Alliance Laundry Systems ADEE9BSS User manual

User's Guide
for Dryers
DRY725C_SVG
Original Instructions
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
www.alliancelaundry.com Part No. 514473R2
November 2014

Front Matter
WARNING
Risk of fire. Highly flammable material.
W881
IMPORTANT: The electrical installation in the site shall
comply with the Australian Electrical Standards,
AS3000, SAA wiring rules, and such local regulations
that might apply. In Australia and New Zealand, installa-
tion must comply with the Gas Installations Standard
AS/NZS 5601 Part 1: General Installations.
The maximum drying load (dry weight) shall not exceed 8.2 kg [18
pounds].
Read all instructions before using unit.
WARNING
FOR YOUR SAFETY, the information in this manual
must be followed to minimize the risk of fire or explo-
sion or to prevent property damage, personal injury or
death.
W033
WARNING
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any oth-
er appliance.
• WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Clear the room, building or area of all occu-
pants.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s in-
structions.
• If you cannot reach your gas supplier, call the
fire department.
• Installation and service must be performed by a
qualified installer, service agency or the gas suppli-
er.
W052
IMPORTANT: Purchaser must consult the local gas sup-
plier for suggested instructions to be followed if the dryer
user smells gas. The gas utility instructions plus the
SAFETY and WARNING note directly above must be
posted in a prominent location near the dryer for cus-
tomer use.
WARNING
• Installation of unit must be performed by a qualified
installer.
• Install clothes dryer according to manufacturer’s
instructions and local codes.
• DO NOT install a clothes dryer with flexible plastic
venting materials. If flexible metal (foil type) duct is
installed, it must be of a specific type identified by
the appliance manufacturer as suitable for use with
clothes dryers. Refer to section on connecting ex-
haust system. Flexible venting materials are known
to collapse, be easily crushed, and trap lint. These
conditions will obstruct clothes dryer airflow and in-
crease the risk of fire.
W729R1
Front Matter
Part No. 514473R2 ©Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 3

WARNING
To reduce the risk of severe injury or death, follow all
installation instructions. Save these instructions.
W894
WARNING
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liq-
uids in the vicinity of this or any other appliance.
W053
This product uses FreeRTOS V7.2.0 (www.freertos.org).
NOTE: For Australian models, the energy consumption
is measured as used once per week using the Perm
Press Automatic cycle with High Temperature and Dry-
ness Dry.
Front Matter
4 ©Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT Part No. 514473R2

Table of Contents
Safety Information.............................................................................6
Explanation of Safety Messages................................................................. 6
Important Safety Instructions....................................................................6
Before Drying.................................................................................... 8
Energy Saving Tips....................................................................................8
Helps and Hints....................................................................................... 8
Sort......................................................................................................8
Load......................................................................................................8
Operating Your Dryer........................................................................10
Control Panel........................................................................................ 10
Digital Display....................................................................................... 10
Cycles................................................................................................. 10
Selections............................................................................................11
Options................................................................................................11
Status................................................................................................ 11
To Dry Clothes.......................................................................................11
Optional Drying Rack...............................................................................12
Maintenance...................................................................................14
Lubrication........................................................................................... 14
Care of Your Dryer..................................................................................14
Motor Overload Protector....................................................................... 14
Lint Filter............................................................................................. 14
Troubleshooting...............................................................................16
Contact Information...............................................................................17
©Copyright 2014, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written
consent of the publisher.
Part No. 514473R2 ©Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 5

Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,” and “CAU-
TION”), followed by specific instructions, are found in this manual
and on machine decals. These precautions are intended for the per-
sonal safety of the operator, user, servicer, and those maintaining
the machine.
DANGER
Indicates an imminently hazardous situation that, if
not avoided, will cause severe personal injury or
death.
WARNING
Indicates a hazardous situation that, if not avoided,
could cause severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided,
may cause minor or moderate personal injury or prop-
erty damage.
Additional precautionary statements (“IMPORTANT” and “NOTE”)
are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used to inform
the reader of specific procedures where minor machine
damage will occur if the procedure is not followed.
NOTE: The word “NOTE” is used to communicate in-
stallation, operation, maintenance or servicing informa-
tion that is important but not hazard related.
Important Safety Instructions
Save These Instructions
WARNING
To reduce the risk of fire, electric shock, serious injury
or death to persons when using your dryer, follow
these basic precautions:
W130
• Read all instructions before using the dryer.
• Install this dryer according to the INSTALLATION INSTRUC-
TIONS. Refer to the EARTH/GROUND INSTRUCTIONS in the IN-
STALLATION manual for the proper earth/ground connection of
the dryer. All connections for electrical power, earth/ground
and gas supply must comply with local codes and be made by
licensed personnel when required. Do not do it yourself.
• Do not install or store the dryer where it will be exposed to wa-
ter and/or weather.
• Do not dry articles that have been previously cleaned in, washed
in, soaked in, or spotted with gasoline or machine oils, vegetable
or cooking oils, cleaning waxes or chemicals, dry-cleaning sol-
vents, thinner, anything containing chemicals such as in mops
and cleaning cloths, or other flammable or explosive substances
as they give off vapors that could ignite, explode or cause fabric
to catch on fire by itself.
• Items that have been soiled with substances such as cooking
oil, acetone, alcohol, petrol, kerosene, spot removers, turpen-
tine, waxes and wax removers, should be washed in hot water
with an extra amount of detergent before being dried in the
tumble dryer.
• To reduce the risk of fire, DO NOT DRY plastics or articles con-
taining foam or latex rubber or similarly textured rubberlike ma-
terials, such as shower caps, water proof textiles, rubber-
backed articles, and clothes or pillows filled with foam rubber
pads.
• Do not tumble fiberglass curtains and draperies unless the la-
bel says it can be done. If they are dried, wipe out the cylinder
with a damp cloth to remove particles of fiberglass.
• Do not allow children to play on or in the dryer. Close supervision
of children is necessary when the dryer is used near children.
This appliance is not intended for use by persons (including chil-
dren) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning the use of the appliance
by a person responsible for their safety. This is a safety rule for
all appliances.
• Cleaning and user maintenance shall not be made by children
without supervision.
• Children less than three years should be kept away unless con-
tinuously supervised.
• Do not reach into the dryer if the cylinder is revolving.
Safety Information
Part No. 514473R2 ©Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 6

• Use the dryer only for its intended purpose, drying clothes. AL-
WAYS follow the fabric care instructions supplied by the gar-
ment manufacturer and only use the dryer drum to dry textiles
that have been washed in water.
• Always read and follow manufacturer’s instructions on pack-
ages of laundry and cleaning aids. Heed all warnings or precau-
tions. To reduce the risk of poisoning or chemical burns, keep
them out of reach of children at all times (preferably in a locked
cabinet).
• Remove laundry immediately after the dryer stops.
• DO NOT operate the dryer if it is smoking, grinding or has miss-
ing or broken parts or removed guards and/or panels. DO NOT
tamper with the controls or bypass any safety devices.
• DO NOT operate individual units if they have been separated
from a stack unit.
• Dryer will not operate with the loading door open. DO NOT by-
pass the door safety switch by permitting the dryer to operate
with the door open. The dryer will stop tumbling when the door
is opened. Do not use the dryer if it does not stop tumbling
when the door is opened or starts tumbling without pressing
the START mechanism. Remove the dryer from use and call the
service person.
• ALWAYS clean the lint filter after every load. A layer of lint in
the filter reduces drying efficiency and prolongs drying time.
Keep area around the exhaust opening and adjacent surround-
ing area free from the accumulation of lint, dust and dirt. The
interior of the dryer and the exhaust duct should be cleaned
periodically by qualified service personnel.
• Do not repair or replace any part of the dryer, or attempt any
servicing unless specifically recommended in the user-mainte-
nance instructions or in published user-repair instructions that
you understand and have the skills to carry out. ALWAYS dis-
connect the electrical power to the dryer before attempting
service. Disconnect the power cord by grasping the plug, not
the cord.
• If supply cord is damaged, it must be replaced by the manufac-
turer, its service agent or similarly qualified persons in order to
avoid a hazard.
• Before the dryer is removed from service or discarded, remove
the door to the drying compartment.
• Failure to install, maintain, and/or operate this machine accord-
ing to the manufacturer’s instructions may result in conditions
which can produce bodily injury and/or property damage.
NOTE: The WARNING and IMPORTANT SAFETY IN-
STRUCTIONS appearing in this manual are not meant to
cover all possible conditions and situations that may oc-
cur. Observe and be aware of other labels and precau-
tions that are located on the machine. They are intended
to provide instruction for safe use of the machine. Com-
mon sense, caution and care must be exercised when in-
stalling, maintaining, or operating the dryer.
Always contact your dealer, distributor, service agent or the man-
ufacturer about any problems or conditions you do not under-
stand.
Safety Information
Part No. 514473R2 ©Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 7

Before Drying
Energy Saving Tips
• Make sure the lint filter is always clean.
• Do not overload the dryer.
• Do not overdry items.
• Remove items to be ironed while still damp.
• Large loads of similar fabrics dry the most efficiently. However,
dry permanent press in smaller loads to prevent wrinkling.
• Use the correct cycle for the type of fabric being dried.
• Locate your dryer so the exhaust duct is as short and straight
as possible.
• Do not open the door during the drying cycle.
• Plan to do your laundry on low humidity days; your clothes will
dry faster.
• Dry multiple loads of clothes one right after another so dryer
interior does not have to be reheated for each load.
Helps and Hints
WARNING
To reduce the risk of fire, explosion, serious injury or
death, clothes which have traces of any flammable
substances such as cooking oil, machine oil, flamma-
ble chemicals, thinner, etc. must not be put into the
dryer.
W131
• The directions for installation and proper exhausting are given
in the Installation Instructions which are included with the dry-
er.
• Static electricity may cause garments of synthetic fibers (as
in lingerie) to cling together, especially if they are overdried. The
use of a liquid fabric softener in the rinse water of the washer,
or a fabric softener sheet in the dryer, will soften clothes and
reduce static electricity.
• Do not wash or dry clothes that shed lint in the same load with
permanent press or knit garments.
• Remove permanent press loads immediately after dryer stops.
• Follow the care labels on FLAME RETARDANT, SCOTCH-
GUARD™, etc., garments for proper washing and drying.
• If loads should be damp for ironing, use the Damp Dryness set-
ting, in an Automatic cycle.
Sort
If you have correctly sorted the items for washing, they should be
properly sorted for drying too.
1. Sort by color.
2. Separate lint shedding fabrics and lint receiving fabrics. Towels,
flannels, chenille, cottons, rugs, etc., shed lint. Corduroys, knits
(including socks), permanent press, and synthetics attract lint.
3. Separate no heat, low heat and high heat items.
In any kind of drying, lightweight fabrics will dry faster than heavy-
weight fabrics. If mixed loads are dried together (such as sheets
and towels), remove the lighter weight fabrics when they are dry to
prevent overdrying and wrinkling. The best method is to dry clothes
which require the same time, temperature or dryness level in the
same load.
TLW1991N_SVG
Load
WARNING
Do not wash or dry items soiled with vegetable or
cooking oils. Some oils may remain after washing and
may cause the fabric to catch on fire by itself.
W527
• Do not overload your dryer. Bulk, not weight, determines the
load size. If the dryer is overloaded, it could cause discoloration
or permanent heat damage to the load.
• There should be space in the dryer for the clothes to tumble
freely and help to reduce wrinkles.
• Large and small pieces together make up loads which will tumble
well. Permanent press loads should be smaller to provide room
for tumbling. Proper tumbling allows for fewer wrinkles.
• A load can be too small. Just a few small pieces will not tumble
properly. They will take longer to dry and they may be wrinkled.
For small loads, add a couple of large towels or non lint shedding
items to aid in tumbling.
• The following illustrations show the ideal load sizes for fabrics.
The average load will fill the cylinder one third to half full when
wet.
Before Drying
Part No. 514473R2 ©Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 8

Cylinder with wet linens and cottons
DRY2031N_SVG
Cylinder with wet permanent press items
DRY2032N_SVG
Before Drying
Part No. 514473R2 ©Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 9

Operating Your Dryer
WARNING
To reduce the risk of fire, electric shock, serious injury
or death to persons, read the Safety Information sec-
tion before operating the dryer.
W520
Control Panel
Preset Cycles
DRY2577N_SVG
Door Open
Status
Heating
Cooling
Low Medium
AUTO-SENSING
MANUAL
HighNo Heat
Temp
Moisture
Level
Dryness
Less Dry Near Dry DryDamp
Wet Damp DrySensing Control Lock
Selections
Extended
Anti-
Wrinkle
EcoDry
Options
Signal
Regular
Heavy
Duty Delicate
Time
Dry
Favorite Quick
Dry
Prem
Press
Fluff
Up
Power
Cancel
Start
Pause
Digital Display
The two-digit display is used to show the time remaining in a cycle.
The display also shows diagnostic codes.
Idle Mode
If no keypads have been pressed for five minutes after a cycle is fin-
ished, the control will enter Idle Mode. A light in the lower right cor-
ner of the digital display will flash once each minute. Press the Pow-
er/Cancel keypad to exit this mode.
Cycles
The following cycle descriptions will help determine which cycle to
choose depending on the type of laundry being dried. The cycle set-
tings may be modified using the Selections and Options.
Auto-Sensing
The Auto-Sensing drying cycle operation is determined by the type
of cycle selected as well as the moisture sensing system, which can
be set by changing the Dryness setting. Auto-Sensing cycles are
Energy Saver cycles that help prevent over-drying.
When a wet load is put into the dryer it takes a certain amount of
time to reach the desired dryness level. The time will vary with load
size, type of fabric, amount of moisture in the load, air flow and the
laundry room environment. The estimated time will be shown in the
digital display.
Cycle Use
Heavy Duty Dry heavy items such as blan-
kets on this cycle.
Regular Use for sturdy items like play or
work clothes.
Perm Press Use for permanent press items
and synthetics.
Delicate Dry delicate items on this cy-
cle.
Manual
There are three manual cycles: Time Dry, Quick Dry and Fluff Up.
These cycles will run for the set number of minutes shown on the
digital display. The cycle time can be increased or decreased using
the up and down arrow keypads. The time and temperature selec-
tion may be adjusted manually at any time before or during the cy-
cle.
Operating Your Dryer
Part No. 514473R2 ©Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 10
