Brother QL 570 - P-Touch B/W Direct Thermal Printer User manual

Distributed by: BROTHER INTERNATIONAL CORPORATION 100 Somerset Corporate
Blvd., Bridgewater, NJ 08807 Machine: made in China.Tape: made in Japan.
Cartridge: assembled in China.Additional imported items individually marked with
country of origin.
Brother is a registered trademark of Brother Industries Ltd.All other brand and
product names are registered trademarks or trademarks of their respective
companies.Specifications subject to change without notice. Printed in the U.S.A.
© 2007 Brother International Corporation
100 Somerset Corporate Blvd., Bridgewater, NJ 08807
Features Specifications Benefits of the feature
Operation Modes Computer connected only
Utilize the full capabilities of P-touch®
Label Creation software plus other programs
and images found on the computer.
Maximum Print Speed (labels per minute
▲
)68
▲
Minimize time spent waiting for labels
Maximum Resolution (dpi) 300 x 600 in Super Fine Mode Produce high quality labels especially for
logos, pictures and graphics.
Cutter Auto Ensures a clean, professional finish
Maximum Cutter Life (cuts)†300,000†Versatility in printing labels of different
widths.
Maximum Label Width Accepted (inches) 2.4 Print larger labels with different widths.
Control Panel Display 3-Color LED Control Panel Quickly and easily recognise the status of
the machine.
Multi-Copy Printing Yes Flexibility to print multiple copies in one
print job.
Mirror Printing, Vertical Printing,
Rotated Printing Yes
Label design versatility. Great for signs,
window signage, binders and other
applications.
Time & Date PC-Generated
Easily incorporate time and date stamp
information into your label. Perfect for time
sensitive applications.
Bar Code Types
CODE 39, ITF 2/5, CODE 128, CODABAR (NW-7), UPC A/E, EAN
8/13/128, PDF 417 (Standard, Truncated, Micro), QR Code (Model1 ,
Model2, Micro), POSTNET, Laser Bar Code, ISBN-2, ISBN-5, Datamatrix
(ECC 200 Square, ECC 200 Rectangular), Maxicode (Model 2, Model 3,
Model 4, Model 5), RSS (Standard, Truncated, Stacked, Stacked Omni,
Limited, Expanded, Expanded Stacked)
Easily integrate commonly used bar codes
into your labels.
Database Connectivity .csv, .mdb, .txt file types Compatible with popular database types
SOFTWARE
Software Add-Ins Yes,
▼
Microsoft®Word®/ Outlook®/ Excel®
Easy to integrate information from these
applications into your label design.
Store and print commonly used names.
Software P-touch®Editor 5.0 for Windows® , P-touch®Editor 5.0 for Mac OS® /
P-touch®Address Book 1.1 for Windows®Easy to use and design customized labels.
Interface USB (cable included in box) Easy to connect and install the label printer
to your computer.
▲
At 300x300 dpi using 4 line address label, text only.
▼
Word-97/98/2000/2002/2003/2007; Outlook-2000/2002/2003/2007; Excel-97/2000/2002/2003/2007
† Based on internal Brother testing when using die-cut labels.
CATQL570
SYSTEM REQUIREMENTS
Compatibility PC & Mac OS®
Operating System Windows®: 2000 Professional/XP/Windows Vista® / Mac OS®: 10.3.9 -10.4.10
Hard Disk Free Space for Install Windows®:Over 70MB / Mac OS®: Over 100MB
Interface USB Port (USB Spec. 1.1 or 2.0 Protocol)
Other CD-ROM Drive for Installation
SUPPLIES
Tapes & Supplies Compatibility Uses DK Labels and DK Tape Rolls.
Options Cleaning Sheets
ITEMS IN BOx
Included Items P-touch®Editor Software & Driver, USB Cord, Power cord, DK Supplies guide and Setup & Operation Guide
Starter Rolls: Standard Address Labels (100 labels), Continuous Length Paper Tape 2-3/7" (25 feet)
WARRANTY
Type of Warranty 2-Year Limited Warranty and Exchange Service

Features Specifications Benefits of the feature
Operation Modes Computer connected only
Utilize the full capabilities of P-touch®
Label Creation software plus other programs
and images found on the computer.
Maximum Print Speed (labels per minute
▲
)68
▲
Minimize time spent waiting for labels
Maximum Resolution (dpi) 300 x 600 in Super Fine Mode Produce high quality labels especially for
logos, pictures and graphics.
Cutter Auto Ensures a clean, professional finish
Maximum Cutter Life (cuts)†300,000†Versatility in printing labels of different
widths.
Maximum Label Width Accepted (inches) 2.4 Print larger labels with different widths.
Control Panel Display 3-Color LED Control Panel Quickly and easily recognise the status of
the machine.
Multi-Copy Printing Yes Flexibility to print multiple copies in one
print job.
Mirror Printing, Vertical Printing,
Rotated Printing Yes
Label design versatility. Great for signs,
window signage, binders and other
applications.
Time & Date PC-Generated
Easily incorporate time and date stamp
information into your label. Perfect for time
sensitive applications.
Bar Code Types
CODE 39, ITF 2/5, CODE 128, CODABAR (NW-7), UPC A/E, EAN
8/13/128, PDF 417 (Standard, Truncated, Micro), QR Code (Model1 ,
Model2, Micro), POSTNET, Laser Bar Code, ISBN-2, ISBN-5, Datamatrix
(ECC 200 Square, ECC 200 Rectangular), Maxicode (Model 2, Model 3,
Model 4, Model 5), RSS (Standard, Truncated, Stacked, Stacked Omni,
Limited, Expanded, Expanded Stacked)
Easily integrate commonly used bar codes
into your labels.
Database Connectivity .csv, .mdb, .txt file types Compatible with popular database types
SOFTWARE
Software Add-Ins Yes,
▼
Microsoft®Word®/ Outlook®/ Excel®
Easy to integrate information from these
applications into your label design.
Store and print commonly used names.
Software P-touch®Editor 5.0 for Windows® , P-touch®Editor 5.0 for Mac OS® /
P-touch®Address Book 1.1 for Windows®Easy to use and design customized labels.
Interface USB (cable included in box) Easy to connect and install the label printer
to your computer.
SYSTEM REQUIREMENTS
Compatibility PC & Mac OS®
Operating System Windows®: 2000 Professional/XP/Windows Vista® / Mac OS®: 10.3.9 -10.4.10
Hard Disk Free Space for Install Windows®:Over 70MB / Mac OS®: Over 100MB
Interface USB Port (USB Spec. 1.1 or 2.0 Protocol)
Other CD-ROM Drive for Installation

The Brother QL-570 Professional
Label Printer is the perfect synergy
of functionality and design.
USER-FRIENDLY
CONTROL PANEL
Easy access control panel
button with 3 color LED
status display
Small footprint and low profile.
Requires minimal space
USB CONNECTION
Connect to your computer via
the included USB cord
BROThER QL-570 PROFESSIONAL LABEL PRINTER KEY FEATURES:
Advanced user-driven features that make it easy to operate, maintain and store.
ACCEPTS UP TO 2.4"
WIDE LABELS
The Brother QL-570
Label Printer prints on
labels up to 2.4" wide.
This provides flexibility,
with a wide range of label
and tape rolls to choose
from. Print on labels as
small as 1/2" diameter
round labels or as large
as our 2 3/7" x 4" shipping
labels.
DURABLE BUILT-IN
AUTOmATIC CUTTER
The Brother QL-570
Label Printer also comes
with a built-in durable
automatic cutter. This
allows for labels to be cut
at the end of each printed
label or the end of the
print job ensuring a clean
professional finish.
EASY TO INSTALL
FAST PRINT SPEED
The Brother QL-570 Label
Printer can print up to 68
labels* per minute (faster
then one per second!).
Brother QL-570 Label
Printer comes with easy
to install label creation
software and drivers.
Simply place the CD into
your PC and follow the
user prompts. When
requested, connect the
Brother QL-570 Label
Printer to your PC via
the included USB cable.
It's that easy!
Professional high-resolution
printing (up to 300 x 600 dpi)
captures all the fine details of
pictures, logos and graphics.
PRINTS hIgh-RESOLUTION
TExT AND gRAPhICS
Resolution up to 300 x 600 dpi
in superfine mode
COmPACT DESIgN
Introducing the sleek, compact and
stylish Brother QL-570 Professional
Label Printer. Perfect for creating
cost effective labels on demand for
envelopes, packages, file folders, CD/
DVD, name badges and more†† ...
Once you use the Brother QL-570
Label Printer you will discover many
more uses for this versatile product.
The Brother QL-570 Label Printer is for
those wanting to create customized
labels quickly and easily so they can
look more professional and become
more organized.
Perfect for general office use, personal use, real estate
offices, doctors' offices, shipping departments, event
coordinators, laboratories, museums, schools and libraries.
hIgh QUALITY PRINTINg**

BROThER QL-570 PROFESSIONAL LABEL PRINTER KEY FEATURES:
Advanced user-driven features that make it easy to operate, maintain and store.
EASY DROP-IN LABEL
AND TAPE ROLLS
The Brother QL-570
Label Printer uses easy
drop-in rolls so you can
switch label types in
seconds. The machine
automatically senses
which roll you have in
and adjusts your on-
screen template to the
correct size.
3 INPUT LEvELS IN ThE LABEL
CREATION SOFTWARE:
1. Snap Function: Allows for screen capture to be
easily incorporated in label design with a press of the
button.
2. ExprESS ModE: This mode is perfect for the
beginner or for creating labels quickly. (shown in
picture above)
3. proFESSional ModE: Create sophisticated label
designs in this mode or for the expert label designer.
POWERFUL AND USER-FRIENDLY P-TOUCh®
EDITOR v.5 LABEL CREATION SOFTWARE
Create labels using information
stored in Microsoft®Word®,
Excel®and Outlook®
Using the included powerful, yet easy to use, label
creation software allows you to get creative and
design your own label
HigHligHt: select
the text from your
document.
click: on the add-in
button on the toolbar
to pull the data into the
label creation software.
print: your label right
away or edit as desired.
OR
†† Comes with starter Rolls of Standard Address Labels (100 labels),
Continuous Length Paper Tape 2-3/7" (25 feet)
* Using standard 4-line address label. ** In superfine mode.
Die-Cut (Pre-sized) Labels
are cut into common label
shapes such as address labels,
shipping labels, CD/DVD labels
and file folder labels.
Continuous Tapes allow you
to determine the length of the
label. Great for labeling long
packages, binders or creating
cost effective signange on
demand.
John
Wilson
MANAGER
J.S. Singer & Son
Anderson, Richard
Acct # G3058417750
Job # 2198a
B
B
G
L
A
B
O
R
A
T
O
R
I
E
S
Batch 6a
placed
11/23
by MC
SALES REPORTS
Reports and
Files
CD Reference Volume
Updated March 2007
2007 Budgets
WIDE RANgE OF hIgh QUALITY SUPPLIES
There is a wide range of cost effective, crisp white paper labels for
your envelopes, packages, file folders, name badges, files and more.
For added durability, use our durable film labels for your CD/DVDs or
for creating customized signage on demand. Once printed - it is easy
to peel and apply your label.
