Briggs & Stratton 073003-1 Setup guide

073003-1
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON, WISCONSIN, U.S.A.
Manual No. 197988D Revision D (04/24/2007)
Illustrated Parts List
Questions? Help is just a moment away!
Vous avez des questions? Vous n'avez pas besoin d'aller
loin pour trouver de l'aide!
Preguntas? La ayuda es justa un momento lejos!
Call: Helpline
Appelez: Ligne d'assistance
Llame: Línea Directa
1-800-743-4115 M-F 8-5 CT
BRIGGSandSTRATTON.COM

2
EXPLODED VIEW
EXPLODED VIEW – MAIN UNIT
Copyright © 2007 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be
reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power
Products Group, LLC.

3
PARTS LIST
Item Part # Description
1 865159GS CRADLE
3 197755GS VALVE, Check
4 198678GS FLANGE, Inlet, 3" NPT
5 198057GS ASSY, Plug
6 * WASHER, Flat, 3/8 M10
7 * HHCS, M10 - 1.5 x 20
8 * HHCS, M10 - 1.5 x 25
9 * WASHER, Lock M10
10 197753GS HOUSING, Pump
11 197759GS GASKET, Out
12 198155GS ASSY, Plug
13 198675GS FLANGE, Out, 3" NPT
14 197748GS VOLUTE, 3"
15 198048GS ASSY, Fastener
16 197739GS ADAPTER, Engine
17 197765GS GASKET, 3"
A 199537GS ASSY, Housing Pump
B 198156GS KIT, Impeller
C 197887GS KIT, Vibration Mount
D 200293GS KIT, Coupler 3" NPT
E 198158GS KIT, Seal
Parts Not Illustrated
197988GS MANUAL, Operator’s
100005 BOTTLE, Oil
198302GS DECAL, Recoil
198301GS DECAL, Air Cleaner
198296GS DECAL, Fuel Tank
198303GS DECAL, Caution
198305GS LABEL, Warning
§ ENGINE
Engine Mounting Hardware Not Illustrated
* HHCS, M8 - 1.25 X 30
* WASHER, Flat, 5/16 - M8
* NUT, Hex, M8 - 1.25
* WASHER, Lock, 5/16 M8
* - Items without part numbers are common fasteners and can be found at your local hardware store.
§ - Contact Engine Manufacturer
PARTS LIST – MAIN UNIT
