Brildor SC-1.1 User manual

Page 1 | 9
User manual
Shin Pad
Heat Press Machine
Brildor SC-1.1
Ref. 045087

2
CONTENTS
I. INTRODUCTION ............................................................................................................................................3
II. PARTS OF THE PRESS ..................................................................................................................................3
III. TECHNICAL DETAILS ...................................................................................................................................4
IV. DIMENSIONS...................................................................................................................................................4
V. CONTROL PANEL OPERATION..............................................................................................................5
Temperature.......................................................................................................................................5
Time.........................................................................................................................................................5
VI. INSTRUCTIONS FOR USE..........................................................................................................................6
Recommended sublimation parameters ...........................................................................6
VII. TROUBLESHOOTING ..................................................................................................................................7

3
INTRODUCTION
This heat press machine has been specially designed for personalisation using dye
sublimation printing. Thanks to its pressure, heat and time control, the transfer will be
permanently embedded in the shin pad.
•Manual opening and closing. The shin pad heat press has a swivel arm that opens
to the left.
•Lower platen dimensions: 19.5 x 20.5 x 8 cm
PARTS OF THE PRESS
1. Digital controller
2. Ergonomic handle
3. Upper platen
4. Swivel arm that opens to the left
5. ON/OFF switch
6. Lower platen
7. Sensor (automatic timer)

4
TECHNICAL DETAILS
Model
Brildor SC-1.1 Shin Pad Heat Press Machine
Type
Manual/Swing Away
Controller
Digital
Pad thickness
0.8 cm
Side opening angle
180º
Voltage
220 V / 50 Hz
Power
450 W / 2 A
Timer
0-9999 s
Temperature range
0-221ºC
Temperature accuracy
±2ºC
Time before Sleep Mode
30 min
DIMENSIONS
Closed in its starting position
31 x 51 x 37 cm
Closed with legs extended
45 x 51 x 37 cm
With the upper platen to the
side
47 x 53 x 37 cm
Lower platen
19.5 x 20.5 x 8 cm
Upper platen
24 x 22.5 x 8 cm
Swivel arm
24 x 38 cm
LCD digital display
13.5 x 14 x 12.5 cm
Handle
11.5 x 10.5 x 2.3 cm
Power cable
151.5 cm
Packaging
46.5 x 43 x 34.5 cm
Net weight
10 kg

5
CONTROL PANEL OPERATION
Temperature
Press the OK button The screen shows P-1
Press the arrows or
and set the temperature
you need
Time
Press the OK button after
selecting the temperature
setting.
Press on the arrows or
and set up the time.
Press the OK button
again after setting up
the timer.

6
INSTRUCTIONS FOR USE
1. Make sure the plug is securely connected
to the power socket, and press the power switch.
2. Set the temperature and time. You can use the
tables above as a reference.
3. The press will notify you when the set temperature
has been reached.
4. Hold the paper's printed side against the shin pad and fix it
with heat-resistant tape.
Place protective paper on the press’ lower platen and the
shin pad on top.
5. Turn the pressure knob to obtain the right pressure.
6. Press down on the handle. The sound will stop and
the sublimation will start
5. The alarm will go off again as soon as the
time is up. Lift the handle and remove the
newly printed shin pad.
Recommended sublimation parameters
MATERIAL
PRESSING TIME
TEMPERATURE
PRESSURE
INK AND
PAPER*
Plastic shin
pads 170 s - 205 s 180 ºC – 185 ºC
Medium -
Heavy
Special for
sublimation
*We recommend using sublimation paper with a grammage of 120 gsm. DO NOT
use adhesive paper.

7
THINGS TO KEEP IN MIND
•When the temperature of the heat platen reaches 80ºC
(176ºF), the extractor fan will turn on automatically. This helps to
keep electrical parts cool and extends their useful life.
•Turn off the machine when it’s not in use and remove the plug from the
power socket.
•The heating platen will automatically cool down if the
press remains idle for more than 30
minutes.
•Different items will require different
temperature and time settings
because their materials and thickness
will differ.
•This press should not be used by
children or for food processing.
TROUBLESHOOTING
The machine isn’t responding:
•Check if the plug is properly connected or if it’s broken.
•Check if the fuse is blown.
•Check if the power switch or the digital controller are broken.
The power light is on, but the display is black:
•Check the cable of the transformer. The connection will be low if the wires are
a little loose. Tighten them.
•If the cable is connected properly, the transformer may be defective. Fix it.
The display is working well, but the press is not heating up:
•Check if the relay indicator light is on, otherwise check if the relay or the digital
controller are broken.

8
•If the heating platen isn't working, and the relay has already been replaced,
check if the heating plate is defective or if the power cable is loose. If the
heating plate is defective, you should change it.
The temperature is higher than expected:
•The relay may be broken, you should change it.
•The digital controller may be defective, you should change it.
The colour of the print is pale or faded:
•The pressure isn’t high enough, the temperature is too low or the transfer time is
too short. Adjust the pressure, temperature or increase heating time.
The colour of the print is too dark or blurred:
•The temperature is too high or the transfer time is too long. Adjust the
temperature or reduce heating time.
The colour of the print is different or the result isn’t right:
•The transfer time is too short or the paper used is of poor quality. Increase
heating time or use high-quality transfer paper.
The transfer paper sticks to the object after the transfer:
•The temperature is too high or the paper used is of poor quality. Adjust the
temperature or use high-quality transfer paper.
