BRINKMAN Mini-Q-Beam System manual

OWNER’S MANUAL &
OPERATING INSTRUCTIONS
®
Halogen Spotlight
WARNING
READ AND FOLLOW ALL WARNINGS
AND INSTRUCTIONS IN THIS
MANUAL TO AVOID PERSONAL
INJURY OR PROPERTY DAMAGE.

• Never place spotlight lens (face) down when light is on or is still hot from recent use. Doing so could burn or ignite
surfaces such as seats, carpeting, etc.and cause major property damage.Always turn spotlight off and disconnect
from power source when not in use.
• To prevent serious damage to eyesight, never look into spotlight when light is on. Do not shine light into the face of
someone else.
• Do not touch lens of spotlight when light is on or if it was recently on.The lens will be hot and could cause serious
burns.
• Do not place spotlight in water. Keep all components dry and out of water at all times.
• Keep cigarette lighter plug dry and out of water at all times.
• Do not allow children to handle or operate this spotlight.
• Do not use this product for other than its intended use.
• Do not operate in close proximity of combustible or flammable materials.
• Do not attempt to operate spotlight if cord, plug,bulb or any part of the spotlight is damaged or corroded.
• Only use DC lighter plug that is provided with the Mini-Q-Beam®spotlight or its replacement.
• Do not dispose of batteries in fire as this may result in explosion.
• Batteries must be recycled or disposed of properly. Contact your local county solid waste authority for proper
recycling or disposal information.
USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR SPOTLIGHT.
FAILURE TO ADHERE TO THE SAFETY WARNINGS AND GUIDELINES IN THIS MANUAL
COULD RESULT IN BODILY INJURY OR PROPERTY DAMAGE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
IMPORTANT SAFETY WARNINGS
READ AND FOLLOW ALL SAFETY WARNINGS AND INSTRUCTIONS IN THE OWNER’S MANUAL
BEFORE OPERATING SPOTLIGHT.
WARNING
1

OPERATING INSTRUCTIONS
READ AND FOLLOW ALL SAFETY WARNINGS AND INSTRUCTIONS IN THE OWNER’S MANUAL
BEFORE OPERATING SPOTLIGHT.
Inspect contents of the box to ensure all parts are included and undamaged.
The Mini-Q-Beam®spotlight operates from 4 D size batteries or from a
12-volt DC lighter plug.
Mini-Q-Beam Using 4 D Size Batteries (Cordless Mode): Always use
alkaline batteries for maximum brightness and longer run times.
Step 1: Follow instructions under“To Replace Batteries” on page 4.
Step 2: Depress trigger switch in handle to turn spotlight ON.
Step 3: Release trigger switch to turn spotlight OFF.
WARNING: Never place spotlight lens (face) down when light is on or is
still hot from recent use. Doing so could burn or ignite surfaces
such as seats, carpeting, etc. and cause major property
damage.Always turn spotlight off and disconnect from
power source when not in use.
Parts List
1Mini-Q-Beam®spotlight
212-volt DC lighter plug
Owner’s Manual
1
2
To Operate
ON/OFF
Trigger
Switch
Lock Button
2

Mini-Q-Beam Using 12-Volt DC Lighter Plug: When using the 12-volt DC
lighter plug, batteries may be left in or taken out of the spotlight.
Step 1: Plug the 12-volt DC lighter plug into the socket located on the
back of the spotlight as shown in Illustration 1.
Step 2: Plug the other end of the 12-volt DC lighter plug into a cigarette
lighter plug for power.
Step 3: Depress trigger switch in handle to turn spotlight ON.
Step 4: Release trigger switch to turn spotlight OFF.
To Operate (continued)
Illustration 1
Continuous Beam Using Lock Button:
Step 1: For a continuous beam,depress trigger switch and push the lock
button to the LOCKED position as shown in Illustration 2.
Step 2: To unlock and turn spotlight OFF, push the lock button to the
UNLOCKED position as shown in Illustration 3.
NOTE: To lock the Mini-Q-Beam in the OFF position, release trigger switch,then
push the lock button to the LOCKED position as shown in Illustration 2.
Illustration 2 Illustration 3
3
12-volt DC lighter
plug socket
Locked
position Unlocked position
12-volt DC
lighter plug

To Replace Batteries
To Replace Bulb
Always use alkaline batteries for maximum brightness and longer
run times.
Step 1: With spotlight facing up, turn head assembly counter-clockwise
and remove.The reflector, bulb and battery plate will be
attached to the head assembly.
Step 2: Remove old batteries and replace with new 4 D size alkaline
batteries.
Step 3: Place the batteries in the compartment in the following
configuration -
++
-(negative side up, positive side up
& positive side up, negative side up) as shown in Illustration 4.
Step 4: Replace the head assembly by aligning the grooves on each
side of the battery plate with the grooves on the insides of the
spotlight.
Step 5: Turn head assembly clockwise until secure.
Only use Brinkmann halogen bulb that is designed for the Mini-Q-Beam
spotlight as a replacement. Use of any other bulb may result in poor
performance and may damage your spotlight.
Step 1: With spotlight facing up, turn head assembly counter-clockwise
and remove.The reflector, bulb and battery plate will be
attached to the head assembly.
Step 2: Firmly grip the battery plate and gently pull way from the head
and reflector.
Step 3: Remove old bulb from bulb holder in center of the battery plate.
Replace with new bulb.
Step 4: Gently press the head and reflector onto the battery plate
to re-attach.
Step 5: Replace the head assembly by aligning the grooves on each
side of the battery plate with the grooves on the insides of the
spotlight.
Step 6: Turn head assembly clockwise until secure.
Head
Assembly
Battery
Plate
Reflector
Bulb
Battery Plate
Illustration 4
Illustration 5
4

The retractable hanging ring allows spotlight to hang while in use or
during storage.
The built-in tripod socket allows spotlight to be mounted on most camera
tripods for hands-free use.
by BRINKMANN
Tips to Avoid Damage to Your
Mini-Q-Beam Spotlight
To Mount Mini-Q-Beam
On a Tripod
To Hang/Store Mini-Q-Beam
5
• Never attempt to wipe or clean the inner reflective surface of the reflector.
Touching or wiping the surface will damage it permanently.
• The lens is made of optical-quality plastic.Avoid dropping or sharp impact
on spotlight to prevent damage.
• Do not allow hot lens to come in contact with water or materials subject to
heat damage.
• The spotlight is weather resistant. It is not waterproof. Do not use the
spotlight under water or store outdoors.
• Use only Brinkmann halogen bulb that is designed for your
Mini-Q-Beam spotlight. Use of any other bulb may result in poor
performance and may damage your spotlight.
• After months of use, cigarette lighters can build up corrosion that may
prevent the DC lighter plug from making good contact. It may be necessary
to clean the inside of your cigarette lighter receptacle with a fine emery
cloth.Before cleaning receptacle, remove the fuse to prevent it from
shorting out.
Hanging
Ring
Tripod Socket

6
MINI-Q-BEAM ACCESSORIES
Rechargeable Battery Pack with
Carrying Case
12-volt rechargeable battery pack adds total mobility to your
Mini-Q-Beam. Includes cigarette lighter receptacle,120-volt
charging transformer and a heavy-duty, woven nylon carrying
case with shoulder strap.
Model 802-1724-1 Black
Model 802-1725-1 Green Camo
Lighter Plug
Extension Cord
Features a 15-ft.cord with a
cigarette lighter plug and
receptacle.
Model 802-1706-0
Mini-Q-Beam
12-Volt DC Lighter Plug
Original replacement DC
lighter plug for
Mini-Q-Beam
spotlight.
Model 110-1800-0
Replacement Bulb For
Mini-Q-Beam
Original replacement halogen bulb for
Mini-Q-Beam spotlight.
Model 802-1744-0
Mini-Q-Beam Replacement Lens
Original replacement lens for
Mini-Q-Beam spotlight.
Model 500-1800-0
Pigtail Adapters
Pigtail adapter with battery terminal clips allow
Mini-Q-Beam spotlights with DC lighter plug to operate
from a 12-volt battery.
Model 802-1704-0 (2-Ft. Cord)
Model 802-1705-0 (10-Ft. Cord)
LOOK FOR THESE ACCESSORIES AT YOUR LOCAL DEALER
WHERE MINI-Q-BEAM IS SOLD, OR ORDER DIRECT
BY CALLING 1-800-468-5252.

For 1-year from date of purchase,The Brinkmann Corporation warrants the Mini-Q-Beam®spotlight against defects due to
workmanship or materials to the original purchaser.The Brinkmann Corporation’s obligations under this warranty are limited to the
following guidelines:
• This warranty does not extend to the bulb or batteries.
• This warranty does not cover spotlights that have been altered or damaged due to: normal wear, abuse, improper maintenance,
improper use, disassembly of parts and/or attempted repair by anyone other than an authorized employee of The Brinkmann
Corporation.
• This warranty does not cover surface scratches or weathering as this is considered normal wear.
• Warranty service is limited to repair or replacement of spotlights which prove defective under normal use and which upon
examination shall indicate to Brinkmann’s satisfaction, they are defective.If Brinkmann confirms the defect and approves the
claim,Brinkmann will elect to repair or replace the spotlight as covered by the terms of this warranty.
• This warranty extends to the original purchaser only and is not transferable or assignable to subsequent purchasers.
The Brinkmann Corporation requires reasonable proof of purchase. Therefore, we strongly recommend that you retain your sales
receipt or invoice. To obtain repair or replacement of your Mini-Q-Beam®spotlight under the terms of this warranty, please call
Customer Service Department at 1-800-527-0717 for a Return Authorization Number and further instructions. A receipt will be
required. A Return Authorization Number must be clearly marked on the outside of the box. Spotlights returned to Brinkmann
must include your name,address and telephone number. Please make sure the light is properly packed, postage prepaid,and
insured.The Brinkmann Corporation will not be responsible for any spotlights forwarded to us without a Return Authorization
Number.
EXCEPT AS ABOVE STATED,THE BRINKMANN CORPORATION MAKES NO OTHER EXPRESS WARRANTY.
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FORA PARTICULAR PURPOSEARE LIMITED IN DURATION TO 1-YEAR
FROM THE DATE OF PURCHASE. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIEDWARRANTY LASTS,SO THE
ABOVE LIMITATION MAY NOT APPLY TO YOU.
ANY LIABILITY FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE FAILURE OF THE
MINI-Q-BEAM®SPOTLIGHT TO COMPLY WITH THIS WARRANTY OR ANY IMPLIED WARRANTY IS EXCLUDED. CUSTOMER
ACKNOWLEDGES THAT THE PURCHASE PRICE CHARGED IS BASED UPON THE LIMITATIONS CONTAINED IN THE WARRANTY SET OUT
ABOVE. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.THIS WARRANTY GIVESYOU SPECIFIC LEGAL RIGHTS,AND YOU MAY
ALSO HAVE OTHER RIGHTSWHICH VARY FROM STATE TO STATE.
1-YEAR LIMITED WARRANTY
140-1800-0
4/99, 12/01 For Model 800-1800-0
