Kenwood ProTalk TK-3201 User manual

INSTRUCTION MANUAL
MODE D’EMPLOI
MANUAL DE INSTRUCCIONES
MANUALE DI ISTRUZIONI
BEDIENUNGSANLEITUNG
GEBRUIKSAANWIJZING
© B62-1980-00 (E2, T2)
09 08 07 06 05 04 03 02 01 00
ProTalk
TK-3201
UHF FM TRANSCEIVER
ÉMETTEUR-RÉCEPTEUR FM UHF
TRANSCEPTOR DE FM UHF
RICETRASMETTITORE FM UHF
UHF-FM-TRANSCEIVER
UHF FM ZENDONTVANGER

ProTalk
TK-3201
UHF FM TRANSCEIVER
INSTRUCTION MANUAL

i
THANK YOU
We are grateful for your purchase of this KENWOOD product
and welcome you to the Private Mobile Radio service
(PMR 446). PMR is a mobile communication system for both
business and personal use without the need for a license and
with no call charges.
Your KENWOOD 2-way Private Radio is called a
“transceiver”, meaning “transmitter & receiver”. We believe
this easy-to-use transceiver will provide you with dependable
and reliable communications. This KENWOOD transceiver is
a precision device. Treat it with care, and you will enjoy years
of reliable operation.
FEATURES
•16 channels with 8 operating frequencies and 38 tone/ code
settings for each channel allows you to ignore unwanted calls.
•Built in voice scrambler gives you complete privacy for your
conversations.
•Hands free operation when using an optional headset.
•Voice announcement lets you know which channel you have
selected and which settings you have made when reassigning
key functions and channel settings.
OPERATING CONDITIONS
snoitacolnepO
)snoitcurtsboon( mk4.6otpU
saeralaitnediseR
)sgnidliubraen( mk4.2otpU
decrofnieretercnoc/leetsnI
sgnidliub m085,81otpU
2
sesirhgihnIsroolf51otpU
Note: The listed ranges are based on field testing and may vary with
your operating conditions and individual transceiver.

ii
NOTICES TO THE USER
◆Government law prohibits the operation of unlicensed radio
transmitters within the territories under government control.
◆Illegal operation is punishable by fine and/or imprisonment.
◆Refer service to qualified technicians only.
SAFETY: It is important that the operator is aware of and
understands hazards common to the operation of any
transceiver.
PRECAUTIONS
•Do not charge the transceiver and battery pack when they are
wet.
•Ensure that there are no metallic items located between the
transceiver and the battery pack.
•Do not use options not specified by KENWOOD.
•If the die-cast chassis or other transceiver part is damaged, do
not touch the damaged parts.
•If a headset or headphone is connected to the transceiver, reduce
the transceiver volume. Pay attention to the volume level when
turning the squelch off.
•Do not place the microphone cable around your neck while near
machinery that may catch the cable.
•Do not place the transceiver on unstable surfaces.
•Ensure that the end of the antenna does not touch your eyes.
•When the transceiver is used for transmission for many hours, the
radiator and chassis will become hot. Do not touch these
locations when replacing the battery pack.
•Do not immerse the transceiver in water.
•Always switch the transceiver power off before installing optional
accessories.

iii
Turn the transceiver power off in the following locations:
•In explosive atmospheres (inflammable gas, dust particles,
metallic powders, grain powders, etc.).
•While taking on fuel or while parked at gasoline service stations.
•Near explosives or blasting sites.
•In aircrafts. (Any use of the transceiver must follow the
instructions and regulations provided by the airline crew.)
•Where restrictions or warnings are posted regarding the use of
radio devices, including but not limited to medical facilities.
•Near persons using pacemakers.
•Do not disassemble or modify the transceiver for any reason.
•Do not place the transceiver on or near airbag equipment while
the vehicle is running. When the airbag inflates, the transceiver
may be ejected and strike the driver or passengers.
•Do not transmit while touching the antenna terminal or if any
metallic parts are exposed from the antenna covering.
Transmitting at such a time may result in a high-frequency burn.
•If an abnormal odor or smoke is detected coming from the
transceiver, switch the transceiver power off immediately, remove
the battery pack from the transceiver, and contact your
KENWOOD dealer.
•Use of the transceiver while you are driving may be against traffic
laws. Please check and observe the vehicle regulations in your
area.
•Do not expose the transceiver to extremely hot or cold
conditions.
•Do not carry the battery pack (or battery case) with metal objects,
as they may short the battery terminals.
•When operating the transceiver in areas where the air is dry, it is
easy to build up an electric charge (static electricity). When using
a earphone accessory in such conditions, it is possible for the
transceiver to send an electric shock through the earphone and
to your ear. We recommend you use only a speaker/microphone
in these conditions, to avoid electric shocks.

iv
CONTENTS
UNPACKING AND CHECKING EQUIPMENT ................................... 1
SUPPLIED ACCESSORIES ......................................................... 1
ORIENTATION .................................................................... 3
PREPARATION ................................................................... 4
BATTERY PACK PRECAUTIONS .................................................... 4
CHARGING THE BATTERY PACK ................................................... 8
INSTALLING/ REMOVING THE BATTERY PACK ..................................... 10
INSTALLING THE BELT CLIP ..................................................... 11
INSTALLING THE COVER OVER THE SPEAKER/ MICROPHONE JACKS ................. 11
INSTALLING THE OPTIONAL SPEAKER/ MICROPHONE (OR HEADSET) ................ 12
GETTING STARTED ............................................................. 13
VOICE OPERATED TRANSMISSION (VOX) .................................. 14
VOX GAIN ................................................................... 14
VOX OPERATION .............................................................. 16
KEY FUNCTIONS ............................................................... 17
CALL KEY .................................................................... 17
MONITOR KEY ................................................................ 17
BACKGROUND OPERATIONS ................................................. 18
TIME-OUT TIMER (TOT) ....................................................... 18
LOW BATTERY WARNING ....................................................... 18
CHANNEL ANNUNCIATION ....................................................... 18
QUIET TALK (QT)/ DIGITAL QUIET TALK (DQT) ................................ 18
CHANNEL SETUP MODE ....................................................... 19
CHANNEL OPERATING FREQUENCIES ............................................. 21
QUIET TALK (QT)/ DIGITAL QUIET TALK (DQT) SETTINGS ....................... 23
CHANNEL CONFIRMATION MODE ................................................ 26
KEY ASSIGNMENT MODE ..................................................... 27
CALLING ALERT ............................................................... 29
KEY LOCK .................................................................... 30
MONITOR/ SQUELCH OFF ...................................................... 30
SCAN ......................................................................... 31
SCRAMBLER ................................................................... 33
OPTIONAL ACCESSORIES ..................................................... 34
TROUBLESHOOTING GUIDE .................................................. 35

1
UNPACKING AND CHECKING EQUIPMENT
Carefully unpack the transceiver. We recommend you identify
the items listed in the following table before discarding the
packing material. If any items are missing or have been
damaged during shipment, file a claim with the carrier
immediately.
SUPPLIED ACCESSORIES
Note: A type code (E2 or T2) can be found on the label attached to
the package box.
metI rebmuNtraP ytitnauQ
)53-CSK(regrahcyrettaBXX-8890-80W1
retpadaCA 2EedocepyTXX-2990-80W1
2TedocepyTXX-3990-80W1
iLi-)L54-BNK(kcapyrettabnoXX-3301-90W1
revockcajenohporcim/rekaepSXX-0860-90B1
gnikcolenohporcim/rekaepS
tekcarb XX-2745-91J1
)01-HBK(pilctleBXX-3170-92J1
teswercSXX-6402-99N1
launamnoitcurtsnIXX-0891-26B1

2
Belt clip (KBH-10)
Speaker/ microphone
jack cover
Screw set
Speaker/ microphone
locking bracket
Li-ion battery pack
(KNB-45L)
Battery charger
(KSC-35)
AC adapter (T2)
AC adapter (E2)

3
ORIENTATION
Antenna
LED indicator
Indicates the transceiver
status. Lights red while
transmitting, green while
receiving, and flashes
red while the battery
power is low while
transmitting.
PTT (Push to
Talk) switch
Press and hold,
then speak into
the microphone
to transmit.
Call key
Press before
making a call, to
alert the other
party members
{page 17}.
Monitor key
Press and hold
to hear background
noise and listen
for weak signals
{page 17}.
Speaker/
microphone
jacks
Battery pac
k
(KNB-45L)
Channel selector
Rotate to change the
operating channel
from 1 ~ 16.
Power switch/
Volume control
Turn clockwise to
switch the power ON
and counterclockwise
to switch the power
OFF. Rotate to adjust
the volume.
Note: The Call and Monitor keys can be reprogrammed {page 27}.

4
PREPARATION
BATTERY PACK PRECAUTIONS
Do not use battery packs or battery chargers not
recommended by KENWOOD.
◆Do not recharge the battery pack if it is already fully charged.
Doing so may cause the life of the battery pack to shorten or the
battery pack may be damaged.
◆After recharging the battery pack, disconnect it from the charger.
If the charger power is reset (turned ON after being turned OFF),
recharging will start again and the battery pack will become
overcharged.
◆Do not use the transceiver while charging the battery pack. We
recommend you switch the transceiver power OFF while
charging is taking place.
◆Do not charge the battery pack when the battery pack or
transceiver is wet, to avoid the risk of fire or damage. Wipe the
water from the battery pack or transceiver using a dry cloth
before charging.
◆Do not short the battery terminals or dispose of the battery by
fire.
◆Never attempt to remove the casing from the battery pack.
Information concerning the Li-ion battery pack:
The battery pack includes flammable objects such as organic
solvent. Mishandling may cause the battery to rupture
producing flames or extreme heat, deteriorate, or cause other
forms of damage to the battery. Please observe the following
prohibitive matters.
•Do not disassemble or reconstruct battery!
The battery pack has a safety function and protection circuit to avoid
danger. If they suffer serious damage, the battery may generate heat
or smoke, rupture, or burst into flame.
DANGER
