Operator’s Manual
1696895 Hedge Trimmer - 82V Attachment
1696895-
1
Complemento -
Manual del operario
1696895 Aditamento 82V de Cortasetos
Lisaseade -
Fixation- Manuel d’utilisation
1696895 Taille-haie - Fixation 82V
Accessorio -
Manuale per l’operatore
1696895 Tagliasiepi - Accessorio 82V
priedas
1696895 Heggenschaar - 82V
Zamocowanie -
Zamocowanie 82V
Acceso
Accesoriu
1
1696895
it
hr
fi
et
es
el
de
da
cs
bg
fr
ru
ro
sk
sl
ar
tr
sv
lt
lv
nl
no
pt
Not for
Reproduction
Meaning
Safety information about hazards that
can result in personal injury.
Read the directions for use of hedge
trimmer before operating the machine.
High voltage hazard. Risk of
electrocution could cause severe
injury or death.
Maintain 50 ft (15m) between the unit
and any electrical line to reduce the
risk of electrocution.
All bystanders must be kept at least
50 ft (15m) away from machine.
Cutting hazard from the blade.
Thrown objects hazard - Wear eye
protection.
Noise hazard - Wear ear protection.
Falling objects hazard - Wear helmet.
Wear safety gloves and boots.
Protect the machine from rain and
damp environments.
Under NO circumstances can you use
more than one pole extension.
Manual Contents:
....................... 2
........................... 2
Parts and Features ........................ 4
Operation ................................ 4
Storage .................................. 4
Maintenance.............................. 5
.......................... 5
Parts List................................. 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
The illustrations in this document are representative.The
unit may vary from the images displayed. LEFT and RIGHT
are referenced from the operator’s position.
exceptions, or alternatives to the procedures given.
All language translations of this document are derived from
This
manual contains safety information to make you aware of
the hazards and risks associated with the product and how
to avoid them. It also contains important instructions that
should be followed during the initial set-up, operation, and
maintenance of the product.
It is important that you read and understand these instructions
before attempting to start or operate this equipment.
The safety alert symbol
about hazards that can result in personal injury. A signal
word (DANGER, WARNING, or CAUTION) is used with the
alert symbol to indicate the likelihood and the potential
severity of injury. In addition, a hazard symbol may be used
to represent the type of hazard.
indicates a hazard which, if not avoided, will
result in death or serious injury.
indicates a hazard which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazard which, if not avoided,
could result in minor or moderate injury.
NOTICE indicates an action that could result in damage to
the product.
This product can expose you to chemicals including
lead and lead compounds, which are known to the State
of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.
P65Warnings.ca.gov.
2
Not for
Reproduction
Do not operate the hedge trimmer attachment before
reading all Safety and Handling sections.
• Stay alert.Watch what you are doing when operating a
power tool. Do not operate the hedge trimmer under the
influence of alcohol, drugs or medication or when you
are tired or sick.
• Do not operate the hedge trimmer for any other purpose
except that for which it is intended.
• Use only manufacturer’s genuine recommended
replacement parts and accessories.
•
The operation of any power tool can result in foreign
objects being thrown into your eyes, which can result in
severe eye damage. Always wear safety glasses with side
shield and a helmet. Always wear nonslip safety shoes,
ear muffs and gloves.
• Know the hedge trimmer controls and learn how to stop
operating the unit quickly in an emergency by releasing
the “ON / OFF” switch.
• Before using the hedge trimmer, make sure that the
blade assembly is not worn or damaged.
• Dress properly. Do not wear loose clothing or jewelry or
long hair which can be caught in moving parts.
• Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools can create sparks which may ignite
the dust or fumes.
• Operate only in daylight or good artificial light. Never
operate in bad weather, especially when there is a risk
of lightning.
• Keep your work area clean and well lit.
• Maintain 50 ft (15 m) between the unit and any electrical
line to reduce the risk of electrocution.
• Electricity can jump from one pole to another by arching.
Higher voltage increases the distance that causes
electricity to arc.
Bystanders must be kept at least 50 ft (15 m) away from
cutting head during operation.
• Stop the machine immediatedly if approached.
• Be careful when turning or swinging the unit.
• Look before turning or changing direction.
Operating the hedge trimmer
• Walk with the hedge trimmer. Never run.
• To maintain full control of the hedge trimmer, keep
a proper footing at all times with your weight evenly
balanced over both feet and never over reach. Use both
hands when operating the hedge trimmer.
• Always keep the handle dry and free from oil and
grease.
• Always make sure the camlock is secure before
operating the trimmer.
• Do not force the hedge trimmer. Always use the correct
tool for your application.
• Do not use the hedge trimmer if the switch does not turn
it ON and OFF.
• Store idle power tools out of the reach of children.
Do not allow persons unfamilar with the power tool or
these instructions to operate the power tool.
• Do not remove trimmed material or hold material to be
trimmed when the blades are moving.
• Keep all body parts, especially hands away from moving
parts when the hedge trimmer is running.
• Always stop the hedge trimmer and remove the battery
if the following conditions apply:
- before clearing any blockage.
- before assemblying, checking, cleaning or working on
the unit.
- whenever leaving the hedge trimmer unattended.
- If the unit becomes jammed.
en
3
Not for
Reproduction
Parts and Features
AConnecting pole
Hedge attachment
C
Blade transport guard
Operation
Loosen the locking lever to adjust the hedge trimmer to the
desired angle (Figures 2, 3, 4). Then tighten the locking
lever.
Do not force the hedge trimmer through heavy shrubbery.
This can cause the blades to bind and slow down. If the
blades slow down, reduce the pace.
Do not cut stems or twigs larger than 15 mm thick, or too
large to feed into the cutting blade. Use a non-powered
hand saw or pruning saw to trim large stems.
When trimming new growth, use a wide sweeping action,
so that the stems are fed directly into the cutting blade.
Older growth will have thicker stems and will be trimmed
easiest by using a sawing movement.
Storage
When transporting or storing the hedge trimmer, always
remove the battery, and install the blade transport guard.
Proper handling of the hedge trimmer will reduce the risk of
personal injury from the cutter blades.
123
Figure 1
Figure 2
Figure 3
Figure 4
4
Not for
Reproduction
Maintenance
Periodically check the hedge trimmer for misalignment,
binding of moving parts, breakage of parts and any other
condition that may affect the hedge trimmer operation. If
damaged, have the unit repaired before use.
Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
All maintenance, repair and inspection work should be
performed by an authorized service center.
Maintenance Chart
Refer to the following table for routine maintenance.
Requirements
Actions
start
10
hours
Cutting
Visual inspection
• •
Inspect and
check assembly
•
Lubricate with oil
• • •
Check •
Retighten • •
Apply grease to the gear box as necessary(Recommended
every 10 hours of operation).
The following chart lists problems, causes and corrective
actions if your hedge trimmer does not operate properly.
If these do not correct the problem, contact an authorized
service center.
Correction
Too much friction. Apply lubricant to the blades.
Cutting tool too hot
Dull cutting blades.
Blades out of alignment.
Too much friction.
Contact an authorized service center.
Contact and authorized service center.
Apply lubricant to the blades.
Loose fasteners. Tighten fasteners.
load Blades out of alignment. Contact an authorized service center.
en
5
Not for
Reproduction
Parts List
ITEM NO. PART NO. DESCRIPTION QTY
0010 771010 BLADE ASSEMBLY 1
0005 84003417 KIT, STRAP & FELT 1
0008 ----- STRAP 1
0009 ----- FELT 1
0011 ----- NUT. M5 4
0012 ----- SPACER, STEP 4
0013 ----- BOLT 4
0014 84003418 BRACE, BLADE 1
0015 84003419 KIT, BLADES 1
0017 ----- NUT. M5 2
0018 ----- WASHER 4
0019 ----- LOCKWASHER 4
0020 ----- SCREW, M4-12 4
0021 ----- GASKET 1
0030 771007 ZERK, Grease Fitting 3
0040 771011 GUARD, Blade 1
0018
0017
0001
Reference Only
0040
0021
0019
0020
0030
0011
0012
0013
0014
0008
0015
0009
0005
6
Not for
Reproduction
80025908_EN Rev A
Briggs & Stratton warrants that, during the warranty period specified below, it will repair or replace, free of charge, any part that is defective in material or workmanship
or both.Transportation charges on product submitted for repair or replacement under this warranty must be borne by purchaser.This warranty is effective for and is
subject to the time periods and conditions stated below. For warranty service, find the nearest Authorized Service Dealer in our dealer locator map at www.snapper.
com.The purchaser must contact the Authorized Service Dealer, and then make the product available to the Authorized Service Dealer for inspection and testing.
.
Some states or countries do not allow limitations on how long an implied warranty lasts, and some states or countries do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation and exclusion may not apply to you. This warranty gives you specific legal rights and you may also have
other rights which vary from state to state or country to country.**
** In Australia - Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable loss or damage.You are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a major failure. For warranty service, find the nearest Authorized Service Dealer in our dealer locator map at
BRIGGSandSTRATTON.COM, or by calling 1300 274 447, or by emailing or writing to salesenquir[email protected], Briggs & Stratton Australia Pty Ltd, 1
Moorebank Avenue, NSW, Australia, 2170.
The warranty period begins on the date of purchase by the first retail or commercial consumer. “Consumer use” means personal residential household use by a retail
consumer. “Commercial use” means all other uses, including use for commercial, income producing or rental purposes. Once a product has experienced commercial use, it
shall thereafter be considered as a commercial use product for purposes of this warranty.
To ensure prompt and complete warranty coverage, register your product on-line at www.onlineproductregistration.com.
Save your proof of purchase receipt. If you do not provide proof of the initial purchase date at the time warranty service is requested, the manufacturing date of the product
will be used to determine the warranty period. Product registration is not required to obtain warranty service on Briggs & Stratton products.
Warranty service is available only through Snapper Authorized Service Dealers.This warranty covers only defects in materials or workmanship. It does not cover damage
caused by improper use or abuse, improper maintenance or repair, or normal wear and tear.
- The proper, intended use of this product is described in the Operator’s Manual. Using the product in a way not described in the Operator’s
Manual or using the product after it has been damaged will not be covered under this warranty. Warranty coverage will also not be provided if the serial number on the
product has been removed or the product has been altered or modified in any way, or if the product has evidence of abuse such as impact damage or water/chemical
corrosion damage.
Improper Maintenance or Repair - This product must be maintained according to the procedures and schedules provided in the Operator’s Manual, and serviced or
repaired using genuine Briggs & Stratton parts or equivalent. Damage caused by lack of maintenance or use of non-original parts is not covered by warranty.
Normal Wear and Tear - Like most mechanical devices, your unit is subject to wear even when properly maintained.This warranty does not cover repairs when normal
use has exhausted the life of a part or the equipment. Maintenance and wear items such as filters, belts, cutting blades, and brake pads (except engine brake pads) are not
covered by warranty due to wear characteristics alone, unless the cause is due to defects in material or workmanship.
This warranty excludes damage due to accident, abuse, modifications, alterations, improper servicing, freezing or chemical deterioration. Attachments
or accessories that were not originally packaged with the product are also excluded.This warranty does not include used, reconditioned, second-hand, or demonstration
equipment or engines.This warranty also excludes failures due to acts of God and other force majeure events beyond the manufacturer’s control.
Item Consumer Use Commercial Use
Accessory/Attachment/Equipment 36 months None
en
7
Not for
Reproduction
ar
OFFON
1550
1550
3
Not for
Reproduction
50
15
1550
4
4
4
5
5
6
7
.www.P65Warnings.ca.gov
2
Not for
Reproduction
ar
10
10
5
Not for
Reproduction
OFFON
1550
1550
4
Not for
Reproduction
80025908_AR Rev A
.
**
**
.
.
36
ar
6
Not for
Reproduction
00017710101 0005840034171 00081 00091 0011M54 00124 00134 0014840034181 0015840034191 0017M52 00184 00194 00204
00211 00307710073 00407710111
0018
0017
0001
Reference Only
0040
0021
0019
0020
0030
0011
0012
0013
0014
0008
0015
0009
0005
7
Not for
Reproduction
....................... 2
................ 2
......................... 4
................................... 4
.............................. 4
.................. 5
5
........................... 6
................................ 7
ЛЯВОДЯСНО
ЗАБЕЛЕЖКА
2
Not for
Reproduction
•
bg
3
Not for
Reproduction
123
4
Not for
Reproduction
• •
•
• • •
•
• •
bg
5
Not for
Reproduction
0001 771010 1
0005 84003417 1
0008 ----- 1
0009 ----- 1
0011 ----- 4
0012 ----- 4
0013 ----- 4
0014 84003418 1
0015 84003419 1
0017 ----- 2
0018 ----- 4
0019 ----- 4
0020 ----- 4
0021 ----- 1
0030 771007 3
0040 771011 1
0018
0017
0001
Reference Only
0040
0021
0019
0020
0030
0011
0012
0013
0014
0008
0015
0009
0005
6
Not for
Reproduction
80025908_BG Rev A
.
.**
**
NSW, Australia, 2170.
bg
7
Not for
Reproduction
stop) mezi jednotkou a elektrickým
stroje.
sluchu.
násady.
...................... 2
....................... 2
.............................. 4
................................. 4
............................... 4
................................... 5
.......................... 5
.......................... 6
................................... 7
LEVÁ a
PRAVÁ jsou zobrazeny z pozice obsluhy.
Veškeré jazykové verze tohoto dokumentu jsou odvozeny z
Tento návod
POZOR
UPOZORNĚNÍ ukazuje na situaci, která by mohla vést k
P65Warnings.ca.gov.
2
Table of contents
Languages:
Other Briggs & Stratton Trimmer manuals
Popular Trimmer manuals by other brands
Makita
Makita UR012G instruction manual
Weed Eater
Weed Eater TE 400 LE instruction manual
Yard Machines
Yard Machines MTD25P Service spare parts list
Bosch
Bosch Universal Hedge Cut 18V-50 Original instructions
Black & Decker
Black & Decker STC1820E user manual
Gardena
Gardena HighCut 48-Li 8882 operating instructions
