USER MANUAL
COMBO
HEAT
PRESS
MACHINE
The user manual is universal for all heater combo versions and is
suitable for all colors of machines.
brildor.com
brildor.com

1 2
Combo Heat Press MachineCombo Heat Press Machine
71.5 cm
66 cm
COMBO HEAT PRESS MACHINE
Power 1000W MAX±5%
Voltage 220V / 110V 50~60Hz
Temp. Range 0-482 ℉ (0-250℃ )
Time Range 0-999 seconds
KNOW THE MACHINE
4
7
3
2
6
5
1Pressure Knob
5Digital Control Meter
7Heating Platen
2Pressure Handle
6Control Box
3Silicone Pad
8Power Switch
4Slide-Out Drawer Handle
41 cm
31.5 cm 48 cm
8
1
brildor.com

3 4
Combo Heat Press MachineCombo Heat Press Machine
COMBO
Flat Heat Press
Cap Heat Press Mug/Tumbler Heat Press
Plate Heat Press
Pen Heat Press
Hip Flask Heat Press
HEATING ATTACHMENTS AVAILABLE
CEHBPJ-JB
30oz Mug/Tumbler Press
Attachment
CEHBPJ-KM
Cap Heater
CEHBPJ-KP8
Plate Heater
Size: 8 in
CEHBPJ-KP10
Plate Heater
Size: 10 in
CEHBPJ-KB
Pen Heater
CEHBPJ-B2330
Heating Board
Size: 20*30cm
CEHBPJ-B1520
Heating Board
Size: 15*20cm
CEHBPJ-KH
Hip Flask Heater
brildor.com

5 6
Combo Heat Press MachineCombo Heat Press Machine
KNOW THE CONTROL PANEL
Time
Setting
Heating
Light flashing when is heating
Time
Minus Plus
Number of Uses
Temperature Unit Switch
Temperature
Setting
Start/Stop
HOW TO USE THE CONTROL PANEL?
Click the button to switch
between ℃ and ℉
2. How to clear the number of uses?
Long press the Time
button for 8 seconds to
clear the number of uses
1. How to switch between ℉ and ℃ ?
brildor.com

7 8
Combo Heat Press MachineCombo Heat Press Machine
3. How to set the time?
4. How to set the temperature?
1. Click the Time
button to enter
time setting mode;
1. Click the Temperature
button to enter
temperature setting
mode;
3. Click the Time
button again, exit
time setting mode.
3. Click the Temperature
button again, exit
temperature setting
mode.
2. Click the Plus or
Minus button to
adjust the value;
2. Click the Plus or
Minus button to
adjust the value;
5. Start printing
6. Temperature compensation
1. Click the Start button to start the
countdown;
2. Press down the handle also can start
the countdown automatically;
3. Click the Start button again at any
time to stop the countdown.
If the actual temperature of the heater does not match the value displayed on the screen,
the temperature compensation value needs to be adjusted.
Enter the exact temperature difference value to be made up. For example, if the actual temperature is
190℃ while the value displayed is 180℃ , then enter 10 as temperature difference value.
1. Long press the Start button for 8
seconds to enter the temperature
compensation settings;
3. Long press the Start button
for 8 seconds again to exit the
temperature compensation settings.
2. Click the Plus or
Minus button to
adjust the value;
brildor.com

9 10
Combo Heat Press MachineCombo Heat Press Machine
7. Restore default values
After pressing the Start button for 8 seconds to enter the temperature compensation settings, click the Start
button to switch to the settings page for the other 3 values, which we normally do not need to change. If
you have accidentally changed the values, you can adjust them back to the default values according to the
diagram below.
1. Long press the Start button for 8
seconds to enter the temperature
compensation settings;
The default temp.
difference value is 0;
2. Click the Start
button to switch
the screen;
3. Click the Plus or
Minus button to
adjust the value;
4. Long press the Start button
for 8 seconds again to exit the
temperature compensation settings.
The default power
parameter is 16;The default current parameter is 100;The default time interval is 3.
HOW TO PRINT A T-SHIRT?
8Remove the image as it
cools down; check the
amazing printout result.
4Adjust the printing pressure;1Put a piece of protective paper
on the silicon pad so that the
inks won't ruin the silicon pad
and the printed items;
2Fix the image on the T-shirt
with heat-resistant tape; 3Slide out the drawer, put
the item on the protective
paper and cover the item with
another piece of protective
paper;
5Turn on the machine; set
printing time and temperature,
and wait for the machine to
heat up;
6When the machine heats
up to the set temperature,
press down the handle, and
the machine will start the
countdown automatically;
7After the countdown, the
machine will beep a sound and
then lift up the handle;
brildor.com

11 12
Combo Heat Press MachineCombo Heat Press Machine
HOW TO PRINT A TUMBLER?
1
5
2
6
3
7
4
8
Fix the image on the tumbler
with heat-resistant tape; Set the printing time and temperature;
Adjust the printing pressure;
Press down the handle, and
the machine will start the
countdown automatically;
As the machine heats up to
the set temperature, put the
tumbler into the attachment;
After the countdown, lift up
the handle;
Turn on the machine;
Check the amazing printout
result!
1Turn off the machine;
HOW TO INSTALL THE MUG/TUMBLER PRESS ATTACHMENT?
2Slide out the drawer for convenient
operation; 3Unplug the connect cable connected to the heating platen ;
5The installation is complete!4Plug in the connect cable connected to
the mug/tumbler heat press;
brildor.com

13 14
Combo Heat Press MachineCombo Heat Press Machine
HOW TO INSTALL THE PLATE HEATER? HOW TO PRINT A PLATE?
1
5
2
6
3
7
4
8
Fix the image on the plate with
heat-resistant tape; Set the printing time and temperature;
Adjust the printing pressure;
Press down the handle, and
the machine will start the
countdown automatically;
As the machine heats up to the
set temperature, put the plate
on the attachment;
After the countdown, lift up
the handle;
Turn on the machine;
Check the amazing printout
result!
Remove the heating platen and install the
plate heater;
4Secure the plate heater with screws;5
Remove the screws from the heating
platen;
3
6Plug in the connect cable, and the
installation is complete!
1Turn off the machine; 2Unplug the connect cable
connected to the heating platen;
brildor.com

15 16
Combo Heat Press MachineCombo Heat Press Machine
HOW TO PRINT A HIP FLASK?
1Fix the image on the hip flask
with heat-resistant tape; 4Set the printing time and temperature;
2Adjust the printing pressure;
6Press down the handle, and
the machine will start the
countdown automatically;
5As the machine heats up to the
set temperature, put the hip
flask on the attachment;
7After the countdown, lift up
the handle;
3Turn on the machine;
8Check the amazing printout
result!
HOW TO INSTALL THE HIP FLASK HEATER?
Secure the bottom with screws;4Secure the hip flask heater with
screws;
5
Remove the screws from the board;3
6Plug in the connect cable, and the
installation is complete!
1Turn off the machine; 2Remove the heating platen;
brildor.com

17 18
Combo Heat Press MachineCombo Heat Press Machine
HOW TO PRINT A CAP?
1Fix the image on the cap with
heat-resistant tape; 4Turn on the machine;2Place the cap on the pad and secure the cap with the
holding device；
6As the machine heats up to the
set temperature, press down
the handle, and the machine
will start the countdown
automatically;
5Set the printing time and
temperature; 7After the countdown, lift up the handle;
3Adjust the printing pressure;
8Check the amazing printout
result!
HOW TO INSTALL THE CAP HEATER?
Secure the cap heater with screws;4Plug in the connect cable;5
Secure the bottom with screws;3
6The installation is complete!
1Turn off the machine; 2Remove the heating platen;
brildor.com

19 20
Combo Heat Press MachineCombo Heat Press Machine
HOW TO PRINT A PEN?
1Fix the image on the pen with
heat-resistant tape; 4Turn on the machine;2Put the pen on the machine, lined up neatly with the print
side facing up;
6As the machine heats up
to the set temperature,
press down the handle, and
the machine will start the
countdown automatically;
5Set the printing time and
temperature; 7After the countdown, lift up the handle;
3Adjust the printing pressure;
8Check the amazing printout
result!
HOW TO INSTALL THE PEN HEATER ？
Secure the pen heater with screws;
4Plug in the connect cable;5
Secure the bottom with screws;3
6The installation is complete!
1Turn off the machine; 2Remove the heating platen;
brildor.com

21 22
Combo Heat Press MachineCombo Heat Press Machine
PRINTING PARAMETERS
Product
Product
Name T-shirt Pillow Cover Photo Slate MDF Plaque Glass Cutting Board Aluminium
Ornament
Temperature 374 ℉ 374 ℉ 374 ℉ 356 ℉ 356 ℉ 356 ℉
Time 60 s 60 s 600 s 150 s 300 s 50 s
Product
Product
Name Shopping Bag Pen Hip Flask Plate Cap Stainless Steel
Tumbler
Temperature 374 ℉ 428 ℉ 356 ℉ 356 ℉ 356 ℉ 356 ℉
Time 60 s 420 s 60 s 220 s 80 s 60 s
1. All the data above are our Combo Heat Press
only.
2. All the data above are based on the test results
of our sublimation blanks and for reference
only. Please test your own products and find
the proper parameters.
Note Safety Instructions
1. Don’t touch the heating platen and the silicone pad
when the machine is heating up or is still very hot.
2. This machine is not intended for use by children.
FAQS:
Colors are lighter The temperature is too low, the pressure is uneven, or the time is too short.
Printed picture is vague The printing time is long, which causes the ink spread.
Colors are less bright The pressure is too high or the temperature is too high.
Printed picture is partially vague The heat is uneven.
Colors are different The pressure is uneven or the surface of the printed item is uneven.
The paper sticks on the printed item The temperature is too high or the coating of the item is in poor quality.
