Brodersen RTU32M Series User manual

Version 1.65.5.54 - August 2018
RTU32M Series
Modular RTU, PLC and Utility Controller
User Manual

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
2
Table of Contents
1. Customer Information..................................................................................................................................................................4
1.1 Copyright Notice.....................................................................................................................................................................4
1.2 Trademark Acknowledgement ................................................................................................................................................4
1.3 Disclaimer ..............................................................................................................................................................................4
1.4 Life Support Policy..................................................................................................................................................................4
1.5 Brodersen Customer Services .................................................................................................................................................4
1.6 Technical Support...................................................................................................................................................................4
1.7 Product Warranty...................................................................................................................................................................5
2Introduction.................................................................................................................................................................................6
2.1 RTU32M –The modular Brodersen RTU, PLC and Industrial Controller.....................................................................................6
2.2 WebServer configuration and PLC programming in all IEC61131 languages ..............................................................................6
3Getting Started ............................................................................................................................................................................7
3.1 Configuration and default settings ..........................................................................................................................................7
4How to connect and prepare your PC to configure the RTU32M....................................................................................................7
4.1 Wiring....................................................................................................................................................................................7
4.2 Setting up your PC Ethernet driver (Windows).........................................................................................................................7
4.3 First time configuration ..........................................................................................................................................................8
4.4 RTU32M –Licensing ...............................................................................................................................................................9
4.5 Adding Drivers and Runtime Options.....................................................................................................................................10
4.6 Settings overview .................................................................................................................................................................11
4.7 Hardware Overview..............................................................................................................................................................12
4.8 User Overview......................................................................................................................................................................13
4.9 Runtime Settings - Main Settings...........................................................................................................................................15
4.9.1 Communication...........................................................................................................................................................15
4.9.2 Start-up.......................................................................................................................................................................16
4.9.3 Options.......................................................................................................................................................................16
4.10 Runtime Settings - Redundancy Settings ...........................................................................................................................17
4.11 I/O Board Settings............................................................................................................................................................17
4.11.1 Current I/O Configuration............................................................................................................................................17
4.12 System Configuration - Network Settings..........................................................................................................................18
4.13 Network Redundancy - Protocols......................................................................................................................................18
4.13.1 HSR –High Availability Seamless Redundancy ..............................................................................................................19
4.13.2 PRP –Parallel Redundancy Protocol.............................................................................................................................19
4.14 Network Redundancy - Bonding .......................................................................................................................................19
4.15 Adding a USB - Ethernet Adapter......................................................................................................................................19
4.16 Adding USB –RS232 Serial Adapters.................................................................................................................................19
4.17 Adding a USB - WiFi Adapter ............................................................................................................................................19
4.18 VPN Settings ....................................................................................................................................................................20
4.19 Time Settings for RTC –Real Time Clock............................................................................................................................21
4.19.1 Time Settings ..............................................................................................................................................................21
4.19.2 Base Station time zone ................................................................................................................................................21
4.20 System Configuration –User Administration.....................................................................................................................22
4.21 Maintenance –Firmware Update .....................................................................................................................................22
4.22 Maintenance - Licensing...................................................................................................................................................23
4.23 Maintenance - password..................................................................................................................................................23
4.24 Maintenance - Edit Config File ..........................................................................................................................................24
4.25 Maintenance - Reboot......................................................................................................................................................24
4.26 Utilities - Back Up and Restore..........................................................................................................................................25
4.27 Utilities - Network Packet Capture....................................................................................................................................26
4.28 DNP3 Slave –Configuration..............................................................................................................................................27
4.29 DNP3 Slave –Serial Tunneling ..........................................................................................................................................28
5Getting Started with the Brodersen WorkSuite tools (3.9.2) ........................................................................................................29
5.1 Introduction .........................................................................................................................................................................29
5.2 Installing the Brodersen WorkSuite Package..........................................................................................................................29
5.3 WorkSuite License ................................................................................................................................................................29
5.4 Compatibility with STRATON WorkBench ..............................................................................................................................29
5.5 User documentation and training/guideline videos ...............................................................................................................29
6RTU32M I/O Setup in WorkSuite ................................................................................................................................................31
6.1 General ................................................................................................................................................................................31

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
3
6.2 WorkSuite I/O Drivers for RTU32M .......................................................................................................................................31
6.3 INTRODUCTION to BL I/O series ............................................................................................................................................32
6.4 BL Series Module Configurator..............................................................................................................................................33
6.4.1 Managing BL Series I/O Modules..................................................................................................................................34
6.4.2 Inserting a module.......................................................................................................................................................34
6.4.3 Moving a module ........................................................................................................................................................34
6.4.4 Remove a module in Worksuite ...................................................................................................................................34
6.4.5 Add variables to a module ...........................................................................................................................................35
6.4.6 Rename auto generated variables................................................................................................................................35
6.4.7 Configure Module Defaults..........................................................................................................................................36
6.4.8 Configure Combination DI/DO module example ...........................................................................................................36
6.4.9 Configure AI module example......................................................................................................................................37
6.4.10 Export/Import Module variables. .................................................................................................................................37
6.4.11 Firmware update I/O modules .....................................................................................................................................37
6.4.12 LB2_INFO Profile –monitoring module status ..............................................................................................................38
6.5 COM Port Settings ................................................................................................................................................................42
6.6 Modbus Drivers....................................................................................................................................................................43
6.6.1 ModbusRTU Master ....................................................................................................................................................43
6.6.2 ModbusRTU Slave .......................................................................................................................................................43
6.7 IEC60870-5-101/103/104 Drivers ..........................................................................................................................................43
6.8 DNP3 Slave and DNP3 Master Drivers ...................................................................................................................................43
6.9 Watchdog ............................................................................................................................................................................44
6.10 Real time / Real time Clock...............................................................................................................................................44
6.11 Modem Functions............................................................................................................................................................44
6.11.1 Dial functions for GSM and PSTN Modems ...................................................................................................................44
6.12 Data Logging....................................................................................................................................................................45
6.13 Status information functions ............................................................................................................................................46
6.13.1 RTU Memory Status (STATMEMORY) ...........................................................................................................................47
6.13.2 RTU Project Information (STATPROJECT) ......................................................................................................................48
6.14 Reading Text Files from WorkSuite ...................................................................................................................................48
7Distributed Event Binding Protocol / Redundancy Binding Communication..................................................................................49
7.1 General ................................................................................................................................................................................49
7.2 Network settings in RTU32 (redundancy binding) ..................................................................................................................49
7.3 Procedure for setting up binding/redundancy binding in WorkSuite.......................................................................................49
8RTU32M cycle / scan time ..........................................................................................................................................................50
8.1 RTU scan time ......................................................................................................................................................................50
8.2 LB2 Bus and Internal I/O Bus scan time .................................................................................................................................50
9RTU HMI ....................................................................................................................................................................................51
9.1 Creating and Viewing RTU Graphics ......................................................................................................................................51
10 RTU Monitoring Applications ................................................................................................................................................53
10.1 Creating and Viewing RTU Monitor Applications ...............................................................................................................53
11 RTU32 Utilities and System Event Log ...................................................................................................................................55
11.1 General............................................................................................................................................................................55
11.2 RTU32 Software Bulk Update Tool....................................................................................................................................55
11.3 RTU32 Search Tool...........................................................................................................................................................55
11.4 System Log/Event Viewer.................................................................................................................................................56
12 RTU32M Technical Description .............................................................................................................................................57
12.1 General............................................................................................................................................................................57
12.2 PLC Runtime ....................................................................................................................................................................57
12.3 Software Versions............................................................................................................................................................57
Appendix 1 –RTU32M Factory Reset ..................................................................................................................................................58
RTU32M complete Reset................................................................................................................................................................58

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
4
1. Customer Information
1.1 Copyright Notice
Copyright 2018, Brodersen A/S, ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical,
for any purpose, without the prior written permission of the original manufacturer.
1.2 Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective owners.
1.3 Disclaimer
Brodersen A/S reserves the right to make changes, without notice, to any product, including circuits and/or software described or
contained in this manual in order to improve design and/or performance. Brodersen A/S assumes no responsibility or liabilities for the
use of the described product(s), conveys no license or title under any patent, copyright, or mask work rights to these products, and
makes no representations or warranties that these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration purposes only.
Brodersen A/S makes no representation or warranty that such application will be suitable for the specified use without further testing
or modification.
1.4 Life Support Policy
BRODERSEN A/S’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS, IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE
PRIOR WRITTEN APPROVAL OF BRODERSEN A/S.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for surgical implant into body, or (b) support or
sustain life and whose failure to perform, when properly used in accordance with instructions for use provided in the labeling, can be
reasonably expected to result in significant injury to the user.
2. A critical component is any component of a life support device or system whose failure to perform can be reasonably expected to
cause the failure of the life support device or system, or to affect its safety or effectiveness.
1.5 Brodersen Customer Services
Your satisfaction is our primary concern. Here is a guide to Brodersen customer services. To ensure you get the full benefit of our
services, please follow the instructions below carefully.
1.6 Technical Support
We want you to get the maximum performance from your products. So if you run into technical difficulties, we are here to help. For the
most frequently asked questions, you can easily find answers in the product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult this manual first.
To receive the latest version of the user manual, please visit our Web site at:
http://www.brodersen.com,
Choose the product in question under product search and under each product you will find accompanying data sheets, manuals, and
user guides etc.
If you still cannot find the answer, gather all the information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our distributors are well trained and ready to give you the support you need to get the most from your
Brodersen products. In fact, most problems reported are minor and are able to be easily solved over the phone.
In addition, technical support is available from Brodersen engineers every business day. We are always ready to give advice on
application requirements or specific information on the installation and operation of any of our products. Please do not hesitate to call
or e-mail us on [e-mail] .
Denmark: Australia:
Brodersen A/S Brodersen Systems Asia Pacific P/L
Islevdalvej 187 832 High Street, Kew East
DK-2610 Roedovre VIC 3102, Australia
Tel.: [phone] Tel: [phone]
[e-mail] [e-mail]
www.brodersen.com

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
5
1.7 Product Warranty
Brodersen warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for
two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized
by Brodersen, or which have been subject to misuse, abuse, accident or improper installation. Brodersen assumes no liability under the
terms of this warranty as a consequence of such events. Because of Brodersen’s high quality control standards and rigorous testing,
most of our customers never need to use our repair service. If a Brodersen product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials,
service time, and freight. Please consult your distributor for more details. If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, Product type and s/n, hardware and software
version etc.) Note anything abnormal and describe the error in a product failure report.
2. Call your distributor and describe the problem. Please have your manual, product, and any helpful information readily
available.
3. If your product is diagnosed as defective, make arrangement with your distributor about this.
4. Carefully pack the defective product, a complete failure report and a photocopy of proof of purchase date (such as your sales
receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service.
5. Ship it to your distributor.

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
6
2Introduction
2.1 RTU32M –The modular Brodersen RTU, PLC and Industrial Controller
The Brodersen RTU32M series is based on a 32-bit i.Mx6 ARM platform, providing a small footprint modular RTU and PLC with leading
edge functionality. As well as being a versatile RTU and PLC with flexible I/O designed to perform embedded data processing, control,
data logging and monitoring, it is also a networking communicator for collecting, managing and communicating data via protocols on
different physical interfaces upwards and downwards in an industrial environment.
Typical applications for the RTU32M are:
•Control and monitoring of water and waste water pump stations
•Substation automation applications
•Railway level crossing monitoring
•Communication Gateway applications between SCADA protocols –including Modbus, DNP3 and IEC60870.
The RTU32M hardware platform includes a 200-900MHz CPU with 128-256MB RAM and integrated 128MB NAND Flash. In addition, an
optional removable microSD Flash card (default is 4GB, supports up to 64GB), provides an easy to use portable access/upgrade option.
The integrated Flash stores the main RTU32 firmware including embedded Linux OS and your PLC runtime application. Standard drivers
like the Modbus Protocol Suite, IEC60870 or DNP3 are stored in the integrated NAND Flash. The removable microSD card can be used
for storing backup files and data logging files.
2.2 WebServer configuration and PLC programming in all IEC61131 languages
The RTU32M, like the other RTU32 Series of RTUs is configured via the integrated WebServer. Settings like LAN port addressing, time
functions and 3g/4g modem credentials are handled in webpages. Online monitoring of connected physical I/O and display of graphical
overviews is possible via webpages.
Programming of logic functions and configuration of communications drivers is managed using the Brodersen WorkSuite package
software. WorkSuite is a powerful tool that is used for configuration and programming of all RTU32 Series products. Applications
developed and running in the RTU32M will easily run directly on the other RTU32 Series products. The full suite WorkSuite software
package is included in the product package, and it will run in demo mode without any license (with some runtime restrictions).

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
7
3Getting Started
3.1 Configuration and default settings
The LAN interface on the RTU32M is set to its factory default settings at delivery:
LAN1: 192.168.0.1, Subnet: 255.255.255.0
You can use the LAN1 interface to configure the basic settings in the RTU32M. The basic settings include setup of network parameters
such as IP address, Subnet mask, default gateway, time settings, general username and password for accessing the web server pages
and file system with FTP etc.
The configuration is done via web pages in the RTU32M Web Server. You must use your normal web browser to setup the basic settings
for the RTU32M. The web pages are optimized for MS Internet Explorer, Firefox and Chrome. If you are experiencing problems with
using the latest MS Internet Explorer version, please enable Compatibility settings in the browser.
4How to connect and prepare your PC to configure the RTU32M
4.1 Wiring
Use a cross-wired or standard patch cable to connect your PC Ethernet interface to the LAN1 Ethernet interface of the RTU. Apply
power to the RTU –make sure that you connect the correct power supply voltage (24VDC).
4.2 Setting up your PC Ethernet driver (Windows)
Your PC Ethernet driver must be setup to work in the same network segment as the LAN interface on the RTU32 you use. You must
setup your PC Ethernet TCP/IP driver to work in the segment IP 192.168.0.x.
To setup the Ethernet driver select start –Settings –Network Connections –Local Area Connections and the following window will
appear:
Click on Internet Protocol 4 (TCP/IPv4), and click Properties. A new window for setting the PC IP address will appear. Set an IP address
in the same segment as the selected LAN IP address, for example 192.168.0.100 as shown here below.

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
8
NOTE: If you want to re-configure your Ethernet TCP/IP driver back to initial settings, it is recommended that you note the settings
before you change them for setting up the RTU32M.
Click OK and OK again at the Local Area Connection Properties window. Now your PC Ethernet driver is setup for communicating with
the RTU32M. Now apply power to the RTU32M. Wait for the RTU32M to boot up –takes approx. 20s. As a minimum the orange Run
LED on the CPU front PANEL must be lit.
4.3 First time configuration
Start your Internet browser and enter the IP address of the RTU32M in the address field:
Now the first web page will appear in your browser and you will be asked to enter a username and password.
The username is admin.
The RTU32M is shipped with the administrator password set to admin. Be sure to change the default password from the
Maintenance>Password menu item.

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
9
4.4 RTU32M –Licensing
The RTU32M includes license options that manage the tag quantity and enable use of advanced drivers and options, hence some
restrictions may be imposed, including limiting the number of project variables, drivers and driver tags/data points. The System
Overview page includes information about the licensing, as shown in the example below.
The license limitations are managed by the firmware of the RTU32M. If you try to start a logic application in the RTU32M that exceeds
these limits, the project will NOT start and an info message in the Runtime info window in WorkSuite will indicate the status of the
limits in your project. Every time you start a runtime project the current status will be shown in the Runtime message window

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
10
and in the System Log of the RTU32M:
4.5 Adding Drivers and Runtime Options
The RTU32M Licensing interface allows loading and activation of runtime license options. The RTU ID is used by the Brodersen factory
to generate a unique license code that enables the required functionality. If you need additional drivers or other increased
functionality that requires a license upgrade, please contact Brodersen or your authorized distributor and provide them with the RTU
ID and details of the license requirements. You will then be sent a new license key that can be pasted in to the License Key field and
then select ‘Apply’ to activate the new license options. The example below shows a RTU32M licensed with many driver and
functionality options.

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
11
4.6 Settings overview
The first page that you access when you enter the RTU32M Web pages is the Settings Overview page:
On this page you will get an overview of the network settings and versions of the primary system files and drivers. If you are contacting
your support office or distributor, you will always be asked for the RTU32M Version Information eg. 1.65.5.40.

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
12
The Drivers installed section lists the installed drivers in your RTU32M. The full Modbus Suite and IEC60870 or DNP3 Slave Drivers are
installed in all RTU32M. Additional drivers are installed if their Driver License is ordered with the RTU32M.
4.7 Hardware Overview
The hardware overview page shows you the current I/O configuration status. It lists the I/O modules and allows you to read the status
of each input or output. In the example below, a RTU32N is equipped with 42 IO points and the status of various analog and digital IO
values can be seen. Note: the hardware overview is disabled in the early release firmware for the RTU32M (available 3Q 2018).

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
13
4.8 User Overview
The User Overview page is a simple user configurable local HMI that allows physical and virtual IO points to be read/written from/to
the RTU32M. The page is edited using the ‘Edit Config File’ menu (and selecting ‘CustomUI.ini’ to be opened). The example below
shows a simple User Overview for a RTU32N with 42 IO points. The descriptive text associated to each IO point can be edited by the
user eg. ‘A-DI ch0’ could be changed to ‘Pump 1 Running’ or ‘Gate 1 – Alarm Status’...
Note: the user overview page is disabled in the early release firmware for the RTU32M (available 3Q 2018).

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
14
The example below shows how the descriptions, point names and colours used in the IO animation can be easily edited.

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
15
4.9 Runtime Settings - Main Settings
The Runtime settings menu allows adjustment of the PLC runtime setup.
4.9.1 Communication
Configuration of basic start-up settings, communication ports and enabling of Remote Access SProtocols. Hold the cursor over the small
icon and you will get online help.
Port (Main)
The Main port is used for Brodersen WorkSuite communication for configuration and debugging. Default setting is 502.
This port is also used for the ModbusTCP Server.
Port (Binding)
The Binding Port is used by the event based binding protocol, where two or more RTU32 and PC STRATON T5 runtimes can exchange
data. Default setting is 9000.
Port (Event log)
The Event Log port is where the RTU32M System Log can be viewed - either by connecting using telnet or the Brodersen Event Viewer
tool. Default setting is 911.
Enable Serial Remote Access Protocol (SP5)
This protocol is to be used for remote serial communication from the Brodersen WorkSuite and is particularly well adapted to
communication systems with severe constraints such as radios and modems. e.g. if you have the RTU32M placed on a remote site
connected via serial communication using multi-drop radio or line connection –or even dial connection, you are able to remotely
connect to the RTU32M with the Brodersen WorkSuite and work online as if it was on your workshop table. The speed will however be
slower depending on your actual serial communication speed. It is possible to attach this protocol to two communication ports.

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
16
Serial settings
The syntax is: [M]COM{n}:{b},{p},{d},{s}[,h][,LL] and the parameters in brackets [ ] are optional:
[M] Use modem connection
{n} Number of the COM port to be used (1 … 8)
{b} Allowed speeds: 300,600,1200,2400,4800,9600,19200,38400,57600,115200
{p} Parity: N,E,O (None,Even,Odd)
{d} Data bits: 7 or 8
{s} Stop bits: 1 or 2
[h] RTS/CTS handshaking where h is either RD,RE,RT:l:t or RC:l:t. In the COM port section you will find details of how to use these
parameters.
[LL] Log all bytes received and transmitted into the system log (port 911)
The following example shows setting for communicating on COM1 port, at 19200 baud, with Even parity, 8 data bits and 1 stop bit:
COM1:19200,E,8,1
Here a modem usage is enabled: MCOM2:9600,N,8,1
Here logging is enabled: COM1:9600,N,8,1,LL
Node address
Node Address (or Unit number) identifies the RTU32 on a multi drop network. The default number for RTU32M on a peer to peer
network is 1. The address must be a value from 1 to 32767.
Modem Init String
Here you enter the initialization string (AT commands) when using a modem.
RTU32M default is: AT E0 V0 &C1 S0=1
4.9.2 Start-up
The start-up option specifies how the PLC application is started when the RTU32M is powered up. The possible options are:
No Start –PLC application is NOT started when booting the RTU32.
Cold Start –PLC application is started without loading retained variables.
Warm Start –PLC application is started and retained variables are loaded (default) **.
Hot Restart –Only supported with battery backed RAM option and in Redundancy configuration!
** Note: RTU32M retained variables are stored to the SD card only if/when the ‘STORERETAIN’ function is called.
4.9.3 Options
Use UTC time for PLC real time functions
If enabled, it instructs all PLC real time functions (e.g. DTCurDate, DTCurTime and day_time) to return time in UTC. UTC time is not
adjusted according to daylight savings. If this parameter is disabled then time is returned in local time which is adjusted to daylight
saving if this option is enabled.
NOTE: Drivers that are implemented via PLC Functions –like the IEC60870 Driver –will use the PLC time stamp for events! Other
drivers may take standard windows time or whatever time is defined in the applicable standards.
Enable Multi Task
This is a licensed option and allows the RTU to run up to 4x independent logic tasks (global variables can be accessed from any/all
tasks).
PLC Main Settings / Binding Protocol Timing (seconds)
When using binding on slower network connection like some optical fibre modems or GPRS/3G wireless connections, you will need to
adjust the timing for the Binding driver.
The possible timing adjustments are:
Heartbeat period –how often a heartbeat is sending to check the binding link connection.
Binding Time-out –time-out on link check and general binding event.

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
17
4.10 Runtime Settings - Redundancy Settings
On this page you can set the rules for RTU redundancy.
4.11 I/O Board Settings
On this page you can:
- Read the actual I/O configuration on the RTU32M.
- Note: the settings for configuration of inputs and output parameters is managed from within WorkSuite. Future releases of firmware
will allow access to these parameters via the web interface.
4.11.1 Current I/O Configuration
Here the module layout is listed. In the example below you will see that the module list includes a power supply, 8ch analog input, 20
ch digital input, 12ch digital output and a mixed I/O module with 10x DI and 10x DO.

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
18
4.12 System Configuration - Network Settings
On the System Configuration>Network Settings page you can change the LAN port settings to fit your local network. You can assign
fixed IP addresses or select DHCP to have the address set via a router. You can then gain access to the RTU32M with your browser,
SFTP client or Brodersen WorkSuite in your LAN network. If you do not know about the IP addresses and Subnet masks in your local
network, please contact your local network manager or IT department for help.
You can also change the RTU Host Name. The default host name of the RTU32M is imx6ul-var-dart.
After entering new settings, click Apply to save. Note that the new settings are activated within a few seconds (you do not need to
restart/reboot the RTU32M, or cycle power to the RTU).
4.13 Network Redundancy - Protocols
Modern substation automation systems use network redundancy to improve reliability and network changeover times. The RTU32M
System Configuration>Network Redundancy page allows selection of network redundancy protocols HSR (High Availability Seamless
Redundancy –where both LAN ports are used to ensure two network paths exist between adjacent nodes in a ring format), or PRP
(Parallel Redundancy Protocol –where both LAN ports are used to communicate via independent/separated networks).

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
19
4.13.1 HSR –High Availability Seamless Redundancy
-Select HSR
-Select the correct HSR version
-HSR/PRP supervision “Specifies the last byte of the multicast address used for HSR/PRP supervision”
-Enter the IP Address that will be common for both LAN interfaces.
-Enter subnet mask or use default
-HSR clone MAC address specifies whether the eth0 adapters MAC is used for both LAN adapters (this is supported by HSR
only).
4.13.2 PRP –Parallel Redundancy Protocol
-Select PRP
-HSR/PRP supervision “Specifies the last byte of the multicast address used for HSR/PRP supervision”
-Enter the IP Address that will be common for both LAN interfaces.
-Enter subnet mask or use default
-HSR clone MAC is only supported by HSR
4.14 Network Redundancy - Bonding
Network Bonding allows both RTU LAN ports to act as a single interface to allow primary/standby modes or load balancing in network
redundancy applications.
The four bonding modes include;
-Active- Backup
-Balance –RR
-Balance –XOR
-Broadcast
4.15 Adding a USB - Ethernet Adapter
The RTU32M supports addition of a USB Ethernet Adapter (Important, use only the Brodersen USB Ethernet adapter). After inserting
the USB Ethernet adapter, ETHERNET LAN 3 will be included on the Network Settings web page and it must be configured in the same
way as LAN 1 and LAN 2.
4.16 Adding USB –RS232 Serial Adapters
The RTU32M supports addition of USB Serial Adapters to add serial ports (Important, use only FTDI USB adapters). After inserting the
USB RS232 serial adapter, an additional com port will be created (eg. COM1 a /dev/ttyUSB1, then COM2 at /dev/ttyUSB2 etc.
4.17 Adding a USB - WiFi Adapter
The RTU32M supports addition of a USB WiFi Adapter to add an access point (default mode) or managed node (Important, use only
WLU6331 USB adapters). After inserting the USB Wifi adapter, ETHERNET LAN 3 will be included on the Network Settings web page.
The adapter can be disabled, configured and the mode changed from the Network Access Web page..

RTU32M Series User Guide
Brodersen A/S, Islevdalvej 187, DK-2610 Roedovre, Denmark, Tel: [phone], Fax: [phone], Email: [e-mail]
August 2018
20
4.18 VPN Settings
The RTU VPN Client supports PPTP and L2TP (IPsec) for up to VPN Servers. The settings for each VPN server interface can be adjusted
using the webpage.
In order to ensure the VPN client is working you will need to enter all credentials correctly. The webpage includes small help icons - just
put the cursor on them and you will get details for each point. Controlling the connection of the VPN Client is done from the RTU logic
application. Use the Function Block ConnectVPN found in the Dial-up function group to manage the VPN connections
Note: the VPN page is disabled in the early release firmware
for the RTU32M (available 3Q 2018).
