PRODUCT INFORMATION
OticOn cOnnectline micrOphOne
Chosen Speaker
up to 15 m
Hearing Instrument User
Improved signal-to-noise ratios
ConnectLine Microphone improves sig-
nal-to-noise ratios, helping instrument
users navigate conversations in very
demanding listening situations, which to
some clients are nearly impossible today.
The improved signal-to-noise ratio is
achieved from a combination of having
the ConnectLine Microphone placed
close to the chosen speaker coupled
with an advanced dual microphone setup
which reduces surrounding noise.
Typical applications for the ConnectLine
Microphone are known problem areas for
existing hearing instrument users: in a
car, at a restaurant, or at lectures.
An integral part of ConnectLine
The ConnectLine Microphone is an
integral part of the ConnectLine system,
making daily use as straightforward as
with any other ConnectLine solution.
The ConnectLine Microphone is controlled
from either the Streamer or the Micro-
phone.
While using the ConnectLine Micro-
phone, the hearing instrument user is
also notified of incoming phone calls
which the user can answer (or reject)
with the push of a button on the Streamer.
(Requires a Bluetooth enabled cell phone
and/or ConnectLine Phone adaptor.)
Versatility in daily use
The ConnectLine Microphone has been
specifically designed for versatile daily
use, with a variety of ways to attach the
microphone to the chosen speaker.
The integrated clip can be adjusted so
that the ConnectLine Microphone can be
placed on practically any type of clothing.
A small pouch provides for storage
and protection of the ConnectLine
Microphone when not in use.
The ConnectLine Microphone allows Oticon hearing instrument users
to receive direct input from communication partners for an improved
signal-to-noise ratio in difficult listening environments. ConnectLine
Microphone is especially useful in challenging situations such as noisy
restaurants, lectures, communicating at a distance, at home, or in the car.

105863US / 12.10
Technical data MIC-110
Dimensions 46 x 17,3 x 16,5 mm
Weight 13 g
Power supply for charging Wall adapter, 5V DC. (included)
Battery life Typically 5 hours constant talk time
Improved SNR vs. HI 1) >12dB
Compatibility Streamer 1.4 or later
AutoConnect (range) Yes (15 meters)
Auto shut off After 30 mins not in use
Transmission range 15 meters typically
Sound delay 2) < 25 ms
Audio bandwidth 200 Hz - 3.5 kHz
Indicators Green when powered on. Orange when connected.
Color Black, high gloss
Operating temperature 10 - 45 °C
Operating humidity Relative humidity < 85%
Storage temperature -20 - 70 °C
www.oticonusa.com
1) Measured as the improved SNR when comparing ConnectLine Microphone to Hearing Instruments alone at 2 meters distance and
72 dB noise level.
2) Measured as the difference between ConnectLine Microphone streamed signal and direct transmitted signal to the output (Hearing
Instrument Receivers) at 10 meters distance.
Genie and ConnectLine Microphone
The Genie fitting software allows for fine-tuning of ConnectLine parameters, e.g., the level of the Streamed signal from the
ConnectLine Microphone. Specifically for ConnectLine Microphone, it is recommended to disable Music Widening and Power Bass
to secure optimal reproduction of speech cues. Please note that fine-tuning possibilities can vary depending on the actual hearing
instrument(s).
ConnectLine Microphone requires Streamer 1.4 or later. Existing Streamers can be upgraded though the Genie fitting
software. Please refer to the Genie fitting software for more details (Genie version 2011.1 or later).
Included accessories
❍Power adaptor for charging
❍Soft carrying pouch
❍Lanyard
Status indicator
(orange)
Mic Input Voice
Power indicator
(green)
On/off button
Mic Input Noise
(do not cover)
prODUct OVerVieW
