APPLICATION NOTE
BCM5221/5220
7/7/00

Broadcom Corporation
16215 Alton Parkway
P.O. Box 57013
Irvine, CA 92619-7013
© 2000 by Broadcom Corporation
All rights reserved
PrintedintheU.S.A.
Broadcom®, the pulse logo, and QAMLink are registered trademarks of Broadcom Corporation and/or its subsidiaries in the
United States and certain other countries. All other trademarks are the property of their respective owners.

Broadcom Corporation
Document 5221/5220-AN01-R Page iii
Application Note ■BCM5221
7/7/00 ■BCM5220
REVISION HISTORY
REVISION # DATE CHANGE DESCRIPTION
AN01-R 7/7/00 Initial release

Broadcom Corporation
Page iv Document 5221/5220-AN01-R
■BCM5221 Application Note
■BCM5220 7/7/00
TABLE OF CONTENTS
Revision History
Overview........................................................................................................................................................1
2.5V/3.3V Tolerance......................................................................................................................................1
Internal Pull-ups and Pull-downs................................................................................................................2
25 MHz Reference Clock ..............................................................................................................................3
RDAC .............................................................................................................................................................4
Low Power Modes ........................................................................................................................................4
Dual Function Pins.......................................................................................................................................4
PHYAD4/CK25.................................................................................................................................5
PHYAD3/PAUSE..............................................................................................................................5
PHYAD2/ACT_LED#........................................................................................................................5
PHYAD1/COL_LED#........................................................................................................................5
PHYAD0/FDX_LED#........................................................................................................................5
SPDLED#/ADV_PAUSE# ................................................................................................................5
100Base-FX ...................................................................................................................................................5
SD+/-................................................................................................................................................7
RD+/-................................................................................................................................................7
TD+/- ................................................................................................................................................7
Serial 10m (7-Wire Interface) .......................................................................................................................7
Auto-MDI/MDIX Crossover...........................................................................................................................8
Magnetics......................................................................................................................................................9
Bel....................................................................................................................................................9
Pulse Engineering............................................................................................................................9
Halo..................................................................................................................................................9
Media Conversion.......................................................................................................................................10
Cable Length Monitoring Capability.........................................................................................................12
JTAG Considerations.................................................................................................................................12
JTAG Functional Description.................................................................................................................13
Eliminating Tri-State Buffer Requirement..............................................................................................13
Preferred Method ...........................................................................................................................13
Alternative Method .........................................................................................................................14
Supply Pins and Power Planes .................................................................................................................14
OVDD.............................................................................................................................................14

Broadcom Corporation
Document 5221/5220-AN01-R Page v
Application Note ■BCM5221
7/7/00 ■BCM5220
REGAVDD and REGDVDD........................................................................................................... 14
DVDD............................................................................................................................................. 14
AVDD............................................................................................................................................. 14
BIASVDD....................................................................................................................................... 14
Multi-Port Designs ..................................................................................................................................... 14
10/100 Twisted Pair MII to MDI.................................................................................................................. 15
General Layout Notes................................................................................................................................17
Analog Related Passive Component Placement........................................................................... 17
TD+/- Trace Routing ...................................................................................................................... 17
100Base-TX and 10Base-T Signaling ........................................................................................... 17
RD+/- Trace Routing...................................................................................................................... 17
Reference Clock ............................................................................................................................ 17
Magnetics to RJ45-8...................................................................................................................... 17
Chassis Ground............................................................................................................................. 17
Board Layer Allocation................................................................................................................... 18
Power Supply Filter Component Placement.................................................................................. 19
General Layout Recommendations ............................................................................................... 20
Thermal Information .................................................................................................................................. 21
BCM5221 vs. BCM5220.............................................................................................................................. 21

■BCM5221 Product Application Note
■BCM5220 7/7/00
Broadcom Corporation
Page 1 5221/5220-AN01 Product Application Note, Revision R
OVERVIEW
This application note contains detailed information regarding the use of the BCM5221 single channel 10/100 Physical Layer
Device. The BCM5221,capable of either 2.5V or 3.3V operation is targeted for single port or odd port copper or fiber designs
such as NIC, motherboard, additional switch port, and MAU type implementations. Dual port designs, such as a dual-port
10/100 uplinks are also discussed herein.
The BCM5221 includes the following features: Auto-MDIX switching capability, Glueless media conversion capability
(100BASE-TX to 100BASE-FX), and Cable Quality Monitoring capability.
The BCM5221 is actually a 2.5V device that includes on-chip 3.3V to 2.5V regulators making it suitable for 3.3V system ap-
plications. The BCM5221 is not suitable for applications that run exclusively at 5.0V. The system designer should consider
the BCM5201/02 for single chip 5.0V applications.
It is recommended that this application note be read in conjunction with the latest versions of the BCM5221 data sheet and
other 5221 application notes in order to ensure the most robust design possible.
The BCM5221 is available in a 64-pin 10 mm2PQFP package (part number BCM5221KPT).
The BCM5221 is also available in a 64-ball 8 mm2FBGA package (part number BCM5221KPB). This is the lowest power,
highest performing single channel PHY available today.
The BCM5220 is identical to the BCM5221 with the exception of a few features. These differences are described at the end
of this application note.
2.5V/3.3V TOLERANCE
There are three basic power supply configurations that can be used with the BCM5221. It can operate exclusively at 2.5V,
it can operate exclusively at 3.3V, or it can operate with the core running at 2.5V while the I/O runs at 3.3V. The latter con-
figuration is the most typical where low power and 3.3V digital compatibility are required.
The BCM5221 digital inputs are 3.3V tolerant and can accept 3.3V CMOS logic levels as long as the OVDD pins are tied to
3.3V. Additionally, the digital outputs will source 3.3V CMOS levels when the OVDD pins are tied to 3.3V. If the OVDD pins
are tied to 2.5V, then all digital inputs and outputs are limited to a 2.5V signal swing.
The BCM5221 is not 5V tolerant.
Figure 1 on page 2 illustrates power supply connections for the three configurations described above.

Product Application Note ■BCM5221
7/7/00 ■BCM5220
Broadcom Corporation
5221/5220-AN01 Product Application Note, Revision R Page 2
Figure 1: Power Supply Configuration Options
INTERNAL PULL-UPS AND PULL-DOWNS
•This section lists those Inputs, or combination Inputs/Outputs, that include internal resistive pull-ups or pull-downs. The
value of each pull-up and pull-down is approximately 50 kΩ (+/-20%).
•REF_CLK > pull-down
•TXD[3:0] > pull-down
•TXEN > pull-down
•TXER > pull-down
•MDC > pull-down
•PHYAD[4:0] > pull-down
•FDX > pull-down
•SD+ > pull-down
•SD- > pull-down
OVDD
DVDD
REGDVDD
AVDD AVDD
BIASVDD REGAVDD
DVDD
2.5V
2.5V
N/C
N/C
2.5V
BCM5221
(2.5V Supply Connection)
OVDD
DVDD
REGDVDD
AVDD AVDD
BIASVDD REGAVDD
DVDD
N/C3.3V
BCM5221
(3.3V Supply Connection)
N/C
(BIASVDD connects to AVDD, however,
none of these pins connects to 3.3V)
OVDD
DVDD
REGDVDD
AVDD AVDD
BIASVDD REGAVDD
DVDD
2.5V
2.5V
N/C
N/C
2.5V
BCM5221
(2.5V Core, 3.3V I/O))
3.3V

■BCM5221 Product Application Note
■BCM5220 7/7/00
Broadcom Corporation
Page 3 5221/5220-AN01 Product Application Note, Revision R
•TESTEN > pull-down
•LOWPWR > pull-down
•MDIO > pull-up
•RESET# > pull-up
•F100 > pull-up
•ANEN > pull-up
•MII_EN > Pull-up
•LNKLED# > pull-up
•SPDLED# > pull-up
•RCVLED# > pull-up
The XMTLED#/INTR#/FDXLED# output is Open Drain
25 MHZREFERENCE CLOCK
TheBCM5221deviceacceptsa25 MHz(or50MHz forRMIIapplications)referenceclockfromeitheralowcostcrystalcircuit
(parallel resonance operating in the fundamental mode) or a single ended clock source such as a 50 ppm self-contained
oscillator or buffered system clock. See Figure 2 for clock connection requirements.
For stand-alone crystal applications, Broadcom recommends that the crystal is located as close to the XTALI and XTALO
pins ofthe BCM5221 as possible to minimize stray capacitance due toexcessive trace routing that could interfere with crystal
start-up as well as clock stability.
Broadcomrecommendsthe use of a crystal rated for a total load capacitance of 18 pF. A calculation for deriving the approx-
imate load capacitance is: ((CL1 xC
L2)/(CL1 +C L2)) + CsWhere CL1 xC L2 are the actual load capacitors connected to either
side of the crystal, and Csis the sum of the stray capacitance and input pin capacitance of the PHY device. Assuming load
caps of 20pF each and a total stray + parasitic capacitance of approximately 8pF, the above equation yields a total load
capacitance of around 18pF. The load capacitor values may need to be adjusted from the example above to account for
variations in parasitic capacitance and/or crystal specification.
For applications using an XTAL based oscillator or buffered system clock, the REF_CLK input should be used. In this in-
stance, the XTALI input should be pulled to ground (4.7K) and the XTALO pin can remain unconnected. The input voltage
swing of the reference clock must be no greater than the voltage at the OVDD power pin.
Figure 2: Oscillator Clock Considerations
The electrical specifications recommended for the crystal or oscillator clock source are as follows:
•Frequency tolerance: +/-50 ppm
•50% Duty Cycle: +/- 10%
BCM5221
(XTAL Connection) BCM5221 (Reference Clock)
+/-50ppm
18pF
18pF
25MHz (MII)
XTALI
XTALO
XTALI
XTALO
REF_CLKN/C REF_CLK

Product Application Note ■BCM5221
7/7/00 ■BCM5220
Broadcom Corporation
5221/5220-AN01 Product Application Note, Revision R Page 4
•Edge rates: from 1 ns to 4 ns (10% to 90%)
•Voltage swing: limited to OVDD maximum
•Crystal Aging: +/- 5 ppm per year, maximum
•Crystal Frequency Stability (over temperature): +/- 10 ppm
The following clock devices exhibit good performance in a variety of Broadcom’s evaluation platforms.
•Oscillator: GED part number LM20001E/DI-25.000M (GED, San Marcos, CA, [phone])
•Crystal: Epson part number MA-506-25.000M-C2 (http://www.epson-electronics.de/download/downcrys.htm)
Digi-Key part number SE2639CT-ND
RDAC
The 100Base-TX and 10Base-T transmit amplitudes can be directly controlled by adjusting the amount of current allowed to
flow from the RDAC pin to GND. It is recommended that in order to verify proper transmit signal amplitude for a given design,
an initial value of 1.27K Ω(1%)beusedfortheexternalRDACresistor(SeeFigure8onpage15andFigure9onpage16).
It is important to note that the transmit signal amplitude can be affected by magnetics insertion loss as well as stray capac-
itance in the front-end design. Therefore, it is important to quantify these additional possible sources of attenuation and ad-
just the value of the RDAC resistor accordingly to compensate.
A 1% change in RDAC currentresults in a 1%change in transmit amplitude at the TD+/- outputs. Increasing the value of the
RDAC resistor results in a proportional decrease in transmit amplitude, and vice - versa.
LOW POWER MODES
The BCM5221 supports two low power modes of operation as discussed in the data sheet: Manual Low Power Mode, and
Automatic Power Down Mode.
Manual Low Power mode (LOW_PWR pin = 1) configures the device such that all circuitry, with the exception of the Energy
Detect block, is powered down. This mode results in maximum device current consumption of approximately 10mA. This
Energy Detect circuit asserts the ENERGY_DET output when receive energy is detected at the RD+/- wire side inputs. Spe-
cifically, if energy of at least 300 mV pk-pk differential is present for at least 1.3 ms, the ENERGY_DET pin asserts.
REF_CLK must be present for the Energy Detection mode to function properly.
In order to remove the PHY from the Energy Detect Low Power mode, the LOWPWR pin must be set to a logic zero. you do
not need to generate a hardware reset. REF_CLK must be active and stable.
Automatic Power Down Mode is enabled by setting bit 5 of the Shadow Register 1Ah. When this mode is enabled, the
BCM5221 remains inactive and will not transmit anything onto the wire until it detects energy (at least 300mV differential) at
it’s RD+/- inputs. Once energy is detected, the BCM5221 will automatically power up operate normally. Note that the use of
this feature should be restricted to implementations and environments where the Link partner is a known entity. Forexample,
if both ends of the link happen to be in Automatic Power Down mode, the link will never activate.
It is important to note that in order to successfully enter either of the Low Power modes, REF_CLK must continue for a least
two full clock cycles after LOWPWR is switched. This is to ensure that low power mode is properly latched in. REF_CLK can
then be deactivated, if needed.
DUAL FUNCTION PINS
The BCM5221 includes several dual purpose pins that combine input and output functions. The input function for these pins
is latched into the device at power-on / reset. These pins assume the output function during normal device operation.

■BCM5221 Product Application Note
■BCM5220 7/7/00
Broadcom Corporation
Page 5 5221/5220-AN01 Product Application Note, Revision R
PHYAD4/CK25. Physical Address input which, along with the other 4 PHYAD pins, sets a unique address for this device
to allow MDIO access. The CK25 output is a buffered version of REF_CLK for general use.
PHYAD3/PAUSE. Physical Address input which, along with the other 4 PHYAD pins, sets a unique address for this device
to allowMDIO access. The PAUSE output isan active low indication of the Flow Control capability of the far-end link partner
(logic 0 =link partner supports PAUSE, logic 1= link partner does not support PAUSE). The state of this output is determined
by the result of auto-negotiation.
PHYAD2/ACT_LED#. Physical Address input which, along with the other 4 PHYAD pins, sets a unique address for this
device to allow MDIO access. The ACT_LED# output is an active low indication of packet activity (transmit and receive)
through the BCM5221 (logic 0 = activity, logic 1= idle). If the use of this LEDoutput is required, Broadcom recommendsthat
PHYAD2 be strapped high since the LED output polarity is active low.
PHYAD1/COL_LED#. Physical Address input that, along with the other 4 PHYAD pins, sets a unique address for this de-
vice to allow MDIO access. The COL_LED# output is an active low indication of collision and only meaningful during half
duplex operation (logic 0 = collision, logic 1 = no collision). If the use of this LED output is required, Broadcom recommends
that PHYAD1 be strapped high because the LED output polarity is active low.
PHYAD0/FDX_LED#. Physical Address input which, along with the other 4 PHYAD pins, sets a unique address for this
device to allow MDIO access. The FDX_LED# output is an active low indication of the current duplex state of the BCM5221
(logic 0 = Full Duplex, logic 1 = Half Duplex). If the use of this LED output is required, Broadcom recommends that PHYAD0
be strapped high because the LED output polarity is active low.
SPDLED#/ADV_PAUSE#. Active LED output that indicates the current operating speed of the BCM5221 (logic 0 = 100
MBps, logic 1 = 10 Mbps). The ADV_PAUSE# active low input allows the local MAC to directly indicate to the BCM5221 it’s
ability to support flow control. A logic 0 will set bit 10 in register 04h. A logic 1 clears bit 10 in register 04h.
100BASE-FX
The BCM5221 supports 100BASE-FX operation via the SD+/-, RD+/-, and TX+/- pins. The connection diagrams in Figure 3
on page 6 illustrate the proper termination and level shifting required to interface the BCM5221 to a 3.3V fiber transceiver.

Product Application Note ■BCM5221
7/7/00 ■BCM5220
Broadcom Corporation
5221/5220-AN01 Product Application Note, Revision R Page 6
Figure 3: BCM5221 3.3V 100BASE-FX Interface
Figure 3 illustrates only the termination scheme for the 100BASE-FX interface. Refer to the fiber transceiver manufacturer’s
guidelines for transceiver power supply connection and filtering.
The TD+/- and RD+/- signal traces between PHY and the fiber transceiver should each be routed with a characteristic im-
pedance of 50Ω (100Ωdifferential) to match the termination network impedance given in Figure 3.
BRCM5221 Fiber
Transceiver
Signal Detect Termination
SD+
SD-
SD+
39.2Ω
1/16W
1%
221Ω
1/16
W
1%
512Ω
1/16
W
1%
487Ω
1/16
W
1%
The PHY RD+/- input
signals are level
shiftedtocreatea
common mode level
of 1.7V
Duetothestatic
nature of SD+, this
signal does not need
to be routed as a
controlled impedance
trace. Placement of
the dividing networks
is noncritical
3.3V
BRCM5221 Fiber
Transceiver
Receive Termination
RD+
RD-
RD+
RD-
130 Ω
1/16W
1%
130 Ω
1
/16W
1%
Route each signal
trace with a controlled
impedance of 50
Ω if the
routing distance
exceeds one inch
12Ω
1/16W
1%
12Ω
1/16W
1%
68 Ω
1/10W
1%
68 Ω
1/10W
1%
3.3V
Place this termination
network close to the
BCM5228 input
BRCM5221 Fiber
Transceiver
100 Ω
1/16
W
5%
100 Ω
1/16W
5%
12.7 Ω
1/16W
1%
68.1 Ω
1/16W
1%
63.4 Ω
1/16W
1%
17.4 Ω
1/16W
1%
Transmit Termination
3.3V
If the trace length from PHY
to Fiber Transceiver is one
inch or less, the two 100
Ω
differential resistors can be
replaced by a single 50
Ω
differential resistor
Place this network
close to the Fiber
Transceiver input
TD+
TD-
Route each signal
trace with a controlled
impedance of 50
Ω
TD+
TD-
0.1uF
Cer 5%
Optional: this cap is only
recommended in layouts
where noise sensitivity is
likely (ie long trace
connected to SD-)
The PHY SD+/-
input signals are
level shifted to
create a common
mode level of
1.7V

■BCM5221 Product Application Note
■BCM5220 7/7/00
Broadcom Corporation
Page 7 5221/5220-AN01 Product Application Note, Revision R
The SD+/- traces do not require special impedance considerations due to the static nature of signal detect. Note that the
actual potential of the 3.3V rail connected to the SD- voltage divider should match the 3.3V potential as measured on the
fiber transceiver power pins (VDD as measured at the transceiver power pins may be less than nominal if series inductive
filtering is used, which may be recommended by the fiber transceiver manufacturer).
Configuring the BCM5221 100Base-FX operation is accomplished simply by connecting the SD+ input to a 100Base-FX
compliant transceiver and by setting the potential of the SD- pin as shown in Figure 3. There is no way to configure for
100Base-FX operation via software.
Hewlett Packard (http://www.hp.com/HP-COMP/fiber/sg/) and Siemens (http://w2.siemens.de/semiconductor/products/37/
37651.htm) both manufacture high quality 100BASE-FX transceivers.
SD+/-. Assuming the use of a 3.3V fiber transceiver, take care to level shift the SD+ signal from the fiber transceiver to the
BCM5221 properly. Because the SD signal from the transceiver is essentially static, there is no need to treat the SD+ trace
as a transmission line. A simple level shifter is required and its placement relative to either the BCM5221 or the fiber optic
transceiver is non-critical. As with any interface, trace lengths should be kept to a minimum wherever possible. The SD- input
of the BCM5221 requires an external bias of 1.7V to ensure that the differential SD+/- input functions properly.
RD+/- . Because the RD+/- inputs of the BCM5221 are internally biased, and because typical 3.3V fiber transceivers nor-
mally source PECL with a Vbb (center of the voltage swing) of approximately 2.0V, level shifting is required. Additionally, if
the system layout requires that the RD+/- trace lengths are more than approximately one inch, take care to set up the termi-
nation to account for transmission line effects as well (as indicated in Figure 3).
TD+/- . The BCM5221 employs current-sink outputs to transmit the 100Base-FX signaling to the fiber transceiver so a spe-
cial level shifting and impedance matching termination network must be implemented. The slight mismatch in the final volt-
age divider for the TD+ versus TD- ensures that the TD+/- input of the fiber transceiver will not switch due tonoise that might
be present when the BCM5221 is quiet.
SERIAL 10M(7-WIRE INTERFACE)
The BCM5221 will interface to most MicroProcessors via serial 10M across the MII (also referred to as 7-Wire interface).
This mode can only be enabled via the MDIO interface by writing a 1 to bit 1 of register 1Eh.
Figure 4 on page 8 illustrates the connection between the BCM5221 and a typical µP. Note that this figure represents con-
nection with the more popular Motorola µPs (such as the MPC850, 860, etc).

Product Application Note ■BCM5221
7/7/00 ■BCM5220
Broadcom Corporation
5221/5220-AN01 Product Application Note, Revision R Page 8
Figure 4: BCM5221 Serial 10 (7-Wire) Interface
AUTO-MDI/MDIX CROSSOVER
In most 10/100Base-TX connections, one end of the link is configured as an MDI (Medium Dependent Interface) crossover
so that each transceiver’s transmitter is connected to the other’s receiver. This allows the end user to install straight-through
cables. However, there are many instances where cross-over cables are required and this has caused significant confusion
and downtime in the field. The BCM5221 contains the ability to perform Auto-MDI/MDIX crossover on chip, thus eliminating
the need for crossover cables or cross-wired (MDIX) ports.
During auto-negotiation and 10/100BASE-TX operation, the BCM5221 normally transmits on TD±and receives on RD±.
When connected via a straight-through cable to another device that does not perform the Auto-MDI/MDIX crossover, the
BCM5221 automatically switches its transmitter to RD±and its receiver to TD±to communicate with the remote device. If
two devices are connected that both have Auto-MDI/MDIX crossover capability, then a random algorithm determines which
end performs the crossover function.
The Auto-MDI/MDIX crossover feature is a function of auto-negotiation. If the BCM5221 is configured not to perform Auto-
Negotiation, the feature does not work, and a specific cable is required to ensure the Transmitter at one end of the cable is
connected with the Receiver at the other end of the cable. This feature is enabled by default, but can be disabled by setting
RENA RXDV
TXD[0]
TXD
RXD RXD[0]
CRS
TXENTENA
CLSN COL
RXER
COL
TCLK
RCLK
BCM5221
Motorola
µ
µµ
µ P
IMPORTANT : Setup and Hold timing
must be carefully considered in order
to ensure proper data transfer timing
across the MII in both directions.
TXC
RXC
TXD[3:1]
RXD[3:1]
n/c
n/c
n/c
n/c
n/c

■BCM5221 Product Application Note
■BCM5220 7/7/00
Broadcom Corporation
Page 9 5221/5220-AN01 Product Application Note, Revision R
bit 11 in Register 1Ch to a 1. During operation, the MDI state can be determined by reading bit 13 of Register 1Ch, as indi-
cated in the BCM5221 data sheet. Additionally, a manual MDI swap can be forced by setting or clearing bit 12 of Register
1Ch.
The Auto-MDI/MDIX feature is implemented in the BCM5221 in accordance with the IEEE 802.3ab specification. The Auto-
matic MDI/MDI-X state machine facilitates switching between the receiving pair and the transmitting pair respectively, prior
to the auto-negotiation mode of operation so that Fast Link Pulses (FLPs) can be transmitted and received in compliance
with Clause 28 of theauto-negotiation specification. The final state of the crossover circuit is determined by an algorithmthat
controls the switching function between the two pairs (transmit and receive). The algorithm uses an 11-bit Linear Feedback
Shift Register (LFSR) to create a pseudo-random sequence with which the BCM5221 determines its initial configuration. In
the BCM5221, care is taken to ensure the LFSR is seeded with a unique value during reset. This determines the initial state
of MDI or MDIX.
Per the specification, a sample timer is implemented in a manner that allows the BCM5221 to detect either valid Link Pulses
or a Valid Link. If after 62+/-2 ms the receiver is unable to detect a valid Link Pulse or a valid Link, the LFSR is advanced,
switching the pairs. Additionally, an asynchronous timer is used in the unlikely event where the two PHYs have identical ref-
erence clocks and reset circuits. When this timer expires,it resets the state machine to the MDI State and restarts the sample
timer. This timer is free running and has no impact on the LFSR.
Auto-MDI/MDIX operates only on the transmit and receive data pairs (swapping them if required). It does not operate on the
individual wires within a given pair and therefore cannot correct for possible polarity swap issues. However, the 10BASE-T
transceiver within the BCM5221 includes polarity detection and correction to ensure proper functionality should a polarity
problem exist in the wiring. Note that100Base-TX signaling isNOT sensitive to polarity and therefore does not strictly require
polarity detection and correction.
Specific magnetics and cable termination issues must be considered when using the BCM5221 in Auto-MDI/MDIX mode.
See the following section for further detail.
MAGNETICS
Most applications requires single channel magnetics to support implementations based on one or more BCM5221 devices.
In some applications, Quad channel magnetics may be more practical.
In any case, note that one important restriction in pairing magnetics with the BCM5221 relates to the ordering of isolation
transformer and common mode choke in the transmit signal path (and receive signal path when Auto-MDI/MDIX is enabled).
The transmit output signal from the BCM5221 must be connected to the isolation transformer first, followed by the common
mode choke (as depicted in Figure 5). If any common mode choke is placed between the transmit output pins and the iso-
lation transformer, potentially severe signal distortion results while operating in 10Base-T and auto-negotiation modes.
The following listincludes recommended Single and Quadchannel magnetics components fromvarious vendorsfor use with
the BCM5221 (and BCM5220). The use of these magnetics is recommended regardless of whether Auto-MDI/MDIX is en-
abled.
Bel. S558-5999-W2 (Single) S558-5999-Q9 (Quad - for use with single height or stacked RJ connectors)
Pulse Engineering. H1102 (single) H1164 (Quad)
Halo. TG110-S050N2 (single)
Figure 5 on page 10 illustrates specific magnetics interconnect and differential cable termination requirements for applica-
tions that use Auto-MDI/MDIX.

Product Application Note ■BCM5221
7/7/00 ■BCM5220
Broadcom Corporation
5221/5220-AN01 Product Application Note, Revision R Page 10
Figure 5: Magnetics Connection and Differential Cable Termination Requirements
MEDIA CONVERSION
This section describes the ability of the BCM5221 to act as a Media Convertor(100Base-TX <> 100Base-FX). The BCM5221
includes internal receive channel FIFOs to allow the data to cross over the clock boundaries without any requirement for
external buffering or clock multiplexing.
Figure 6 on page 11 illustrates how to implement glueless media conversion using two BCM5221 devices. Note that Auto-
negotiation should be disabled for both of the BCM5221 devices. Additionally, half-duplex operation between the two 5221
devices is not supported. Media Conversion must be implemented in full-duplex. Note that this does not preclude the use of
a BCM5221 media converter in a half-duplex system.
The following pin strapping is required for Media Conversion. Pull-up and pull-down values of 4.7 KΩare recommended.
100BASE-TX PHY:
•LINKLED#/MEDIA_CONV# (pin 35) must be pulled low
•MII_EN (pin 18) must be pulled low
•ANEN (pin 38) must be pulled low
•F100 (pin 37) must be pulled high or left unconnected
•FDX (pin 39) must be pulled high
•SD+ and SD- (pins 21 and 19) must be pulled low or left unconnected
100BASE-FX PHY:
•LINKLED#/MEDIA_CONV# (pin 35) must be pulled low
•MII_EN (pin 18) must be pulled low
•ANEN (pin 38) must be pulled low
•F100 (pin 37) must be pulled high or left unconnected
•FDX (pin 39) must be pulled high
•SD+ and SD- (pins 21 and 19) must be connected as specified in the 100BASE-FX section of this application note.
TDP
BCM5221 PHY
TDN
2.5V
2.5V
1:1
RDP
RDN 49.9
Ω
MDIX Magnetics
2.5V 1:1
49.9 Ω
49.9 Ω
49.9 Ω
2KV, 1nF
0.01uF
RJ45
3
6
2
1
Note that the 49.9 Ω pull-up resistors and transformer primary center-tap connection
may be pulled- to either 2.5V or 3.3V depending on the application.

■BCM5221 Product Application Note
■BCM5220 7/7/00
Broadcom Corporation
Page 11 5221/5220-AN01 Product Application Note, Revision R
Figure 6: Media Conversion Connection Example
TD+
BCM5221 PHY
(100BASE-TX)
TD-
2.5V
2.5V
1:1
RD+RD-
49.9 Ω
MDIX Magnetics
2.5V
1:1
49.9 Ω
49.9 Ω
49.9 Ω
2KV, 1nF
0.01uF
3 6
2
1
RXD1 RXD0
TXD1
TXD0
TXEN
CRS_DV
REF_CLK
REF_CLK
BCM5221 PHY
(100BASE-FX)
RXD0 RXD1
TXD0 TXD1
TXEN
CRS_DV
50MHz +/-50ppm
Xtal based clock source.
(Clock source must not be
PLL based)
50MHz
SD+
SD-
TD+ TD- RD+ RD- SD+
Fiber Transceiver
(100BASE-FX - Mini MTRJ)
TD+ TD- RD+ RD- Voltage Divider
(1.7V)
Refer to 100BASE-FX
section in this application
note for termination details
Series Source Termination required
only if the two BCM5221 devices are
greater than 2 inches apart
RJ45-8

Product Application Note ■BCM5221
7/7/00 ■BCM5220
Broadcom Corporation
5221/5220-AN01 Product Application Note, Revision R Page 12
CABLE LENGTH MONITORING CAPABILITY
The DSP nature of the 10/100 receiver within the BCM5221 allows real-time access to equalizer states that provide cable
length estimate information.
Specifically, bits [14:12] in Shadow Register 1Bh provide a +/- 10 meter length estimate of the CAT 5cable connected to the
receiver inputs of the 5221 (assuming of course that the far end station is operational). This estimate is accessed by simply
reading the aforementioned bits.This provides the user with an easily accessed and powerful diagnostic tool for determining
potential problems within the cable plant and/or associated connectors. See Table 1 for decode.
JTAG CONSIDERATIONS
The BCM5221 device incorporates JTAG as a shared function with several device input control and output LED functions.
This pin sharing should be carefully considered if the use of JTAG is required. This pin sharing approach provides JTAG
functionality within the feature-rich BCM5221.
JTAG test mode is onlyenabled when the active high JTAG_EN input is pulledhigh. When JTAG_EN is enabled, the follow-
ing pins become the JTAG test interface for the BCM5221.
Table 1: Cable Length Estimate
Register 1Bh
14, 13, 12 Cable Length in Meters
000 <20
001 20 to <40
010 40 to <60
011 60 to <80
100 80 to <100
010 100 to <120
100 120 to <140
010 >140
Table 2: JTAG Signals
JTAG Signal Type BCM5221
KPB BCM5221 KPT Description
JTAG_EN IPD A2 64 JTAG Enable. Active high. When this signal is high, causes
the BCM5221 to enter JTAG test mode which enables
TRST#, TCK, TMS, TDI and TDO signals. For normal opera-
tion leave this pin unconnected.
TRST# IPU F7 38 Test Reset. This pin becomes JTAG TRST#. This is an asyn-
chronous active low reset input to JTAG TAP controller. This
signal is multiplexed with ANEN signal input.
TCK IPU F6 37 JTAG test clock input. This signal is multiplexed with F100
signal.
TMS I/OPU G8 36 Test Mode Select input. This signal is multiplexed with
SPD_LED# and ADV_PAUSE#.

■BCM5221 Product Application Note
■BCM5220 7/7/00
Broadcom Corporation
Page 13 5221/5220-AN01 Product Application Note, Revision R
JTAG FUNCTIONAL DESCRIPTION
The JTAG_EN signal should be set to a high logic level to enable JTAG function since JTAG signals are multiplexed with
other signals during normal operation. Once enabled, TCK, TRST#, TMS, TDI and TDO provide JTAG functionality. Please
refer to the following schematics to connect JTAG signals and JTAG compatible devices to JTAG chain.
Figure 7: JTAG Chain Schematics
Setting JTAG_EN to a high level causes the BCM5221 to enter JTAGmode. You must connect the JTAG TDI and TMS input
signals to the BCM5221 TDI and TMS input signals through tri-state buffers as shown in the above schematics because
these inputs are multiplexed with other output signals during normal operation.
ELIMINATING TRI-STATE BUFFER REQUIREMENT
Preferred Method. If the design does not require LNKLED# and SPD_LED# signals, it is possible to connect the JTAG
TDI and TMS signals directly to the TDI and TMS pins of the BCM5221. Eliminating the TDI tri-state buffers is accomplished
by the following two writes.
1Enable shadow register by writing a 1to bit 7 of MII register 1Fh.
2Write a 1 to bit 3 of MII shadow register 1Ah.
TDI I/OPU H8 35 TestDataInput.ThissignalismultiplexedwithLNKLED#and
MEDIA_CONV# signals.
TDO I/OPU H7 33 Test Data Output. This signal is multiplexed with RCVLED#,
ACTLED# and MDIX_DIS signals.
IPD = Input with internal pull-down. IPU = Input with internal pull-up.
I/OPD = Input/Output with internal pull-down. I/OPU = Input/Output with internal pull-up.
Table 2: JTAG Signals (Cont.)
JTAG Signal Type BCM5221
KPB BCM5221 KPT Description
Enable JTAG
TDI
JTAG_EN
TDI TDO
TCK
TRST#
TMS
BCM5221
TRISTATE
BUFFER
EN
TMS
TDI TDO
TCK
TRST#
TMS
JTAG
DEVICE

Product Application Note ■BCM5221
7/7/00 ■BCM5220
Broadcom Corporation
5221/5220-AN01 Product Application Note, Revision R Page 14
After the 1 is written to bit 3 of MII shadow register 1Ah, set the JTAG_EN signal high to enable JTAG operation.
Alternative Method. After a normal reset, the BCM5221 JTAG signal pins for TDI and TMS are used to source LNKLED#
and SPDLED# signals. At this point if the JTAG_EN signal is set high without first completing the above two writes, then
there is a potential contention between JTAG signals and the BCM5221 signals driving the same pins. However, even if the
Preferred Method is not followed, analysis has shown that the inherent current limiting capability of Broadcom LED output
buffers is such that there will be no reliability impact as long as the above two writes are executed within 5 seconds of
JTAG_EN being set high.
SUPPLY PINS AND POWER PLANES
This section describes the power pins and recommended power plane partitioning for the BCM5221 as well as detailed de-
scriptions of each type of power supply pin.
A solid power supply plane is always recommended for each supply required by the application. If the design calls for both
2.5V and 3.3V supples, then dedicated board layers should be provided for each supply. Fragmenting, segmenting, or oth-
erwise interrupting a power supply plane is not recommended.
The BCM5221 is essentially a 2.5V device with on-chip regulators, making it suitable for 3.3V applications. To clarify the
purpose of the power pin types, each type is listed and defined below (See Figure 1 on page 2).
OVDD. This pin supplies power to the digital input and output buffer stages of the BCM5221. By connecting OVDD to a
3.3V power rail, all of the 3.3V tolerant digital inputs accepts either CMOS or TTL input signaling or static levels. If the system
design allows for all input signaling to be limited to a maximum swing of 2.5V, the OVDD pin can be connected to the 2.5V
rail.
REGAVDD and REGDVDD. These voltage regulator input pins should be connected to the 3.3V system power rail only
if the device is to be powered from a single 3.3V supply (See Figure 1). These pins should be left unconnected in applications
where the BCM5221 is powered by 2.5V.
DVDD. In 3.3V applications, these pins serve as connection points for the internal digital core circuitry to allow for external
supply filtering. In 2.5V applications, these pins must be connected to an external 2.5V supply to supply power to the core.
AVDD. In 3.3V applications, these pins serve as connection points for the internal analog circuitry to allow for external sup-
ply filtering. In 2.5V applications, these pins must be connected to an external 2.5V supply to power the analog circuits.
BIASVDD. This pin, which supplies power to internal bias circuitry, should always be connected to the AVDD pins.
MULTI-PORT DESIGNS
For applications requiring two or three ports (such as uplinks or router designs), multiple BCM5221 PHYs can be implement-
ed.
For BCM5221 multi-port applications, Broadcom recommends that VDD and GNDare implemented via uninterrupted power
and ground planes for the entire system with the exception of chassis ground.
See Figure 8 on page 15 for a simplified illustration of a BCM5221 multi-port power plane layout recommendation.

■BCM5221 Product Application Note
■BCM5220 7/7/00
Broadcom Corporation
Page 15 5221/5220-AN01 Product Application Note, Revision R
Figure 8: Multiport Power Plane Example
10/100 TWISTED PAIR MII TO MDI
Figure 9 on page 16 represents a typical 10/100 twisted pair DTE implementations, MII to MDI inclusive, for the BCM5221.
This example assumes the use of 2.5V VDD for the system, with the digital interface running at 3.3V.
Logic Power Plane (2.5V or 3.3V)
Magnetics
Magnetics
BCM5221
RJ45-8RJ45-8
ASIC /
MAC ASIC / MAC
BCM5221
Chassis Ground Plane
