Brodie BiRotor Plus B27X User manual

IOM BiRotor Plus R27Page 1/58
BiRotor Plus
Positive Displacement Flow Meter
B through F Series Meters
Installation & Operation Manual

IOM BiRotor Plus R27Page 2/58
Table of Contents
1 Read Me First .............................................................................................................................3
2 Essential Instructions ............................................................................................................ 4
3 Warranty Claim Procedures.................................................................................................. 8
4 Receipt of Shipment ............................................................................................................. 12
5 Return of Equipment ............................................................................................................ 12
6 Storage .................................................................................................................................... 13
7 Description............................................................................................................................... 13
8 Installation and Operation ................................................................................................... 15
8.1 - Installation Requirements ............................................................................................... 15
8.2 - Installing the Instrument................................................................................................ 16
8.3 - Meter Start Up and Operation.......................................................................................18
8.4 - Higher Temperature Start Up........................................................................................ 19
8.5 - Custody Transfer .............................................................................................................. 19
8.6 - Electrical - Symbols and Definitions...........................................................................20
9 Maintenance............................................................................................................................ 21
9.1 - Removal/Replacement of Circuit Board...................................................................... 22
9.2 - Removal/Replacement of Pick Off Sensors ............................................................. 22
9.3 - Removal of the Measuring Unit from the Process Line.......................................... 23
9.4 - Removal of the Measuring Unit from the Instrument Body.................................. 23
9.5 - Measuring Unit Disassembly While Maintaining Clearance Settings .................. 25
9.6 - Complete Disassembly of the Measuring Unit.......................................................... 25
9.7 - Complete Reassembly of the Measuring Unit B27 thru B34 ................................ 26
9.8 - Complete Reassembly B35 thru B38.......................................................................... 29
9.9 - Setting Clearances ........................................................................................................... 31
10 Troubleshooting ................................................................................................................... 32
11 Strainers.................................................................................................................................. 33
12 Parts Lists.............................................................................................................................. 34
13 Parts Lists (extended) .......................................................................................................... 51
Appendix A .................................................................................................................................58
Appendix B .................................................................................................................................59

IOM BiRotor Plus R27Page 3/58
1 Read Me First
Notice
Brodie International, a Brodie Meter Co., LLC
Company (“Brodie”) shall not be liable for
technical or editorial errors in this manual or
omissions from this manual.
Brodie makes no warranties, expressed or implied,
including the implied warranties of merchantability
and fitness for a particular purpose with respect to
this manual and, in no event, shall Brodie be liable
for any special or consequential damages
including, but not limited to, loss of production,
loss of profits, etc.
Product names used herein are for
manufacturer or supplier identification only and
may be trademarks/registered trademarks of these
companies. The contents of this publication are
presented for informational purposes only, and
while every effort has been made to ensure their
accuracy, they are not to be construed as
warranties or guarantees, expressed or implied,
regarding the products or services described
herein or their use or applicability. We reserve the
right to modify or improve the designs or
specifications of such products at any time.
Brodie does not assume responsibility for the
selection, use or maintenance of any product.
Responsibility for proper selection, use and
maintenance of any Brodie product remains solely
with the purchaser and end-user.
No part of this work may be reproduced or copied
in any form or by any means - graphic, electronic
or mechanical - without first receiving the written
permission of Brodie International.

Page 4/58IOM BiRotor Plus R27
2 Essential Instructions
General
Brodie International designs, manufactures and
tests its products to meet many international
standards. As the instruments are sophisticated
technical products they must be installed, used
and maintained properly to ensure they continue
to operate within their normal specifications. The
following instructions must be adhered to and
incorporated into onsite safety programs where
possible.
Read all instructions prior to installing, operating,
and servicing the product. If this instruction
manual is not the correct manual, telephone +1
912 489 0200 and the requested manual will be
provided.
Save this instruction manual for future reference.
If you do not understand any of the instructions,
contact your Brodie representative for
clarification.
Follow all warnings, cautions, and instructions
marked on and supplied with the product.
Inform and educate your personnel in the proper
installation, operation, and maintenance of the
product. Install your equipment as specified in
the installation instructions of the appropriate
instruction manual and per applicable local and
national codes. Connect all products to the proper
electrical and pressure sources.
To ensure proper performance, use qualified
personnel to install, operate, update, program, and
maintain the product. When replacement parts
are required, ensure that qualified personnel use
replacement parts specified by the manufacturer.
Unauthorized parts and procedures can affect the
product’s performance and place the safe
operation of your process at risk. Look-alike
substitutions may result in fire, electrical hazards,
or improper operation.
Ensure that all equipment doors are closed and
protective covers are in place, except when
maintenance is being performed by qualified
personnel, to prevent electrical shock and
personal injury.
It is the customer’s responsibility to provide fire
prevention measures and equipment per local
regulations.
Use of this equipment for any purpose other than
its intended purpose may result in property
damage and/or serious personal injury or death.

IOM BiRotor Plus R27Page 5/58
Essential Instructions for Measuring Equipment, Including the
European Union (Directive 2014/32/EU MID)
Although measurement transducers are not
specifically included in the MID regulations as they
do not form a complete measuring instrument
system, in accordance with Article 1 and 4, Annex
I and Annex VII, Brodie Meter Co., LLC implements
the same stringent regulations for all products and
tests to the same standards which are used for
complete measuring instrument systems.
The complete system must contain all the
necessary components to meet the requirements
of the local regulations. These components may
include pumps, air eliminators, strainers, valves,
flow computers, etc. The unit must be sealed in
accordance with the local regulations; it is the end
user’s responsibility to ensure this happens.
Flow measuring devices are provided with two
labels which specify flow ranges. The name plate
label, which includes the factory serial number,
details the operating flow range. This is the flow
range the device will operate within without
causing damage. The custody transfer label details
the working flow range associated with a particular
weights and measures approval.
It should be noted that these may not be the same;
therefore, in trade applications, the flow ranges
specified on the custody transfer label should be
followed.
Essential Instructions for Electrical Equipment, Including the
European Union (Directive 2014/30/EU and 2014/32/EU)
This unit contains Electrostatic sensitive circuit
boards. Electrostatic safety precautions should be
taken to prevent damage.
When connecting wiring it is good practice to use
shielded cable. The shield should be connected to
earth at the read out or control systems end of the
cable; the other end of the shield should not be
connected.
This wiring practice is mandatory in order to
comply with the requirements for electromagnetic
compatibility as per the EMC directive 2014/30/EU
and MID 2014/32/EU of the council of the
European Union.
It is the end user’s responsibility to ensure that all
protective covers are in place to prevent electrical
shock and/or personnel injury.

Page 6/58IOM BiRotor Plus R27
Essential Instructions for Pressure Containing Equipment,
Including the European Union (Directive 2014/68/EU)
When installing the equipment the bolting must
conform to the requirements of ASME B16.5,
paragraph 5.3, and to the material requirements of
ASME B16.5, Table 1B. Gaskets must conform to the
requirements of ASME B16.20.
Although it is not expected for the device to
be used in a service where it would come in to
contact with unstable fluids, it is the end user’s
responsibility to assess any risks and take any
precautions necessary.
It is the end user’s responsibility to ensure that
piping and other attachments connected to the
Brodie instrument do not place adverse stresses
upon it, the design of the instrument has not
been assessed for the effects of traffic, wind or
earthquake loadings.
It is the end user’s responsibility to ensure that the
instrument is mounted when required on suitable
supporting foundations.
It is the end user’s responsibility to install the
device in a well-designed system to avoid potential
hazards such as water hammer, vacuum collapse
or uncontrolled chemical reactions.
It is the end user’s responsibility to provide fire
protection measures and equipment in accordance
with the local regulations.
It is the end user’s responsibility to install suitable
straining and air/gas elimination systems.
The instrument has been designed without
allowance for corrosion or other chemical attack.
The end user should implement a periodic
inspection and maintenance program to ensure
that none of the instruments pressure containing
components have been subject to any corrosion. It
is possible to examine the instrument for evidence
of corrosion through the inlet and the outlet.
When the ambient temperature is below the
minimum operating temperature specified on the
device it is the end user’s responsibility to ensure
that the device is warmed to an appropriated
temperature before being pressurized.
Do not exceed the operating pressure and
temperature limits of the instrument as stamped
on the nameplates.
It is the customer’s responsibility to install this
equipment in a system that provides adequate
over-pressure protection and that limit pressure
surges to 10% of the maximum allowable working
pressure of the instrument.
It is the end user’s responsibility to provide fire
protection measures and equipment in accordance
with the local regulations.

IOM BiRotor Plus R27Page 7/58
Essential Instructions for Equipment to be Used in Hazardous
Locations, Including the European Union
(Directive 2014/34/EU)
Any Hazardous area approval applies to equipment
without cable glands. When mounting the
flameproof enclosure in a hazardous area only
cable glands/conduit seals certified to meet or
exceed the rating of the equipment should be
used, refer to the type approval documentation
for further details. Cable glands and cable must
be suitable for the operating temperature of
the device under its rated conditions, this is
especially important if the device has an operating
temperature above 1580F (700C). It is the end
user’s responsibility to ensure this happens.
The meter has been provided with an approved
sealing device in one of the cable entries, the other
entry has been closed with a plastic cap plug. It is
the end user’s responsibility to remove the cap plug
and replace it with a suitable cable gland or conduit
seal before the equipment is put into service.
It is the end user’s responsibility to ensure, when
the instrument is located in a hazardous area, that
all cable glands and conduit seals are installed in
accordance with all local codes and regulations.
It is the end user’s responsibility to ensure that
before opening an electronic enclosure in a
flammable atmosphere that all the electrical
circuits have been interrupted.
If replacement of the screws which secure the
sensor housing, the UMB cover of the electronic
register and its cover, are required, they must be
replaced with either factory direct parts or M6-1x16
(6g) mm hex head socket screws of equal length.
The screws must be made from stainless steel
grade A1-70 or A2-70 and be torqued to a value of
55 inch lbs. upon installation. It is the end user’s
responsibility to ensure this happens.
It is the end user’s responsibility to assess the
maximum surface temperature of the device
and the equipment the device is attached to
and located next to as this may exceed the
temperature ratings of the device itself. If this
happens, additional safety precautions will need to
be implemented by the end user.
Flame proof housings contain Aluminum; although
the composition of these enclosures is carefully
maintained to prevent any risk of an ignition source
it is the end users responsibility to ensure that the
housing is not struck by rusty tools or objects.
If the equipment is to be installed in an area where
dust deposits and build up are to be expected, a
maintenance plan should be arranged to include
regular removal of the dust build up. This will prevent
the dust from forming a possible source of ignition.
The power supply requirements for this
product are specified within the operating
and maintenance manual, it is the end user’s
responsibility to operate the product within these
specified limits.
The instrument may contain surfaces that
constitute flames paths, these surfaces should
not contain any mars or scratches. Damaged
flamepath surfaces may not be repaired. If
any damage is present, the factory or the local
representative should be contacted immediately
to obtain a new housing as the safety of the
enclosure may be impaired and must be replaced.
It is the end user’s responsibility to inspect these
surfaces every time the enclosure is opened.
When flanged flame paths are reassembled the
gap between them should be less than 0.0015”
(0.038 mm) such that a 1/2” (12.5mm) wide
0.0015” (0.038 mm) feeler gauge will not enter
the gap more than 1/8” (3mm). It is the end user’s
responsibility to ensure this happens each time the
enclosure is reassembled.

Page 8/58IOM BiRotor Plus R27
3 Warranty Claim Procedures
These terms and conditions, the attendant
quotation or the acknowledgement, and all
documents incorporated by reference therein,
binds Brodie Meter Co., LLC, who issues the
quotation or acknowledgment for the provision of
services and/or the sale of goods (except as
provided in Section 11), to be provided hereunder
by seller (Brodie Meter Co., LLC) hereinafter Seller,
and the buyer, hereinafter Buyer, and constitute
the entire agreement (Agreement) between Buyer
and Seller regarding such sale and/or provision.
To the extent not in conflict with the superseding
terms of the Sales Order, these terms and
conditions will be in force.
1. PRICES: Unless otherwise specified by Seller,
Seller’s price for the Goods and/or Services shall
remain in effect for thirty (30) days after the date
of Seller’s quotation or acceptance of the order for
the Goods/Services, whichever is delivered first,
provided an unconditional, complete authorization
for the immediate manufacture and shipment of
the Goods and/or provision of Services pursuant
to Seller’s standard order processing procedures
is received and accepted by Seller within such
time period. If such authorization is not received
by Seller within such thirty (30) day period, Seller
shall exercise the right to change the price for the
Goods/Services to Seller’s price in effect for the
Goods/Services at the time the order is released
to final manufacture. Notwithstanding any of the
foregoing to the contrary, the price for
Goods/Services sold by Seller, but manufactured
by others, shall be Seller’s price in effect at the
time of shipment to Buyer.
2. DELIVERY, PASSING OF RISK, RETENTION OF
TITLE, AND DOCUMENTATION: All shipping dates
are approximate and are based upon Seller’s
prompt receipt of all necessary information from
Buyer to properly process the order. Any agreed
trade term shall be construed in accordance with
the INCOTERMS® in force at the formulation of
the contract. If no trade term has been specifically
agreed, the delivery shall be F.O.B. Brodie Factory,
FCA Brodie Factory, or EXWORKS Brodie Factory.
Notwithstanding, any provisions to the contrary in
this or other documents related to this transaction,
the passing of risk of loss thereto shall transfer
to Buyer upon delivery to the first freight carrier
at the shipping point. The Goods shall remain the
property of the Seller until paid for in full to the
extent that such retention of title is valid under the
relevant law. The retention of title shall not affect
the passing of risk. The Seller shall provide Buyer
with that data/documentation which is
specifically identified in the contract. If additional
copies of data / documentation or non-standard
data/documentation are to be provided by Seller,
they shall be provided to Buyer at Seller’s price
then in effect.
3. EXCUSE OF PERFORMANCE: Seller shall not be
liable for delays in performance or for
non-performance due to acts of God, war, riot,
fire, labor trouble, unavailability of materials or
components, explosion, accident, compliance with
governmental requests, laws, regulations, orders
or actions, or other unforeseen circumstances or
causes beyond Seller’s reasonable control.
4. CHANGE, CANCELLATION AND RESTOCKING
CHARGES: Once an order has been acknowledged
by the Seller, any changes requested by the Buyer
must be communicated to the Seller. The Seller
will notify the Buyer of any fees associated with
the requested change. Buyer may terminate or
suspend its non-shipped order for any or all of the
Goods/Services covered by the Agreement,
provided that Buyer gives Seller reasonable
advance written notice of such termination or
suspension and reimburses Seller accordingly:

IOM BiRotor Plus R27Page 9/58
25% of Net Order after Release to Engineering,
50% of Net Order after Release to Manufacturing,
75% of Net order after 50% Manufacture
Complete and 100% of Net Order once
Manufacturing is complete. Any request for
return of product already shipped to Buyer will be
at the discretion of Brodie. If so approved, a
Return Authorization will be provided and a
restocking fee assessed.
5. LIMITED WARRANTY: Subject to the limitations
contained in Section 2 herein and except as
otherwise expressly provided herein, Brodie Meter
Co., LLC (“Brodie”) warrants the
Goods-manufactured by Brodie will be free from
defects in materials or workmanship under normal
use and care until the expiration of the applicable
warranty period. Goods are warranted for twelve
(12) months from the date of installation and 18
months from date of shipment, whichever occurs
first. Consumables and Services are warranted for
a period of 90 days from the date of shipment or
completion of the Services. Products purchased
by Brodie from a third party for resale to Buyer
(“Resale Products”) shall carry only the
warranty extended by the original manufacturer.
Buyer agrees that Brodie has no liability for Resale
Products beyond making a reasonable commercial
effort to arrange for procurement and shipping of
the Resale Products. If Buyer discovers any
warranty defects and notifies Brodie thereof in
writing during the applicable warranty period,
Brodie shall, at its option, repair or replace, that
portion of the Goods found by Brodie to be
defective or refund the purchase price of the
defective portion of the Goods/Services. All
replacements or repairs necessitated by
inadequate maintenance, normal wear and usage,
unsuitable power sources, unsuitable
environmental conditions, accident, misuse,
improper installation, modification, repair, storage
or handling, or any other cause not the fault of
Brodie, are not covered by this limited warranty,
and shall be at Buyer’s expense. Brodie shall not be
obligated to pay any costs or charges incurred by
Buyer or any other party except as may be agreed
upon in writing in advance by an authorized Brodie
representative. All costs of dismantling,
reinstallation and freight and the time and
expenses of Brodie’s personnel for site travel
and diagnosis under this warranty clause shall
be borne by Buyer unless accepted in writing by
Brodie. Brodie is not responsible for damages that
incur during shipment to Buyer for shipments that
are F.O.B. Brodie Factory, FCA Brodie Factory, or
EXWORKS Brodie Factory. Shipping charges for
goods returned to Brodie under warranty will be at
Buyer’s expense. Products found not to be
warranted can be repaired and returned at
Buyer’s expense and return charges born by Brodie
will be added to the cost of repair or returned to
Buyer “as received” at Buyer’s expense. Insurance
for returned products will be at Buyer’s expense.
For all returned products please package to
prevent damage, or future damage during
shipment. Make sure the products are cleaned,
free from grease oil, chemicals and other
materials that may hamper defect detection and
impede repair. All returned items must be
accompanied with a MSDS for the products that
have been in contact with the equipment, including
cleaning agents. A decontamination statement,
RMA, and Customer Problem Report must also
accompany equipment returned. Product received
in an unsuitable condition will be returned at
Buyer’s expense without being examined. Goods
repaired, and parts replaced during the warranty
period shall be in warranty for the remainder of
the original warranty period or ninety (90) days,
whichever is longer. This limited warranty is the
only warranty made by Brodie and can be
amended only in a writing signed by an
authorized representative of Brodie. Except as
otherwise expressly provided in the Agreement,
there are no representations or warranties of any
kind, expressed or implied, as to
merchantability, fitness for a particular purpose, or
any other matter with respect to any of the goods
or services. It is understood that corrosion or
erosion of materials is not covered by our
guarantee unless the Buyer has notified the Seller
the product will be used in an environment
conducive to corrosion and/or erosion and the
product has been coated with Brodie’s
recommended method of protection against
corrosion / erosion.

Page 10/58IOM BiRotor Plus R27
6. LIMITATION OF REMEDY AND LIABILITY:
Brodie shall not be liable for damages caused
in delay in performance. The sole and exclusive
remedy for breach of warranty hereunder shall be
limited to repair, correction, replacement or refund
of purchase price under the limited warranty
clause in section 5. In no event, regardless of
the form of the claim or cause of action (whether
based in contract, infringement, negligence, strict
liability, other tort or otherwise), shall Brodie’s
liability to buyer and/or its customers exceed the
price to buyer of the specific goods manufactured
or services provided by Brodie giving rise to the
claim or cause of action. Buyer agrees that in
no event shall Brodie’s liability to buyer and/
or its customers extend to include incidental,
consequential or punitive damages. The term
“consequential damages” shall include, but not be
limited to, loss of anticipated profits, loss of use,
loss of revenue and cost of capital.
7. PATENTS: Subject to the limitations contained
in Section 6, Seller shall defend any suits brought
against Buyer based on a claim that use of the
Goods manufactured by Seller constitutes an
infringement of a valid patent of the United States,
and shall pay any damages awarded therein
against Buyer, provided that Buyer: promptly
notifies Seller in writing of the filing of such suit
or the threat thereof; permits Seller to control
completely the defense or compromise of such
claim of infringement; and provides all reasonable
assistance and cooperation requested by Seller
for the defense of such suit. In the event that only
the Goods manufactured by Seller are held to be
infringing in such suit and their use is enjoined,
Seller shall, at its sole option and expense, provide
a commercially reasonable alternative, including,
but not limited to, procuring for Buyer the right
to continue using the Goods, replacing them with
a non-infringing product or modifying them so
they become non-infringing. Buyer agrees that
Seller shall not be liable for infringement, and
that Buyer shall fully indemnify Seller therefore,
if infringement is based upon the use of Goods
in connection with Goods not manufactured by
Seller or in a manner for which the Goods were
not designed by the Seller or if the Goods were
not designed by the Seller or if the Goods were
designed by the Buyer or were modified by or for
the Buyer in a manner to cause them to become
infringing.
8. INSTALLATION: Buyer shall be responsible
for receiving, storing, installing, starting up and
maintaining all Goods. Seller shall provide a
quotation for services to assist Buyer in these
functions if requested.
9. TAXES: Any tax or governmental charge
payable by the Seller because of the manufacture,
sale or delivery of the Goods, or provision of
Services, may at Seller’s option be added to the
price herein specified. The foregoing shall not
apply to taxes based upon Seller’s net income.
10. TERMS OF SHIPMENT AND PAYMENT: Subject
to the approval of Seller’s Credit Department,
shipping terms are F.O.B. Brodie Factory, FCA
Brodie Factory, or EXWORKS Brodie Factory.
Payment terms are subject to the approval of
Seller’s Credit Department and may vary based on
Buyer’s creditworthiness. Payment is expected, in
U.S. currency, as per the prearranged agreement
between the Buyer and Seller stated on the sales
order. In the absence of such agreement, payment,
in U.S. currency, is due Net30 days from the
date of invoice. If any payment owed to Seller
hereunder is not paid when due, it shall bear
interest, at a rate to be determined by Seller which
shall not exceed the maximum rate permitted
by law, from the date on which it is due until it is
received. Seller shall have the right, among other
remedies, either to terminate the Agreement or
to suspend further deliveries under this and/or
other agreements with Buyer in the event Buyer
fails to make any payment hereunder when due.
Buyer shall be liable for all expenses incurred
for collection of past due amounts, including
attorneys’ fees.
11. STORAGE FEES
1. Per diem charges are applicable when equipment
is held beyond the acknowledged ready for
shipment date.
Per diem storage charges will be assessed on each

IOM BiRotor Plus R27Page 11/58
calendar day excluding the date of readiness.
The customer shall indemnify and hold Brodie
International harmless from any and all liability
and expense for such damages that might result
from extended storage beyond six months. Brodie
may place the cargo in another warehouse facility
with all charges associated with the transfer and
storage to be paid by the customer.
12. SOFTWARE AND FIRMWARE: Notwithstanding
any other provision herein to the contrary, Seller
or applicable third-party owner shall retain all
rights of ownership and title in its respective
firmware and software, including all copyrights
relating to such firmware and software and all
copies of such firmware and software. Except as
otherwise provided herein, Buyer is hereby granted
a nonexclusive, royalty free license to use firmware
and software, and copies of firmware and software,
incorporated into the Goods only in conjunction
with such Goods and only at the Buyer’s plant
site where the Goods are first used. Buyer may
negotiate with Seller separate licenses to use such
copies and firmware and software at other plant
sites. Buyer’s use of certain firmware (as specified
by Seller) and all other software shall be governed
exclusively by Seller’s and/or third-party owner’s
applicable license terms.
13. BUYER SUPPLIED DATA: To the extent
that Seller has relied upon any specifications,
information, representation of operating
conditions or other data or information supplied
by Buyer to Seller in the selection or design of
the Goods and/or provision of the Services and
the preparation of Seller’s quotation, and in the
event that the specifications or information is
inaccurate or actual operating conditions differ,
any warranties or other provisions contained
herein which are affected by such conditions shall
be null and void, unless otherwise mutually agreed
upon in writing.
14. GENERAL PROVISIONS: (a) Buyer shall
not assign its rights or obligations under the
Agreement without Seller’s prior written consent.
(b) There are no understandings, agreements
or representations, express or implied, not
specified in the Agreement. (c) No action,
regardless of form, arising out of transactions
under the Agreement, may be brought by either
party more than two (2) years after the cause
of action has accrued. (d) Any modification of
these terms and conditions must be set forth in
a written instrument signed by a duly authorized
representative of Seller. (e) The Agreement is
formed and shall be construed, performed and
enforced under the laws of the state of Georgia.
However, Buyer and Seller agree that the proper
venue for all actions arising under the Agreement
shall be only in the State where the Goods involved
in such actions were manufactured. (f) GOODS
AND SERVICES PROVIDED HEREUNDER ARE NOT
SOLD OR INTENDED FOR USE IN ANY NUCLEAR
OR NUCLEAR RELATED APPLICATIONS. Buyer (i)
accepts Goods and Services in accordance with the
restriction set forth in the immediately preceding
sentence, (ii) agrees to communicate such
restriction in writing to any and all subsequent
purchasers or users and (iii) agrees to defend,
indemnify and hold harmless Seller from any and
all claims, losses, liabilities, suits, judgments and
damages, including incidental and consequential
damages, arising from use of Goods and Services
in any nuclear or nuclear related applications,
whether the cause of action be based in tort,
contract or otherwise, including allegations that
the Seller’s liability is based on negligence or strict
liability. (g) The 1980 United Nations Convention
on Contracts for the International Sale of Goods
does not apply to this Agreement. (h) If any
provision of the Agreement is invalid under any
statute or rule of law, such provision, to that
extent only, shall be deemed to be omitted without
affecting the validity of the remainder of the
Agreement.

Page 12/58IOM BiRotor Plus R27
4 Receipt of Shipment
When you receive your equipment inspect the
outside of the packing case for damage which may
have incurred during shipping. Damage incurred
during shipment is the responsibility of the carrier
and is not part of the factory warranty. If the
packing case is damaged, notify the local carrier
immediately.
If the package is in good condition remove the
envelope containing the packing list and carefully
remove the equipment and all components
included in the shipment from the packing case.
Inspect for damaged or missing parts, referring to
the packing list, and prior to discarding the packing
material.
If Items are missing from your shipment, contact
your sales representative. Your sales order number
will be required.
5 Return of Equipment
If the equipment must be returned to the factory
for repair or replacement, a Returned Materials
Authorization (RMA) must be included with the
components.
RMA forms may be obtained from your sales
representative or from the Product Service
Department.
In addition to the RMA, a Material Safety Data
Sheet and a Decontamination Statement must be
included with Items being returned to the factory.
A Decontamination Statement is included in the
back of this manual.
If the equipment is removed from service it must
be thoroughly drained and neutralized before it is
packed for shipment. Care must be taken to ensure
that product removed from the equipment is
disposed of in accordance with all applicable local,
state and federal regulations.
The flanges should be sealed to keep residual fluid
from leaking out of the meter during transport.
The type of flange seal required will vary with the
form of transportation used. Contact the carrier
for specific instructions.
The equipment should be securely mounted on a
wooden skid for shipment. The original container
or a solid wooden box should be used to protect
the exterior of the components.
When packing the components for return to the
factory, place the RMA and a copy of the packing
list that was delivered with the equipment inside
an envelope. Place the envelope inside the
shipping container with the Item being returned
and reference the RMA number on the outside of
the shipping container.
Equipment returned to the factory without the
proper documentation will be returned to sender
at their expense.
Ship the container to:
Brodie Meter Co., LLC
Product Service Department
19267 Highway 301 North
Statesboro, GA 30461, USA
Phone: [phone]
Fax: [phone]
[e-mail]

IOM BiRotor Plus R27Page 13/58
6 Storage
Brodie International instruments are precision
devices and should be handled and stored with
care. They should not be subjected to rough or
improper handling or stored in an environment
where moisture, extreme temperatures, or foreign
material can damage the meter.
The inlet and outlet flange covers should remain
on the instrument until the unit is ready for
installation.
If extended storage is required it is
recommended that the instrument be placed in an
environmentally controlled warehouse.
If this is not possible the instrument should be
stored in a waterproof lined wooden box. Desiccant
packs should be taped to the inside of the
instrument end connections before they are sealed
to reduce the effect of humidity on the equipment
and accessories. Caution must be used to ensure
desiccant packs are removed prior to installation.
Depending on the storage time it may also be
preferable to use a compatible corrosion inhibitor.
If the meter is removed from service for an
extended period of time it should be flushed with a
light oil before being placed into storage.
7 Description
General
The BiRotor Plus is an extremely accurate,
dualcased, flow measuring device. It produces a
high resolution signal, via the use of non-wetted
pick offs, which is directly proportional to the rate
of liquid flow through the meter. These signals
can be shaped by a simple pre-amplifier for
transmission to ancillary equipment.
The BiRotor Plus meter utilizes the exclusive
BiRotor principle. There are no sliding, oscillating,
or reciprocating parts.
The BiRotor Plus (models B27X, B28X, B29X,
B30X, B31X, B32X, B33X, B34X, B35X, B36X, B38X,
SB25X, LB27X, LB28X, LB29X) electrical enclosure
comprises of a cast aluminum body and a plain lid
containing a PCB which consists of an inductive
proximity sensor which detects metallic objects
without coming in direct contact. Two entry holes
are provided on one face of the enclosure to allow
the fitment of suitable cable entry devices. A
closed cell silicon rubber compound sponge gas-
ket is fitted around the top of the enclosure, onto
which the lid is fitted. The lid is held in position
with four socket head screws. A warning label is
fitted on the lid and held in place with four rivets
secured into blind holes.

Page 14/58IOM BiRotor Plus R27
The model type is identified by the model code. Eg. B27X:
B, SB, LB – symbolizes that it is a model of BiRotor Plus series.
25 through 38 – indicates meter size in inches.
X - represents maximum working pressure of:
1 for 16 bar (DIN) / 285 p.s.i. (ANSI), OR
2 for 40 bar (DIN) / 740 p.s.i. (ANSI), OR
5 for 100 bar (DIN) / 1480 p.s.i. (ANSI), OR
6 for 200 p.s.i (Victaulic) for B27, B28, or B29 only.
The BiRotor Plus meter can be supplied with the
following approvals and certifications:
CSA 2142875
Class I, Division 1, Groups C & D T6
-40 °C < Ta < 60 °C
Class I, Division 1, Groups C & D T4
-40 °C < Ta < 60 °C
IECEx ITS 08.0021X
Ex db IIB T6 Gb IP65
-40 °C < Ta < +60 °C
Ex db IIB T4 Gb IP65
-40 °C < Ta < +60 °C
Tested to standards:
IEC 60079-0:2017
IEC 60079-1:2014
ITS 08 ATEX 15842X
ITS 22 UKEX 0503X
II 2 G Ex db IIB T6 Gb IP65
-40°C < Ta < +60°C
II 2 G Ex db IIB T4 Gb IP65
-40°C < Ta < +60°C
Tested to standards:
EN IEC 60079-0:2018
EN 60079-1:2014
Specific Conditions of Use / Schedule Limitations
/ Special Conditions for Safe Use / Special
Considerations of Certification:
• On assembly the gap between the lid and the
enclosure must be less than 0.0381mm (0.0015”)
in accordance with drawing ENG-7617-300.
• The Flameproof Joints are not intended to be
repaired or changed without the manufacturer’s
consent.
• The SB25X enclosure is to be routine pressure
tested at 170.1 psi / 11.73 bar.
General Note:
Temperature class is based on process
temperature range.
T6: 75°C Maximum Standard Process
Temperature
T4: 110°C Maximum High Process
Temperature

IOM BiRotor Plus R27Page 15/58
8 Installation and Operation
General
The operation of the meter is embodied in the
function of the measuring rotors; they are always
dynamically balanced but hydraulically unbalanced
during operation. The rotors have no metal to
metal contact with each other or the housing in
which they rotate. Clearances between moving
components are maintained with the use of timing
gears.
The BiRotor Plus is a positive displacement (PD)
meter. A PD meter uses a mechanical principle that
measures flow by continuously dividing the flowing
stream into known volumetric segments, isolating
those segments momentarily, and then returning
them to the flowing stream while counting the
number of displacements. This is a direct volume
measurement, there is no inferred, or software
generated, measurement.
8.1 - Installation Requirements
1. The instrument should be mounted on a
secure foundation. Provisions should be made
for vertically mounting the meter to ensure
stability.
2. The process piping should not place any undue
strain on the instrument.
3. Precautions should be taken to ensure that
thermal fluid expansion does not raise the line
pressure above the maximum working pressure
of the instrument.
4. Process piping must be clean and free of any
foreign matter.
5. A strainer should be installed upstream of the
instrument.
6. An air eliminator should be installed upstream
of the instrument if the process fluid is
expected to contain entrained air.
7. A flow limiting valve should be installed
downstream of the instrument, this will
maintain a back pressure on the instrument
and prevent excessive flow rates.
8. Isolation valves should be located at either
ends of the instrument run and a bypass
section installed. This will facilitate ease of
component removal, when required, and
reduce loss of product.

Page 16/58IOM BiRotor Plus R27
8.2 - Installing the Instrument
1. Remove the inlet and outlet protection covers.
2. Install the instrument into the pipe work
using suitable hardware as specified in the
local codes and regulations. Ensure that the
connections are made tight and torqued to the
correct values.
3. Connect the instrument wiring, refer to Figures
9-1 and 9-2. Cable entry into the electrical
enclosure is by two 3/4-14 NPT female threads.
All flame paths must be protected from
damage during work.
4. Use wiring appropriate for the location and
operating conditions. Wiring glands and/or
conduits must conform to local electrical codes
and regulations if wiring is to be installed in a
hazardous area.
NOTE:
For additional requirements on installation please
refer to Chapter 2, Essential Instructions, at the
beginning of this manual.
If the instrument is being installed with additional
accessories, the instructions for those accessories
should be read and understood before continuing
with the installation. The output signal from the
preamplifier, if one is fitted, can be altered to
interface with most electronic accessories. This is
accomplished by the use of jumpers on the circuit
board. Refer to Figure 8-1 for their configurations.
The UMB housing may be rotated in 90°
increments to accommodate the mounting of
accessories. If the UMB housing is removed for
any reason, the flame path at the base must not
be damaged. No repair is allowed if the surface is
damaged. Care must also be taken to disconnect
the sensor wires to prevent damage. It is
essential that the four retaining screws used to
secure the UMB housing to the meter body be
torqued to 55 in/lbs.
Internal grounding terminal must be used for the
equipment grounding connection, and the external
terminal is for supplementary bonding connection.
Grounding symbol congruent to IEC 60417 number
5019 located on the grounding connection to UMB.

IOM BiRotor Plus R27Page 17/58
TB1 Function
1 9-28 VDC Supply
2 V Comm
3 Channel A Signal
4 Channel A and B Common
5 Channel B Signal
Jumper Position
J1 (Channel A) B
1
J2 (Channel B) B1
5 VDC Pulse V Supply Pulse2
J3 (Channel A) A B
J4 (Channel B) A B
Figure 8-1 Wiring Connections
NOTE:
1 Do not Change without consulting factory.
2 V Supply Pulse = Input V minus approximately 2 volts
The instrument should not be located in a location
where excessive vibration is to be expected.
Care should be taken not to locate the instrument
near any source of electromagnetic interference, such
as those produced by electric motors, transformers,
solenoids, etc.
Either of these factors could induce a signal into the
flow sensing pickoff and interfere with the accuracy of
line product measurement.

Page 18/58IOM BiRotor Plus R27
Figure 8-2 Wiring Connections
Integral Brodie Electronic Rate Totalizer
(BERT-E)
If the instrument has been supplied with an
integral electronic register, the internal wiring
connections will already be in place. For additional
functions and wiring possibilities please refer to
the BERT-E’s instruction manual.
8.3 - Meter Start Up and Operation
Review the system installation to ensure all the
components are in proper sequence, all isolation
valves must be closed, all electrical connections
are complete, and all covers are in place.
1. To pressurize the system, slowly open the
inlet valve so as to prevent system shock.
Slowly allow product to enter the system while
keeping the downstream isolation valve closed.
2. Open the downstream valve (10%) to allow
any air to be flushed from the system. Do not
overspeed the instrument.
3. Once the air has been flushed from the system,
close the downstream isolation valve and check
for any leaks. If leaks are found, check all seals
and retighten connections.
4. Fully open the upstream isolation valve to
pressurize the system.
Flow start up can commence once the system has
been pressurized.
1. Turn on all electronic circuits and check for
proper function.
2. Open flow control valves and allow the
instrument to run at 20% of its rated flow for 5
minutes.
3. During this initial run, check all other
components in the system for functionality.
4. Once this run is complete, set the flow control
valve to the required flow and ensure that
the maximum flow for the instrument is not
exceeded.

IOM BiRotor Plus R27Page 19/58
8.4 - Higher Temperature Start Up
On higher temperature start up above 212°F
(100°C), based on an ambient temperature of 70°F
(21°C), special start up procedures are required to
prevent damage to the flow meter components.
A similar procedure should be followed on any
thermal shock in excess of 176°F (80°C). The
following equation may be used to determine the
approximate flow meter warm up time.
th= [(Cnom )∙ (OT°f - 212)]/100
th= Warm Up Time in Hours
Cnom = Nominal Connection Size
OT°f = Operating Temperature in °F
During this warm up time the meter should be
operated at approximately 5% of maximum flow to
allow the temperature to stabilize.
8.5 - Custody Transfer
A meter factor will need to be established under
actual operating conditions if the instrument is to
be used in custody transfer applications. This inital
proving run should be carried out following the
completion of the meter start up procedure, and in
accordance with local regulations.
NOTE:
There are no user adjustable parts in these
instruments, however, the instrument housing is
provided with two cross-drilled bolts and drain
plugs to facilitate sealing if required by the local
weights and measurements regulations.
Typical Horizontal Installation with Associated Accessories
Model 200
F/A Converter
Electronic Register
Batch Controller
Pressure
Gauge
Strainer
Pressure
Gauge
Upstream
Digital Control Valve
Electronic Preset
BiRotor Plus
Figure 8-3 Horizontal Installation

Page 20/58IOM BiRotor Plus R27
Truck Loading - Vertical Installation for Marketing Terminal Applications
BiRotor Plus
Strainer
Digital
Control Valve
Electronic Preset
Figure 8-4 Vertical Installation
8.6 Electrical - Symbols and Definitions
ISO 7000-0434A : Caution Risk of Danger or Attention, Consult
Accompanying Documents
IEC 60417-5019 : Protective Earth (Ground)
IEC 60417-5032 : Alternating Current
IEC 60417-5007 : “ON” (Power)
IEC 60417-5008 : “OFF” (Power)
