Broan RM50000 Series User manual

RM50000
Series
ENGLISH......................................2

2
READ AND SAVE THESE INSTRUCTIONS
WARNING
SUITABLE FOR USE IN HOUSEHOLD
COOKINGAREA.
TOREDUCETHERISKOFFIRE,ELECTRICAL
SHOCK,ORINJURYTOPERSONS,OBSERVE
THEFOLLOWING:
1. Use this unit only in the manner intended by
themanufacturer.If youhave questions, con-
tact the manufacturer at the address or tele-
phonenumberlisted in thewarranty.
2. Beforeservicingorcleaningunit,switchpower
off at service panel and lock service panel to
prevent power from being switched on
accidentally.When theservice disconnecting
means cannot be locked, securely fasten a
prominent warning device, such as a tag, to
theservice panel.
3. Installationwork and electricalwiring mustbe
done by a qualified person(s) in accordance
withallapplicablecodesandstandards,includ-
ing fire-rated construction codes and stan-
dards.
4. Sufficientairis neededforproper combustion
andexhaustingofgasesthroughtheflue(chim-
ney) of fuel burning equipment to prevent
backdrafting. Follow the heating equipment
manufacturer’s guidelines and safety stan-
dardssuchasthosepublishedbytheNational
Fire Protection Association (NFPA), and the
American Society for Heating, Refrigeration
andAirConditioningEngineers(ASHRAE),and
thelocalcode authorities.
5. Whencutting or drilling intowall or ceiling, do
notdamageelectrical wiring andotherhidden
utilities.
6. Ductedfansmustalwaysbeventedtotheout-
doors.
7. Donotuse this unitwithany solid-statespeed
controldevice.
8. To reduce the risk of fire, use only steel
ductwork.
9. Thisunitmust begrounded.
TO REDUCE THE RISK OF A RANGE TOP
GREASEFIRE:
A. Neverleavesurfaceunitsunattendedathighsettings.
Boiloverscausesmokingandgreasyspilloversthat
mayignite.Heatoilsslowlyonlowormediumsettings.
B. Alwaysturn hood ONwhen cookingathigh heator
whencookingflamingfoods.
C. Cleanventilatingfansfrequently.Greaseshouldnot
beallowed toaccumulateonfanorfilter.
D. Useproperpansize.Alwaysusecookwareappropriate
forthesizeofthesurfaceelement.
WARNING
TO REDUCE THE RISK OF INJURY TO PER-
SONS IN THE EVENT OF A RANGE TOP
GREASEFIRE,OBSERVETHEFOLLOWING:*
1. SMOTHER FLAMES with a close-fitting lid,
cookie sheet, or metal tray, then turn off the
burner.BECAREFULTOPREVENT BURNS.
Iftheflamesdonotgooutimmediately,EVACU-
ATEAND CALLTHEFIREDEPARTMENT.
2. NEVER PICKUPAFLAMING PAN -Youmay
beburned.
3. DONOTUSEWATER,includingwetdishcloths
ortowels - violentsteam explosionwill result.
4. Useanextinguisher ONLYif:
A. You know you have a Class ABC extin-
guisherand you already know how to op-
erateit.
B. The fire is small and contained in the area
whereit started.
C. Thefire department isbeingcalled.
D. You can fight the fire with your back to an
exit.
* Based on “Kitchen Fire Safety Tips” pub-
lishedbyNFPA.
CAUTION
1. Toreduceriskoffireandtoproperlyexhaustair,
besuretoductairoutside.Donotventexhaust
air into spaces within walls or ceilings or into
attics,crawlspaces, or garages.
2. Take care when using cleaning agents or
detergents.
3. Avoidusingfoodproductsthatproduceflames
undertheRangeHood.
4. For general ventilating use only. Do not use to
exhausthazardousorexplosivematerialsand
vapors.
5. Toavoidmotorbearingdamageandnoisyand/
or unbalanced impellers, keep drywall spray,
constructiondust,etc.off power unit.
6. Yourhood motor hasathermaloverloadwhich
willautomaticallyshutoffthemotorifitbecomes
overheated.Themotorwillrestartwhenitcools
down. If the motor continues to shut off and
restart,havethehoodserviced.
7. For best capture of cooking impurities, the
bottomofthehoodshouldbeaminimumof24"
anda maximum of30" above the cooking sur-
face.
8. Twoinstallersarerecommendedbecauseofthe
largesizeand weight ofthishood.
9. Please read specification label on product for
furtherinformationandrequirements.

3
FRAMING BEHIND DRYWALL
ADDITIONAL
MOUNTING
SCREWS
RECTANGULAR
CUTOUT
HEIGHT
ADJUSTMENT
SCREWS
36 3/4"= bottom of hood 24" above
cooktop
42 3/4"= bottom of hood 30" above
cooktop
ROOF CAP
6” ROUND
DUCT
DECORATIVE
FLUE
HOOD
WALL
CAP
6”
ROUND
ELBOW
24” TO 30” ABOVE
COOKING SURFACE
36 3/4 to 42 3/4
above cooktop
INSTALL BACKSPLASH (OPTIONAL)
If optional backsplash is used, attach it to the
finished wall. Secure hood mounting bracket
to the backsplash and omit wall framing
described below.
INSTALL MOUNTING
BRACKET
1. Construct wood wall framing that is flush
with interior surface of wall studs.
Make sure:
a) the framing is centered over installation location.
b) the height of the framing will allow the mounting bracket to be secured to the
framing within the dimensions shown.
2. Afterwallsurfaceisfinished,securemountingbrackettoframingusingdimensions
shown.
INSTALL THE HOOD
1. Hang the hood from the bracket through the rectangular cut-out on the back of
the hood. Cut-out is
larger than the bracket to
allow for horizontal
adjustment.Thebottomof
the hood should be 24"
to 30" above the cooking
surface.
2. Height adjustment
screws provide vertical
adjustment.
3. Secure the hood with
additional mounting
screws. Use drywall
anchors, provided, if wall
studs or framing are not
available.
WALL FRAMING
MOUNTING
BRACKET
INSTALL THE DUCTWORK
NOTE: To reduce the risk of fire, use only
metal ductwork.
1. Decide where the ductwork will run
between the hood and the outside.
2. A straight, short duct run will allow the hood
to perform most efficiently.
3. Long duct runs, elbows, and transitions will
reduce the performance of the hood. Use
as few of them as possible.
4. Install a roof or wall cap. Connect 6" round
metal ductwork to cap and work back to-
wards hood location. Use duct tape to seal
the joints between ductwork sections.

4
WIRING
Note: This range hood must be properly
grounded.The unit should be installed by a
qualified electrician in accordance with all
applicable national and local electrical
codes.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the
event of an electrical short circuit, grounding
reducestheriskofelectricshockbyproviding
an escape wire for the electric current. This
appliance is equipped with a cord having a
grounding wire with a grounding plug. The
plug must be plugged into an outlet that is
properly installed and grounded.
WARNING - Improper grounding can result in a risk of electric shock.
Consult a qualified electrician if the grounding instructions are not completely
understood, or if doubt exists as to whether the appliance is properly grounded.
Do not use an extension cord. If the power supply cord is too short, have a qualified
electrician install an outlet near the appliance.
Set the electrical power supply within the space covered by the decorative flues.
Position the power socket at a maximum distance of 33-7/16” (850 mm) from where
the lead exits from the hood (see illustration alongside). Make sure this does not
interfere with the bracket fastening area or with the decorative pipe (where the flue
touches the wall).
Fit the plug into the power socket.
CONNECT DUCTWORK
Adjust the width of the flue mounting bracket using screws (A) indicated in Figure.
Use screws (B) and wall anchors to secure flue mounting bracket to the ceiling as
shown.
FLUE MOUNTING
BRACKET
SCREWS A
SCREWS B
=
=

5
UPPER
FLUE SECTION
DUCTFREE
PLENUM
AIR
VENTS
(in upper flue section)
UPPER
BRACKET
LOWER
FLUE SECTION DUCT
SEAM
DISCHARGE
COLLAR
MEASURE
5" ROUND
METAL DUCT
DuctedConfiguration
1. Use 6" round metal duct to connect the
duct collar on the hood to the ductwork
above.
2. Use duct tape to make all joints secure
and air tight.
3. Insert the decorative flues setting them on
the hood.
4. Extend the upper flue to the ceiling and
secure with the 2 screws (C).
6" ROUND
METAL DUCT
DUCT TAPE
DECORATIVE
FLUE
Ductfree Configuration
1. Turn upper flue section upside
down so air vents are at the top.
Slide upper flue section into
lowerflue section.
2. Connect the ductfree plenum to
theupperfluesectionwith(4)flat-
head screws (supplied).
3. Install the reduction on the
discharge collar.
4. Measure the distance from the
topofthereductiontotheceiling.
Cut a length of 5" round metal
duct 5" shorter than this
dimension.
5. Fit duct section over the ductfree
plenum. For best fit, make sure
duct seam is toward the front.
6. Set duct/flue assembly on hood
with top tilted away from wall.
Reach around flue to engage
bottom of duct with discharge
collaronhood.Tiltflueupagainstwall.Ductseamcanbecuttolengthifnecessary.
7. Extend the upper flue to the ceiling and secure with the 2 screws (C).
FASTEN FLUE TO
UPPER BRACKET
WITH SCREWS (C)
REDUCTION

6
MAINTENANCE
Proper maintenance of the Range Hood will
assure proper performance of the unit.
Grease Filter
The grease filter should be cleaned fre-
quently. Use a warm detergent solution.
Grease filter is dishwasher safe.
Remove filter by pushing filter towards the
back of hood and rotating filter downward.
Ductfree Filters
The ductfree filters should be changed every 6 months. Rotate the filters to remove
and replace.
HoodCleaning
Stainless steel is one of the easiest materials to keep clean. Occasional care will help
preserve its fine appearance.
Cleaning tips:
• Hot water with soap or detergent is all that is usually needed.
• Follow all cleaning by rinsing with clear water. Wipe dry with a clean, soft cloth to
avoid water marks.
• Fordiscolorationsordepositsthatpersist,useanon-scratchinghouseholdcleanser
or stainless steel polishing powder with a little water and a soft cloth.
• For stubborn cases, use a plastic scouring pad or soft bristle brush together with
cleanser and water. Rub lightly in direction of polishing lines or "grain" of the
stainless finish. Avoid using too much pressure which may mar the surface.
•DO NOT allow deposits to remain for long periods of time.
•DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere
to the surface causing rust.
•DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds to
remain in contact with stainless steel for extended periods. Many of these com-
pounds contain chemicals which may be harmful. Rinse with water after expo-
sure and wipe dry with a clean cloth.
Painted surfaces should be cleaned with warm water and mild detergent only.
GREASEFILTER
DUCTFREE FILTER
INSTALLATION
1. Ductfree filter kit (B08999634) is included.
2. Position the filters over the blower.
3. Rotate to lock filters in place.
DUCTFREE
FILTERS

7
OPERATION
Controls
The hood is operated using the slide controls
under the bottom of the hood.
The light switch turns the lamps on and off.
Theblower switch:makesitpossibletoselect
the motor operating speed. Position 0: motor
off.
The pilot lamplights up whenever the blower
is on.
LIGHT
SWITCH
PILOT
LAMP
BLOWER
SWITCH
LIGHT BULBS
This range hood requires two 40-Watt light
bulbs (included).
ALWAYS SWITCH OFF THE ELECTRICITY
SUPPLY BEFORE CARRYING OUT ANY
OPERATIONS ON THEAPPLIANCE.
To change bulbs:
1. Remove the screw securing the light fitting.
2. Replace with light bulbs of the same type.
CAUTION:BULBMAYBEHOT!
BROAN-NUTONE LLC ONE YEAR LIMITED WARRANTY
Broan-NuTone LLC warrants totheoriginal consumer purchaser of itsproductsthat such products will be freefromdefects
in materials or workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WAR-
RANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITEDTO, IMPLIED WARRANTIES OR MERCHANT
ABILITY OR FITNESS FORAPARTICULAR PURPOSE.
Duringthisone-yearperiod,Broan-NuToneLLCwill,atitsoption,repairorreplace,withoutcharge,anyproductorpart which
isfound to be defective under normaluseand service.
THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS, TUBES, HALOGEN AND
INCANDESCENDTBULBS. Thiswarrantydoesnot cover (a) normal maintenance and service or(b)anyproductsorparts
whichhavebeensubjectto misuse, negligence,accident,impropermaintenanceorrepair(other thanbyBroan-NuTone LLC),
faultyinstallation or installation contrary to recommended installationinstructions.
Thedurationofanyimplied warranty is limited to the one-year periodasspecifiedfortheexpresswarranty. Some statesdo
not allow limitation on how long an implied warranty lasts, so the above limitation may not apply to you.
BROAN-NUTONE LLC’S OBLIGATIONTOREPAIR OR REPLACE,AT BROAN-NUTONE LLC’S OPTION, SHALL BE
THE PURCHASER’S SOLEAND EXCLUSIVE REMEDY UNDERTHIS WARRANTY. BROAN-NUTONE LLC SHALL
NOTBE LIABLE FOR INCIDENTAL, CONSEQUENTIALOR SPECIALDAMAGESARISING OUT OF OR IN CONNEC-
TION WITH PRODUCT USE OR PERFORMANCE. Some states do not allow the exclusion or limitation of incidental or
consequentialdamages, so the above limitationorexclusion may not applytoyou.
Thiswarrantygivesyouspecificlegalrights,and you may alsohaveotherrights,whichvaryfromstatetostate. Thiswarranty
supersedes all prior warranties.
To qualify for warranty service, youmust(a)notify th company at the addressstated (b) give the model number and part
dentificationand(c)describethenatureofanydefectintheproductorpart. Atthe time of requesting warranty service,
youmust present evidence ofthe original purchase date.
WARRANTY
