Broce K00037 User manual

Pressurized Cab Filter K00037
• Your Broce Broom comes with a
standard lter. This how-to shows you
how to change it and install a pressurized
cab lter.
1. Start by removing the lter from the front of
the broom.
2. You’ll want to remove the hose clamp rst.
3. After you’ve removed the hose clamp, while
stabilizing the lter, remove the two screws
located at the top.
4. Once the lter is off, you can start prepping
the new pressurized lter to be installed onto
the cab.
5. Your new cab lter comes with the lter
itself and the wires needed. You will need to
change out the end of the wire provided.
6. The wire has two ends. One end is shaped
like a triangle and one is shaped like a
rectangle. Clip the rectangle end off.
7. Next pull the plastic covering out from that
end about 3 inches and cut that off. When you
slide it back down in place, the end wires will
be exposed.
8. Strip the ends of the wires.
2
3

Pressurized Cab Filter K00037
9. Grab the two ends that come in your kit.
One is grey and the other is blue. They blue
end goes on the red wire and the grey end
goes on the black wire.
10. Once you’ve prepped your wires you can
prep your new lter.
11. The lter attachment needs to be rotated
180 degrees to the other side of the
pressurized lter. Start by removing the 4
screws located on the top. Next, loosen the
screws on the clamp around the middle of the
lter. Then rotate the silver assembly around.
You can then put the 4 screws back on the top
and tighten the screws back on the clamp.
12. You now need to switch the mounting
piece from the old lter to the new one. There
are two brackets with 4 screws that need to
be removed.
13. Take the plate that was included in your kit
and lay it over the two brackets. You’ll want to
attach the brackets to that plate. There are 6
holes in the plate. You are only going to use
the 4 outside holes for this install. Leave the
bottom or 4th screw off for now.
14. Now set the new lter onto the plate. Your
new lter has 3 bolt holes that are going to go
into the middle two on the plate and the far
right hole that we left open. Attach
everything. There should be a total of 6 bolts
to attach the plate to the new lter.
6
9
11

Pressurized Cab Filter K00037
15. You’re now going to mount the lter back
onto the broom the same way you took it off.
It is ideally a job for 2 people but with time,
one person can get it attached.
16. Once attached, you’ll need to connect the
hosing back together and the wiring.
17. For the wiring, the triangle end should t
back into where you removed it from. Then
take the modied end and come over behind
the horn and unplug the white wire. Also
remove the nut on the black wire which is
where you will ground it to.
18. Now plug the red wire into where the
white one was. Then put the white one back
one. Next take the black wire and put it in the
ground spot and reattach the screw.
19. After everything is attached, it’s a good
idea to take any loose wires and zip tie them
up so that they are out of the way. Best place
is to tuck it in between the lter and the hose.
20. Lastly, install a 25 amp fuse into position
#9 in the fuse box which is located in the cab.
13
14
17
You can see a video of this install on
the Broce website or by visiting our
YouTube channel.
