Brock MEYER ENERGY MISER ME1000S Quick start guide

2022
For Intui-DRY® Controller Alarms/Levels/Color Codes,
and FAULT CODES displayed on the Intui-DRY screen, refer to:
the Intui-DRY® Controller Manual MFH2191 or MEYER Owner/Operator Manual MFH1937.
Tower Dryer
ME1000S/SG-ME2650S/SG
LICENSED and
QUALIFIED
ELECTRICIANS ONLY!
MFH1968-3GMarch 2022
SCHEMATICS and FAULT CODES
ORIGINAL INSTRUCTIONS • ENGLISH

SAFE Electrical Installations BROCK® MEYER® Schematics
2MFH1968-3G
SAFETY First!
This symbol is used throughout this Manual to identify particular stages where the
bin Contractor and/or Operator need to take special note and precautions regarding
the danger described in these Instructions. Please read all the SAFETY information
and the instructions completely prior to beginning the construction.
Recognize and Understand SAFETY Information
This is the Safety-Alert Symbol. When you see this symbol on your equipment or in
this Manual, be alert to the potential for personal injury. It may be used alone or in
conjunction with a signal word. Signal words DANGER, WARNING, or
CAUTION, are used with the Safety-Alert Symbol. Be sure to follow ALL national,
state and local safety standards governing each installation site.
DANGER! Electricity can KILL! All electrical installations and testing MUST be done by a
QUALIFIED and properly certified/licensed ELECTRICIAN, in accordance with
all applicable national, state/provincial and local codes. Brock Grain Systems
neither will be liable for damage to the Dryer or to person(s) because of
unqualified electrical testing, installation or use. Improper procedures willvoid
the Warranty. Failure to follow these instructions will create an imminently
hazardous situation which, if not avoided, will result in serious injury that
could lead to death. See the chapter on Electrical Installations.
IMPORTANT! It is the responsibility of the Contractor, Installer, Owner and Operator to
supplement the Dryer furnished by Brock Grain Systems with any necessary
ELECTRICAL or STRUCTURAL items to make the Dryer installation comply
with the National Electric Code, National Electric Safety Code, and OSHA
(U.S.); the Canadian Electrical Code (Canada); and any other applicable
federal, state and local laws and ordinances.
SAFE Electrical Installations
Think SAFETY!
Work SAFELY!
Symbol Description
DANGER is a signal word that indicates an imminently hazardous
situation which, if not avoided, WILL result in death or serious injury.
WARNING is a signal word that indicates a potentially hazardous situation
which, if not avoided, COULD result in death or serious injur y.
CAUTION is a signal word that indicates a hazardous situation which,
if not avoided, MAY result in minor or moderate injury.
IMPORTANT indicates vital information or instructions, highly
recommended and/or pertinent, for the safe installation or operation
of your equipment. It may have a pictogram to indicate mandatory
equipment (i.e., PPE) or action (i.e., grounding, read the manual).
This is the International PROHIBITION Sign, or NO Sign, which indicates
something (i.e. smoking) is not permitted.
This internationally recognized HAZARD symbol is customized with
a pictogram showing the general type of DANGER.
© 2022 Brock Grain Systems. All rights reserved.
All product names in this Manual are trademarked or copyrighted by their respective owners. All rights reserved.
This Manual may not, in whole or in part, be copied, reproduced, or converted to digital format without prior written
consent of Brock Grain Systems. Details herein are subject to change without notice. Printed in the United States.

BROCK® MEYER® Schematics SAFE Electrical Installations
MFH1968-3G 3
Qualified Electrical Personnel ONLY!
WARNING! Procedures in this Manual are intended for use by qualified electricians ONLY!
Failure by qualified electrical installers to read and/or understand the contents
of this Manual, and/or the failure to follow proper procedures outlined in this
Manual—BEFORE Dryer testing and startup—constitutes a misuse of the
equipment and an unsafe situation that could result in death or serious injury,
and/or could damage the equipment and void the Warranty.
This Manual contains diagrams and basic steps to provide the qualified electrical
Installer with information for a safe installation. Due to the customized design of the
BROCK® MEYER® Dryer some electrical installation remains at the Installer’s
discretion according to all applicable federal, provincial/state and local laws and
codes. Follow recommended precautions and safe operating practices of national and
local codes at each installation site.
IMPORTANT! It is the responsibility of the Contractor, Installer, Owner and Operator to
supplement the Dryer furnished by Brock Grain Systems with any necessary
ELECTRICAL or STRUCTURAL items to make the Dryer installation comply
with the National Electric Code, National Electric Safety Code, and OSHA
(U.S.); the Canadian Electrical Code (Canada); and any other applicable
federal, state and local laws and ordinances.
Always use properly rated/insulated PPE when working near sources of electricity
and other hazards. Installation is not complete until a SAFETYSystems checkout is
run to see that all SAFETY systems are in working order. This must be done before
initial startup. It should also be done at the beginning of each season, and any
components replaced if necessary.

Table of Contents BROCK® MEYER® Schematics
4MFH1968-3G
SAFE Electrical Installations.......................................................................................................................... 2
Safety First! • Recognize and Understand Safety Information ............................................................................2
Qualified Electrical Personnel Only! .......................................................................................................................3
Intui-DRY® Controller: The Brain of the Dryer.......................................................................................... 5
Allen-Bradley Power Flex 525 Setups..........................................................................................................6-10
Display and Control Keys • Control and Navigation Keys.......................................................................6-7
Viewing and Editing Parameters...................................................................................................................8-9
Setup for 5 HP 230V • Setup for 5 HP 380V................................................................................................... 10-11
Setup for 5 HP 400V • Setup for 5 HP 460V................................................................................................... 11-12
Setup for 5 HP 600V ...............................................................................................................................................13
Setup for 15 HP 230V Drive, Single-Phase Input, 5 HP Motor....................................................................14
Allen-Bradley Power Flex 525 Fault Code Descriptions..........................................................................15-17
Honeywell® Fault Codes.............................................................................................................................18-23
Honeywell® Burner Control Faults (Blink Codes) ..........................................................................................18
Honeywell® Keyboard Display Module Sequence and Status Hold Messages............................................18-19
Honeywell® Fault Codes: Hold and Fault Message Summary.....................................................................20-23
Error Codes Indicate Linear Limit Trips.....................................................................................................24
Set/Reset L/R Thermostats................................................................................................................................24
Electrical Symbols...........................................................................................................................................25
Minimum LOCKOUT/TAGOUT Energy Control Procedures...............................................................26-27
Schematics (attachment MFH1968-3F-S)
Wiring Diagram - Power Circuit 2011 + ME1000S - 2650S ..................................................................... 3124-00061
Intui-DRY® Unload Cont. AB525 MEYER and BCT ................................................................................3924-00001
Honeywell Internal Connections DIF, 8-Pin (Canada) ................................................................................3924-00021
Honeywell 7800 Connections Dual UV, 10-Pin (Canada)...........................................................................3924-00023
Wye-Delta Start Option, All Dryers Intui-DRY® 2021...............................................................................3924-00027
Wiring Diagram, Power Section and External Components, ME1000SG-2650SG (Canada) ................... 3924-00046
Electrical Schematic Control Wiring, MEYER Intui-DRY® ......................................................................3924-00047
Electrical Schematic Control Wiring Block-and Bleed w/Honeywell®
and Intui-DRY® (Canada
....................................................................................................................3924-00048
MEYER Control Wiring w/Intui-DRY®
Block-and Bleed w/Honeywell UV (Hungarian)......................3924-00049
Power Section and External Components, MEYER 1000S-2650S (Hungarian).........................................3924-00050
Wiring Diagram, Power Section, ME1000S-2650S (U.S.) ........................................................................ 3924-00052
Table of Contents

BROCK® MEYER® Schematics Intui-DRY® Controller: the Brain of the Dryer
MFH1968-3G 5
Manual MFH2191 is necessary for installing the Intui-DRY® Controller.
The Installer will need schematic drawings 3924-00001, 3924-00031 and 3924-
00033 (Block-and-Bleed) to install the Intui-DRY Controller on the MEYER®
Dryer. Those are included in the back of this Manual and in the Intui-DRY Manual.
Other than factory-approved software options or upgrades described in the Manual,
no other equipment or devices are to be mounted or installed inside the red
Control Cabinet. All auxiliary equipment (contactors, relays, motors, etc.) must be
mounted separately in the red MEYER® Power Cabinet.
Intui-DRY® Controller: the Brain of the Dryer
Intui-DRY® Manual MFH2191

Allen-Bradley Power Flex 525 Setups BROCK® MEYER® Schematics
6MFH1968-3G
Display and Control Keys
Allen-Bradley Power Flex 525 Setups

BROCK® MEYER® Schematics Allen-Bradley Power Flex 525 Setups
MFH1968-3G 7
Control and Navigation Keys

Allen-Bradley Power Flex 525 Setups BROCK® MEYER® Schematics
8MFH1968-3G
Viewing and Editing Parameters
The following is an example of basic integral keypad and display functions. This example provides basic
navigation instructions and illustrates how to program a parameter.

BROCK® MEYER® Schematics Allen-Bradley Power Flex 525 Setups
MFH1968-3G 9
Setup for 5 HP 230V
Parameter
Group No. Name Default BROCK Setting
P
34 Motor NP FLA 12.8 13.4
36 Motor NP RPM 1750 1800
39 Torque Perf Mode SVC 0
41 Accel Time 1 10 30
42 Decel Time 1 10 30
44 Maximum Freq 60 120
46 Start Source 1 Keypad 2
47 Speed reference1 Drive Pot 13
48 Start Source 2 DigIn TrmBlk 1
49 Speed Reference2 0-10V input 1
51 Speed Reference3 EtherNet/IP 5
T
62 DigIn TermBlk 02 2-Wire FWD 49
63 DigIn TermBlk 03 2-Wire REV 0
65 DigIn TermBlk 05 Preset Freq 13
66 DigIn TermBlk 06 Preset Freq 24
67 DigIn TermBlk 07 Spd + Strt 2 2
68 DigIn TermBlk 08 Jog Forward 0
81 Relay Out2 Sel MotorRunning 24
105 Safety Open En FaultEnable 1
C
128 EN Addr Sel BOOTP 1
129 EN IPAddr Cfg 1 0 192
130 EN IPAddr Cfg 2 0 168
131 EN IPAddr Cfg 3 0 1
132 EN IPAddr Cfg 4 0 1
133 EN Subnet Cfg 1 0 255
134 EN Subnet Cfg 2 0 255
135 EN Subnet Cfg 3 0 255
L
180 Stp Logic 0 00F1 21
181 Stp Logic 1 00F1 4021
182 Stp Logic 2 241 4021
183 Stp Logic 3 241 3811
190 Stp Logic Time 0 30 20
191 Stp Logic Time 1 30 90
192 Stp Logic Time 2 30 10
193 Stp Logic Time 3 30 2
A
410 Preset Freq 0 0 8
411 Preset Freq 1 5 30
412 Preset Freq 2 10 8
413 Preset Freq 3 20 0
439 S Curve % 0 10
531 Start Boost 2.5 8
556 Text Scroll Mid Speed 0

Allen-Bradley Power Flex 525 Setups BROCK® MEYER® Schematics
10 MFH1968-3G
Setup for 5 HP 380V
Parameter
Group No. Name Default BROCK Setting
P
31 Motor NP Volts 460 380
32 Motor NP Hertz 60 50
34 Motor NP FLA 12.8 13.4
36 Motor NP RPM 1750 1440
39 Torque Perf Mode SVC 0
41 Accel Time 1 10 30
42 Decel Time 1 10 30
44 Maximum Freq 60 120
46 Start Source 1 Keypad 2
47 Speed Reference1 Drive Pot 13
48 Start Source 2 DigIn TrmBlk 1
49 Speed Reference2 0-10V input 1
51 Speed Reference3 EtherNet/IP 5
T
62 DigIn TermBlk 02 2-Wire FWD 49
63 DigIn TermBlk 03 2-Wire REV 0
65 DigIn TermBlk 05 Preset Freq 13
66 DigIn TermBlk 06 Preset Freq 24
67 DigIn TermBlk 07 Spd + Strt 2 2
68 DigIn TermBlk 08 Jog Forward 0
81 Relay Out2 Sel MotorRunning 24
105 Safety Open En FaultEnable 1
C
128 EN Addr Sel BOOTP 1
129 EN IPAddr Cfg 1 0 192
130 EN IPAddr Cfg 2 0 168
131 EN IPAddr Cfg 3 0 1
132 EN IPAddr Cfg 4 0 1
133 EN Subnet Cfg 1 0 255
134 EN Subnet Cfg 2 0 255
135 EN Subnet Cfg 3 0 255
L
180 Stp Logic 0 00F1 21
181 Stp Logic 1 00F1 4021
182 Stp Logic 2 241 4021
183 Stp Logic 3 241 3811
190 Stp Logic Time 0 30 20
191 Stp Logic Time 1 30 90
192 Stp Logic Time 2 30 10
193 Stp Logic Time 3 30 2
A
410 Preset Freq 0 0 8
411 Preset Freq 1 5 30
412 Preset Freq 2 10 8
413 Preset Freq 3 20 0
439 S Curve % 0 10
531 Start Boost 2.5 8
556 Text Scroll Mid Speed 0

BROCK® MEYER® Schematics Allen-Bradley Power Flex 525 Setups
MFH1968-3G 11
Setup for 5 HP 400V
Parameter
Group No. Name Default BROCK Setting
P
31 Motor NP Volts 460 400
32 Motor NP Hertz 60 50
34 Motor NP FLA 6.4 7.66
36 Motor NP RPM 1750 1450
37 Motor NP Power 4 3.7
39 Torque Perf Mode SVC 0
41 Accel Time 1 10 30
42 Decel Time 1 10 30
44 Maximum Freq 60 100
46 Start Source 1 Keypad 2
47 Speed Reference1 Drive Pot 13
48 Start Source 2 DigIn TrmBlk 1
49 Speed Reference2 0-10V input 1
51 Speed Reference3 EtherNet/IP 5
T
62 DigIn TermBlk 02 2-Wire FWD 49
63 DigIn TermBlk 03 2-Wire REV 0
65 DigIn TermBlk 05 Preset Freq 13
66 DigIn TermBlk 06 Preset Freq 24
67 DigIn TermBlk 07 Spd + Strt 2 2
68 DigIn TermBlk 08 Jog Forward 0
81 Relay Out2 Sel MotorRunning 24
105 Safety Open En FaultEnable 1
C
128 EN Addr Sel BOOTP 1
129 EN IPAddr Cfg 1 0 192
130 EN IPAddr Cfg 2 0 168
131 EN IPAddr Cfg 3 0 1
132 EN IPAddr Cfg 4 0 1
133 EN Subnet Cfg 1 0 255
134 EN Subnet Cfg 2 0 255
135 EN Subnet Cfg 3 0 255
L
180 Stp Logic 0 00F1 21
181 Stp Logic 1 00F1 4021
182 Stp Logic 2 241 4021
183 Stp Logic 3 241 3811
190 Stp Logic Time 0 30 20
191 Stp Logic Time 1 30 90
192 Stp Logic Time 2 30 10
193 Stp Logic Time 3 30 2
A
410 Preset Freq 0 0 8
411 Preset Freq 1 5 30
412 Preset Freq 2 10 8
413 Preset Freq 3 20 0
439 S Curve % 0 10
531 Start Boost 2.5 8
556 Text Scroll Mid Speed 0

Allen-Bradley Power Flex 525 Setups BROCK® MEYER® Schematics
12 MFH1968-3G
Setup for 5 HP 460V
Parameter
Group No. Name Default BROCK Setting
P
34 Motor NP FLA 6.4 6.7
36 Motor NP RPM 1750 1800
39 Torque Perf Mode SVC 0
41 Accel Time 1 10 30
42 Decel Time 1 10 30
44 Maximum Freq 60 120
46 Start Source 1 Keypad 2
47 Speed Reference1 Drive Pot 13
48 Start Source 2 DigIn TrmBlk 1
49 Speed Reference2 0-10V input 1
51 Speed Reference3 EtherNet/IP 5
T
62 DigIn TermBlk 02 2-Wire FWD 49
63 DigIn TermBlk 03 2-Wire REV 0
65 DigIn TermBlk 05 Preset Freq 13
66 DigIn TermBlk 06 Preset Freq 24
67 DigIn TermBlk 07 Spd + Strt 2 2
68 DigIn TermBlk 08 Jog Forward 0
81 Relay Out2 Sel MotorRunning 24
105 Safety Open En FaultEnable 1
C
128 EN Addr Sel BOOTP 1
129 EN IPAddr Cfg 1 0 192
130 EN IPAddr Cfg 2 0 168
131 EN IPAddr Cfg 3 0 1
132 EN IPAddr Cfg 4 0 1
133 EN Subnet Cfg 1 0 255
134 EN Subnet Cfg 2 0 255
135 EN Subnet Cfg 3 0 255
L
180 Stp Logic 0 00F1 21
181 Stp Logic 1 00F1 4021
182 Stp Logic 2 241 4021
183 Stp Logic 3 241 3811
190 Stp Logic Time 0 30 20
191 Stp Logic Time 1 30 90
192 Stp Logic Time 2 30 10
193 Stp Logic Time 3 30 2
A
410 Preset Freq 0 0 8
411 Preset Freq 1 5 30
412 Preset Freq 2 10 8
413 Preset Freq 3 20 0
439 S Curve % 0 10
531 Start Boost 2.5 8
556 Text Scroll Mid Speed 0

BROCK® MEYER® Schematics Allen-Bradley Power Flex 525 Setups
MFH1968-3G 13
Setup for 5 HP 600V
Parameter
Group No. Name Default BROCK
Setting
P
34 Motor NP FLA 5.1 5.2
36 Motor NP RPM 1750 1755
39 Torque Perf Mode SVC 0
41 Accel Time 1 10 30
42 Decel Time 1 10 30
44 Maximum Freq 60 120
46 Start Source 1 Keypad 2
47 Speed Reference1 Drive Pot 13
48 Start Source 2 DigIn TrmBlk 1
49 Speed Reference2 0-10V input 1
51 Speed Reference3 EtherNet/IP 5
T
62 DigIn TermBlk 02 2-Wire FWD 49
63 DigIn TermBlk 03 2-Wire REV 0
65 DigIn TermBlk 05 Preset Freq 13
66 DigIn TermBlk 06 Preset Freq 24
67 DigIn TermBlk 07 Spd + Strt 2 2
68 DigIn TermBlk 08 Jog Forward 0
81 Relay Out2 Sel MotorRunning 24
105 Safety Open En FaultEnable 1
C
128 EN Addr Sel BOOTP 1
129 EN IPAddr Cfg 1 0 192
130 EN IPAddr Cfg 2 0 168
131 EN IPAddr Cfg 3 0 1
132 EN IPAddr Cfg 4 0 1
133 EN Subnet Cfg 1 0 255
134 EN Subnet Cfg 2 0 255
135 EN Subnet Cfg 3 0 255
L
180 Stp Logic 0 00F1 21
181 Stp Logic 1 00F1 4021
182 Stp Logic 2 241 4021
183 Stp Logic 3 241 3811
190 Stp Logic Time 0 30 20
191 Stp Logic Time 1 30 90
192 Stp Logic Time 2 30 10
193 Stp Logic Time 3 30 2
A
410 Preset Freq 0 0 8
411 Preset Freq 1 5 30
412 Preset Freq 2 10 8
413 Preset Freq 3 20 0
439 S Curve % 0 10
531 Start Boost 2.5 8
556 Text Scroll Mid Speed 0

Allen-Bradley Power Flex 525 Setups BROCK® MEYER® Schematics
14 MFH1968-3G
Setup for 15 HP 230V Drive, Single Phase Input,
5 HP Motor
Parameter
Group No. Name Default BROCK Setting
P
34 Motor NP FLA 12.8 13.4
36 Motor NP RPM 1750 1800
39 Torque Perf Mode SVC 0
41 Accel Time 1 10 30
42 Decel Time 1 10 30
44 Maximum Freq 60 120
46 Start Source 1 Keypad 2
47 Speed reference1 Drive Pot 13
48 Start Source 2 DigIn TrmBlk 1
49 Speed Reference2 0-10V input 1
51 Speed Reference3 EtherNet/IP 5
T
62 DigIn TermBlk 02 2-Wire FWD 49
63 DigIn TermBlk 03 2-Wire REV 0
65 DigIn TermBlk 05 Preset Freq 13
66 DigIn TermBlk 06 Preset Freq 24
67 DigIn TermBlk 07 Spd + Strt 2 2
68 DigIn TermBlk 08 Jog Forward 0
81 Relay Out2 Sel MotorRunning 24
105 Safety Open En FaultEnable 1
C
128 EN Addr Sel BOOTP 1
129 EN IPAddr Cfg 1 0 192
130 EN IPAddr Cfg 2 0 168
131 EN IPAddr Cfg 3 0 1
132 EN IPAddr Cfg 4 0 1
133 EN Subnet Cfg 1 0 255
134 EN Subnet Cfg 2 0 255
135 EN Subnet Cfg 3 0 255
L
180 Stp Logic 0 00F1 21
181 Stp Logic 1 00F1 4021
182 Stp Logic 2 241 4021
183 Stp Logic 3 241 3811
190 Stp Logic Time 0 30 20
191 Stp Logic Time 1 30 90
192 Stp Logic Time 2 30 10
193 Stp Logic Time 3 30 2
A
410 Preset Freq 0 0 8
411 Preset Freq 1 5 30
412 Preset Freq 2 10 8
413 Preset Freq 3 20 0
439 S Curve % 0 10
531 Start Boost 2.5 8
556 Text Scroll Mid Speed 0

BROCK® MEYER® Schematics Allen-Bradley Power Flex 525 Fault Code Descriptions
MFH1968-3G 15
Allen-Bradley Power Flex 525 Fault Code Descriptions
Fault Types, Descriptions and Actions
No. Fault Type (1)
Description Action
F000 No Fault No fault present.
F002 Auxiliary Input 1 External trip (Auxiliary) input. • Check remote wiring. • Verify communications
programming to intentional fault.
F003 Power Loss 2
Single-phase operation
detected with excessive load.
• Monitor the incoming AC line for incoming
voltage or line power interruption.
• Check input fuses.
• Reduce load.
F004 UnderVoltage 1
DC bus voltage fell below
the minimum value. Monitor the incoming AC line for low voltage or line power interruption.
F005 OverVoltage 1
DC bus voltage exceeded
maximum value.
Monitor the AC line for high line voltage or
transient conditions. Bus overvoltage can also
be caused by motor regeneration. Extend the
decel time or install dynamic brake option.
F006 Motor Stalled 1
Drive is unable to accelerate or
decelerate motor.
• Increase P041, A442, A444, A446
[Accel Time x] or reduce load so drive output
current does not exceed the current set by param-
eter A484, A485 [Current Limit x] for too long.
• Check for overhauling load.
F007 Motor Overload 1
Internal electronic overload
trip.
• An excessive motor load exists.
Reduce load so drive output current
does not exceed the current set by
parameter P033 [Motor OL Current].
• VerifyA530 [Boost Select] setting.
F008 Heatsink OverTmp 1
Heatsink/Power Module
temperature exceeds a
prefedined value.
• Check for blocked or dirty heat sink fins.
Verify that ambient temperature has not
exceeded the rated ambient temperature.
• Check fan.
F009 CC OverTmp 1
Control Module temperature
exceeds a prefedined value
• Check product ambient temperature.
• Check for airflow obstruction.
• Check for dirt or debris.
• Check fan.
F012 HW OverCurrent 2
The Drive output current has
exceeded the hardware
current limit.
Check programming. Check for excess load,
improper A530 [Boost Select] setting, DC brake
volts set too high or other causes of excess current.
F013 Ground Fault 2
A current path to earth ground
has been detected at one or
more of the drive
output terminals.
Check the motor and external wiring to the
drive output terminals for a grounded condition.
F015 Load Loss 2
The output torque current is
below the value programmed in
A490 [Load Loss Level] for a
time period greater than the
time programmed in A491
[Load Loss Time].
• Verify connections between motor and load.
• Verify level and time requirements
F021 Output Ph Loss 2
Output Phase Loss (if enabled).
Configure with A557 [Out
Phas Loss En].
• Verify motor wiring.
• Verify motor.
F029 Analog In Loss 1
An analog input is configured
to fault on signal loss. A signal
loss has occurred. Configure
with t094 [Anlg In V Loss] or
t097 [Anlg In mA Loss].
• Check for broken/loose connections at inputs.
• Check parameters.
F033 Auto Rstrt Tries 2
Drive unsuccessfully
attempted to reset a fault and
resume running for the
programmed number of A541
[Auto Rstrt Tries].
Correct the cause of the fault and manually clear.

Allen-Bradley Power Flex 525 Fault Code Descriptions BROCK® MEYER® Schematics
16 MFH1968-3G
F038 Phase U to Gnd 2
A phase to ground fault has
been detected between the
drive and motor in this phase.
• Check the wiring between the drive and motor.
• Check motor for grounded phase.
• Replace drive if fault cannot be cleared.
F039 Phase V to Gnd
F040 Phase W to Gnd
F041 Phase UV Short 2
Excessive current has been
detected between these two
output terminals.
• Check the motor and drive output
terminal wiring for a shorted condition.
• Replace drive if fault cannot be cleared.
F042 Phase UW Short
F043 Phase VW Short
F048 Params Defaulted 1
The drive was commanded
to write default values to
EEPROM.
• Clear the fault or cycle power to the drive.
• Program the drive parameters as needed.
F059 Safety Open 1
Both of the safety inputs
(Safety 1, Safety 2) are not
enabled.
Configure with t105 [Safety
Open En].
Check safety input signals. If not using safety,
verify and tighten jumper for I/O terminals S1,
S2 and S+.
F063 SW OverCUrrent 1
Programmed A486, A488
[Shear Pinx Level] has been
exceeded for a time period
greater than the time
programmed in A487, A489
[Shear Pin x Time].
• Verify connections between motor and load.
• Verify level and time requirements.
F064 Drive Overload 2
Drive overload rating has
been exceeded. Reduce load or extend Accel Time.
F070 Power Unit 2
Failure has been detected in the
drive power section.
• Check maximum ambient temperature
has not been exceeded.
• Cycle power.
• Replace drive if fault cannot be cleared.
F071 DSI Net Loss 2
Control over the Modbus or
DSI communication link has
been interrupted.
• Cycle power.
• Check communications cabling.
• Check Modbus or DSI setting.
• Check Modbus or DSI status.
F072 Opt Net Loss 2
Control over the network
option card’s remote
network has been interrupted.
• Cycle power.
• Check communications cabling.
• Check network adapter setting.
• Check external network status.
F073 EN Net Loss 2
Control through the
embedded EtherNet/IP adapter
has been interrupted.
• Cycle power.
• Check communications cabling.
• Check EtherNet/IP setting.
• Check external network status.
F080 Autotune Failure 2
The autotune function was
either cancelled by the user
or failed. Restart procedure.
F081 DSI Comm Loss 2
Communications between
the drive and the Modbus or
DSI master device have been
interrupted.
• Cycle power.
• Check communications cabling.
• Check Modbus or DSI setting.
• Check Modbus or DSI status.
• Modify using C125 [Comm Loss Action].
• Connecting I/O terminals C1 and C2 to
ground may improve noise immunity.
• Replace wiring, Modbus master device,
or control module.
F082 Opt Comm Loss 2
Communications between the
drive and the network option
card have been interrupted.
• Cycle power.
• Reinstall option card in drive.
• Modify using C125 [Comm Loss Action].
• Replace wiring, port expander, option
card, or control module.
Fault Types, Descriptions and Actions
No. Fault Type (1)
Description Action

BROCK® MEYER® Schematics Allen-Bradley Power Flex 525 Fault Code Descriptions
MFH1968-3G 17
F083 EN Comm Loss 2
Internal communications
between the drive and the
embedded EtherNet/IP adapter
have been interrupted.
• Cycle power.
• Check EtherNet/IP setting.
• Check drive’s Ethernet settings
and diagnostic parameters.
• Modify using C125 [Comm LossAction].
• Replace wiring, Ethernet switch,
or control module.
F091 Encoder Loss 2
Requires differential encoder.
One of the 2 encoder channel
signals is missing.
• Check Wiring.
• If P047, P049, P051 [Speed Referencex]
= 16 “Positioning” and A535 [Motor Fdbk Type]
= 5 “Quad Check”, swap the Encoder channel
inputs or swap any two motor leads.
• Replace encoder.
F094 Function Loss 2
“Freeze-Fire” (Function Loss)
input is inactive, input to the
programmed terminal is open.
Close input to the terminal and
cycle power.
F100 Parameter Chksum 2
Drive parameter non-volatile
storage is corrupted. Set P053 [Reset To Defalts] to 2 “Factory Rset”.
F101 External Storage 2
External non-volatile storage
has failed. Set P053 [Reset To Defalts] to 2 “Factory Rset”.
F105 C Connect Err 2
Control module was
disconnected while drive
was powered.
Clear fault and verify all parameter
settings. Do not remove or install the
control module while power is applied.
F106 Incompat C-P 2
The control module could not
recognize the power module.
• Cycle power.
• Flash with newer firmware version.
• Replace drive if fault cannot be cleared.
F107 Replaced C-P 2
The control module was
mounted to a power module
with a different power rating.
Set P053 [Reset To Defalts] to any
of the reset options.
F109 Mismatch C-P 2
The control module was
mounted to a different drive
type power module.
Set P053 [Reset To Defalts] to any
of the reset options.
F110 Keypad Membrane 2
Keypad membrane
failure / disconnected.
• Cycle power.
• Replace control module if fault
cannot be cleared.
F111 Safety Hardware 2
Safety input enable hardware
malfunction. One of the safety
inputs is not enabled.
• Check safety input signals. If not using safety,
verify and tighten jumper for I/O terminals S1,
S2 and S+.
• Replace control module if fault
cannot be cleared.
F114 uC Failure 2 Microprocessor failure. • Cycle power.
• Replace control module if fault cannot be cleared.
F122 I/O Board Fail 2
Failure has been detected in
the drive control and I/O
section.
• Cycle power.
• Replace drive or control module
if fault cannot be cleared.
F125 Flash Update Req 2
The firmware in the drive is
corrupt, mismatched, or
incompatible with the
hardware.
Perform a firmware flash update operation to
attempt to load a valid set of firmware.
F126 NonRecoverabErr 2
A non-recoverable firmware or
hardware error was detected.
The drive was automatically
stopped and reset.
• Clear fault or cycle power to the drive.
• Replace drive or control module
if fault cannot be cleared.
F127 DSIFlashUpdatReq 2
A critical problem with the
firmware was detected and the
drive is running using backup
firmware that only supports
DSI communications.
Perform a firmware flash update operation using
DSI communications to attempt to load a valid set
of firmware.
See Fault Types for more information.
Fault Types, Descriptions and Actions
No. Fault Type (1) Description Action

Honeywell Fault Codes BROCK® MEYER® Schematics
18 MFH1968-3G
Honeywell Burner Control Faults (Blink Codes)
Honeywell Fault Codes
Blink Code* Fault Description Blink Code* Fault Description
1-1 Low AC Line Voltage 4-3 Flame Amplifier Problem
1-2 AC Quality Problem 4-4 Configuration Jumper Problem
2-1 Unexpected Flame Signal 5-1 PII Fault
2-2 Flame Signal Absent 5-2 HFS/LFS Fault
2-3 Flame Signal Overrange 5-3 MOS/Start Switch
3-1 Running ILK Switch Problem 6-1 Output Drive Failure
3-2 Running ILK Switch in Standby 6-2 Internal Fault
3-3 Valve Proving Fault 6-3 Device Specific Fault
4-1 Purge Card Problem 6-4 Accessory Fault
4-2 Wiring Problem/Internal Fault 7-7 Unrecognized Fault
* Blink Codes are read from the green power LED when the relay module is locked out
(alarm LED is on). A blink code consists of 1 or more fast blinks followed by one (1) or more
slow blinks.
HONEYWELL Keyboard Display Module Sequence and Status Hold Messages

BROCK® MEYER® Schematics Honeywell Fault Codes
MFH1968-3G 19
HONEYWELL Keyboard Display Module Sequence andStatus Hold Messages (cont’d)

Honeywell Fault Codes BROCK® MEYER® Schematics
20 MFH1968-3G
HONEYWELL Fault Codes: Hold and Fault Message Summary
