319700
Illustrated Parts List
Model Series
319700
TYPE NUMBERS
0110 THROUGH 0115.
TABLE OF CONTENTS
Air Cleaner 6.........................
Blower Housing 6.....................
Camshaft 2...........................
Carburetor 4..........................
Controls 7............................
Crankshaft 2..........................
Cylinder 2............................
Cylinder Head 3.......................
Electric Starter 7......................
Engine Sump 2.......................
Flywheel 6............................
Fuel Supply 4.........................
Gasket Set -- Engine 2.................
Gasket Set -- Valve 3..................
Governor Spring 7....................
Ignition 7.............................
Intake Manifold 3.....................
Kit -- Carburetor Overhaul 4............
Lubrication 3.........................
Operator’s Manual 2..................
Piston, Rings, Connecting Rod 2.......
Valves 3..............................
Warning Label 2......................
Not for
Reproduction

319700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6142--2 Assemblies include all parts shown in frames. 07/22/2010
2
4A
12
20
1017
29 32
307
306
718
3
22
15
1
2
24
691
552
684 11
584
585
1263
1264
43
1270
758
759
757
27
28
26
27
25
741
146
16 46
24
45
1058 OPERATOR’S MANUAL 1319 WARNING LABEL
REQUIRED when replacing parts
with warning labels affixed.
850
239
6
1027
1022
12
585
7
3
358 ENGINE GASKET SET
868
691
524
51
20 617
883
1266
842
1266A 51A
943
Not for
Reproduction

319700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6142--3 Assemblies include all parts shown in frames. 07/22/2010
3
51
617
50
617
830
1034
1022
51
7
238 36
868
1029
33
534
192
35
45
383
337
635
1026
13
1022
868
51
1095 VALVE GASKET SET
7
847
523
842
525
524
750
943
965 42
42
883
1022
1023
914
850
53
54 654
1024A
883
51A
307 306
Not for
Reproduction

319700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6142--4 Assemblies include all parts shown in frames. 07/22/2010
4
431 1266A
1266
125
51
NIKKI
142
Not for
Reproduction

319700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6142--5 Assemblies include all parts shown in frames. 07/22/2010
5
1267
305
305A
1036 EMISSIONS LABEL
1040
304 1267
967
643
968
445 187D
601
187A
601
773
1139
304D
967
643
968
445
Not for
Reproduction

319700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6142--6 Assemblies include all parts shown in frames. 07/22/2010
6
37
78
783
1051
23
363
1044
1005
1005A
415A
1070A
1070
74
73B 324
Not for
Reproduction

319700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6142--7 Assemblies include all parts shown in frames. 07/22/2010
7
851
334
333
729
202
232
268
269
271
270
209 188
616
404
614
562
505
227
697
729A
802
462
579
503
310
801
309
1090 311
797
521
222A
356
1051
510
513
783
Not for
Reproduction

REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
319700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6142--8 Assemblies include all parts shown in frames. 07/22/2010
8
1 796010 Cylinder Assembly
-- -- -- -- -- -- N o t e -- -- -- -- -- --
796010 Cylinder
Assembly
(Used Before Code
Date 08042800)
Must Be Used With
The After 08042700
Cylinder Shield, Ref
306.
2 399265 Kit--Bushing/Seal
(Magneto Side)
3 391086S Seal--Oil
(Magneto Side)
4A 790725 Sump--Engine
(Used After Code Date
05100200).
-- -- -- -- -- -- -- N o t e -- -- -- -- --
795939 Sump--Engine
(Used Before Code
Date 05100300).
(Must Use Kit 795939,
Includes Sump And
Counterweight).
5 796026 Head--Cylinder
6 690310 Washer
(Used After Code Date
07070900).
7 796584 Gasket--Cylinder Head
(Breather Assembly)
11 794683 Tube--Breather
12 697110 Gasket--Crankcase
(.015” Thick)
(Standard)
13 793988 Screw
(Cylinder Head)
(Used After Code Date
07010900).
-- -- -- -- -- -- N o t e -- -- -- -- -- --
690360 Screw
(Cylinder Head)
(Used Before Code
Date 07011000).
15 690946 Plug--Oil Drain
(Square Head)
16 699106 Crankshaft
Used on Type No(s).
0110.
-- -- -- -- -- -- N o t e -- -- -- -- -- --
797584 Crankshaft
Used on Type No(s).
0114, 0115.
793245 Crankshaft
Used on Type No(s).
0112, 0113.
20 795387 Seal--Oil
(PTO Side)
22 692125 Screw
(Crankcase
Cover/Sump)
23 693557 Flywheel
-- -- -- -- -- -- N o t e -- -- -- -- -- --
698281 Flywheel
Used on Type No(s).
0114, 0115.
24 222698S Key--Flywheel
25 796172 Piston Assembly
(Standard)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
796173 Piston
Assembly
(.020” Oversize)
26 791936 Ring Set
(Standard)
(Used After Code Date
08042700).
-- -- -- -- -- -- N o t e -- -- -- -- -- --
699026 Ring Set
(Standard)
(Used Before Code
Date 08042800).
792649 Ring Set
(.020” Oversize)
27 698469 Lock--Piston Pin
28 796007 Pin--Piston
(Standard)
(Used After Code Date
08042700).
-- -- -- -- -- -- N o t e -- -- -- -- -- --
697099 Pin--Piston
(Standard)
(Used Before Code
Date 08042800).
29 794122 Rod--Connecting
(Standard)
Used on Type No(s).
0110.
-- -- -- -- -- -- N o t e -- -- -- -- -- --
794571 Rod--
Connecting
(Standard)
Used on Type No(s).
0112, 0113, 0114,
0115.
32 791118 Screw
(Connecting Rod)
33 792868 Valve--Exhaust
34 791935 Valve--Intake
35 691279 Spring--Valve
(Intake)
36 691279 Spring--Valve
(Exhaust)
37 697352 Guard--Flywheel
42 499586 Keeper--Valve
43 691968 Slinger--Governor/Oil
45 690564 Tappet--Valve
46 793880 Camshaft
50 793668 Manifold--Intake
51 692137 Gasket--Intake
51A 692137 Gasket--Intake
53 690227 Stud
(Carburetor)
54 691148 Screw
(Intake Manifold)
73B 697133 Screen--Rotating
(Used Before Code
Date 07040900).
74 697897 Screw
(Rotating Screen)
78 691003 Screw
(Flywheel Guard)
125 793115 Carburetor
(Nikki Mixer Assembly)
142 793906 Nozzle--Carburetor
146 691639 Key--Timing
187A 791806 Line--Fuel
(Formed)(21 Inches
Long)(Cut to Required
Length)
187D 791744 Line--Fuel
(Formed)(14 Inches
Long)(Cut to Required
Length)
188 691693 Screw
(Control Bracket)
192 691986 Adjuster--Rocker Arm
202 691841 Link--Mechanical
Governor
209 792602 Spring--Governor
(Used After Code Date
05112700).
-- -- -- -- -- -- N o t e -- -- -- -- -- --
690480 Spring--
Governor
(Used Before Code
Date 05112800).
222A 694335 Bracket--Control
227 694339 Lever--Governor
Control
232 691842 Spring--Governor Link
238 691843 Cap--Valve
239 694115 Switch--Oil Pressure
268 691025 Casing--Control Wire
(Cut To Required
Length)
Not for
Reproduction

REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
319700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6142--9 Assemblies include all parts shown in frames. 07/22/2010
9
269 691026 Wire--Control
(Cut To Required
Length)
270 691027 Nut
(Control Wire Casing)
271 691028 Lever--Control
304 796416 Housing--Blower
(Black)
(Used After Code Date
08082400).
304D 790719 Housing--Blower
(Black)
(Used Before Code
Date 08082500).
305 697102 Screw
(Blower Housing)
305A 793376 Screw
(Blower Housing)
306 796006 Shield--Cylinder
(Used After Code Date
08042700).
-- -- -- -- -- -- N o t e -- -- -- -- -- --
697107 Shield--
Cylinder
(Used Before Code
Date 08042800).
307 691003 Screw
(Cylinder Shield)
309 693552 Motor--Starter
310 691263 Screw
(Starter Motor)
311 497608 Brush Set
324 796308 Screen--Rotating
(Used After Code Date
07040800)
333 795315 Armature--Magneto
334 691061 Screw
(Magneto Armature)
337 491055S Plug--Spark
356 697397 Wire--Stop
358 796187 Gasket Set--Engine
363 19203 Puller--Flywheel
383 89838S Wrench--Spark Plug
404 691691 Washer
(Governor Crank)
415A 794129 Plug
(Cover/Retainer)
431 793669 Elbow--Intake
445 790263 Filter--Air Cleaner
Cartridge
(UL Recognized)
462 691261 Washer
(Starter Cable)
503 691532 Strap--Starter
505 691251 Nut
(Governor Control
Lever)
510 693699 Drive--Starter
513 692024 Clutch--Drive
521 690581 Shield--Cable
523 699908 Dipstick
524 691032 Seal--Dipstick Tube
525 697184 Tube--Dipstick
552 697144 Bushing--Governor
Crank
562 691119 Bolt
(Governor Control
Lever)
579 691029 Nut
(Starter Cable)
584 794682 Cover--Breather
Passage
(Use With Liquid
Sealant Reference
850)
585 697109 Gasket--Breather
(Used Before Code
Date 07071900).
(After Date Code Use
Liquid Sealant
Reference 850)
601 791850 Clamp--Hose
(Green)
614 691620 Pin--Cotter
616 692012 Crank--Governor
617 692138 Seal--O Ring
(Intake Manifold)
635 691909 Boot--Spark Plug
643 698401 Retainer--Air Filter
654 690958 Nut
(Carburetor)
684 697157 Screw
691 692407 Seal--Governor Shaft
697 791680 Screw
(Drive Cap)
718 690959 Pin--Locating
729 691335 Clip--Wire
(Wire Saddle)
729A 691224 Clip--Wire
(Aluminum Coated
Steel)
741 697128 Gear--Timing
750 790832 Screw
(Oil Pump Cover)
757 793242 Link--Counterweight
773 796448 Retainer
(Fuel Pump)
758 793763 Counterweight
(Used After Code Date
05100200).
-- -- -- -- -- -- -- N o t e -- -- -- -- --
795939 Counterweight
(Used Before Code
Date 05100300).
(Must Use Kit 795939,
Includes Sump And
Counterweight).
759 697392 Pin--Counterweight
783 693713 Gear--Pinion
797 693167 Nut
(Brush Retainer)
801 691283 Cap--Drive
802 691286 Cap--End
830 691095 Stud--Rocker Arm
842 691031 Seal--O Ring
(Dipstick Tube)
847 790442 Dipstick/Tube
Assembly
850 100100 Sealant--Liquid
(Rocker Cover Gasket
and Breather Gasket)
(Used After Code Date
07071800).
851 692424 Terminal--Spark Plug
868 690968 Seal--Valve
883 692236 Gasket--Exhaust
914 697551 Screw
(Rocker Cover)
943 690589 Seal--O Ring
(Oil Pump Cover)
965 499613 Cover--Oil Pump
967 697015 Filter--Pre Cleaner
968 698403 Cover--Air Cleaner
(Black)
1005 796083 Fan--Flywheel
(Used After Code Date
07040800).
1005A 796201 Fan--Flywheel
(Used Before Code
Date 07040900).
1017 690770 Screen--Oil Pump
(Push In)
Not for
Reproduction

REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
319700
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6142--10 Assemblies include all parts shown in frames. 07/22/2010
10
1022 272475S Gasket--Rocker Cover
(Used Before Code
Date 07091000).
(After Date Code Use
Liquid Sealant
Reference 850)
1023 797421 Cover--Rocker
1024A 794644 Pump--Oil
(Used After Code Date
07051600).
1026 692003 Rod--Push
(Intake)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
692011 Rod--Push
(Exhaust)
1027 492932S Filter--Oil
1029 691751 Arm--Rocker
1034 690822 Guide--Push Rod
1035 693784 Shaft--Pump
1036 Label--Emissions
(Available From A
Briggs & Stratton
Authorized Dealer)
1040 698368 Plate--Trim
1044 698139 Screw
(Flywheel)
1051 691265 Ring--Retaining
1058 277766 Manual--Operator’s
1070 791680 Screw
(Flywheel Fan)
(Used Before Code
Date 07040900).
1070A 690363 Screw
(Flywheel Fan)
(Used Before Code
Date 08061000 and
After Code Date
07040800).
1090 691293 Retainer--Brush
1095 690190 Gasket Set--Valve
1139 796449 Washer
1263 697124 Reed--Breather
1264 697104 Screw
(Breather Reed)
1266 691917 Seal--O Ring
(Intake Elbow)
1266A 697123 Seal--O Ring
(Intake Elbow)
1267 697419 Latch--Blower Housing
1270 793243 Plug--AVS
Counterweight
(Used After Code Date
06081300).
-- -- -- -- -- -- N o t e -- -- -- -- -- --
697156 Plug--AVS
Counterweight
(Used Before Code
Date 06081400).
1319 794467 Warning Label
Not for
Reproduction

Not for
Reproduction

Not for
Reproduction
