SPECIFICATION SHEET
90B 99044082B
SPECIFICATIONS
VOLTS AMPS CFM SONES DUCT
HIGH NORMAL HIGH NORMAL
120 1.9 190 100 6.0 2.0 3¼" X 10" (H)
120 1.9 190 130 6.0 2.0 3¼" X 10" (V)
120 1.9 230 150 6.0 2.0 7" Round (V)
120 1.9 -- -- -- -- Non-Ducted
QL1 SERIES
4-WAY
CONVERTIBLE
RANGE HOOD
HVI-2100 CERTIFIED RATINGS comply with new testing
technologies and procedures prescribed by the Home
Ventilating Institute, for off-the-shelf products, as they are
available to consumers. Product performance is rated at 0.1 in.
static pressure, based on tests conducted in a state-of-the-art
test laboratory. Sones are a measure of humanly-perceived
loudness, based on laboratory measurements.
Deluxe features in our smaller shell - offers the
most hood for the money.
FEATURES
•2-speed fan control
•Polymeric blade and light lens (accepts two 60W bulbs)
• Washablealuminumlter
•Converts to non-ducted by removing cover plate from
controlpanelandinstallingthenon-ductedlterBPQTF
(purchase separately)
• 3¼" x 10" damper/duct connector included
•7" round duct adapter plate included
•Mitered sides and hemmed bottom for safety,
cleanability and good looks
• Contemporary styling in White and Biscuit
• Available in 30" width only
Broan-NuTone LLC Hartford, Wisconsin www.broan.com 800-558-1711
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
TYPICAL SPECIFICATION
RangehoodshallbeBroanQL1Series.
Unit shall be convertible between ducted (using a washable
aluminum lter) and non-ducted (using non-ducted lter
BPQTF).
Motor to be permanently lubricated.
Unit shall have a 2-speed fan control with separate 2-level
light switch.
Sides shall be mitered and bottom edge hemmed with no
sharp edges.
Air delivery shall be no less and sound levels no greater than
shown.AllairandsoundratingsshallbecertiedbyHVI.
Unit shall be U.L. listed.
