cloth and a small amount of
methylated spirits. Remove the methylated spirit with a damp cloth. Ensure soleplate is
dried thoroughly.
Cleaning the Steam Holes
To remove build-up from the steam holes which may affect steam performance, use a
cotton wool tip moistened in methylated spirits. Wipe over with a damp cloth.
To clean the exterior of your iron, wipe over with a damp soft cloth and wipe dry. Ensure
the soleplate is then dried thoroughly.
Putting your Iron Away
Set the steam control to the no steam position (0).
Turn the power off and remove the plug from the power outlet.
When the soleplate has cooled, empty remaining water from the tank.
Storage
Always store the iron on its heel rest, allowing to cool for 30 minutes.
Do not store the iron with the soleplate facing down, or in the carton.
Do not wrap the cord around the soleplate. The cord can be neatly wrapped around
the heel of the iron.
1.
2.
3.
1.
2.
3.
care and cleaning

9
product safety
Please read these instructions before operating the appliance and retain them for
future use.
This product is not suitable for use by children, and may not be suitable for persons
requiring supervision unless they receive instruction by a competent person on how to
safely use the product. Children should be supervised to ensure that they do not play
with the product.
Never use this appliance for anything other than its intended use. This appliance is for
household use only. Do not use this appliance outdoors.
Always ensure that hands are dry before handling the plug or switching on the
appliance.
Never leave the appliance unattended when it is connected to the mains supply.
Ensure the appliance is switched off and unplugged from the supply socket before
lling or emptying the water tank, after use and before cleaning.
Do not use the appliance if it has been dropped, if there are any visible signs of
damage or if it is leaking.
Always use the appliance on a stable, secure, dry and level surface. When placing the
appliance on its stand, ensure that the surface on which the stand is placed is stable.
Do not touch the metal parts of the appliance during use as they may become very hot.
Never operate the appliance by means of an external timer or separate remote-control
system.
This appliance must not be placed on or near any potentially hot surfaces (such as a
gas or electric hob).
The power cord is not replaceable by the user. Always return the appliance if the power
cord is damaged to avoid any hazard.
Always allow the appliance to cool before cleaning or storing.
Never immerse any part of the appliance or power cord and plug in water or any other
liquid.
Never let the power cord hang over the edge of a worktop, touch hot surfaces or
become knotted, trapped or pinched.
!
!
!
!
!
!
!
!
!
!
!
!
!
!

10
This appliance must be earthed.
This appliance is tted with either a moulded or rewirable BS1363, 13 amp plug. The fuse
should be rated at 13 amps and be ASTA approved to BS1362.
If the fuse in a moulded plug needs to be changed, the fuse cover must be retted. The
appliance must not be used without the fuse cover tted.
If the plug is unsuitable, it should be dismantled and removed from the supply cord
and an appropriate plug tted as detailed below. If you remove the plug it must not be
connected to a 13 amp socket and the plug must be disposed of immediately.
The wires of the mains lead are coloured in accordance with the following code:
GREEN/YELLOW = EARTH BLUE = NEUTRAL BROWN = LIVE
The wire which is coloured GREEN/YELLOW must be connected to the terminal in
your plug which is marked with an E or by the earth symbol ( ) or coloured GREEN or
GREEN /YELLOW.
The wire which is coloured BLUE must be connected to the terminal in your plug which is
marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in your plug which
is marked with the letter L or coloured RED.
If any other plug is used, a 13 amp fuse must be tted either in the plug or adaptor or at
the distributor board.
Plug should be BS1363 approved
Fit a 13 Amp Fuse
Ensure that the outer sheath of the cable
is rmly held by the clamp
BROWN
(Live)
13 Amp
Fuse
BLUE
(Neutral)
GREEN/YELLOW
(Earth)
connection to the mains supply

11
after sales service
These appliances are built to the very highest of standards. There are no user serviceable
parts. Follow these steps if the unit fails to operate:
Check the instructions have been followed correctly.
Check that the fuse has not blown.
Check that the mains supply is functional.
If the appliance will still not operate, return the appliance to the place it was purchased for
a replacement. To return the appliance to the Customer Service Department, follow the
steps below:
Pack it carefully (preferably in the original carton). Ensure the unit is clean.
Enclose your name and address and quote the model number on all correspondence.
Give the reason why you are returning it.
If within the guarantee period, state when and where it was purchased and include
proof of purchase (e.g. till receipt).
Send it to our Customer Service Department at the address below:
Customer Service Department
Pulse Home Products Limited
Middleton Road
Royton
Oldham
OL2 5LN, UK.
Telephone: [phone] Fax: [phone]
e-mail: [email protected]
1.
2.
3.
1.
2.
3.
4.
5.

12
This product is guaranteed for a period of 1 year from the date of purchase against
mechanical and electrical defects.
This guarantee is only valid if the appliance is used solely for domestic purposes in
accordance with the instructions provided, that it is not connected to an unsuitable
electricity supply, dismantled or interfered with in any way or damaged through misuse.
Under this guarantee we undertake to repair or replace free of charge any parts found to
be defective.
Nothing in this guarantee or the instructions relating to the product excludes, restricts or
otherwise affects your statutory rights.
In line with our policy of continuous development, we reserve the right to change this
product, packaging and documentation without notice.
This product is manufactured to comply with the radio interference
requirements of EEC directive 93/68 EEC.
guarantee

13

14

15

Vine Mill, Middleton Road, Royton, Oldham OL2 5LN, UK
www.breville.co.uk
Breville is a registered trademark of Pulse Home Products Limited
© Pulse Home Products Limited
92977 -0
VIN143_Iss_1 03/09
