AC0101
Illustrated Parts List
Model Series
AC0101
2” Water Pump

AC0101
5436–2 Assemblies include all parts shown in frames. 02/04/2004
2
813
813
5009
5003
5004
5005
5006
5007
5008
1058 OWNER’S MANUAL
5012
5011
5000
1059
5010
5002
5014 PUMP OVERHAUL KIT
1117
5013
For Engine Service Information,
Contact Engine Manufacturer.
Non–Serviced Part
Non–Serviced Part
Non–Serviced Part
5015
5015

AC0101
5436–3 Assemblies include all parts shown in frames. 02/04/2004
3
813 865110 Clamp
1058 MS5234 Owner’s Manual
Used on Type No(s).
0001, 0002, 0003.
––––––– Note –––––
MS5238 Owner’s
Manual
Used on Type No(s).
0005.
1059 865112 Kit–Screw/Washer
(Flange to Crankcase
Cover)
1117 865147 Screw
(Engine Mount)
5000 865085 Pump–Water 2” Outlet
5002 865089 Foot–Rubber
Used on Type No(s).
0001.
5003 865087 Bracket–Flange
5004 865090 Impeller
5005 865092 Volute
5006 865094 Flange–Inlet
5007 865096 Drain–Water
5008 865098 Flange–Outlet
5009 865100 Strainer–Water
5010 865102 Coupling–Water
5011 865104 Screw
(Inlet Flange)
5012 865106 Screw
(Outlet Flange)
5013 865108 Kit–Screw/Nut
(Pump Housing to
Flange)
5014 865114 Kit–Pump Overhaul
5015 865148 Seal–Impeller
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
