Briggs & Stratton 73005 Setup guide

Model No. 073005 WP1-1.0 Water Pump Manual No. 202064A Revision - (03/06/2007)
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON, WISCONSIN, U.S.A.
Questions? Help is just a moment away!
Call: Pressure Washer Helpline
1-800-743-4115 M-F 8-5 CT
Illustrated Parts List

2BRIGGSandSTRATTON.COM
Copyright © 2007 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be
reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power
Products Group, LLC.
EXPLODED VIEW – MAIN UNIT
EXPLODED VIEW

3
PARTS LIST – MAIN UNIT
Item Part # Description
A 197648GS KIT, Pump
B 197649GS KIT, Acc Micro Pump
1 B197461GS BASE, Pump
2 197169GS PLATE, Seal, Pump
3 197545GS SHAFT, Pump
4 51713GS WASHER, M5
5 197800GS NUT, Hex M5 - 0.8 w/ Locking Insert
6 197574GS SCREW, Plastite #10 - 14 x 1.0
7 197546GS MOUNT, Vibration
8 66476GS HHCS, M6 - 1.0 x 12 w/ LW
9 197605GS CAP, Mounting
10 197606GS THROTTLE, Capro
11 197653GS ADAPTER
12 194561GS HHS, Trilobular, #10-32 x 3/8
13 202227GS FITTING, Hose, 1/2
14 202228GS FITTING, Hose, 3/4
900 § ENGINE
Parts Not Illustrated
202064GS MANUAL, Operator’s
MS3287 MANUAL, Engine
198290GS LABEL, Pump
202010GS LABEL, Warning
202012GS DECAL, Caution, Prime Pump
695877 BEARING, Ball
198425GS HOSE, Intake
100091 MICRO OIL
282751 CUP, Oil Fill
202011GS LABEL, Start Instructions
NOTE: Item letters A - B are service kits and include all parts shown within the box.
§ - Contact Engine Manufacturer
