Bruckhoff La belle BC D50 User manual

Händlerstempel
headset
Identical for all control units:
Open the battery cover. Remove the
battery with the supplied magnetic pen.
Insertion is in reverse order:
Insert the new type 312 battery with
the „+“ sign facing up. Close the cover.
The hearing aid is automatically swit-
ched on again!
Changing the battery la belle junior headset
la belle junior headset
Identical for all control units:
When the battery cover is closed, your
hearing aid is always switched on
automatically.
The hearing aid is turned off by simply
opening the battery cover.
Turning the unit on/off
Battery cover closed
switched on
Battery cover open
switched off
Magnetic pen
Battery
Type 312 standard*
*Optional:
Battery
Type 13
AUDIA AKUSTIK GMBH
Franz-Mehring-Str. 13
99610 Sömmerda
Germany
Tel: [phone]
E-Mail: [e-mail]
www.bruckhoff.com
Operating manual
Bone conducting hearing aids
la belle BC D50 and BC D70;
Junior BC D50 and BC D70;
headset BC D50 and BC D70
- EN -
We understand hearing.
BRH 200301 Art. 48167
Dealer‘s stamp
la belle junior headset
Fitting and wearing instructions
Insert the la belle listening module
(1) on your spectacle arm. Use your
glasses without hearing aid - using
the push-on spectacle end piece (2).
The children‘s junior hearing system
(3) is connected to the headband
using two snaps (4).
(5) The headset hearing system can
be easily adjusted to your head shape
via the pull-out adjustment (6).
(1) (2) (3)
(5)
(4) (6)
junior
For Junior BC D50 and Junior BC D70:
Each Junior BC comes with a screwdri-
ver and two screws. The screws are
screwed into the battery cover.
We recommend this safety lock for
children min. up to the age of 3 years.
Installing the child safety lock
Tighten the
screws
Insert
screws
la belle junior headset
Technical data
Output force level OFL90
Maximum acoustic-mech.
Force level @60 dB Input
Frequency range
Operating current
116 (dB re 1µN)
200 – 5000 (Hz)
1,2 mA
48 dB
BC D50 IEC 118-9
116 (dB re 1µN)
200 – 5000 (Hz)
1,3 mA
48 dB
BC D70 IEC 118-9
Number of microphones 1 Omnidirectional 2 Omni or directivity
bone conduction
bone conductionbone conduction

Bone conduction
• la belle (control unit above/below)
• junior
• headset
You can set the following functions
yourself:
• Adjust the volume
• Select the listening programs
• Switch the unit on/off:
Setting options on the control unit 1 left right
Volume control Program button
The program button
is located on the pro-
gramming chamber
and not on the control
unit.
Bone conduction
• junior
You can set the following functions
yourself:
• Adjust the volume
• Select the listening programs
• Switch the unit on/off:
Setting options on the control unit 2
Function buttons:
1 x short forward:
one step louder
1 x short back:
one step quieter
1 x long forward:
one program further
1 x long back:
one program back
left right
Button for
volume and
program selection
Childlock
Safety, care and use information. Please read before use!
Your hearing aid does not restore
normal hearing, nor does it prevent
or improve an organically induced
hearing loss.
Safety and Warnings
• Your hearing aid must not be worn
by other persons. A risk of hearing da-
mage will ensue.
• Unauthorized modifications to the
hearing aid may damage your hearing.
• Never wear your hearing aid in areas
where there is a risk of explosion.
• Keep the hearing aid out of the reach
of small children, people with cogniti-
ve impairment and pets. The ingestion
of hearing aid parts, in particular of
batteries, is hazardous to life. There
is a danger of suffocation. In case of
emergency call a doctor or a hospital
immediately.
• If you are experiencing pain in or
behind the ear, or if you develop in-
creased earwax, contact your hearing
healthcare professional or doctor.
• For safety reasons, children and per-
sons with cognitive impairments may
only use this device under supervision.
Never leave children and persons with
cognitive impairment unattended
with this hearing aid.
• If the hearing impression changes
with the hearing aid, please consult
your hearing care professional.
• For Junior BC D50 and Junior BC
D70: With children, make sure that
the front of the headband is not pulled
over the neck. If the headband gets
caught somewhere, there is a danger
of suffocation.
• Listening programs in the directional
microphone mode reduce background
noises. Warning signals or noises co-
ming from behind are not perceived or
only weakly perceived.
• Only use certified medical device
accessories for connection to our hea-
ring aids. Your hearing care professi-
onal will provide you with a hearing
program to use an FM system, such
as the Roger X from Phonak. A spe-
cial adapter cable from Bruckhoff is
available for the Junior BC D50 and
BC D70.
• The use of a hearing aid by persons
with an actively implanted medical
device (for example heart pacema-
ker, defibrillator, etc.) requires prior
consultation and clarification with a
specialist physician. (For further infor-
mation please refer to the download
area from our website at www.bruck-
hoff.com)
Information on product safety, use
and maintenance
Your hearing aid is very robust and can
be worn during all normal everyday
activities, even under extreme condi-
tions for short periods.
• Never immerse it in/under water
or use it while showering, bathing or
swimming. The hearing aid electronics
will become damaged.
• Never clean the microphone ope-
nings with moist agents. They will lose
their special acoustic properties.
• Protect your hearing aid from heat.
• Never use a microwave or other hea-
ting appliances to dry it.
• As far as possible, leave unused hea-
ring aids with an open battery com-
partment so that moisture can escape.
• For long-term non-use, remove the
battery.
• Always store the hearing aid in a
safe, dry, and clean place.
• Do not drop it!
• Always replace weak or defective
batteries (e.g. liquid loss) immediately.
Always use new batteries.
• Do not dispose of old batteries in do-
mestic waste. Your hearing care pro-
fessional will dispose of these for you.
• Use only batteries with max.1.5 Volt.
• Never use silver-zinc or lithium-ion
batteries.
• Some (dental) medical examinations
with x-rays, e.g. CT examination, MRT/
NMRT, can impair the functioning of
your hearing aid. Remove your hearing
aid beforehand.
• Hearing aids do not have to be re-
moved before passing through a se-
curity sluice (e.g. at the airport). The
low X-ray radiation emitted there
does not affect your hearing aid.
• Do not use your hearing aid in lo-
cations where electronic devices are
prohibited.
Detailed information can be found on
the internet in the download area
at www.bruckhoff.com. In case of
doubt, please contact your hearing
healthcare professional or a specia-
list physician.
Application risks and symbols
Application risks, contraindication
• The fitting range does not match the patient‘s
hearing loss.
• Skin irritations despite the skin-friendly material
used.
• Mutual deafness.
By affixing the CE mark, AUDIA AKUS-
TIK GMBH confirms that this AUDIA
AKUSTIK GMBH product – including
accessories – meets the requirements
of the 93/42/EEC directive concerning
medical devices. The numbers indicated
after the CE marking refer to the certi-
fied equipment used in accordance with
the directives listed above.
Important information on handling and
effective use of the product.
The symbol showing a crossed-out
waste container indicates that this ap-
pliance must not be disposed of with
household waste. Please dispose of old
or no longer used hearing aids at the
collection points provided for electronic
waste or give the hearing aid to your
hearing care professional for proper
disposal. Proper disposal protects the
environment and your health.
Indicates the need for the user to con-
sult the instructions for use.
Refers to the need for the user to review
the instructions for use for important
safety information, such as warnings
and precautions, which for a variety of
reasons cannot be affixed to the medical
device itself.
Displays the manufacturer‘s serial
number, which can be used to identify
a specific medical device.
Temperature during transport and sto-
rage: -20° to +60° Celsius (-4° to +140°
Fahrenheit).
Air humidity during transport: Up to
90% (non-condensing). Humidity during
storage: 0% to 70% when not in use.
Drying the hearing aid after use.
Air pressure: 200 hPa to 1500 hPa.
Shows the date on which the medical
device was manufactured.
Indicates the manufacturer of the medi-
cal device according to the EU directives
90/385/EEC, 93/42/EEC and 98/79/EC.
Designates a medical device that must
be protected against moisture.
Displays the manufacturer‘s catalogue
number, which can be used to identify a
specific medical device.
xxxx
SN
REF
