BRITISH BERKEFELD SS Gravity User manual

SS Gravity
Drinking Water Filter
Assembly, Operating and Maintenance Instruction
The SS Drinking Water Filter:
• is designed to be free standing on a stable surface
• can be fitted with 2, 3 or 4 ceramic filter elements
Note: the number of elements supplied will depend on the type of filter purchased
• should only be used for the treatment of cold water
• is designed to filter out harmful bacteria from water
Extreme cleanliness is important. Wear rubber gloves or wash hands
thoroughly before and after handling the product and take care to
ensure that no contamination of the components occurs during
assembly and cleaning.
Tap Assembly:
Remove the plastic nut. Moisten both rubber washers with clean water
Place one washer over the threaded part of the tap and then insert the threaded part
through the hole in the side of the bottom chamber as illustrated
Replace the second rubber washer onto the thread protruding through to the inside of
the bottom chamber and secure the tap in place with the nut. To achieve a tighter seal,
hold the outlet tap until the nut is hand tight. Then hold the nut and tighten the assembly
by rotating the tap body through at least a quarter turn to reach the upright position
Ceramic Filter Assembly:
Fit the knob onto the lid by inserting the screw up through the hole in the lid and
screwing on the knob, hand tighten only
Remove all protective packaging from the filter elements
Place a sealing washer over each filter element mount stem
Place the filter element mount stem through the holes in the base of the top chamber
Secure each filter element in place by screwing a wing nut onto the threaded stem
protruding through the holes
Put the top chamber onto the bottom chamber and place the lid in position
Filter Operation:
Ensure the outlet tap is in the “off” position
Fill the top chamber with water and replace the lid
Leave to allow the water to filter through the ceramic filter elements and collect in
the bottom chamber, from where it can be accessed via the tap. The maximum flow
rate will be achieved once the ceramic filter elements have become fully saturated -
usually after filtering of 2-3 full chambers of water
It is recommended that this first supply of filtered water is thrown away, as it may
contain loose material washed from the filter elements
The filter is now ready for use
The top chamber can be replenished with more water as required
Ceramic Filter Cleaning:
Due to filtration of particulate contaminants from the water during use, the flow of
the water from the filter may reduce over a period of time, depending on the quality
of the water. To restore the water flow to its normal level, simply clean the filter
elements as follows:
Remove the elements from the top chamber by unscrewing the wing nuts
Hold the filter elements in a bowl of water or under running water. To avoid
contamination of the open ended plastic threaded mount, take care to ensure that the
mount is always clear of the water NEVER use soap or detergents
Take a soft bristle brush or lightly abrasive pad and cup it around the circumference
of the filter element
Apply a gentle pressure with the brush or pad and slowly work down the length of each
filter element once, ensuring the cleaning is even over the whole filter element surface
Replace the filter elements as per assembly instructions above
Refill the top chamber and replace the lid
The filter is now ready for use
Manufactured by:
Doulton Water Filters, Newcastle, Staffordshire, ST5 9BT, United Kingdom.
Telephone: [phone]
Fax: [phone]
Email: fi[email protected]
Website: www.doulton.com
British Berkefeld®is a trademark registered to Fairey Industrial Ceramics Limited.
W2393017 Issue 4 October 2016 Fairey Industrial Ceramics Limited trading as Doulton Water Filters. www.doulton.com
A GENUINE WATER FILTER
A GENUINE
WATER FILT ER

Healthy water, healthy life.
Filter Performance
October 2016 www.faireyceramics.com
A GENUINE WATER FILTER
A GENUINE
WATER FILT ER
Candle Grade 49mmø Sterasyl
® Super Sterasyl ® ATC Super Sterasyl ®
Supercarb®Chlorasyl®Ultracarb®BioTect Ultra®
Selection of the most appropriate grade of candle allows
filter performance to be matched to the requirements Silver impregnated Sterasyl
®
microfilter Sterasyl
®
microfilter Sterasyl
®
microfilter Sterasyl
®
microfilter Sterasyl
®
microfilter Sterasyl
®
microfilter
of the local water conditions ceramic microfilter plus granular plus granular plus carbon block plus carbon block plus carbon block plus carbon block
activated carbon activated carbon and core core core and lead core and heavy metals
lead removal media removal media removal media
Filtration Rating (% particulate filtration efficiency)
Absolute (defined as >99.99%) 0.9 micron 0.9 micron 0.9 micron 0.9 micron 0.9 micron 0.9 micron 0.9 micron
Nominal (defined as >99.9%) 0.5 to 0.8 micron 0.5 to 0.8 micron 0.5 to 0.8 micron 0.5 to 0.8 micron 0.5 to 0.8 micron 0.5 to 0.8 micron 0.5 to 0.8 micron
Nominal (defined as >97%) 0.2 to 0.3 micron
Working Pressure (for pressure filter use)
Minimum 10 psi 10 psi N/A 10 psi 10 psi 10 psi 10 psi
Maximum 125 psi 125 psi N/A 125 psi 125 psi 125 psi 125 psi
Working Parameters
Working temperature range 5 - 30 (ºC) 5 - 30 (ºC) 5 - 30 (ºC) 5 – 30 (°C) 5 – 30 (°C) 5 – 30 (°C) 5 – 30 (°C)
Working pH range 5.5 - 9.5 5.5 - 9.5 5.5 - 9.5 5.5 – 9.5 5.5 – 9.5 5.5 – 9.5 5.5 – 9.5
Suitable for use in Gravity filters Yes Yes Yes N/A N/A N/A N/A
Recommended change frequency 12 months 6 months 6 months 6 months 6 months 6 months 6 months
Flow Rate
Unrestricted Flow at 3 Bar Pressure up to Litres per minute 5 4.5 N/A 3.7 3.7 3.3 3.3
US gallons per minute 1.33 1.2 N/A 1 1 0.9 0.9
To achieve maximum performance Litres per minute N/A 1.2 l/hr under gravity 1.2 l/hr under gravity 1.9 1.9 1.9
US gallons per minute N/A 0.3 g/hr under gravity 0.3 g/hr under gravity 0.5 0.5 0.5 0.5
Capacity
Before replacement to Litres 10,000 2000 1500 3800 3800 2300 2300
guarantee performance US gallons 2600 535 400 1000 1000 600 600
Quality Approval certified version available YES+NO NO YES NO YES YES
approved YES YES NO YES NO YES ‡PENDING
Turbidity reduction to NSF std. 53 >98% >98% >98% >98% >98% >98% >98%
Pathogenic Organisms
% Bacteria Removal* E. Coli / Cholera / Shigella /
Typhoid / Klebsiella Terrigena >99.99% >99.99% >99.99% >99.99% >99.99% >99.99% >99.99%
% Cyst Removal Cryptosporidium >99.99% >99.99% >99.99% >99.99% >99.99% >99.99% >99.99%
Giardia >99.99% >99.99% >99.99% >99.99% >99.99% >99.99% >99.99%
Trace Organics Removal
Insecticides Lindane @ 0.1ppb presence N/A NO DATA NO DATA >85% NO DATA >85% >85%
Herbicides Atrazine @ 1.2ppb presence N/A NO DATA NO DATA >85% NO DATA >85% >85%
Phenols TCP @ 1.2ppb presence N/A NO DATA NO DATA >50% NO DATA >50% >50%
Polyaromatic Hydrocarbons PAHs @ 0.2ppb presence N/A NO DATA NO DATA >95% NO DATA >95% >95%
Trihalomethanes Chloroform @ 150ppb presence N/A NO DATA NO DATA >50% NO DATA >50% >50%
Enhanced Organics Removal
Lindane 2ppb presence N/A N/A N/A N/A Ave 95% N/A Ave 70%
Atrazine 9ppb presence N/A N/A N/A N/A N/A N/A Ave 90%
Benzene 15ppb presence N/A N/A N/A N/A Ave 87% N/A Ave 87%
Inorganics Removal
Free Chlorine Removal 2ppm presence to N/A Under Gravity > 95% >95% under gravity >97% >97% >96% >96%
NSF Class 1 Std 42 Under Pressure > 50%
Monochloramine Reduction
3ppm presence N/A N/A N/A N/A Ave 95% (600 USG) N/A N/A
2ppm presence N/A N/A N/A N/A N/A N/A Ave 64%
Heavy Metals Remova l
Lead reduction pH6.5 @ 150ppb presence to NSF Std 53 N/A N/A >94% under gravity N/A N/A 98.7% 98.7%
Lead reduction pH8.5 @ 150ppb presence to NSF Std 53 N/A N/A N/A N/A N/A 98.7% †99.1%
Mercury reduction pH6.5 @ 6ppb presence N/A N/A N/A N/A N/A N /A Ave 90%
Cadmium reduction pH 6.5 @ 30ppb presence N/A N/A N/A N/A N/A N//A Ave 95%
Scale Inhibition Slow release scale inhibition available with Ultracarb SI®and Supercarb SI®ceramic filter candles.
State restrictions may limit the availability of certain products in California, Iowa and Wisconsin. For product availability in these States please refer to our website: www.faireyceramics.com
+NSF certified replacement elements are Doulton Sterasyl®, Doulton Supercarb®, Doulton Ultracarb®and Doulton BioTect Ultra®as verified by testing in HIP Inline, and EcoFast®Inline Systems.
† Internally generated test data.
‡ Under approval process.
*Ceramics tested in HIS filter housing with a minimum of 5 log/100mls influent challenge.
